Waterpik Complete Care CC-01 User manual

Waterpik®Complete Care
Models CC-01 | CC-02
•
8
•
6
•
4
•
2
•
ON
OFF
Mode
Clean
Whiten
Massage
CHARGE
•
8
•
6
•
4
•
2
•
ON
OFF
Mode
Charge
Low
High
Massage

2
IMPORTANT SAFEGUARDS
IMPORTANT
SAFEGUARDS
When using electrical products, especially when
children are present, basic safety precautions
should always be followed, including the following:
READ ALL INSTRUCTIONS
BEFORE USING.
DANGER:
To reduce the risk of electrocution:
• Do not handle plug with
wet hands.
• Do not place in or drop into
water or other liquid.
• Do not use while bathing.
• Do not place or store product where it can fall or
be pulled into a tub or sink.
• Do not reach for a product that has fallen into
water. Unplug immediately.
• Check the power supply cord for damage before
the first use and during the life of the product.
WARNING:
To reduce the risk of burns,
electrocution, fire, or injury to
persons:
• If product is opened/disassembled for ANY reason
warranty is VOID.
• Do not use this product if it has a damaged cord
or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into any liquid.
Contact Water Pik, International, Inc. UK Service
Centre on [phone].
• Do not direct water from the Water Flosser under
the tongue, into the ear, nose or other delicate
areas. This product is capable of producing
pressures that may cause serious damage in
these areas.
• Use this product only as indicated in these
instructions or as recommended by your dental
professional.
• Only use tips and accessories recommended by
Water Pik, Inc.
• Do not drop or insert any foreign object into any
opening or hose.
ON
OFF
•
8
•
6
•
4
•
2
•

ENGLISH
3
• Keep electrical cord away from heated surfaces.
• Do not use Water Flosser or Toothbrush outdoors
or operate where aerosol (spray) products are
being used or where oxygen is being administered.
• Do not use iodine, or water insoluble concentrated
essential oils in the Water Flosser. Use of these can
reduce product performance and will shorten the
life of the product.
• Remove any oral jewelry prior to use of the Water
Flosser or Toothbrush.
• Do not use either the Water Flosser or Toothbrush
if you have an open wound on your tongue or in
your mouth.
• If your physician or cardiologist has advised you
to receive antibiotic premedication before dental
procedures, you should consult your dentist and/
or medical professional before using the Water
Flosser or Toothbrush or any other oral hygiene aid.
• This product complies with the safety standards for
electromagnetic devices. If you have a pacemaker
or other implanted device containing magnets or
electronics, contact your physician or the device
manufacturer prior to using the Toothbrush.
• If the Pik Pocket ® tip (not included in all models)
separates from the shaft for any reason, discard tip
and shaft and replace with new Pik Pocket ® tip.
• Do not use the Water Flosser for more than 5
minutes in each two-hour period.
• Do not attempt to open either component except
for battery disposal. See Battery Removal Section.
• Using toothpastes containing peroxide may
damage the plastic housing of this product.
• Using abrasive or chemical cleaners may damage
the plastic housing of this product.
• Closely instruct and supervise
children 6 years and above
and individuals with special
needs in the proper use of this
product.
• Children should be supervised
to ensure that they do not play
with the appliance.
• Fill Water Flosser reservoir
with warm water or other dental
professional recommended
solutions only.
• There are no consumer
serviceable parts in the
toothbrush handle or Water
Flosser unit. This appliance
does not require maintenance.
SAVE THESE INSTRUCTIONS.

4

ENGLISH
5
TABLE OF CONTENTS
Product Description 6
Getting Started With Your Water Flosser
8
Cleaning and Troubleshooting Your Waterpik® Water Flosser 10
Getting Started With Your Sonic Toothbrush 11
Getting Started With Your Oscillating Toothbrush 12
Care of Your Waterpik

Toothbrush 13
Disposal and Battery Removal
13
Limited Two Year Warranty 14

6
•
8
•
6
•
4
•
2
•
ON
OFF
PRODUCT DESCRIPTION
Water Flosser
1. Hinged Reservoir Lid
2. Reservoir
3. Hose
4. Water Flosser Pressure
Control Dial
5. Power Button
(Push to turn unit on/off)
6. Power Cord
7. Magnetic Handle Cradle
8. Tip
9. Tip Eject Switch
10. Water On/Off Switch
11. Toothbrush Charger post
12. Base
NOT ALL TIPS INCLUDED IN ALL MODELS
Water Flosser Tips
A. Orthodontic Tip*
- Braces
- General Use
B. Pik Pocket®Tip*
- Periodontal Pockets
- Furcations
C. Plaque Seeker®Tip*
- Implants
- Crowns
- Bridges
- Retainers
- General Use
D. Classic Jet Tip**
- General Use
E. Tongue Cleaner**
- Fresher Breath
AE B C D
2
1
3
4
5
7
6
8
9
10
12
11
*Replace Every 3 months
**Replace Every 6 months

