Watermark Zip HydroTap Celsius Arc User manual

807115 v1.00 11.20 Celsius Arc Cube Instructions
6Connect the water supply
All fittings are supplied apart from the isolation
valve.
2x male
adaptor
T-piece
!
Valves and fittings must
be sealed with PTFE tape.
See 2
Red marked
braided hose
to mixer tap
Blue marked
braided hose
to mixer tap
Mains water
isolation valve
(not supplied)
Hot water isolation valve
(not supplied)
8
Connect fittings together
Zip
HydroTap
Installation instructions
Celsius Arc & Celsius Cube
B, CS
Cleaning and general maintenance
Command Centre connections
Mains In Mains potable water supply.
USB Connected to the Tap.
Boiling out Red silicone tube from tap. Cut to length.
Chilled out (CS) Blue JG pipe from tap. Cut to length.
Vent Clear silicone tube from tap. Cut to length.
Sparkling out (CS) White JG pipe from tap. Cut to length.
7
Wipe surfaces with a damp cloth and then wipe dry
with a clean, dry cloth. Do not use disinfectant sprays
without wiping dry afterwards. Visit our website to download the manuals
Australia UK
Zip Water (Aust) Pty Ltd
ABN 46 000 578 727
67 - 77 Allingham Street, Condell Park, NSW 2200
Postal: Locked Bag 80, Bankstown 1885, Australia
([phone] | Free Call (Aust): 1800 947 827
www.zipwater.com
Zip Water UK
Trafalgar House
Rash’s Green, Dereham,
Norfolk NR19 1JG
0345 6 005 005 | [email protected].uk
specify.zipwater.co.uk
WMK25927
AS/NZS 3718
Braided hose to
Command Centre
MAINS inlet (supplied
with Command Centre)
1/2” BSP adaptor
Strainer

Please refer to all safety and installation requirements
detailed in the Quick start guide provided with the
HydroTap Command Centre, and HydroTap Command
Centre installation instructions found online, prior to
installation of, or any change to, the complete system.
Before commencing the
installation,download
& read the HydroTap
Command Centre
installation instructions
!
Using these instructions
Read the
instructions
WARNING
Tools needed for tap installation (not supplied)
In addition to normal tools, the following (or equivalent
equipment) will be required.
• 35mm diameter sheet metal hole punch for sinks.
• 35mm diameter hole saw for worktops.
• Tube spanner for fixing the tap assembly.
220mm
250 - 255mm
Positioning
Position the tap such that it dispenses into the
sink bowl with clearance for a cup or tea pot.
Ensure that taps are positioned to minimise
the risks of scalding by dispensing boiling
water while using the tap.
!
1
Position Command Centre
and Tap as close together as
possible. See below.
4Cut the hole
• Cut a Ø35mm hole in the worktop / sink.
• Make sure the tap location will allow the tap
spout to drain into the sink.
Ø35mm
5
Familiarise yourself with the tap connections
3
Mount and secure the tap
Upper rubber
washer
Lower rubber
washer
Brass
washer
Fixing nut
Mains
See 6
Hot
Cold Mains
See 6
Chilled sparkling
model shown
Familiarise yourself with the mains
connections
2
RED
Boiling
tube
Sparkling models
WHITE
JG
pipe
BLUE
JG
pipe
Boiling models
CLEAR
Vent
tube
USB USB
BLUE
Chilled
tube
BCS Comm
InLine
ELECTRONIC
Min - Max pressure, kPA (bar)
Australia UK
HydroTap 170 (1.7) - 700 (7.0) 170 (1.7) - 500 (5.0)
Sparkling
HydroTap 250 (2.5 ) - 700 (7.0) 250 (2.5) - 500 (5.0)
Booster 200 (2.0) - 700 (7.0) 200 (2.0) - 500 (5.0)
Water supply pressure requirements
Be aware of the risks of hazards which could
cause harm when using tools. Assess the
risks before starting the installation.
!
Fit braided hoses, matching
the hose colours to the tap
