WATSON C9 Height Adjustable Desk User manual

ASSEMBLY
C9 Power Pole
V.2.00 09/2019
TM
watsonfurniture.com360.394.1300

2 C9 POWER POLE ASSEMBLY INSTRUCTIONS
C9 Power Pole Basic Components
Tools
3mm Hex Key
Ceiling Bar
Ceiling Bar Clamp
Power Pole
Cover
Hardware
M6-1.0x12mm Low
Profile Cap Screw
(0001140)
M4-0.7x8mm Button
Head Cap Screw
(0001246)
M4-0.7x10mm
Socket Head Cap
Screw (0001246)
Philips Screwdriver

3 C9 POWER POLE ASSEMBLY INSTRUCTIONS
Attach Power Pole to End Leg
Attach the power pole to the end of the rail run, in place of the
end cap, using (4) screws (0001246).
Attach Clamp to Ceiling Bar
Fit the ceiling bar clamp into the slots at the end of the ceiling
bar, and rotate into place, as shown below.
1.
2.
M4-0.7x8mm Button
Head Cap Screw
(0001246)

4 C9 POWER POLE ASSEMBLY INSTRUCTIONS
Mount Ceiling Bar to Ceiling
Hook the celiling bar on the 2’ celiling grid and screw the clamp to the ceiling bars with one screw
(0001140) on each side. Note: ensure that celiling system has required weight capacity.
M6-1.0x12mm Low
Profile Cap Screw
(0001140)
3.
Connect Power Pole to Ceiling
Hook the power pole onto the ceiling bar, and align the pole with the bracket at the desired position. Screw the
pole to the ceiling bar using (4) screws (0001140).
4.

5 C9 POWER POLE ASSEMBLY INSTRUCTIONS
Run Cables Down Pole
Run the cables down from the roof through the pole,
then through the opening of the rail end. Wire as
normal.
5.

6 C9 POWER POLE ASSEMBLY INSTRUCTIONS
Mount Cover
Place cover around the power pole and secure with
four screws, two screws per side.
6.
M4-0.7x8mm Button
Head Cap Screw
(0001246)
