WaterLogic PUREZZA WL2FL FIREWALL User manual

WL2FL FIREWALL
MANUAL

WL2FL Manual
Page 2 – Revision AU27-04-2023
WL2FL MANUAL
Congratulations on your choice of the Waterlogic WL2FL Water Treatment System. The WL2FL
Water Treatment System model dispenses cold, and hot. Every WL2FL Water Treatment System
includes:
High Performance Multi-Stage Filtration
Bio-Cote Anti-MicrobialProtection
Firewall Advanced Purification
The Waterlogic WL2FL Water Treatment System provides exceptional quality and great tasting
water with every use.
INTRODUCTION
Carefully read and follow all instructions to ensure proper and efficient operation of your Water
Purification System. Contact Waterlogic or an Authorized Waterlogic Dealer if you have any
questions.
Waterlogic and Authorized Waterlogic Dealers employ trained service personnel who are
experienced in the installation, function and repair of Waterlogic equipment. This publication is
written for use by these qualified individuals. Waterlogic encourages users to learn about products,
however, we believe that product knowledge and service is best obtained by consulting Waterlogic
or an Authorized Waterlogic Dealer.
Waterlogic Water Purification Systems should be combined with selected water treatment
components to create a system specifically tailored for each application by trained and qualified
personnel.
Products manufactured and marketed by Waterlogic and its affiliates are protected by patents.
Waterlogic reserves the right to change the specifications referred to in this Literature at any time,
without prior notice. Changes or modifications not expressly approved by Waterlogic could void the
warranty and user’s authority to operate the equipment.
Waterlogic technical manuals cover voltages of both 120v and 220v for all our markets. Please
ensure that you carefully read the information in this manual and for any parts specific to any
market, refer to your technical agreement or specific part listing.

WL2FL Manual
Page 3 – Revision AU27-04-2023
TABLE OF CONTENTS
USER GUIDE
•Safety Alert Symbols................................................................4
•Safety Precautions...................................................................4
•Features and Benefits..............................................................7
•Certifications ...........................................................................8
•Model Designations and General Specifications......................9
•Electrical and Shipping Specifications....................................10
•Operating Instructions.......................................................... 11
SERVICE GUIDE
•Service Requirements........................................................... 12
•Hot Tank Principles of Operation.......................................... 13
•Heater Circuit – Hot Tank Wiring.......................................... 14
•Resetting the Hot Tank Overheat (High Limit Safety) ........... 15
•Hot Tank Descaling............................................................... 17
•Recommended Spares Holding ............................................ 19
•Mini Drawings and Parts List ................................................ 20
•Free standing Drawings and Parts List .................................. 25
•Flow Diagrams...................................................................... 31
•Electrical Schematic.............................................................. 34
INSTALLATION GUIDE
•Pre-delivery Procedures ....................................................... 42
•Mini Draining Procedure ...................................................... 46
•Free standing Draining Procedure ........................................ 45
•Installation Instructions........................................................ 48
TROUBLESHOOTING GUIDE
•Fault Codes........................................................................... 50
•Power Troubleshooting ........................................................ 53
•Dispense Troubleshooting.................................................... 56
•Cold Water Troubleshooting ................................................ 71
•Hot Water Troubleshooting.................................................. 72
CONTACTLESS GUIDE
•Pedal .................................................................................... 75
•Infra-red ............................................................................... 78

WL2FL Manual
Page 4 – Revision AU27-04-2023
SAFETY ALERT SYMBOLS
Read and follow all safety information carefully. The signal words used in this manual are selected as
shown below and based on an assessment of the degree of potential injury or damage (severe or
minor) and the occurrence of injury (definitely occurs or has the potential to occur) when the
warning is ignored:
DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.
WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or severe
injury; and/or severe property damage.
CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in minor
injury; and/or minor property damage.
SAFETY PRECAUTIONS
Basic safety precautions should be followed, including the following:
Ensure all local laws and codes including health and safety guidelines are met when installing
Waterlogic Equipment. Only qualified service technicians should attempt installation and service of
Waterlogic Equipment. Always read the entire operating instructions before using the appliance
and save these instructions for future use.
DANGER! ELECTRICAL SHOCK HAZARD. Always use a dedicated and properly earthed outlet. Unit
should be protected by residual current device (RCD) having a rated residual operating current not
exceeding 30mA. Use only Waterlogic supplied power cord. Never use extension cords or power
strips to connect unit. Do not use if the power supply cord is damaged. Always unplug from power
supply prior to servicing.
WARNING! AUTHORIZED USE ONLY. This appliance is to be used for its intended purpose as
described in this manual, and untrained individuals who use this manual assume the risk of any
resulting property damage or personal injury. This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazardsinvolved.
WARNING! SUPERVISE CHILDREN. Keep appliance and cord out of reach of children under the
age of 8years. Children under the age of 8 years must not use or play with the appliance.
WARNING! DO NOT OPERATE IF DAMAGED. Unplug for safety. Contact Waterlogic or authorized
dealer for repair, service, and installation to avoid hazards.
WARNING! HOT WATER. Unit produces Hot Water in excess of 87oC (188oF). Water above 52oC
(125oF) can cause severe burns or scalding. Keep unauthorized people and children away from the
unit to avoid accidental dispensing of hot water.