ENGLISH
7
NOTE: BRUSH HEADS ARE
NOT INTERCHANGEABLE.
EACH UNIT ONLY CONTAINS
ONE TYPE OF TOOTHBRUSH.
Brush Heads
F. Triple Sonic Brush Head*
-Plaque Removal
-Whitening
G. Triple Clean (Oscillating)
Brush Head*
- Plaque Removal
G
Mode
Clean
Whiten
Massage
CHARGE
Mode
Charge
Low
High
Massage
F
Sonic/Oscillating Toothbrush
13. Sonic Brush Head
14. Oscillating Brush Head
15. Toothbrush Power Button
16. Toothbrush Mode Button
17. Toothbrush Mode Indicator Lights
18. Toothbrush Recharge Indicator
13
(F)
14
(G)
15
16
17
18
*Replace Every 3 months
Sonic Oscillating
Replacement tips/attachments may
be purchased directly from Waterpik
International, Inc. [phone]
or from your local Water Pik stockist.

8
ON ON
•
8
•
6
•
4
•
2
•
ON
OFF
4
•
2
•
ON
OFF
ON
OFF
•
8
ON
Fill
High
Low
Power
ON
Push
Power
ON
Water
ON
Water
ON
Insert Slide
to
Eject
Powering the Unit
Plug the cord into an electrical outlet. If the outlet is controlled by a wall
switch, be sure it is turned on.
Preparing the Reservoir
Lift the reservoir lid, remove the reservoir, and fill with lukewarm water.
Replace the reservoir over the base and press down firmly and close the lid.
Inserting and Removing Tips
Insert tip into the center of the Water Flosser handle, pressing down firmly
until tip clicks into place. The colored ring will be flush with the top of the
handle if the tip is correctly locked into place.
To remove tip from the handle, slide the tip eject button on the handle.
Caution: Do not use tip eject slide while unit is running.
Prime Unit (First Time Use Only)
Set pressure control dial on base to high (pressure setting No. 10), point
the handle and tip into sink. Turn unit ON and water ON until water flows
from the tip. Turn Power Off.
Adjusting the Pressure Setting
Turn the pressure control dial on the base of the unit to the lowest setting
(pressure setting No. 1) for first-time use. Gradually increase pressure over
time to the setting you prefer – or as instructed by your dental professional.
Using the Water Flosser
Always place the tip in your mouth before turning the water ON. With water
switch in OFF position, turn power on. Lean over sink and slightly close lips
enough to prevent splashing while still allowing water to flow from mouth
into the sink. Turn water switch ON. When finished, turn water switch and
power OFF. During use you can stop the flow of water by sliding the water
switch on handle to the OFF position.
NOTE: Motor will continue to run.
Recommended Technique
For best results, start with the back teeth and work toward the front teeth.
Glide tip along gumline and pause briefly between teeth. Continue until you
have cleaned the inside and outside of both the upper and lower teeth.
GETTING STARTED WITH YOUR WATER FLOSSER

9
ENGLISH
When Finished
Turn the unit OFF. Empty any liquid left in the reservoir. Unplug the unit.
NOTE: If you used mouthwash or other solution besides water, see “Using
Mouthwash and Other Solutions” section.
NOTE: NOT ALL TIPS INCLUDED WITH ALL MODELS.
TIP USAGE
Plaque Seeker® Tip
To use the Plaque Seeker®tip, place the tip close to the teeth so that the
bristles are gently touching the teeth. Gently glide tip along gumline,
pausing briefly between teeth to gently brush and allow the water to flow
between the teeth.
Orthodontic Tip
To use the orthodontic tip, gently glide tip along gumline, pausing briefly to
lightly brush area between teeth and all around orthodontic bracket, before
proceeding to the next tooth.
Pik Pocket® Tip
The Pik Pocket®tip is specifically designed to deliver water or anti-bacterial
solutions deep into periodontal pockets.
To use the Pik Pocket®tip, set the unit to the lowest pressure setting.
Place the soft tip against a tooth at a 45-degree angle and gently place the
tip under the gumline, into the pocket.
Tongue Cleaner Tip
Set to lowest pressure setting, place tip in the center/middle of your tongue
about half way back. Pull forward with light pressure. Increase pressure as
you prefer.

