Wasp DELTA 2040 Instruction manual

MANUAL OF USE AND MAINTANANCE
ORIGINAL INSTRUCTIONS
INDUSTRIAL X LINE

Discalaimer
IMPORTANT:
We kindly praise to read carefully and comprehend totally the content in this manual of Use and
Maintanance.
The missing acknowledgment of the manual can be cause of personal injury, worst quality results or
damages to the DELTA WASP 2040 INDUSTRIAL X LINE printer. Always make sure that the personal
using the 3D printer knows and understands the manual’s content in order to obtain the best results
from DELTA WASP 2040 INDUSTRIAL X LINE.
No part of this publication could be reproduced, stored in a filing system or transmitted to third parties in any form or by any means, without
the Manufacturer having issued a prior written authorization. The Manufacturer reserves the right to make changes to its products at any
time and without notice in order to constantly increase the quality, therefore this publication may also be subject to future modifications and
updates.
Copyright 2018 CSP S.r.l. – All rights reserved
1First edition 31/06/2020
Revision Reason for the revision Revision date

© WASP S.r.l.
Summary
0 Premises............................................................................. 5
0.1. Aim of the instruction manual............................................ 5
0.2. How the read the manual of instructions...................... 6
0.3. Storage of the manual of instructions ........................... 6
0.4. Updating the manual of instructions .............................. 6
1 General information....................................................... 7
1.1. Manufacturer identification data...................................... 7
1.2. Indentification label................................................................ 7
1.2.1. Position of the label on the printer .....................................8
1.3. Testing..........................................................................................8
1.4. Warranty......................................................................................8
1.5. General safety warnings....................................................... 9
1.5.1. Personal protective equipment...........................................9
1.5.2. Operators for whom the manual is intended .............. 10
1.5.3. Protection systems ................................................................ 10
1.5.4. Residual risks ............................................................................10
1.5.5. Safety stickers..........................................................................12
1.6. Glossary and pictograms.................................................. 12
1.6.1. Identification of operating personnel ............................ 12
1.6.2. Editorial pictograms............................................................... 13
2 Description of the printer..........................................15
2.1. Control panel.......................................................................... 16
2.2. Work area................................................................................. 17
2.3. External area of the printer .............................................. 18
2.4. Technical data........................................................................ 19
2.5. Noisiness.................................................................................. 20
2.6. Intended use of the printer .............................................. 20
2.7. Improper use of the printer.............................................. 20
3 Transport and handling ..............................................21
3.1. General warnings.................................................................. 21
3.1.1. Delivery of the printer............................................................21
3.2. Unpackaging........................................................................... 22
3.3. Content ..................................................................................... 22
3.4. Lifting and handling of the printer................................. 22
4 Installation.......................................................................23
4.1. General warnings.................................................................. 23
4.1.1. Placement...................................................................................23
4.2. Electrical connection.......................................................... 24
5 Preparing to use the printer .....................................25
5.1. General warnings.................................................................. 25
5.2. User interface......................................................................... 26
5.2.1. Main board.................................................................................. 26
5.2.2. PRINT Menu................................................................................ 27
5.2.3. PREPARE menu ........................................................................28
5.2.4. ADVANCED menu ................................................................... 29
5.2.5. WIFI settings..............................................................................30
5.2.6. GCODE ......................................................................................... 31
5.2.7. INFO menu..................................................................................32
5.3. First start .................................................................................. 33
6 First use of the printer ................................................35
6.1. General warnings.................................................................. 35
6.2. Gcode creation...................................................................... 36
6.3. Slicing software..................................................................... 36
6.4. Autocalibration...................................................................... 36
6.5. Loading / removal of the filament ................................. 36
6.6. Adhesion to the bed............................................................ 37
6.7. Selecting gcode.................................................................... 37
6.8. Function during the print................................................... 37
6.9. Piece removal......................................................................... 37
7 Ordinary and extraordinary maintanance..........39
7.1. General warnings.................................................................. 39
7.2. Ordinary maintanance........................................................ 40
7.2.1. Fan filter....................................................................................... 40
7.2.2. Arms ball joint............................................................................40
7.2.3. Extruder fans ............................................................................. 40
7.2.4. Sliders........................................................................................... 40
7.2.5. Extruder ....................................................................................... 41
7.2.6. Replacing Ooze shield protection ...................................41
7.2.7. Print bed cleaning ...................................................................42
7.3. Extraordinary maintenance ............................................. 43
7.3.1. Change nozzle Zen Extruder .............................................. 44
7.3.2. Manual leveling......................................................................... 48
7.3.3. Zen Extruder nozzle cleaning.............................................48
7.3.4. Change nozzle Flex Extruder..............................................50
7.3.5. Cleaning nozzle Flex Extruder ...........................................52
8 Use of the printer ..........................................................55
8.1. Adhesion to the bed............................................................ 55
8.2. Zen extruder calibration.................................................... 56
8.3. Load .gcode ............................................................................ 58
8.3.1. Loading with pendrive USB.................................................58
8.3.2. Loading with Wi-fi....................................................................58
8.4. Continuous printing............................................................. 60
8.5. Deleting gcode from machine........................................ 60
8.6. Manual extrusion .................................................................. 62
8.7. Free zeta system .................................................................. 64
8.8. Modify height.......................................................................... 64
8.9. Multi-core: change extruder............................................ 66
8.10. Resurrection system........................................................ 76
8.11. Removal of the print ......................................................... 76
8.12. Wifi and remote control .................................................. 78
9 Additional instructions ...............................................80
9.1. General warnings.................................................................. 80
9.2. Decommissioning and dismantling.............................. 80
9.3. Instructions for emergency situations ....................... 81

