Wasserstein 3-in-1 Smart Plug-in Floodlight for Blink... User manual

3-in-1 Smart Plug-in Floodlight
for Blink Outdoor/XT2
USER MANUAL
Sensor

In the Box
Safety Information
• Disassembling the floodlight is not recommended and may damage the
internal components. The floodlight may not function properly after it is
disassembled.
• DO NOT remove the protective LED lens.
• DO NOT look directly at LEDs for any length of time.
Installing Your Floodlight
1. Install the wall plate using the 4 screws and wall anchors provided.
Page 1
4 x screws
EVA gasket
camera mount adapter
power adapter floodlight
US, UK, EU plugs
long screw
8 x cable clips4 x wall anchors
USB cable
wall plate

2. Remove the protective tape from the EVA gasket and press the adhesive
side firmly against the rear of the floodlight.
Page 2
3. Mount the floodlight onto the wall plate and secure it with the long
screw provided.
Note: 3 x plug heads are included (US, UK, EU).
4a. Insert the appropriate plug into the power adapter. Turn clockwise
until it clicks.

Page 3
4c. Plug the power adapter into the wall socket.
4b. Connect the floodlight cable to the adapter cable, then screw
on the plastic cover.
5. Peel off the covers from the back of the cable clips and stick them onto
the wall. Then run the power adapter cable through the clips.

Page 4
Mounting Your Camera
1. Insert the camera mount adapter to the back of the Blink cam.
2. Screw the camera/mount adapter to the mounting screw on the floodlight.

Page 5
3. Open the USB port on both the camera and the floodlight and connect
the USB cable.
4. Adjust the camera to your preferred viewing angle.

Page 6
App Setup
Minimum requirements:
• Smartphone or tablet running iOS 9.0 or later / Android 5.0 or later.
• 2.4 GHz WiFi Network (not compatible with 5 GHz connections).
• Upload speed of at least 2 Mbps.
1. Download the App by scanning the QR code or by searching
"Wasserstein App" in Google Play Store or the App Store.
2. Sign up for a new account or log in to an existing account.
3. Click "Add Device" or "+" in the top right corner. You can add your
device by selecting "Add Manually" or "Auto Scan".

Page 7
1. Select "Lighting" - "PIR Light（BLE+Wi-Fi)".
2. Reset the floodlight by turning it on and off in the following sequence:
on-off-on-off-on (steps also displayed in your App). Then, your floodlight
will flash in intervals (Figure 1).
Add Manually
selection
Figure 1
Flash Flash
Dim Dim
If the light is flashing already,
please skip the reset steps.
Resetting the device:
1. Power on the device.
2. Turn on-off-on-off-on.
3. Make sure the light is flashing.
Note: Please complete the network
selection within 3 minutes after
resetting the device.
Confirm that the light is flashing.

Page 8
3. Enter your Wi-Fi details, and click "Confirm".
4. Wait until your device has been added successfully.
Wasserstein Smart Floodlight
WiFi Login
WiFi Password

Page 9
1. Reset the floodlight to enable pairing mode. Turn on and off in the
following sequence: on-off-on-off-on. Your floodlight will then flash
in intervals.
2. Wait until your floodlight has been automatically detected.
Auto Scan

Page 10
Note: Display and interface are subject to change.
1. Settings
App Functions
Sensor
Manual
On/off
Light intensity
Floodlight color
Turn on/off timer
Schedule
Sensor
On/Off
Motion detection range
Floodlight light sensitivity
Duration of light flash
Event records

Page 11
2. How to Use Linked Devices
On the ‘Sensor’ page click "Linked Devices"，then click "+" on the lower
right corner to enter the ‘Create New Smart’ page. Here, you can add
multiple trigger conditions and tasks for your floodlight to perform.

Page 12
3. Third-Party Control (Google Assistant & Amazon Alexa)
Follow the instructions in the App to link to your Google Assistant, or
Amazon Alexa. Examples of voice commands are also available
in the App.

Page 13
FAQ
1. The smart floodlight will not turn on. What's going on?
2. Will the floodlight turn on during the day?
Yes, to turn on your floodlight during the day, set it to "Sensor" mode
and adjust the light sensitivity to "Day". Or, set to "Manual" mode and
you can turn on your floodlight manually, whether it is day or night.
3. Is a solar panel recommended, or will the plug-in floodlight keep the
camera charged?
4. After installing the floodlight, how can I confirm that it is working?
Set it to "Manual" mode, you can turn it on or off whether it is day or
night. Set it to "Sensor" mode and adjust the light sensitivity to "Day".
You can test to trigger it by moving. Remember to reset the light
sensitivity to your preference after testing.
A solar panel is not recommended. The power adapter will keep the
floodlight powered continuously.
There are several possibilities. Try the following steps:
• Check the connection to your home power source.
• Set the floodlight to "Manual" mode and try turning it on manually.
• Set the light sensitivity to "Day" and see if you can trigger it by
moving. Remember to reset the light sensitivity to your preference
after testing.
• Make sure the App is installed and paired correctly with your
Smart Floodlight.
• Make sure your Wifi network is in 2.4 GHz, not 5 GHz.

Get More Support
Blink Outdoor/XT2 are not included.
Blink Outdoor is a trademark of Immedia Semiconductor Inc.
Blink XT2 is a trademark of Immedia Semiconductor Inc.
Wasserstein is not affiliated with Immedia Semiconductor Inc.
Wasserstein is a trademark of Dropcases Ltd.
Scan the QR code below or email us at [email protected].
Specifications
Materials:
Sensor angle range:
Sensor thresholds:
Max LED light intensity:
Color temperature:
Power:
Frequency:
PC + Aluminum
120°
13 to 33 ft (4 to 10 m)
1500 lumens
3000 - 6500 k
100 - 240 AC 50/60 Hz
2.4 GHz
Made in China
www.wasserstein-home.com