10
•
8
ON
Using Mouthwash and Other Solutions
Your Waterpik
®
Water Flosser can be used to deliver mouthwash and
antibacterial solutions. After using any special solution, rinse unit to prevent
clogging by partially filling reservoir with warm water and running unit with
tip pointed into sink until unit is empty.
Cleaning
Before cleaning, unplug from the electrical outlet. Clean the product
when necessary by using a soft cloth and mild non-abrasive cleanser.
The water reservoir is removable for easy cleaning and is top rack
dishwasher safe.
General Cleaning/Removing Hard Water Deposits
Hard water deposits may build up in your unit, depending on the mineral
content of your water. If left unattended, it can hinder performance. Cleaning
internal parts: add 2 tablespoons of white vinegar to a full reservoir of warm
water. Point the handle and tip into sink. Turn unit ON and run until reservoir
is empty. Rinse by repeating with a full reservoir of clean warm water.
This process should be done every 1 to 3 months to ensure optimal
performance.
Leakage
If leaking due to a damaged hose, replacement hoses and handles can be
purchased at waterpik.co.uk or contact Water Pik Inc. customer service for a
self service repair kit.
CLEANING AND TROUBLESHOOTING YOUR WATERPIKWATER FLOSSER

11
ENGLISH
Mode
Clean
Whiten
Massage
CHARGE
Mode
Clean
Whiten
Massage
CHARGE
Mode
Clean
Whiten
Massage
CHARGE
30 sec.
30 sec.
30 sec.
30 sec.
Charging the Sonic Toothbrush
Charge for 24 hours before rst use. All 3 charge indicator lights will
stay on continuously when the unit is fully charged. A full charge will last for
approximately 1 week of typical use (2 minutes of brushing twice a day).
If the toothbrush is to be stored for an extended period of time (six months or
more), be sure to fully charge it prior to storage.
Recharge Indicator Lights
Charge indicator lights will indicate level of battery charge for approximately 10
seconds after use and after removal from the charging base, and will then turn off.
Fully Charged
2/3 Charged
1/3 Charge Life (Recharging is Recommended)
Unit will not operate if the bottom LED begins to blink rapidly.
In order for the toothbrush to begin to work again, it must be placed on the
charger for approximately 1 hour.
Modes
Clean: Standard mode for superior teeth cleaning.
Whiten: Teeth cleaning with polishing and whitening.
Massage: Pulsates for gentle gum stimulation.
Sonic brushing
• Slide the brush head onto handle and push it down firmly.
• Select mode by pressing mode button until light is by desired mode then
press power button.
• Place the brush head into your mouth before turning the unit on.
• For best results, position brush along gumline at a 45-degree angle.
• Use light pressure with a small, slow back and forth motion covering one or
two teeth at a time.
• Quad Timer: The Toothbrush will create a short pause every 30 seconds,
to remind you to move to the next quadrant of your mouth.
• 2-Minute Timer: The brush will automatically shut off after 2 minutes
of run time.
GETTING STARTED WITH YOUR SONIC TOOTHBRUSH
Mode
Clean
Whiten
Massage
CHARGE
FULLY
CHARGED
2/3
CHARGED
1/3
CHARGED
CHARGE

12
Mode
Charge
Low
High
Massage
CHARGE
MASSAGE
LOW
MASSAGE
CHARGE
Mode
Clean
Whiten
Massage
CHARGE
Mode
Charge
Low
High
Massage
Mode
Charge
Low
High
Massage
30 sec.
30 sec.
30 sec.
30 sec.
Charging the Oscillating Toothbrush
Charge for 24 hours before rst use. When the toothbrush is fully charged,
the charge indicator will be green while sitting on the base. A full charge will last
for approximately 1 week of typical use (2 minutes of brushing twice a day).
If the toothbrush is to be stored for an extended period of time (six months or
more), be sure to fully charge it prior to storage.
Recharge Indicator Lights
Charge indicator lights will indicate level of battery charge for approximately 10
seconds after use and after removal from the charging base, and will then turn off.
Fully Charged – CHARGE light is green
2/3 Charged –Both MASSAGE and LOW lights are flashing green.
1/3 Charge life – MASSAGE light is green. Recharging is recommended.
NOTE: If the charger light blinks red and green when off the charger base, the
unit has a low battery level and may not operate.
In order for the toothbrush to begin to work again, it must be placed on the
charger for approximately 1 hour.
Modes
High: Everyday cleaning performance
Low: Gentle movements for effective cleaning of sensitive teeth
Massage: Micro-pulse pattern for enhanced gum stimulation
Brushing
• Slide the brush head onto handle and push it down firmly.
• Select mode by pressing mode button until light is by desired mode then
press power button.
• Place the brush head into your mouth before turning the unit on.
• Use light pressure with a small, slow back and forth motion covering
one or two teeth at a time.
• Quad Timer: The Toothbrush will create a short pause every 30 seconds, to
remind you to move to the next quadrant of your mouth.
• 2-Minute Timer: The brush will automatically shut off after 2 minutes
of run time.
GETTING STARTED WITH YOUR OSCILLATING TOOTHBRUSH

