Wavecom TnP 3PLM 20A User manual

Wavecom
User Manual
+ Certificate of Warranty and Product Support Information
TnP 3PLM 20A/32A/50A
3 Phase Portable Appliance Test and Print Kit

WavecomCertificate
of Warranty
Your Wavecom Appliance Tester comes with a
conditional 24 month warranty.
Your warranty applies for 12 months from the date of purchase, and will
be extended an additional 12 months if your Tester is calibrated within 12
months of the date of purchase (see rear cover of this manual).
The Manufacturer (Wavecom Instruments Pty. Ltd.) warrants its products against defects in materials and
workmanship for a period of 12 months from the date of purchase. During the warranty period, the Manufacturer
will repair (or at its option replace at no charge) the product that proves to be defective. This warranty does not
apply if the product has been damaged by accident, abuse, misuse or mis-application or as a result of service
or modification by anyone other than the Manufacturer of this tester.
The TnT & TnP Product Range of devices or its Manufacturer is not responsible for incidental or consequential
damages resulting from the breach of any express or implied warranty, including damage to property and to the
extent permitted by law, damages for personal injury. The distributors of this product cannot assume liability
or responsibility for any loss of damage resulting from the use of this device.
The Manufacturer reserves the right to discontinue models, change specifications, price or designs at any time
without notice or obligation.

Product Support
Safety Information
Important Calibration Information
At Wavecom we take great pride in our customer service and support. We provide assistance,
troubleshooting and support over the phone, via Skype or Facetime, via email or in person to help
you get the most from your Wavecom Portable Appliance Tester. To be eligible for our support
services you must register your product.
You can register via the WinPATS App (this is done automatically during the setup process), or
online at:
https://www.wavecom.com.au/wcm_product_registration.php
The TnP 3PLM has been designed to meet stringent safety requirements, however no device can
completely protect you from the consequences of incorrect use. The testing of electrical appliances
requires that extra care and caution is taken at all times to ensure personal safety.
The Manufacturer also advises that appliance testing should be conducted by a Competent Person
who is suitably trained (see P.5 AS/NZ 3760:2010 for the definition of Competent Person), as well as
any additional legislation or rulings in different states. If in doubt, the manufacturer suggests the
user contact their responsible authority.
For maximum safety, always ensure that the following advice is followed:
• The equipment being tested is in good condition and passes a visual check.
• All instructions are read, understood and followed.
• The power supply connections are always checked - if the N-E (middle) LED Indicator flashes
red, do not proceed before consulting the manual.
• Always use specified fuses and protection devices.
• Do not use leads that require repair or are damaged.
• If you are unsure, call a licensed Engineer/Electrician.
Your Wavecom Appliance Tester should be calibrated every 12 months. A correctly calibrated
tester is essential for ensuring testing accuracy is maintained, and for complying with the AS/NZS
3760:2010.
To book your tester in for calibration, go to:
https://www.wavecom.com.au/calibration_services.php
Then, send your tester to your nearest calibration service centre:
For Western Australian customers:
Wavecom WA Calibrations
Unit 2/17 Casino Street,
Welshpool, WA 6016
For all other customers:
Wavecom Calibrations
257 Grange Road,
Findon, SA 5023

4
TnP 3PLM User Manual Wavecom
Important Information 5
Contents 5
TnP 3PLM Diagrams 5
Precautions 6
Operating the TnP 3PLM 10
Powering on the Tester 10
Using the TnP 3PLM with WinPATS 10
Setting up the Barcode Scanner 16
LED Indicators 17
TnP 3PLM Menu System 18
TnP 3PLM Testing Menu – Main Menu A 19
TnP 3PLM Testing Menu – Main Menu B 20
TnP 3PLM Testing Menu – Main Menu C 26
Meter Mode ® [Not available in Battery Mode] 28
Specifications 30
Technical Information 31
Visual Inspection 31
Class 1 (Earthed Appliance) Construction 31
Class 2 (Double Insulated) Construction 32
Testing of Electrical Equipment 32
Leakage Test 33
Earth Continuity Test 33
3 Phase Testing 33
Integrated Tests 33
No Connection No Test 34
Wavecom Thermal Transfer Printer 35
Loading the printing ribbon 36
Loading the media 38
LED and Button Functions 39
Power on Utilities 39
Gap/Black Mark Sensor Calibration 40
Dump mode 41
Printer Initialization 41
Set Black Mark Sensor as Media Sensor and Calibrate the Black Mark Sensor 42
Set Gap Sensor as Media Sensor and Calibrate the Gap Sensor 42
Troubleshooting 42
Maintenance 44
Other Information 45
Wavecom Tags 46
Tester Serial, WinPATS Coupon Code & Purchase Information Rear Cover