© WASP S.r.l. 5
Premises
0 PREMISES
0.1. Aim of the instruction manual
IMPORTANT:
Before proceding with the installing and starting of the printer, technicians, users, maintainers and
safety responsibles must read and understand the manual.
The manual must be considered as a fundamental part of the printer. The correct use and maintanence of the
machine depends on the informations contained here.
It contains instructions that must be acknowledged by the personal devoted to the use, maintanance and
transport of the machine, supposing the adequate experience, preparation and professional abilitation as well as
a psychophysical attitude. For certain operations it may be necessary to ask for the intervent of personnel who
have achieved a specific preparation.
It must always be available for consultation, in copy and by the recipient, on the printer itself or in its immediate
vicinity. In the second case the manual’s location must be indicated on the printer clearly.
It is susceptible of updates which, appropriately classified, will be transmitted to the employer in order to update
the consultation copy (s).
• The recipient must ensure that the personnel authorized by him to start up, use, maintain and transport the
printer have obtained adequate knowledge of the instructions contained in this manual.
• The recipient must check that the maintenance operations, prescribed in the appropriate chapter, are carried
out and recorded promptly and effectively.
• We accept no responsibility for damage to persons or property resulting from improper use and / or omitted
or inadequate maintenance.
• The recipient has the right to request further information.
In case of loss and / or damage of the present manual is responsibility of the recipient to ask for one or more
copies.

© WASP S.r.l.
6
Premises
0.2. How the read the manual of instructions
This manual is composed by:
COVER WITH PRINTER IDENTIFICATION
By consulting the cover you can trace to the printer model covered in the manual and to the printer serial number
in your possession.
ANALYTICAL INDEX
By consulting the index it is possible to indentify the chapter and the paragraph on which all the notes relating to
a given topic are reported.
NUMERATION FIGURES
Each figure is numbered progressively, indicating with the first digit the reference chapter and with the second
the progressive image (example Fig. 3.4 is the fourth figure of chapter three)
0.3. Storage of the manual of instructions
It is mandatory to keep this manual and all attached documents in an easily accessible place near the printer and
known to all users (operators and maintenance personnel).
Operators and maintenance technicians must be able to quickly find and consult the manual in any situation.
The manual is an integral part of the printer for security purposes.
Therefore:
• It must be kept intact (in all its parts);
• It must follow the printer until its disposal (even in case of travel, sale, rental, rent, etc.);
• It must be kept up to date and report any changes made to the printer.
0.4. Updating the manual of instructions
This manual must be regularly updated by attaching additional or altered parts.
The sending of any additional parts is the responsibility of the Manufacturer; the user is responsible for the
replacement of parts that may be altered as a result of use, making a request directly to the Manufacturer.

1
2
3
4
5
© WASP S.r.l. 7
General information 1
1 GENERAL INFORMATION
1.1. Manufacturer identification data
CSP S.r.l.
Registered office: Viale Zaganelli, 26 - 48024 Massa Lombarda (RA) Italy
Operational headquarters: Via Castelletto, 104 - 48024 Massa Lombarda (RA) Italy
Tel. [phone]
[email protected] / www.3dwasp.com
1.2. Indentification label
The printer is CE marked and complies with all relevant provisions:
Machinery Directive 2006/42 / EC, EMC Directive 2014/30 / EU and LVD Directive 2014/35 / EU
EN 55022
EN 55024
EN 60204-1
The marking can be identified by means of an identification plate of the Manufacturer as required by the
Machinery Directive. In case of damage, the Recipient must commission a copy.
Legend:
1. Model
2. Voltage
3. Maximum power
4. Year of production
5. Serial number
6. Advanced settings

