Waterdrop WD-TSA-10 User manual

Step 2: Connect the water supply (cold water only)
1. Shut o the water supply. Remove the faucet hose. (Figure 1)
2. Connect the inlet hose to the cold water valve.
• If the angle valve outlet is 3/8”, it can be directly connected to the water supply. (Figure 3)
• If the angle valve outlet is 1/2”, connect it with a No.1 converter at rst. (Figure 4)
Triple-Stage Undersink Water Filtration System
WD-TSA-10 system | Installation Instructions
Note: The service life mentioned above is subject to chlorine reduction. Actual result varies according
to the local water quality.
Precautions
• Do not use it with water that’s microbiologically unsafe or of unknown quality without adequate disinfection.
• For use only with cold water.
• Do not freeze the lter, as this can cause cracking and water leakage.
• Do not allow children under 3 years old to have access to small parts during installation of this product.
• This installation must comply with all applicable state and local regulations.
• Turn o the water supply while replacing the lter.
Inlet hose Outlet hose
Teflon tape
Filter head
3/8”-1/2” converter
Operating temperature
Working pressure
Flow rate
Filter capacity
2-38℃/35-100℉
10-125psi (0.7-8.6bar)
1gpm
Specifications
Feed water requirement Municipal tap water
WD-10PP: up to 6 months
WD-10GC: up to 8-12 months
WD-10CT: up to 12-18 months
Figure 3 Figure 4
3/8” outlet
1/2” outlet
Connect
① to the cold angle valve
①
WARNING Please read it carefully before installation.
Step 3: Connect to the faucet
1. If the angle valve outlet is 3/8”, it can be directly connected to the water supply. (Figure 5)
2. If the angle valve outlet is 1/2”, connect it with a No.2 converter at rst. (Figure 6)
Figure 5 Figure 6
②
Faucet hose
Outlet hose
Faucet hose
Note: If a female threaded connector is needed, please contact our service team for help.
Step 4: Connect to the filter system
Connect the inlet hose and the outlet hose to the lter head. Make sure the hoses hit the bottom of
the lter head.
Note: When the hose is tightly inserted, there will be a 1/8 inch gap between the hose and the lter
head, which is designed for easy replacement and won't aect the sealing performance.
Step 5: Flush the filter and check the leaks
1. Flush the lter for 5 minutes before use.
2. If water leakage occurs, turn o the water supply. If the water leakage is occurring at position 1 and 2,
wrap Teon tape on the external thread. If the water leakage is occurring at position 3 or 4, insert the
quick-connect tting to the end and make sure the hoses hit the bottom of the tting.
Inlet hose
ColdHot
Outlet hose
Filter system
Faucet hose
1
23 4
Figure 1
Inlet hose outlet hose
Installation of the filter system
Tips: How to disconnect the quick-connect?
Use your thumb and index nger to press down on the lock sleeve. Use your other hand to pull out the
hose from the tting.
Note: Please do not pull out the tubing directly, or else it will damage the tting and cause leakage.
Step 1: Fix the filter head and the filter
1. Paste the assistant label to nish drilling.
Note: Mount the water lter at least 2 inches higher
than the ground for easier lter change.
2. Install the screw and reserve enough space to hang the lter.
3. Hang the lter system on the screw.
Press
Pull
Press

Filter replacement
1. It’s recommended to turn o the water supply and
turn on the faucet to release the water pressure.
2. Rotate 1/4 turn to the left to remove the lter.
3. Take out the new lter and remove the protective cap.
4. Rotate 1/4 turn to the right to install the lter. Ensure
that the lter’s triangle mark is aligned with the
connection mark.
5. Turn on the cold water valve and ush for 5 minutes.
Frequently asked questions
Q: What should I do if water leaks after installation?
A: In the event of water leakage, turn o the water supply. If the water leakage is occurring at the
thread, wrap Teon tape on the external thread. If the water leakage is occurring at the quick
connection position, insert the quick-connect tting to the end and make sure the hoses hit the
bottom of the tting. Contact us for solutions if the water leakage persists.
Q: Why doesn’t the TDS value lower after filtration?
A: The main purpose of this waterdrop lter is not to remove TDS. TDS stands for total dissolved solids,
and it is basically composed of inorganic salts and a small amount of organic matter. The lter can
remove harmful substances while keeping benecial trace elements. Please choose Waterdrop RO
system if you are looking for physical removal of TDS.
Q: When should I replace the filter?
A: The lter’s service life is related to the water quality. If the ow rate is signicantly reduced or if the
water has a peculiar smell, we suggest that you replace the lter. The recommended service life of the
lter is as follows: The PP lter has a 6 month lifetime; the GC lter has an 8-12 months lifetime; the CT
lter has an 12-18 months lifetime.
Q: What substances can the filter reduce?
A: Our premium coconut carbon block lter has been tested by an independent laboratory against
NSF standards. It can eectively reduce chlorine, taste and odor, cysts, hydrogen sulde, and other
heavy metals.
Q: What is the difference between the WD-TSA system and the WD-TSB system?
A: The WD-TSA system does not come with a faucet. It will connect to your existing faucet. Meanwhile,
the WD-TSB system comes with an additional water faucet.
1 -year quality assurance
All mechanical devices with moving parts have a normal life span and will need to be replaced periodically. For
this reason, mechanical devices such as water ttings, lter head, and faucets have a limited replacement
assurance of 1 year. No assurance is given as to the service life of any lter cartridge, as the service life will vary
based on local water conditions and water consumption.
If the product proves to be defective within 1 year from the date of purchase, please contact our customer
service department. During the assurance period, we will replace or repair any part that is deemed to be
defective if the product has not been subjected to tampering, alteration, or improper use after delivery, and
has not been repaired by the manufacturer.
We do not make any promises in the event of misuse, use in abnormal temperature conditions, conditions
outside those listed in the operating parameters, or use in commercial operations.
Remove the filter Install the filter
Made in China V020
Manufacturer Technical Support:
1-888-352-3558 (U.S.) Mon-Fri 8:00AM-5:00PM (PST)
Qingdao Ecopure Filter Co., Ltd.
If you encounter any problem with our product, please contact us to get support
via the purchase channel.