WL2FL Manual
Page 5 – Revision AU27-04-2023
DANGER! This product can cause death or severe injury if incorrectly operated, installed or
maintained. The installation, maintenance, sanitizing and any repair must be performed by
qualified persons trained by Waterlogic International or their approved distributors only. Do not
remove any panel or cover to protect against electrical shock and exposure to UV radiation.
WARNING! AUTHORISED USE ONLY. This appliance is to be used for its intended purpose as
described in this manual, and untrained individuals who use this manual assume the risk of any
resulting property damage or personal injury. This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved.Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children without supervision.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance
WARNING! UV-C EMITTER (UV LAMP). This appliance contains a UV-C emitter (UV Lamp). UV-C
radiation may, even in little doses, cause harm to the eyes and skin. Unintended use or damage to
the housing may result in the escape of dangerous UV-C radiation.
Never operate the UV-C emitter if damaged or removed from enclosure. Do not touch or look
directly into the faucet. Appliances that are obviously damaged must not be operated.
Replacement of the UV-C emitter can not be conducted by the user, please contact Waterlogic for
assistance or help finding an Authorized Service Representative.
Read the maintenance instructions before opening the appliance
Appliance must be disconnected from the supply before replacing the UV-C emitter.
WARNING! UV-C EMITTER (UV LAMP).
Do not operate the UV-C emitter when it is removed from the appliance enclosure
WARNING! USAGE. This appliance is intended to be used in household and similar applications
such as: staff kitchen areas in shops, offices and other working environments; farm houses and by
clients in hotels, motels and other residential type environments; bed and breakfast type
environments; catering and similar non-retail applications.

WL2FL Manual
Page 6 – Revision AU27-04-2023
WARNING! REFRIGERANT. Caution with cooling fluid: Do not damage the cooling circuit,
Waterlogic machines use both R134a and R600a (market dependent) as cooling gas. R600a is a
flammable gas, precaution is required, and only qualified and certified personnel should empty,
replace or fil the machines with R134a and R600a refrigerant gases.
Ensure always the proper management and transportation of the machine to avoid damaging the
refrigerant fluid and causing a dangerous leak.
Discarded appliance should be isolated from fire sources and cannot be burned.
Please transfer the appliance to qualified professional recycling companies for processing to avoid
damages to the environment or other hazards.
WARNING! VENTILATION. Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING! REFRIGERANT. Do not damage the refrigerant circuit.
WARNING! STORAGE. Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of the type recommended by the manufacturer.
Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
WARNING! CONNECT TO POTABLE WATER SUPPLY. This system is to be used for water only and
is not intended for use where water is microbiologically unsafe or with water of unknown quality
without adequate disinfection. System is designed for the supplemental bactericidal treatment of
public drinking water, or other drinking water, which has been tested and deemed acceptable for
human consumption by the water provider. The system is designed to reduce normally occurring
non-pathogenic or nuisance microorganisms only. System is not intended for treatment of
contaminated water.
WARNING! TIP HAZARD. Dispenser could tip or fall causing serious injury. Always install unit on a
firm, flat, and level surface and secure the WL2FL Water Treatment System to the base cabinet
with the screw provided to lock the components together. Secure unit to cabinet, wall, or floor if
needed. Never place heavy items on top of unit and never climb, stand, or hang on unit or storage
cabinet to prevent injury and damage.
WARNING! UNIT IS HEAVY. TWO PERSON LIFT REQUIRED. Transport unit empty and always use
material handling equipment or two people with proper lifting technique to reduce injury risk.
WARNING! STORE AND TRANSPORT UNIT EMPTY. ALWAYS SANITIZE BEFOREUSE.
The unit must be completely drained and sealed before storing to avoid stagnation and reduce
microbiological contamination (potential bacterial growth). Sanitize before use to eliminate any
potential microbiological contaminates
CAUTION! INDOOR USE ONLY. Intended for household use only. Never expose to direct sunlight,
heat sources, or ambient air temperature above 30°C (86°F) or below 2°C (35°F). Install indoors
and keep unit away from excessive humidity. Never expose to freezing temperatures. Ensure
there is adequate clearance around the unit (50mm minimum) to allow refrigeration system
condenser to dissipate heat. Warmer environments require more clearance around the unit.