13
ENGLISH
GETTING STARTED WITH YOUR OSCILLATING TOOTHBRUSH
Mode
Clean
Whiten
Massage
CHARGE
2.
Cleaning
1. After each use, turn off unit, remove the brush head from the handle
and rinse brush head under running water.
2. Wipe the handle dry after each use.
Disposal
This product contains rechargeable Nickel Metal Hydride batteries. The
batteries are not replaceable.
Please do not dispose of the unit in the household waste. Remove the
batteries per the instructions below and recycle at your local recycling
center.
Battery Removal
Note: This process is not reversible
Remove the battery only at the end of the product’s life for recycling. Doing
so earlier will destroy the product. Deplete the battery charge until the
brush no longer operates. Observe basic safety precautions.
Remove the batteries as shown and recycle them and the rest of the product
according to local regulations.
1. Use a screwdriver to remove the screw and battery door.
2. Hold the handle upside down, press the toothbrush shaft, and release
the two tabs inside the handle using a flathead screwdriver to release
the internal components of the handle.
3. Insert screwdriver next to the battery connections, and push out of
plastic covering. Twist and break the battery connections. Remove the
circuit board and pry the battery from the circuit carrier.
4. Recycle or dispose of the battery properly.
CARE OF YOUR WATERPIK

TOOTHBRUSH /
DISPOSAL AND BATTERY REMOVAL
1.
1.
2.
3.

14
LIMITED TWO YEAR WARRANTY
Service Maintenance
Waterpik®Water Flossers have no consumer-serviceable electrical items
and do not require routine service maintenance. For all your service needs
please call the Waterpik International, Inc. UK Customer Service Centre
at [phone]. Some replacement parts and accessories for
the Water Flosser are also available at www.waterpik.co.uk. For questions
or problems please call the customer service centre before returning the
product. Please do not send your unit to the Waterpik International, Inc.
address as this can cause lengthy delays. Refer to the serial and model
numbers in all correspondence. These numbers are on the bottom of the
unit behind the reservoir.
Water Pik, Inc. warrants to the original consumer of this product that it is free
from defects in materials and workmanship for 2 years from the date of purchase.
Consumer will be required to submit the original purchase receipt
as proof of purchase date and if requested, the entire product, to
support a warranty claim. Water Pik, Inc. will replace at its discretion any
part of the product, which in its opinion is defective, provided the product has not
been abused, misused, altered or damaged after purchase, was used according to
instructions, and was used only with accessories or consumable parts approved
by Water Pik, Inc. This limited warranty excludes accessories or consumable
parts such as tips and brush heads. Use with improper voltage will damage
product and VOID warranty.
This warranty gives you specific legal rights. You may also have other rights that
vary, depending on the law in your place of residence.

FN 20024640-F AA
©2018 Water Pik, Inc.
Waterpik®is a trademark of Water Pik, Inc. registered in Argentina, Australia, Benelux, Brazil, Canada, Chile, China, Czech Republic,
Denmark, EU, Finland, France, Germany, Hong Kong, Hungary, India, Israel, Italy, Japan, Kazakhstan, Korea, Malaysia, Mexico,
New Zealand, Norway, Pakistan, Philippines, Poland, Russian Federation, Saudi Arabia, Singapore, South Africa, Spain, Sweden,
Switzerland, Taiwan, Turkey, Ukraine, United Kingdom, United States and Vietnam.
Waterpik®(stylised) is a trademark of Water Pik, Inc. registered in Australia, Brazil, Canada, China, EU, Hong Kong, India, Israel, Japan,
Korea, Malaysia, Mexico, Philippines, Russian Federation, Saudi Arabia, South Africa, Switzerland, Taiwan, Thailand, Trinidad &
Tobago, Ukraine, United States, and Vietnam.
Waterflosser®(stylised) is a trademark of Water Pik, Inc. registered in Brazil, Canada, China, Mexico, Switzerland and the United States.
Pik Pocket®is a trademark of Water Pik, Inc. registered in Canada and the United States.
Plaque Seeker®is a trademark of Water Pik, Inc. registered in Canada, China, EU, and the United States.
Made in China.
Water Pik, Inc.
1730 East Prospect Road
Fort Collins, CO 80553-0001 USA
844-821-4873
www.waterpik.com
Waterpik, International, Inc.
Castle Court, 41 London Road
Reigate, Surrey RH2 9RJ
United Kingdom
www.waterpik.co.uk
Waterpik, International, Inc.
UK Customer Service Centre
[phone]