5
TnP 3PLM User Manual Wavecom
Important Information
Contents
TnP 3PLM Diagrams
Case Diagram
Rear Panel of Tester Diagram
• TnP 3PLM Integrated Appliance Tester
• 8 inch 4G-Ready Android tablet with mount
accessories
• Tablet Charging Cable
• Right Angle Micro USB Data Charging Cable
• USB-OTG Adapter
• Advanced Bluetooth Laser Barcode Scanner
• Wavecom Thermal Transfer Printer
• WinPATS voucher (valued at $30+GST) for App
Purchase through Google Playstore
• Shockproof Industrial Case
• 1 Roll (500) of White Labels
• 1 Roll of Printing Ribbon
• IEC Test Lead (500mm Orange)
• USB A to USB B Interface Cable
• Earth Lead with Alligator Clips (1800mm Black)
• IEC Power Cable (10A units)
• IEC 20/10 Power Cable with Circuit Breaker (20A
Units)
• 12 Month Calibration Certificate
• 24 Month Conditional Warranty
• User Manual & Quickstart Guide
Thermal Transfer Printer
Circuit Breaker
TnP Appliance Tester
3 Phase Test Socket
Power Button
Single Phase OR 3
Phase Power Input
Power Button

6
TnP 3PLM User Manual Wavecom
Tester Diagram
Precautions
Competent Person
To ensure that all electrical equipment or devices are inspected, tested and tagged correctly, regulations
require that a ‘competent person’ such as a Licensed Electrician be employed to perform the required tests.
Please refer to the above definition as described in the current AS/NZ-3760:2010 Standard and in addition, to
any other local legislation or jurisdictions as may be relevant in your State.
A person competent to undertake Inspection and Testing of electrical equipment must have:
• Knowledge and practical experience of electricity and its hazards.
• A clear understanding of precautions to avoid danger.
• The ability to recognise at all times whether or not it is safe for work to continue.
• The ability to carry out visual examinations of electrical equipment.
• The ability to distinguish between electrical equipment that is double insulated and equipment that is
earthed as well as being able to identify the appropriate test for each type.
• The competency to safely carry out the Earthing Continuity, Insulation Resistance or Leakage Test and RCD
Tablet Dock
Function Buttons
Indicator LEDs
Appliance Test Socket
Enter/Power Button
Power Button
Battery Indicator
IEC Test Socket
LCD Screen
Bluetooth LED

7
TnP 3PLM User Manual Wavecom
tests on electrical equipment.
• The knowledge of how to use the relevant testing instruments, interpret and record the results for
compliance with the Standard/Workplace requirements.
• The knowledge to be able to correctly recommend the frequency of testing required.
Due to the potential hazards of electrical testing, due care must be taken at all times.
Using the Tablet
The TnP 3PLM comes with an Android tablet to be used with the WinPATS App to control your tester, save your
test results and generate reports. In the next section you will find a short introduction to using the TnP 3PLM
with your tablet, and more detailed, step by step guides are available on our website - www.wavecom.com.au
The tablet provided is intended for use with WinPATS only - using additional apps (other than those already
installed) may interfere with the functions of WinPATS and may slow down the app significantly. We strongly
recommend that you do not install other apps on this tablet, to ensure the stable operation of the WinPATS
App.
Before using your tablet with WinPATS, you must set it up as per the manufacturers instructions, and connect it
to the internet (via 4G or wifi). We also recommend that the tablet is fully charged before the first use.
Your tablet warranty is covered by the manufacturer (Telstra). While Wavecom are happy to provide support to
help you use your tablet for WinPATS, any issues that arise from the tablet (and not the WinPATS App) will need
to be resolved with the manufacturer.
With your TnP 3PLM you will have two tablet docking accessories. These are to be attached to your tablet so
you can secure your tablet to your TnP 3PLM.
To attach the docking accessories, we recommend docking them to the TnP 3PLM as shown below.
Then, peel off the backing plastic to expose the adhesive and place your tablet onto the docking accessories.
Take care to ensure that your tablet’s camera and charging port are not blocked by the docking accessories.