WL2FL Manual
Page 7 – Revision AU27-04-2023
Installs where the ambient temperature exceeds 25°C (77°F), require a minimum of 100mm
clearance for proper heat dissipation and efficient operation.
CAUTION! USE A WATER PRESSURE REGULATOR. Waterlogic will not be responsible for injury or
damage caused by excessive water pressure. Input or feed pressure must be 2.5 to 3Bar. Be aware
of any potential pressure surges caused by building/municipal pumping stations. Water block
devices and external leak detectors are strongly recommended. Locate the unit as close to the
water supply and the electrical connections as possible to minimize risk.
CAUTION! USE PROPER SUPPLY LINES AND FEED WITH POTABLE AMBIENT WATERONLY.
Feed water over 25°C (77°F) may damage the treatment components. Always use supply lines
with adequate pressure rating and UV resistance. Close water supply valve and contact service
representative if a leak is noticed.
Contact Waterlogic for assistance or help finding an Authorized Service Representative.

WL2FL Manual
Page 8 – Revision AU27-04-2023
WL2FL FEATURES AND BENEFITS
Ambient, Cold and Hot Water
Cold and Hot Selections, which can be changed to Ambient and Cold settings to meet a wide range of
customer demands.
High Volume Storage and Water Capacity
Free standing model has 4 Litres of Cold Water Capacity and 1.5 litres of Hot Water.
Mini model has 2 Litres of Cold Water Capacity and 1.5 litres of Hot Water.
BioCote®Anti-Microbial Protection
Certain plastic, silicon, and painted surfaces surrounding the dispensing areas and
drip try are infused with an exclusive additive called BioCote®. BioCote® provides
an effective barrier against microbes like bacteria and mould, which may cause
odours or staining.
Large Dispense Area with Recessed Faucet
230mm dispense height with BioCote® recessed faucet to protect from cross-contamination.
Child Safeguard
WL2FL Water Treatment Systems requires Hot Water selection followed by main dispense for Hot
Water, and defaults back to cold selection after 3 seconds of inactivity to prevent accidental
dispensing of hot water.
Energy Saving Sleep Mode
Energy Saving Sleep Mode can be programmed to turn off heater after 3 hours of inactivity.
Firewall™
Firewall is proprietary technology that places the UV lamp at the point of
dispense. This point of dispense purification keeps the dispense nozzle free
from external contamination as well as purifying the water, making the
freshest water possible.

WL2FL Manual
Page 9 – Revision AU27-04-2023
WL2FL CERTIFICATIONS
Waterlogic Water Treatment Systems have been tested, approved, and certified by the world’s top
standards bodies such as NSF and ANSI. These organizations set and regulate national standards. We
believe that performance testing and certifications validate Waterlogic as a world-leader in water
treatment systems.
WL2FL Water Treatment System Certifications Include
This system is certified by IAPMO R&T according to NSF/ANSI 42, NSF/ANSI 53*,
NSF/ANSI 55 Class A, NSF/ ANSI P231, US EPA Guide Standard and Protocol for Testing
Microbiological Water Purifiers for the reduction of the contaminants on the Performance
Data Sheet, NSF/ANSI 372 for lead free compliance.
See the performance data sheet for specific reduction claims.
System claims vary depending on filters used within the system.
*when using Waterlogic 1 Micron CBC Filter (FT-0065 or FT-0034).
UL399 – Certified Drinking Water Cooler
Intertek Labs (ETL) Certified the WL2FL Water Treatment System to ANSI/UL 399 Standard for
Drinking Water Coolers.
BPA Free - Waterlogic tests for BPA and declares that all of its products are Bisphenol-A FREE
and contain no harmful BPA plastics.
Waterlogic is certified to ISO 9001:2008 – Quality Management Systems (certified by
Intertek). ISO 9001 is the internationally accepted standard for well managed
organizations that have adopted the key quality management principles to its operations
to bring consistent quality products and a culture of continuous improvement.

