Wassermann Wapo-Mat III User manual

Polymerisation Unit
Wapo-Mat III
USER MANUAL

Dear customer,
Thank you for choosing a product from the Wassermann range Wassermann Dental-
Maschinen incorporates the highest standards of quality and the latest technology
In order to enjoy maximum performance and years of trouble-free operation, please read
this user manual carefully before you connect this device and start work, and operate the
device according to the recommended guidelines The operation safety and the
functionality of this device can only be guaranteed if you follow both the general safety
guidelines and the applying laws to prevent accidents as well as the precautions given in
this user manual We are not liable for any damages which occur due to inappropriate
usage or faulty operation of this device
Make sure that anyone using this device has read and understood this user
manual
Keep this user manual in a safe place where it can be referred to as required at
any time
The unit complies with the relevant EU guidelines
The unit is subject to the EU guidelines 2012/19/EU (WEEE Directive)
Company address:
Wassermann Dental-Maschinen GmbH
Rudorffweg 15-17
21031 Hamburg, Germany
Phone : [phone]/ -24 Fax : [phone]
export@wassermann-dental com
www wassermann hamburg
Erstellt: 06 07 17/ msc Version: 2 Wapo-Mat III: 170980

Contents
1 Features 4
2 Safety Symbols used in this Manual 4
3 Safety Guidelines 5
4 Responsibility for Operation or Damage 5
5 Application 5
6 Before Starting 6
6 1 Transport 6
6 2 Installation 6
6 3 Storage 6
7 Installation/ Commissioning/ Menufunctions 7
8 Operation 13
8 1 General Operating Instructions 13
8 2 Operation 14
9 Warranty 14
10 Troubleshooting 15
11 Maintenance 16
11 1 Cleaning 16
11 2 Maintenance 17
11 3 Repairs 17
11 4 Spare Parts 17
11 5 Service Hotline [phone]/ -24 17
11 6 Scope of Delivery/ Accessories 17
12 Technical Data 18
13 Disposing of the Unit 18
13 1 Information on disposal for countries within the EU 18
14 EU Declaration of Conformity 19

1 Features
•Compact benchtop unit for long-time and boiling polymerisation
•Fully automatic program sequence, capable to handling 9 flasks simultaneously
•Touchscreen-multifunctional display with minute and degree settings, remaining
time reading
•Powerful, electronically controlled heater for optimal water temperature, low water
level indicated visually and audibly
•Energy-saving tank thermal insulation
•Low maintenance, easy to clean
•All stainless steel construction
2 Safety Symbols used in this Manual
Warnin !
This is a warning of risk situations and dangers
Failure to observe this warning could be life-threatening These warnings has to
be observed
Information!
This symbol draws your attention to specific features that has to be observed
4

3 Safety Guidelines
Configuring and operating this equipment requires precise knowledge and observance
of the instructions in this user manual The equipment is designed only for its intended
application
WARNING:
Servicing and repairs should be carried out only by authorised specialists
Disconnect the power plug before starting any maintenance work
Make sure that the equipment is connected to the correct power source
Wear heat-retardant gloves when working with the Wapo-Mat III
4 Responsibility for Operation or Dama e
The responsibility for operating the device lies exclusively with the owner or user if said
device is incorrectly serviced, maintained or altered by persons not employed by an
authorised dealer or if the device is used in a manner contrary to its specified purpose
The unit has to be maintained and operated in accordance with this user manual
Wassermann Dental-Maschinen GmbH is not responsible for damage arising from the
nonobservance of these instructions
Warranty and responsibility provisions contained in the sales and supply conditions of
Wassermann Dental-Maschinen GmbH are not extended by these instructions
5 Application
The Wapo-Mat III is designed for water-bath polymerisation All readily available plastics
can be polymerised fully automatically, slowly (up to 99 hours), and at high temperature
(99°C)
Only use the device for this type of application
5

6 Before Startin
6.1 Transport
Before transporting the unit, ensure that it has been unplugged from the power socket
Make sure that it is packed correctly in order to avoid accidental damage
Be sure to check for any transport damage when unpacking the goods Note down
any damage if found
6.2 Installation
Remove all packing material and place the unit on an even and stable surface
Check the parts included in delivery (see 8 5)
Place the unit so that the work area is freely accessible and operation is not
restricted (Please consider the structural dimensions)
Do not place the unit outdoors
Before start-up, be sure the device reaches room temperature
We strongly recommend to install the unit firmly to the discharge system, since it
is equipped with an automatic water overflow
discharge system, i e too much filled water runs out automatically, even when
the discharge cock is closed Furthermore complete emptying for cleaning
purposes etc is thus simplified
6.3 Stora e
The unit should not be stored or set up outdoors
In case of long-term storage, the unit must be protected against humidity and dust
6