8
TnP 3PLM User Manual Wavecom
Using the Lithium Ion Battery
Using the TnP 3PLM on Mains Power
To use the TnP 3PLM on mains power, simply plug in the supplied power cable and connect it to a mains power
outlet. Your TnP 3PLM will automatically connect to mains power and begin charging the battery.
Using the TnP 3PLM on Battery Power
When unit is not connected to mains, simply press and hold the power button at the rear of the tester till unit
you hear a beep and the LCD screen turns on. Use the same button to turn off the unit when in battery mode.
Mains Supply tests, Leakage tests and Meter Mode functions are not available on battery power. To perform
RCD Tests, the TnP 3PLM is required to be connected to mains power.
Important: Ensure that the battery isolation switch is ON while operating the unit & performing tests. The
isolation switch is located inside the storage compartment
To Charge the Battery
Internal lithium-ion battery (98Wh, 6700mAh) can power the TnP 3PLM for around 3000 sets of tests. The
battery is charged simply by plugging the TnP 3PLM into mains power, and it takes around four hours to fully
charge.
Note: Turning off the red Isolation Switch (located inside the storage compartment) isolates the battery completely and
prevents the battery from charging.
While the TnP 3PLM is charging and not in use, the display can be turned off by pressing and holding the ENTER
button until you hear a beep and the LCD screen backlight turns off. You will then see charging information
displayed on the screen. Once the battery is fully charged and it is still connected to mains, battery symbol will
convert to plug symbol. It is advised not to put unit to charge when it is unattended or overnight.
Transporting Lithium Ion Battery Products
It has come to the attention of Wavecom Instruments Pty Ltd, that products containing batteries are being
shipped by customers through air freight. It is our understanding that, for the purpose of air transport,
lithium ion batteries are considered dangerous goods under the International Air Transport Authority (IATA)
regulations. It is the responsibility of the shipper to ensure that the product being shipped and the packaging
used comply with all regulations, noting that extensive penalties can be imposed by the relevant authorities
for any breach.
The IATA and other laws and regulations covering the transport of goods are very comprehensive, and Wavecom
Instruments makes no warranty that these regulations will permit particular shipments of its products by air
freight. Lithium ion batteries are not allowed to be transported by air. Products that contain internal batteries
are allowed, as long as the batteries are not damaged.
Should you require further information on the relevant regulations and requirements, please contact your
dangerous goods adviser and/or review the IATA website:
www.iata.org/publications/dgr/Pages/index.aspx

9
TnP 3PLM User Manual Wavecom
This letter is not intended to constitute legal advice, and you should obtain your own professional advice.
Please contact Wavecom Instruments Pty Ltd for more information.
Warnings
Operating Environment: Charging – 0° to ~45°C; Discharging -20°to ~ 60°C.
Please ensure the unit is stored in compliance with the operating environment requirements and in a safe and
secure location.
When sending the TnP 3PLM for calibration, please turn off the battery isolation switch which is located in
the storage compartment of the tester. If you have any questions about the battery of your TnP 3PLM please
contact Wavecom for further advice.
Thermal Circuit Breaker
The TnP 3PLM uses a 16A rated thermal circuit breaker which will trip after 30 minutes of continual 20A testing.
To avoid tripping the circuit breaker avoid running >16A tests for extended periods of time. If the circuit breaker
trips, wait a short time for the breaker to cool down, then simply flip the breaker back into the on position.