WL2FL Manual
Page 10 – Revision AU27-04-2023
MODEL/PART DESIGNATIONS
BRAND NAME DESCRIPTION MODEL – PART NUMBER
WL2FL Free Standing
Waterlogic WL2FL Free Standing - Cold and Hot
F-2FW-FS-HC & F-2FX-FS-HC
Waterlogic WL2FL Free Standing - Cold and
Ambient F-2FW-FS-CA & F-2FX-FS-CA
Waterlogic WL2FL Free Standing – Cold
F-2FW-FS-C & F-2FX-FS-C
WL2FL Mini
Waterlogic WL2FL Mini - Cold and Hot
F-2FW-M-HC & F-2FX-M-HC
Waterlogic WL2FL Mini - Cold and Ambient
F-2FW-M-CA & F-2FX-M-CA
Waterlogic WL2FL Mini - Cold
F-2FW-M-C & F-2FX-M-C
WL2FL Tall
Waterlogic WL2FL Tall - Cold and Hot
F-2FX-FT-HC
Waterlogic WL2FL Tall - Cold and Ambient
F-2FX-FT-CA
SPECIFICATIONS
ITEM WL2FL Mini WL2FL Free Standing
Power Supply 220V/50Hz or 120V/60Hz
Water Connection ¼” Quick Connect
Cold Water Temperature Cold Water Temperature – Factory Set Point 5°C (41°F)
Cold Tank Size Mini - 2 Litres
Free standing – 4 Litres
Hot Water Temperature 87°C (187°F)
Hot Tank Size 1.5 litres
Hot Water Manual Reset
Overheat
105°C (221°F)
Recommended Incoming
Feed Pressure
2.5Bar – 3Bar – Use Pressure Regulator
Maximum Service Pressure 3Bar – Use Pressure Regulator
Rated Service Flow Out 1.89 Litres per Minute – Firewall Purification
Environmental Temperature 2°- 25°C (35°- 77°F)
Climate Class 220V available in both Class T and N
UV Lamp 15 Watts 15 Watts
Heater 500 W
Refrigerant Gas 220v = R600a 20g
120v = R134a 1.52oz
220v = R600a 20g
120v = R134a 1.34oz
WL 2FW FS
WL 2FX FS
WL 2FW M
WL 2FX M
WL 2FX FT

WL2FL Manual
Page 11 – Revision AU27-04-2023
SHIPPING SPECIFICATIONS
ITEM WL2FL Mini WL2FL Free Standing WL2FL Tal
Width/Depth/Height
34cm x 37cm x 45cm
13.5” x 14.5” x 17.75”
34cm x 41cm x 104cm
13.5” x 14.5 x 41”
34cm x 41cm x 118cm
13.5” x 14.5 x 46”
Weight (dry)
26.3 kg (58 pounds)
30 kg (66 pounds)
32kg (70 pounds)
ELECTRICAL SPECIFICATIONS
220V-TT and ES
TT
ES
COMPONENT
POWER (approximate)
POWER (approximate)
Heater 500 Watts 800 Watts
Compressor
100 Watts
100 Watts
UV Lamp System 15 Watts 15 Watts
WL2FL TOTAL
640 Watts
930 Watts
120V-TT TT
COMPONENT
Current (approximate)
Heater 4.2 Amps
Compressor
1.4 Amps
UV Lamp System 0.3 Amps
WL2FL TOTAL
5.9 Amps

WL2FL Manual
Page 12 – Revision AU27-04-2023
OPERATING INSTRUCTIONS
The above picture shows front LCD display and control panel for the Waterlogic WL2FL.
For Cold Water: Press Cold Water Select Button followed by the Dispensing Button (within 3
seconds).
For Ambient Water: Press Ambient Water Select Button followed by the Dispensing Button
(within 3 seconds).
For Hot Water: Press Hot Water Select Button followed by the Dispensing Button (within 3
seconds).
NOTE: Default selection mode is Cold Water. Selection will return to default after 3 seconds of
inactivity.
NOTE: Selection indication light will turn Red when the Hot Water Select button is pressed, and will
switch back to the default green within 3 seconds after dispensing the hot water.
Temperature Indicator Light