7 Installation/ Commissionin / Menufunctions
Before commissioning, please install the following connections:
Firmly clamp the supplied drainage hose to the device and ensure there is a
suitable drainage facility
Insert the plug into the socket – make sure that the voltage information between the device
and the mains network is identical Fill the device with mains water to above the white
plastic ring in the container (max 18 5 litres) Switch on the mainswitch (green rocker
switch) Symbol must not appear
Water deficit
Make sure you define the device's main parameters before switching it on These settings
are performed in the set-up menu Familiarise yourself with the many options which the
system offers before starting polymeration This applies in particular to functions
and
The Set-Up Menu
Title Actual temperature To the set-up menu
Heating On/Of Program start Program parameters
7
13
2
46b 6a
A
A
3
14
7

The Set-Up Menu Pa e 1
Make the following settings in the set-up menu:
Start temperature Timer Continue in the menu
Sleep Calibration method Back to start menu
The Set-Up Menu Pa e 2
C/°F Date and time Continue in the menu
Heating ramp Information Back to the start menu
8
89
11
13 9
15
7
10
12
14
16
16

6a
Description of Functions 6 - 14
Pro ram Parameters
Defines the parameters for the program temperature and time Touch the numbers to
change the values It is possible to store up to three polymerization steps # 1-3
Polymerization Step 1:
Delete To the next pro ram Save
Examples of the Steps 2 and 3:
Start
Touch the arrow to start the polymerization Interrupt or cancel the program using
Start/Stop
9
6b

Polymerization
Stop / Pause Cancel Pause Back Start
Preheatin Temperature
Defines the target temperature once the main switch has been activated
The preheat temperature also applies to waiting times and rest periods Default: 65°C
If the programme temperature selected is higher, the temperature falls back to
this value when the programme ends
After defining the desired mode it may make sense to adjust the preheat temperature
of the programme temperature This avoids long heating up or cooling down phases
Timer This defines the weekday activation and deactivation times
Programs running currently have a higher priority; they are not switched off until complete
10
7
8
6b
14

Sleep Button Display
Press the Sleep button to switch the system to sleep mode
Definition of Calibration Method
DEF: Default (calibrated for mains water)
CAL Calibration (only necessary for extreme deviations in water quality)
Drain water
Replenish water
This measure defines the conductance of the water!
11
10
11

Choose between °C Celsius and °F Fahrenheit
Picto ram for the Sequence in Time and Date Function
Choice of Workin Mode
Defines whether the time should start immediately or once the heating value has been
reached
(a) (Default) Unit heats up to the temperature programmed via After reaching this
value, the result measured is validated by a control cycle If the value is confirmed, the
polymerzation will start
(b) The programmed polymerization starts immediately
12
13
12
14
6b
a
b

8 Operation
8.1 General Operatin Instructions
All recommendations to operate the device, whether verbal or written, are based on our
experience and tests and can therefore only be considered reference points
The Wapo-Mat III is protected against dry running
in order to prevent the heating from burning out (flashing symbol:
display on the left) While the program is running,
an alarm sounds when there is insufficient water Take care that the water level is
always above the white plastic ring (see in the housing), as the heating and the
program will otherwise shut down automatically! An additional safeguard protects
the heating against overheating; it is automatically deactivated at above 99°C
Wear heat-retardant gloves when working with the Wapo-Mat III
Unplug the device if it is not in use for a longer period
13

8.2 Operation
Fill the work device with mains water to above the white plastic ring in the container
(max 18 5 litres)
Activate main switch (green rocker switch)
Check the water level – the low water alarm must not flash
Place prepared cuvettes in the device clamp
The polymerization is started by touching the symbol or alternatively via the
parameter menu
fter the polymerations process has ended, the temperature falls/rises to the preset
temperature again
9 Warranty
The warranty period for our equipment is 12 months If faults occur within the
warranty period, contact your dental depot or get in touch directly with our service
department
Your equipment should only be operated in perfect condition If faults occur which
could harm operators or third parties, the unit should not be used until it has been
fixed
This warranty does not cover damage caused by improper use, external mechanical
causes, transport damage or interference with the unit by unauthorized persons
14
6b
A
A
6b 6a
6a
7

10 Troubleshootin
Fault Cause Solution
Wapo-Mat III does not
heat up
Dirty level sensor Clean level sensor
Water level too low Add water
Water-level LED comes
on and warning tone
sounds fig,: 1
Dirty level sensor Clean level sensor
Water level too low Top up water until control light goes
off
Re-calibrating the touch
display
Turn the unit on and while the
Wassermann logo appears tap the
touch display twice This will take
you to the self-explanatory touch
panel calibration process
Fig : 2-3
Programme not starting
although set temperature
has been reached
In mode (a)
the unit intentionally
overheats by 1°C and waits
briefly to validate the value
This is not a fault, please wait
roughly 45 sec
If the above recommendations do not solve the problem, contact your dental depot
or our service department
15
Figure 2 Figure 3
Figure 1