10
TnP 3PLM User Manual Wavecom
Operating your TnP 3PLM
Powering on the Tester
To use your TnP 3PLM, ensure the red isolation switch (located in the storage compartment) is switched ON.
We recommend that the TnP 3PLM is fully charged before the first use.
Your TnP 3PLM will be powered on automatically when you connect it to mains power. To power on your TnP
3PLM in battery mode, press and hold the rear power button until the unit beeps and the LCD screen turns on.
Initially the printer’s status light will be orange but after about 5-10 seconds it will change to green. The tester
will not print unless the printer light is solid green. A flashing red status light can indicate a media or general
printer fault (see ‘Wavecom Thermal Transfer Printer’ for more information).
Using your TnP 3PLM with the new WinPATS App
Setting up the new WinPATS App is simple, but can take some time. We recommend setting up WinPATS before
you need to use it on site. You will need to download “WinPATS Pro” from the Google Play Store onto your
Android tablet. On our website, you can find a set of videos that will guide you through the various functions
and features of the new WinPATS App. This guide will walk through setting up WinPATS and connecting to your
tester.
Once you have downloaded the WinPATS App, open it and create up a 4 digit pin code. This will help keep your
data secure.
Next, it’s time to set up your Company Account. If your employer or organisation has an account already, you
can log in straight away using the details provided to you. Otherwise, tap Register Company to set up your
Company Account - you will be prompted to enable WinPATS’ permissions - this allows you to use the full set of
WinPATS features.
Now, fill in your details - a valid ABN is required to register a new company. You should use the address and
contact details of your head office. Once your details are entered, check they are correct, then tap Register.
You will be sent a One Time Password to the email you entered in the previous step. This is used to verify your
email address - enter the OTP to continue. This OTP is only valid for 10 minutes - if your OTP expires, simply go
back and then tap ‘Register’ again. If you don’t see your OTP email, check your spam folder.
Now you can pay for your WinPATS License - you should have a coupon code on the rear of this booklet which
provides you with one free license for the WinPATS App. Your coupon code is linked to your tester, and you will
need to connect your Android tablet to your TnP 3PLM to authenticate your code. Using the USB-OTG cable
supplied with your tester, connect your tablet to your tester in the following chain: Tablet > USB-OTG > USB-A to
USB B Cable > USB B port of your TnP 3PLM (located inside the storage compartment). See diagram on page 11.
Then, enter your coupon code and tap APPLY. You should see the Total Amount number drop to zero. Tap PAY to
proceed.
Once you have entered your code or paid, you can now Log In and set up your password. Enter the Company ID
and temporary Password which was emailed to you, which will enable you to log in for the first time. You will
now be prompted to set up a new password.

11
TnP 3PLM User Manual Wavecom
You can now set up your User Account - this is your individual profile. If you are the first or the only Test and
Tag technician at your organisation, you should set yourself as an ‘ADMIN’ user, which will allow you to use the
full features of WinPATS. Technician users have reduced access to features - this is designed for organisations
with multiple technicians and/or multiple sites.
Once your details are complete, tap ADD to create your account. Confirm your details are correct, then tap
CONFIRM to finish registering your user account.
When you start WinPATS for the first time you’ll be required to perform a data sync. This creates a new cloud
database for you, or connects your WinPATS App to your company’s existing database. If your database has
many items, this may take up to 5 minutes, but usually only takes a few seconds.
Connecting via Bluetooth
To control your TnP 3PLM via Bluetooth, you will need to perform a short setup procedure. Ensure you have
both your tablet with WinPATS installed, and your TnP 3PLM in front of you.
Go to the Bluetooth settings in your Tablet’s settings menu
Ensure that Bluetooth is enabled, then select your TnP 3PLM from the list of available devices (ensure you
select the correct tester by referring to the serial number. Your TnP 3PLM’s serial number is located on the side
of your tester, and on the rear cover of this booklet).
You may now be prompted to pair your two devices using a PIN code. If so, your TnP 3PLM will display a code on
the screen. Enter this code into WinPATS and tap OK. You will be asked to confirm the connection - tap Confirm
after checking the details are correct.
Note: If you have any issues with the PIN code, you can disable this function from the TnP 3PLM settings menu. Power on
your TnP 3PLM, then hold Enter and press F2 to open the settings menu. Navigate to ‘Bluetooth Configuration’ and press
Enter. When prompted with ‘Use Security PIN for Bluetooth’ select ‘Disable’ by pressing F3.
Go to the WinPATS App
To connect your TnP 3PLM, go to the Test menu in the WinPATS App (at the top of the screen). You should be
prompted to connect a Wavecom Appliance Tester as soon as you open the Test Menu for the first time. Tap
‘BLUETOOTH’ to begin the Bluetooth setup process.

12
TnP 3PLM User Manual Wavecom
WinPATS will scan for any available TnT or TnP testers and display them in a list - select your tester from the
list by tapping it. If you see multiple TnT or TnP products in the list, use the serial number of your TnP 3PLM to
identify your tester.
You will now be asked to register your TnP 3PLM - this allows you to receive product support, service and
calibration reminders from Wavecom. Once complete, tap Register. You’re now ready to start testing with
WinPATS!
Connecting via USB
You can also connect to your TnP 3PLM via USB if needed. Follow the following diagrams to connect your TnP
3PLM to your tablet or PC, with or without your printer. Please note that you need to connect your printer in
addition to your TnP 3PLM as shown.
Connecting your TnP 3PLM to your Tablet via USB
To connect your TnP 3PLM to your tablet via USB, you will need:
• A USB-A to USB-B cable (1 Included)
(2 Cables are required if connecting your TnP 3PLM and your Printer)
• A USB Hub or USB Splitter cable
• A USB-OTG Cable (Included)
Connect your cables in the sequence shown below. Your TnP 3PLM USB-B port is located inside the storage
compartment, and the Printer USB-B port is located at the rear of the printer. Once connected, open WinPATS
on your tablet. You should see the Test icon and the Print icon (if you connect the printer) at the top of the
screen change to green.
Connecting your TnP 3PLM to your PC via USB
To connect your TnP 3PLM to your PC via USB, you will need:
• A USB-A to USB-B cable (1 Included)
(2 Cables are required if connecting your TnP 3PLM and your Printer)
• A USB Hub or USB Splitter cable