WL2FL Manual
Page 13 – Revision AU27-04-2023
SERVICE REQUIREMENTS
WARNING! Read and understand the contents of this manual before attempting to service
WL2FL Water Treatment System. Failure to follow the instructions in this manual could
result in death, serious personal injury, or severe property damage. Only trained and
qualified technicians should attempt to install, maintain, or service Waterlogic Equipment.
1. Visually inspect all electrical and water connections for signs of wear or damage.
DANGER! HIGH VOLTAGE ELECTRICAL HAZARD. Unplug before inspection andservice.
2. Waterlogic recommends changing the UV Lamp every 6 months.
WARNING! ULTRAVIOLET RADIATION. Protect your skin and eyes against ultraviolet rays.
Never look directly at an operating UV light. Disconnect before removing UV Lamp.
CAUTION! UV LAMPS ARE HAZARDOUS. Lamps are considered Hazardous Waste andmust
be disposed of accordingly. Refer to Product MSDS sheet fordetails.
3. Clean the Spiral Quartz Sleeve that surrounds the UV Lamp with a non-abrasive cloth, descaling
solution, or ultrasonic bath if needed when changing UV Lamps.
CAUTION! UV SYSTEM IS FRAGILE. Never handle the UV lamp or Quartz Sleeve with bare
hands. UV Lamp and quartz sleeve must be free of oils and contaminants to ensure proper
operation. Use a soft non-abrasive cloth to clean.
4. Sanitize the Cold Tank per instructions in the pre-delivery procedures.
5. Clean and sanitize external surfaces of the unit. Sanitizing chemicals that are compatible with
ABS plastic and will not damage or degrade the productsurfaces.
6. Remove and clean the Faucet. Replace as needed.
WARNING! SANITIZER MAY CONTAIN HAZARDOUS CHEMICALS. Use of properpersonal
protective equipment such as rubber gloves and eye protection is required.

WL2FL Manual
Page 14 – Revision AU27-04-2023
HOT TANK PRINCIPLES OF OPERATION
HOT TANK
OUTLET TUBE
All Waterlogic Hot Tanks have a built-in Vent or
Expansion Chamber in the top of the tank except for
WL1000GF units.
The Vent Chamber allows for expansion of the water
when it is heated.
The chambers are separated by a welded-in tank
baffle.
EXPANSION
CHAMBER Water always flows into the bottom of the tank and
out the top to the faucet.
EXPANSION SLIT The hot tank outlet tube has a restrictor in its base.
This ensures the reservoir is always full by allowing
more water in than out.
There is a small hole in the side of the tank outlet tube
that allows air and water to pass into the vent
chamber as it is heated.
Water in the vent chamber is suctioned back through
the outlet tube vent hole when water is dispensed.
THERMISTOR
WELL
Expansion of water as it is heated in the reservoir will
push the water out the faucet when the outlet tube
vent hole becomes plugged with debris or scale.
HEATER
ELEMENT
The small Outlet Vent Hole is susceptible to scale build
up and is a key indicator that descaling is required.
It is critical to descale the hot tank through the vent
line and outlet line on a regular basis to prevent this
problem.
INLET TUBE
Descaling through the inlet and/or outlet lines only
will not clean the vent chamber and outlet vent hole
properly.

WL2FL Manual
Page 15 – Revision AU27-04-2023
HEATER CIRCUIT – HOT TANK WIRING

WL2FL Manual
Page 16 – Revision AU27-04-2023
RESETTING THE HOT TANK OVERHEAT OR HIGH LIMIT SAFETY
1.
Red Compressor/Heater Switch must be in the O=OFF position
2. Unplug the Power Cord from rear of WL2FL Water Treatment System.
3.
Free Standing Model: Remove the Lower Front Panel by removing the Phillips Head
Screws underneath the Lower Front Panel.
Mini Model: Remove the Side Panel by removing Phillips Head Screws from Side Panel.
4.
Locate the Protective Metal Box on the rear of the hot
tank. As you look through the condenser coils on the
rear of the unit, you will see the hot tank located on the
right-hand side.
5.
From the front of the Water Treatment System, reach
up behind the hot tank and take hold of the protective
metal box covering the thermostat and overheat on the
hot tank.
There are nuts that secure the Protective Metal Box to
the Hot Tank, are loose enough to allow you to remove
the Protective Metal Box.
If the nuts on the metal box are too tight, loosen the
nuts securing the Hot Tank to the upper base of the
WL2FL Water Treatment System unit and lower the
Hot Tank so you can remove the Protective Metal Box.

WL2FL Manual
Page 17 – Revision AU27-04-2023
6.
For demonstrative purposes, photos below have lowered the hot tank from the unit.
Press the reset button
7.
Reattach the Protective Metal Box by depressing the top
flap of the Protective Metal Box so it snaps back into its
original position on the Hot Tank.
8. Replace the Lower Front Panel.
9. Plug in the Power Cord.
10.
Turn on the Red Compressor/Heater Switch I=ON position
The Hot and Cold tanks must be filled with water BEFORE turning on the
Red Heater and Compressor Switch.
11. Verify the cooler is fully operational before installing it at the customers’ site.