11 Maintenance
11.1 Cleanin
Pull out the mains plug before maintenance work
The model plate must always be legible and must not be removed
Clean the outside of the unit and any accessories with a sponge and/or a soft
cloth and mild detergent
The equipment should be cleaned regularly (ie, clean every 4 weeks with Kalk-Ex) to
guarantee problem-free operation
Quantity: approx 300ccm Kalk-Ex per full tank (18 5 litres water)
If there is considerable limescale present, increase the amount of Kalk-Ex appropriately
The initial supply of Kalk-Ex comes with the machine
Clean the level sensor (white plastic ring) in the tank using a nailbrush, for example
Leave KALK–EX to work for a maximum 12 hours Then drain the tank and rinse
thoroughly
Please clean the water level sensor every 14 days with a brush
16
Water level sensor

11.2 Maintenance
The Wapo-Mat III does not require any special maintenance You just need to keep it
clean
11.3 Repairs
Servicing or repairs to the equipment must only be carried out by trained
technicians Only ori inal Wassermann spares are to be used Responsibility
for the product is voided if altered by unauthorised persons or if inappropriate
components are installed
11.4 Spare Parts
If necessary please contact our service hotline phone
11.5 Service Hotline [phone]/ -24
11.6 Scope of Delivery/ Accessories
Included parts Item no.
PVC hose 19 x 4 ( 3/4“ ) - 1500 mm long 320030
Hose clip Ø 20 – 32 x 12,2 322017
Kalk-Ex, lime remover - 1000 ccm 655002
Accessories: Item no.:
PVC hose 19 x 4 ( 3/4“ ) - 1500 mm long 320030
Kalk-Ex, lime remover - 1000 ccm 655002
17

12 Technical Data
Wapo-Mat III Item no.: 170980
Voltage* 220–240 V / 50/60 Hz
Power consumption: 8 A
Output: 1800 W
Overall dimensions: Width x
Height x Depth
330 x 460 x 530 mm
Weight: 18,5 kg
Capacity : 18,5 l
*Other voltages on request
The noise level of the unit amounts to ≤ 70 dB (A)
Technical changes reserved
13 Disposin of the Unit
The unit has to be disposed by an authorized recycling operation The selected company
has to be informed of all possibly health-hazardous residues in the unit
13.1 Information on disposal for countries within the EU
To conserve and protect the environment, prevent environmental pollution and
improve the recycling of raw materials, the European Commission adopted a
directive that requires the manufacturer to accept the return of electrical
and electronic units for proper disposal or recycling
Within the European Union units with this symbol should not therefore be disposed of
in unsorted domestic waste
For more information regarding proper disposal please apply at your local authoritie
18

14 EU Declaration of Conformity
in accordance with 2014/35/EU (Low Voltage Directive) and 2014/30/EU (Electromagnetic
Compatibility Directive) and 2006/42/EC (Machinery Directive) and 2011/65/EU (RoHS
Directive)
Manufacturer: W A S S E R M A N N
Dental-Maschinen GmbH
Rudorffweg 15-17
21031 Hamburg
Germany
Product description: Polymerisation
Unit for dental
applications
Model: Wapo-Mat III Item no 170980
Applicable
standards
DIN EN 61010-1
DIN EN 61000-6-3
DIN EN 61000-6-1
DIN 45635-1
DIN EN 60335-1
Hiermit wird bestätigt, dass die oben bezeichnete Maschine den genannten EU-Richtlinien
entspricht Diese Erklärung wird ungültig, falls die Maschine ohne unsere Zustimmung
verändert wird
This is to confirm that the above mentioned machine complies with the described EU
guidelines This declaration becomes invalid if the machine is modified without our
approval
Cette machine est conforme aux normes en vigueur d´Union européenne Cet avis est
nul et non avenant si cette machine est modifiée sans notre accord
Esta máquina, anteriormente mencionada, cumple con los limites requeridos por el
reglamento UE Ahora bien, esta declaración quedará invalidada en caso de realizar
modificaciones al aparato sin nuestra aprobación
Hiermee wordt bevestigd dat bovengenoemde machine voldoet aan de voorgeschreven
EU normen Deze verklaring verliest geldigheid als er zonder onze uitdrukkelijke
toestemming wijzigen aan de machine worden aangebracht
Place, date: Hamburg, den 06 07 17 Company stamp:
Signature : ________________________
Wilfried Wassermann
(Managing Director)
19