13
TnP 3PLM User Manual Wavecom
Connect your cables in the sequence shown below. Your TnP 3PLM USB-B port is located inside the storage
compartment, and the Printer USB-B port is located at the rear of the printer.
Adding a User
Note: You will have already created a WinPATS User during the setup process. Follow this process to add another user, or
to edit the details of your users. This feature requires Admin access, Technician level users will need to enter the Company
Password to access this feature.
Important: To avoid duplication of data a User must only be logged in and active on one tablet at a time.
To add a new User to WinPATs, open the Side Menu, then tap the User Profile Picture at the top of the menu. If required,
enter the Company Password. You can now view the Users at your company using the dropdown menu, then edit,
suspend (lock the user but keep the profile) or delete the user.
To add a new User, tap the ‘+’ symbol next to the dropdown menu. Fill out the form, including selecting a profile picture
and assigning Admin permissions (if required), then tap ‘Add’ when complete. You can now select this user from the
dropdown menu.
When changing users, select your user from the menu, then tap ‘Confirm’ to switch to that user.
Adding a Customer
Note: You can also add a new customer during the ‘Adding an Item’ process if needed.
To add a new Customer to WinPATS, open the Side Menu, then tap ‘Database+’, then tap ‘Customers’. You can
view your existing customers in the list, and add a Site, edit their details and delete the customer by tapping a
customer in the list.
Tap ‘Add Customer’ to open the new Customer form. Fill out the form - please note, a valid ABN is required to
add a new customer. When complete, tap ‘Add Customer’. You will now be able to assign sites and items to this
customer.

14
TnP 3PLM User Manual Wavecom
Adding a Site
Note: You can also add a new site during the ‘Adding an Item’ process if needed.
To add a new Site to WinPATS, open the Side Menu, then tap ‘Database+’, then tap ‘Sites’. You can view your
existing sites (and filter by Customer) in the list, and edit or delete your sites by tapping a site in the list.
Tap ‘Add Site’ to open the new Site form. Fill out the form, and tap ‘Add Site’ when complete. You will now be
able to assign locations (places within a site) and items to this customer.
Entering a New Item
To add a new item to WinPATs, open the Side Menu, then tap ‘Database+’, then tap ‘Add Equipment’. Fill out the
form, including selecting the Customer and Site. Set the Current Status, Test Frequency and Test Sequence -
this allows WinPATS to tell your TnP 3PLM which test to run when you test this item.
If you wish to add multiple versions of your item (for instance, if your company has purchased 5 identical new
printers), you can change ‘Add Multiple Identical Equipment’ to ‘Yes’.
When you have added all the information to your item, tap ‘Add Equipment’. You can now test this item by
searching for it in your database.
Testing Items
Note: There are multiple ways an item can be tested using WinPATS. This part will cover the two most common methods.
Both of these methods require that your TnP 3PLM to be connected to your tablet (see above ‘Connecting via Bluetooth’).
Testing from the Test Menu
At the top of the WinPATS home screen you should see the ‘Test’ icon. Tap this to open the Test Menu. Here you
will see 6 options:
Quick Test This allows you to run a test first, then create an item or assign the results to an existing item after the test is complete
New Test This allows you to select an existing item from your database, or add a new item, then conduct tests on it. Using this method means you
can use the ‘Test Procedure’ assigned to the item to run the test, meaning you don’t need to manually select a test.
New to Service This is the same as ‘New Test’, but will categorise the item as ‘New to Service’
Out of Service This is the same as ‘New Test’, but will categorise the item as ‘Out of Service’
Visual Check
Only
This is the same as ‘New Test’, but will categorise the item as ‘Visual Check Only’
Data Logger This feature is still in production
Select the best option for your situation. If you select Quick Test, select the test you wish to conduct from the
list. Set up the item to be tested by plugging it into the TnP 3PLM (along with any accessories as required),
adjust any options (such as test voltage), then tap ‘Start Test’.

