Wasserstein Floodlight For Google Nest Cam User manual

Floodlight For Google Nest
Cam (battery) USER MANUAL

1 x floodlight
2 x screws
2 x small screws
1 x crossbar
1 x screw cap
3 x wire nuts
1 x EVA gasket
1 x user manual
floodlight
screws
small screws
wire nutscrossbar
screw cap EVA gasket
In the Box
Page 1 Page 2
Installation
Product Highlights
1. Make sure that you have all the included materials.
2. You will be working with electrical wires during the
installation process. For safety reasons, shut off the
power to your floodlight at the circuit breaker.
If you have an existing Floodlight
1. Remove your existing floodlight from the junction box it is attached to, and
disconnect the wires.
Pre-installation
Note: If you are unfamiliar with electrical installations, we highly recommend
hiring a professional electrician to perform the installation.
• 3-in-1 Floodlight, Charger and Mount.
• The Wasserstein Floodlight gets triggered in the presence of motion at night.
• Its PIR Motion Detection range is between 13 to 33 ft.
• The Wasserstein Floodlight lights up for 30 seconds after detecting motion at
night.
• For optimum results, we recommend mounting the floodlight on walls at a high
vantage point. The motion sensor works best when movements are detected
parallel to the floodlight, not towards it.
Before installing this accessory, please first set up the Google
Nest Cam (battery) using the in-box cable provided with the
camera. This will ensure that you have the latest firmware.

Page 3 Page 4
2. Remove the crossbar attached to your junction box.
Installing the Floodlight to the Junction Box
1. Attach the crossbar included in the package to the junction box with the
screws.
2. Remove the protective tape from the EVA gasket. Press the adhesive side
firmly against the rear of the floodlight.
3. Ensure that the center screw hole and wire slot of the foam gasket are
aligned with the screw hole and wire slot.

Page 5 Page 6
1. Connect the green and yellow wire from the floodlight to the existing ground
wire inside the junction box. Use the included wire nut to connect the wires
properly.
2. Using a wire nut, connect the white neutral wire from the floodlight to the
neutral wire of the junction box.
3. Using a wire nut, connect the black hot wire from the floodlight to the hot
wire of the junction box.
The white wire on your floodlight is a neutral wire.
The black wire on your floodlight is a hot wire.
Wiring the Floodlight and Junction Box through
the EVA Gasket
Neutral Wire (White)
Hot Wire (Black)
Ground Wire (Copper) Junction Box
Wire Nuts
Important:
Before mounting the floodlight, completely apply the EVA gasket around
the perimeter of the cover plate where the back of the cover plate meets
the mounting surface. This prevents water from seeping into the junction
box.
4. Make sure that the wire connections are secured. Carefully place the
wires into the junction box.
6. Switch on the electricity, checking that the wiring has been done correctly
and that the floodlight illuminates.
5. Mount the floodlight onto the crossbar and secure it with the screw cap
provided.

Page 7 Page 8
Mounting Your Camera
1. To charge your camera via the floodlight, please install the camera wall plate
onto the floodlight.
2. Install the Nest Cam wall plate on the floodlight using the two short screws
included. Screw in tightly.
3. Attach the magnetic plate onto the wall plate and turn it clockwise to lock it
in place

Page 9 Page 10
Mounting Your Camera along with the Anti-Theft
Mount
4. Attach the camera to the mount, and connect the charging connector to the
camera to charge it.
1. Place the security chain underneath the wall plate of the camera behind
the screw hole.
2. Screw in the wall plate tightly using the two short screws provided.
5. Adjust your Nest Cam to your preferred viewing angle. You may use
the video streaming feature in the Nest app to fine-tune your camera’s
position.
Note:
Make sure that the connector is connected in the right direction as
shown in the picture.
Front
Bottom
Back View Front View

Page 11 Page 12
3. "Attach the magnetic plate onto the wall plate, and turn it clockwise to
lock it in place."
4. Slide in the anti-theft mount on the camera, make sure to align the
speaker/cable opening at the bottom.
5. Make sure that the end of the security chain with the small hole goes in
between the screw holes of the mount. Use the hexagon screwdriver to
tighten the mount and lock the security chain.

• Disassembling the floodlight is not recommended as it may cause damage
to internal components. The floodlight may not function properly after
disassembly.
• Turn the main circuit OFF before installation.
• Do NOT remove the protective LED lens.
• Do NOT look directly at LEDs that are turned on for any length of time.
• Do NOT leave bare wires exposed outside the wall canopy enclosure.
Safety Information
Page 13 Page 14
FAQ
Checking the Power Status via Your
Nest App
• Check your connection of all three wires to the house power.
• Check the area around the floodlight as it may be detecting motion.
The floodlight keeps flashing. What should I do?
• Make sure you are testing the floodlight in darkness.
• Check your connection to the house power.
• Leave the area for 10 minutes to give time for the floodlight to reset
without triggering it. Return and check the floodlight by turning off
the power for at least a minute, then turning it back on.
The floodlight will not turn on. What should I do?
• The floodlight has a maximum LED light intensity of 2400 lumens.
How bright is the floodlight?
• No, the floodlight will only turn on during the night or when the
surrounding light is dim.
Will the floodlight turn on during the day?
7. Attach the camera to the floodlight with the magnetic mount and connect the
magnetic connector to it.
The oodlight continuously powers your Google Nest Cam (battery).
The ∞ sign will be displayed in the Google Home App.

Page 15 Page 16
For more information, visit:
www.wasserstein-home.com
or contact us at:
[email protected]om
Made in China
Google Nest Cam (battery) is not included.
Wasserstein is not affiliated with Google LLC.
Wasserstein is a trademark of Dropcases Ltd.
Google Nest Cam is a trademark of Google LLC.
This product has been certified by Wasserstein to
meet Google’s compatibility standards. Google
is not responsible for the operation of this
product or its compliance with any applicable
safety or other requirements.
Learn more at g.co/madeforgoogle.