© WASP S.r.l.
8
1
1.3. Testing
The printer is tested directly by the Manufacturer during the phase of mounting and post mounting.
1.4. Warranty
The printers built by WASP S.r.l. are covered by a warranty for a period of 12 months for companies or VAT and
24 months for individuals, according to the specifications set out in the sales contract.
If during the period of validity, defective operations or faults of parts of the printer that fall within the cases
indicated in the warranty occur, WASP S.r.l. (after the appropriate checks) will repair or replace the defective
parts.
The defective parts under warranty will be repaired or replaced free of charge by WASP S.r.l. .
The transport and / or shipment’ costs are always charged to the Customer, as well as the return / return travel
expenses related to the intervention of the Manufacturer’s technicians at the Customer’s premises.
The labor costs related to the intervention of the Manufacturer’s technicians at the Customer’s premises, for
the removal of defects under warranty are Manufacturer responsibility, except in cases where the nature of the
defect is such that it can be easily removed on site by the Customer.
All consumables are excluded from the warranty, possibly supplied by the manufacturer together with the
machines.
For any dispute, the court of Ravenna is competent. The producer declines every responsibility on the parts
produced with this machinery.
In no cases WASP s.r.l. can be held responsible of any delay, breaches of contracts or for other commitments
of Client with towards third parties.
In no cases WASP s.r.l. is responsible for direct or consequential damages included but not limited to loss of
use, profits or income.
NOTE:
The guarantee lapses in the following cases:
• In case of default or other contractual non-fulfillment;
• Improper use of the printer
• Failure to comply with the standards and maintenance intervals
• Tampering
• The printer is returned to the Manufacturer in a different packaging from the one supplied at the
time of purchase;
• Use of non-original spare parts not supplied directly by the Manufacturer;
• Extraordinary interventions not carried out by personnel sent by the Manufacturer;
• Any variation and / or non-observance of what is indicated in the technical documents and in
this manual entails the forfeiture of the technical and functional guarantees, and release the
printer’ Manufacturer from any responsibility.
1.2.1. Position of the label on the printer
Fig. 1.2.1 The identification label can be found on the back of the printer in proximity of the supply plug.

© WASP S.r.l. 9
1
1.5. General safety warnings
CAUTION:
Any intervention that must be performed on the printer requires particular caution by the operator.
NOTE:
Any intervention on the printer must be carried out in strict compliance with the operational skills
(see paragraph 1.6.1 “Identification of Operational Staff”). CSP S.r.l. declines any responsibility in
case of non-compliance with these skills.
The purpose of this chapter is to indicate which are the specific points and measures to avoid incurring any kind
of accidents, which may be defined as residual risks, which are the minimum essential safety provisions to be
maintained, which characteristics must have the assigned personnel to the normal assembly operations and
which must be the characteristics of the maintenance personnel.
We are not responsible for unspecified operations, as they are considered strictly pertinent to technical
assistance personnel or for operations performed differently from what we described in the documentation
presented.
Possible operations on the printer can be:
• Mechanical
• Electrical
MECHANICAL NATURE INTERVENTIONS
Any intervention of a mechanical nature must be carried out in strict compliance with the directives required by
current safety regulations. It is absolutely forbidden to perform any type of mechanical maintenance intervention
on the printer during the operating cycle or in any case with parts of the printer moving.
Every mechanical adjustment operation must be carried out with the printer stopped and only and exclusively
by the mechanical maintenance technician, qualified to operate in conditions of disconnected protection (see
paragraph 1.6.1 “Identification of the operating personnel”).
Maintenance work must only be performed with the printer disconnected from the mains and taking all the safety
measures required by current regulations.
ELECTRICAL NATURE INTERVENTIONS
Every electrical adjustment operation must be carried out taking all the safety measures required by current
regulations.
1.5.1. Personal protective equipment
It is mandatory to use the specific personal protection devices (PPE) to the current operations made available
by the company (in relation to the risk attached to the performance of certain processes), even if not directly
concerning the use of the printer.

© WASP S.r.l.
10
1
1.5.2. Operators for whom the manual is intended
The manual is written for:
• The operators involved in using the printer (in the continuation of the manual will be briefly called “users”);
• Mechanical maintenance workers: trained and authorized operators for the maintenance of mechanical
parts, pneumatic and oil-hydraulic systems;
• Electrician maintenance technicians: trained and authorized operators for the maintenance of electrical and
/ or electronic parts and systems;
• Qualified technicians (employees of the Manufacturer or authorized service center), special maintenance
staff and operations of a complex and / or particular nature.
ATTENTION:
The user must not perform operations reserved for maintenance personnel or qualified technicians.
The manufacturer is not liable for damages deriving from failure to observe this prohibition.
1.5.3. Protection systems
The machine is provided with automatical systems of protection that reduces the risks for the user.
These systems are present as a standard in all machines and shall not, for any reason, be manipulated nor
damaged. The user is responsible of reporting abnormalities in the fuctions of these systems to the Manifacturer,
who’ll fix it.
Anytime the fuctions of these systems are compromised, the machine must not be used for no reason as it may
be dangerous for the user and may lead to major damages to the machine itself.
DOOR SENSOR
ATTENTION:
Do not put any magnet or magnetic device near the door’s frame as it may compromise its right
behaviour
The Door sensor activates anytime the door is open and automatically pauses any action on the machine
(including heating, movements and tool-change).
OVERHEATING BLOCK
The machine is designed with a control system to prevent the overheating of its parts by blocking the heating
parts as the temperatures recorded overcome the safety threshold.
1.5.4. Residual risks
Residual risk of scalding
This risk exists during the filament’s removal phase from the extruder and during the removal of the piece from
the plate.
CAUTION:
Remove the part only when both the extruder and the bed are cool.