15
TnP 3PLM User Manual Wavecom
Conduct the Visual Test, and if the item passes, the test will be conducted in stages automatically, and the
results displayed on screen. If you wish to continue without saving, simply tap the ‘Home’ button. If you wish to
save these results, tap ‘Save Results’.
You will be taken to a screen where you can either search for an item in your database, or add an existing item.
Follow the relevant steps and your test results will be assigned to the item you select/create. If required, you
can print a tag at the end of this process. Otherwise you can now continue with your testing.
If you select New Test (or New to Service, Out of Service, or Visual Check Only), you will create or select the
item you wish to test first. Either search for an existing item in your database, or add a new item.
Once you have created/selected the item, review the Assigned Test Sequence and ensure the correct test will
be conducted. Set up the item to be tested by plugging it into the TnP 3PLM (along with any accessories as
required) then tap ‘Start Test’.
Conduct the Visual Test, and if the item passes, the test will be conducted in stages automatically, and the
results displayed on screen. Your results will be saved, and you can now print your tag (or save it to the Print
Queue to print later). You can now continue with your testing.
Testing from the Item Information Screen
You can also conduct tests from the Item Information Screen. If you: Search for an Item from the Asset Lookup
on the Home Screen, scan a barcode or find the item in your Inventory (Side Menu > Database+ > Inventory).
Once you are on the Item Information screen, review the Assigned Test Sequence and ensure the correct test
will be conducted.
Set up the item to be tested by plugging it into the TnP 3PLM (along with any accessories as required) then tap
‘Start Test’. Conduct the Visual Test, and if the item passes, the test will be conducted in stages automatically,
and the results displayed on screen. Your results will be saved, and you can now print your tag (or save it to
the Print Queue to print later). You can now continue with your testing.
Printing Tags
The WinPATS App can print tags to your TnP 3PLM printer via Bluetooth. You can print tags at the end of a test
as part of the testing process, or save tags to print later from the Print Menu.
To print a tag during the test process, carry out the test as described above. Once the test is complete, tap
‘Save Result’. After the result is saved, you will see the ‘Save Result’ button change to ‘Print Tag’. To print a tag
now, tap this button. To save a tag to print later, tap the arrow at the bottom of the screen (in the centre). This
will open a sub menu, including the option ‘Print Later’. Tap this to save the tag to print later from the Print
Menu.
To access to Print Menu, tap the ‘Print’ icon at the top of the Home Screen. You will see a list of tags that have
been saved to print later. To print a tag from the list, tap on it. You will see a number of options appear: Print
Tag, Print Mini and Delete. To print a standard tag, tap ‘Print Tag’. To print a small form tag, tap ‘Print Mini’. To
delete the item from the print menu, tap ‘Delete’.
You can also adjust print settings and more by tapping the ‘More’ symbol above the list of tags.

16
TnP 3PLM User Manual Wavecom
Editing Items
Items in your database can be edited from the Inventory screen. To open the Inventory screen, open the Side
Menu, tap ‘Database+’ then ‘Inventory’. Double tap (or press and hold) an item in the Inventory list to open the
Item Information screen.
You can then tap ‘Update Details’ to change any of the details of the items. You can then edit any of the fields,
and tap ‘Update Item’ when complete.
You can also edit multiple items at once - view the ‘Managing your Inventory with WinPATS’ video on the
Wavecom Youtube channel for more information.
Deleting Items
Items in your database can be deleted from the Inventory screen. To open the Inventory screen, open the Side
Menu, tap ‘Database+’ then ‘Inventory’. Double tap (or press and hold) an item in the Inventory list to open the
Item Information screen. Tap ‘Update Details’, then scroll to the bottom of the ‘Update Details’ screen and tap
the red Trash icon to delete that item.
Setting up the Barcode Scanner
To use the supplied Bluetooth 1662 BT scanner you will need your tablet and Bluetooth scanner in front of
you. Your Bluetooth scanner comes with a quick start guide which may be useful for troubleshooting, but you
can set up your scanner using the following instructions. We recommend that you ensure the scanner is fully
charged before using it on site.
First, ensure the battery is in installed in your barcode scanner. The LED on your scanner should begin flashing
blue, indicating it is ready to be paired to your tablet. Now, open the Bluetooth Settings menu of your tablet
and turn Bluetooth on (if it is not already on). Tap ‘Pair New Device’ to begin scanning for Bluetooth devices.
Your scanner should appear in the list - you can identify your scanner by the first 4 numbers “1662” followed
by the serial number (e.g 1662CFJ000123). The serial number of your scanner is located on the label of your
scanner box. Tap your scanner in the list to pair it with your tablet. If you see a prompt to enter a PIN code,
simply tap ‘Pair’ without entering anything - the PIN setting is disabled by default on the scanner and is not
required.
Your scanner should now be paired with your TnP 3PLM. To test your scanner, open the WinPATS App and return
to the Home screen. Scan one of the barcodes on the outside of the scanner box, and you should see the
barcode appear in the ‘Search Barcode’ field on screen.
Important: After pairing the barcode scanner, you may find that the on screen keyboard of your tablet no
longer appears when you tap a text field. To fix this, tap any text field (such as the ‘Search Barcode’ field on
the WinPATS home screen). You will see a keyboard icon appear in the bottom right corner of your screen. Tap
this icon, then turn ‘Show Virtual Keyboard’ on. Your tablet will remember this setting and will display the
keyboard from now on.
If you encounter any issues consult the quick start guide included with the scanner, or contact us for support.