WL2FL Manual
Page 18 – Revision AU27-04-2023
HOT TANK DESCALING INSTRUCTIONS
The Hot Tank requires removal of mineral deposits (descaling) on a regular basis. Typically
descaling should take place every 6 to 12 months to preserve the long-term health of your unit.
Use non-toxic cleaner such as ScaleKleen, DEZCAL or Citric Acid Solution to remove mineral
deposits as directed by the manufacturer depending upon filtration and local water conditions.
Descaling is an important process that removes calcium deposits, or scale, that can build up
inside a tank over time. Calcium and scale is non-toxic but if left unattended will hinder your
unit’s performance.
WARNING! PERSONAL PROTECTIVE EQUIPMENT REQUIRED. Always ensureproper
ventilation and use rubber or nitrile gloves and eye protection when using chemicals. Refer to
Material Safety Data Sheet for specific requirements of each product.
CAUTION! STAINLESS STEEL TANK DESCALING.
The Hot Tank is made from stainless steel. Ensure descaling solution is compatible with
stainless and always flush the unit completely. Dispose in an environmentally safe manner.
Materials Needed:
•Personal Protective Equipment. Rubber or Nitrile Safety Gloves and ProtectiveEyewear
•Phillips Screwdriver
•Temperature Gauge
•Water Pitcher or Container to collect water from the faucet
•20 Litre container or drain basin
•Citric Acid Based Cleaner
•¼” Plastic Tubing, at least 1m in length, and assorted ¼” quick connect fittings
•Empty Cartridge
1. Put descaler solution as per directions into the empty cartridge.
2. Connect descaling cartridge to the inlet water supply and connect to inlet bulkhead fitting on the
back of the WL2FL Water Treatment System. Turn on Water Supply.
3. Select Hot Water and depress the Main Dispensing Button on the Front Control Panel until
descaling solution (cloudy water) comes out of the faucet. Container and drain basin will be
required to catch water from the faucet.
4. Turn off water supply and remove the empty cartridge from inlet water supply. Reconnect water
supply to inlet fitting.
5. Allow descaling solution to remain in the Hot Tank for 15 minutes (length of time may vary
depending on water conditions).

WL2FL Manual
Page 19 – Revision AU27-04-2023
6. Place a pitcher, catch basin or other container under the faucet of the WL2FL WaterTreatment
System.
7. Flush the Hot Tank until water runs clear.
8. Once clear Water dispenses from the faucet the Hot Tank has been descaled. Always ensure the
WL2FL Water Treatment System is performing to the customer’s satisfaction.
WARNING! HOT WATER. The WL2FL Water Treatment System produces Hot Water up to
87°C (189°F). Water above 52°C (125°F) can cause severe burns or scalding. Hot water should
be dispensed carefully into insulated container to avoidinjury.
WARNING! REINSTALL ALL PANELS AND COVERS. Always reinstall all Panels,Protective
covers, and fasteners after servicing equipment. Failure to do so could result in severe
personal injury and will void the certifications and warranty of theequipment.

WL2FL Manual
Page 20 – Revision AU27-04-2023
RECOMMENDED SPARES HOLDING
WLI recommends that you order spare parts and consumables at the same time as you order
machines to minimise delivery costs. The list below contains the minimum parts WLI recommends
that you keep per 10 machines. These recommendations are based upon the servicing and
maintenance guidelines, water conditions and use mean more stock may be required.
➢ Waterlogic technical manuals cover voltages of both 120v and 220v for all our markets.
Please ensure that you carefully read the information in this manual and forany parts specific
to any market, refer to your technical agreement or specific partlisting.
Recommended Spare Part
Amount per 10 machines
1-micron 10" Inline CBC Filter
cartridge
10
1-micron 10" GAC Inline Filter
cartridge
10
20 Micron Sediment Filter
cartridge
10
15w UV Lamp
10
Quartz Spiral for Firewall
10
Solenoid Valve 1000mm
(recommend replacing Solenoid
Cushion at same time)
2
Solenoid Cushion
2
Hot Water Faucet
2
Main PCB
4
Silicon Button Key Mat
5
Drip Tray Grill
4
Drip Tray
4
UV 15W 220V/50Hz Electronic
Ballast
2
Hot Tank 87°C (187°F)
2
