Waterstone Hampton Series User manual

41180 Raintree Court
Murrieta, CA 92562
1-888-304-0660
www.waterstoneco.com
MADE IN THE USA
INSTALLATION INSTRUCTIONS
ITEM NO:
4300
Hampton Series Kitchen Faucets
BEFORE YOU BEGIN YOUR INSTALLATION:
1. Make sure your water supply is turned o
2. Observe all local plumbing codes
3. Inspect waste and water supplies for any signs of damage and replace as necessary
4. Do not use petroleum based products on this faucet.
RECOMMENDED TOOLS AND MATERIALS
1. Phillips Screwdriver
2. Adjustable Wrench
FAUCET INSTALLATION (see diagram)
1. Remove the clamp nut (A) and washer (B) from the threaded shroud (C) under the faucet and t the faucet exible
hoses and rigid sidespray tube through the hole on the counter or sink. (No plumbers putty is required in that the
faucet has an O-ring seal built into its base).
2. Slide the washer and thread the clamp nut onto the threaded shroud. Make sure clamp screws are screwed back and
thread the nut snug to the underside of the sink or counter.
3. Make sure the faucet is in the correct position you want it for your sink and securely tighten the clamp screws.
CONNECTING SUPPLY HOSES
1. Carefully position the hot and cold supplies so they will not interfere with other hoses
2. Connect the supply hoses to the supply stops
Note – the most common faucet installation is with the handle positioned to the right. Pull the handle for hot water or
push the handle for cold water. If the handle is centered, push it to the right for cold and to the left for hot water
If the handle is installed to the left, reverse the supply hoses (connect the hose for cold water to the hot supply and the
hose for hot water to the cold supply).This will maintain the relationship of pulling the handle for hot water or pushing
for cold water.

41180 Raintree Court
Murrieta, CA 92562
1-888-304-0660
www.waterstoneco.com
MADE IN THE USA
INSTALLATION INSTRUCTIONS
ITEM NO:
4300
Hampton Series Kitchen Faucets
CONNECTING OPTIONAL SIDE SPRAY
1. Mount side spray base in the side spray hole on your sink or counter.
2. Tighten guide nut.
3. Fit sidespray hose through the side spray guide
4. Remove the sidespray hose cap on the end of the sidespray hose tube on the faucet.
5. Connect and tighten the end of the sidespray hose to the sidespray hose tube underneath the faucet.