17
TnP 3PLM User Manual Wavecom
LED Indicators
Battery LEDs
The battery LED indicators display how much charge is remaining in your TnP 3PLM. Use the table below for
reference.
100% - Battery is fully charged
80%
60%
40%
20% (LED 2 will be flashing)
0% (LED 1 will be flashing)
Indicator LEDs
The indicator LEDs are used to display various statuses and results. Use the table below for reference.
TnP 3PLM is running on battery power, no Bluetooth connection
TnP 3PLM is running on battery power, active Bluetooth connection
TnP 3PLM is running on mains power, and is charging, no Bluetooth connection
TnP 3PLM is running on mains power, and is charging, active Bluetooth connection
TnP 3PLM is fully charged, no Bluetooth connection
TnP 3PLM is fully charged, active Bluetooth connection
When an appliance fails a test, the Indicator LEDs will turn red while the test
results are on screen
When an appliance passes a test, the Indicator LEDs will turn green while the test
results are on screen

18
TnP 3PLM User Manual Wavecom
If there is a fault with the mains power connection, you may see one (or more) of the Indicator LEDs turn
red. This may indicate a serious issue with the mains power supply - consult a qualified professional before
proceeding. This won’t apply when using battery power.
Standard Mains Supply Test result with no issues.
N-E Fault - If the N-E light in on, DO NOT PROCEED. The N-E LED will turn red if there
is a voltage difference between the neutral and earth, or if no earth is connected.
If you are working from a generator or inverter this is likely to occur and you may
need to consult a qualified electrician before proceeding.
If the N-E LED is red, and A-N is green, there is a fault with the Mains Supply
You may also see more than one, or all of these turn red. For more information, see Mains Supply Test (Page 26)
TnP 3PLM Menu System
The menu system of the TnP 3PLM is divided into 3 pages. Menu A and B contain single phase tests, while Menu
C contains three phases tests. The TnP 3PLM has in internal contactor that switches between the single and
three phase sockets. When performing single phase tests only the single phase test socket will be used, and
when performing three phase tests only the three phase test socket will be used. If you have connected an
appliance to the wrong socket a ‘No Connection, No Test’ message will be displayed on screen.
Certain tests will only be available when the TnP 3PLM is connected to the correct power source. Use the table
below to ensure you have the correct power source for the test you need to conduct. If you don’t have the
correct power source a message will be displayed on screen.
Single Phase, 3 Wire All tests except Three Phase Leakage Tests
Three Phase, 4 Wire All tests except Single Phase Power Tests
Three Phase, 5 Wire All tests can be conducted

19
TnP 3PLM User Manual Wavecom
TnP 3PLM Testing Menu – Main Menu A
If you are using your TnP 3PLM with the WinPATS App, you do not need to operate the TnP 3PLM manually - all
functions can be controlled directly from the App.
Class 1 - Earthed Appliance Test - Menu A - F1
The Class 1 Test completes the following sequences as part of its procedure:
• Integrated Supply Mains Test - Refer to Integrated Test section
• Integrated NCNT Test - Refer to Integrated Test section
• Earth Bond Test (@ 200mA): 200mA test current, pass level less than 1Ω
• Insulation Test (@ 250V, 500V or 1000V): pass level greater than 1MΩ
Note: 250V insulation testing applies to Class 1 appliances if selected (refer to Technical Information for details to change
test voltage).
In some situations, if the DUT is labelled with “Surge Protection Fitted” or if it contains MOV’s (Metal Oxide
Varistors), conduct a 250V-insulation test. If unsure refer to the AS/NZS:3760 Standard. Should it still fail,
remove it from service. (Refer to the Technical Information section to change test voltage).
Note: Ensure that the device is isolated from any ground loop.
Procedure:
1. Complete a Visual Inspection.
2. Plug device into appliance test socket.
3. Plug the IEC Clamp Cable into the IEC socket of the TnP 3PLM
4. Connect earth clip to any exposed metal on the device. If this is not possible, you can use a metal mesh
braid to establish an earth connection (sold separately)
5. Navigate to Main Menu A, then Press the F1 key to begin the test
6. The test will be conducted
7. Once complete, read and record results appropriately
If the result was a PASS - Tag with PASS tag showing “next test due” date and return the device to service.
If the result was a FAIL - Tag the DUT with a DANGER tag and remove the device from service.
Class 2 Test - Double Insulation Test – Menu A - F2
The Double Insulation Test completes the following test sequences as part of its procedure:
1. Integrated Supply Mains Test - Refer to Integrated Test section
2. Integrated NCNT Test - Refer to Integrated Test section
3. Double Insulation Test (@ 250V, 500V or 1000V): pass level greater than 1MΩ
Procedure:
1. Complete a Visual Inspection, and inspect the compliance plate to ensure the appliance is a
Class 2 appliance. Look for the double insulated symbol, seen here.
2. Plug the appliance into the appliance test socket of the TnP 3PLM
3. Navigate to Main Menu A, then Press the F2 key to begin the test
4. Read and record results appropriately
If the result was a PASS - Tag with PASS tag showing “next test due” date and return the device to service.
If the result was a FAIL - Tag with a DANGER tag and remove the device from service.

20
TnP 3PLM User Manual Wavecom
Note: In some situations, if the device is labelled with “Surge Protection Fitted” or if it contains MOV’s (Metal Oxide
Varistors), conduct a 250V-insulation test. Always read the compliance plates before testing, especially on surge protected
powerboards. If unsure always refer to the AS/NZS:3760:2010 Standard. Should it still fail, remove it from service.
Lead Test (Extension Lead Test) – Menu A - F3
Note: Extension leads should always be uncoiled before using or testing. Please ensure that the IEC Adaptor & the IEC
socket are inserted firmly or it may result in a continuity/polarity fail.
The Lead Test completes the following sequence as part of its comprehensive testing procedure:
1. Integrated Supply Mains Test - Refer to Integrated Test section
2. Earth Bond Test (@ 200mA): 200mA test current, pass level less than 1Ω
3. Insulation Test (@ 250V, 500V or 1000V): pass level greater than 1MΩ
4. Continuity and Polarity Test 240VAC @ 2mA Checks continuity & polarity of leads
Procedure:
1. Complete a Visual Inspection
2. Plug in the IEC-550 Orange Lead adaptor lead supplied into the IEC socket.
3. Plug male end of extension lead or power board into the appliance test socket.
4. Connect the IEC-550 Orange lead to your extension lead
5. Navigate to Main Menu A, then Press the F3 key to begin the test
6. Read and record results appropriately.
If the result was a PASS - Tag with PASS tag showing “next test due” date and return the device to service.
If the result was a FAIL - Tag with a DANGER tag and remove the device from service.
TnP 3PLM Testing Menu – Main Menu B
Use the Enter button to switch between Menu A , B & C. All tests on Menu B require a Mains Power source.
Power Test - Menu B – F1
The Power Test is for the purposes of monitoring and performance of equipment. The Power Test feature is
for single phase appliances only. The Power Test allows the user to turn the appliance on and measure its
performance as a digital wattmeter.
Displayed parameters are:
• Volts AC
• Current
• Volt Amp
• Power Factor
• Watts
This test is ideal for service agents and electricians. The user can plug in the appliance and turn it on with real
time measurements displayed on the display. This is useful when testing an appliance with a compliance/
name plate on it. The operator can compare the name plate details of operating voltage, operating current,
and power factor etc. Should the appliance exceed the said values on the name plate it could be deemed faulty
and require service.
