WE-EF PSY414 LED User manual

WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Bollard
PSY414 LED
PSY424 LED
PTY414 LED
PTY424 LED
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Installation tools
Mounting hardware used on this product
includes fasteners with hexalobular socket
heads (ISO 10664). Installation requires the
use of matching tools.

1
IP66, IK10, Class I, ta = 40°C
Weight kg
for PSY414 13.3
for PSY424 16.1
for PTY414 14.0
for PTY424 19.0
Accessories:
Planted root – Galvanised steel. kg
ESV2 for PSY414/424 300-9115 3.8
ESV2 for PTY414/424 300-9115 3.8
ESV2
Bollard
PSY414
PSY424
PTY414
PTY424
190180
75
304
800
100
90
ø 14.5
180
260180
75
440
1000
100
90
ø 14.5
180

2
Light Source
LED
Maintenance
Apart from cleaning the product’s exterior surfaces, no special maintenance work is required.
Do not use high-pressure cleaners.
In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out
E\DVXLWDEO\TXDOLƂHGDQGWUDLQHGSURIHVVLRQDO
Warning: Do not open luminaire while mains supply is switched on.

3
Installation
The product must be installed and maintained by a
VXLWDEO\TXDOLƂHGSURIHVVLRQDOLQFRPSOLDQFHZLWKODWHVW
building/construction and/or electrical regulations and
relevant legislation.
Warning: Switch off mains electrical supply prior to
installing and connecting the luminaire.
Notice:,IWKHOXPLQDLUHLVPRGLƂHGE\DQ\ERG\RWKHU
than the original manufacturer, then the warranty will
no longer be valid and shall become the full respon-
sibility of the modifying person/organisation. Claims
based on defects attributable to improper installation
and/or application, and the consequences thereof, are
excluded.
Attention: The luminaire is factory-sealed and does
not need to be opened during installation.
The installation on site must comply with local and/or
national health and safety regulations.

4
Installation Procedure
It is recommended to incorporate the optional planted root to ensure maximum stability.
1) Switch off mains electrical supply.
4) Lift tab Hand remove terminal box cover Cas
shown.
2) Remove sleeve Afrom post B.
 3XOOFDEOHWKURXJKFHQWUHKROHDQGVFUHZƃDQJH
plate Ewith M12 bolts/nuts to ground. Ensure
proper orientation of terminal box. An optional
planted root is available.
Note: Planted root installation instruction is
available in additional document.

5
6) Pull cable D(and second cable for through wir-
ing, if required) through membrane spout(s) F
and terminate in terminal block G. Lock cable(s)
with strain relief(s).
7) Return terminal box cover Cand push until
tab Hengage with pins.
5) Check that rating shown on luminaire label
conforms with mains electrical supply.
(example)
PSY424 220-240V/50-60 Hz
114-XXXX SOE XXXXXXX
LED 4000K 18W item no. XXX
08/18 IP66
8) Place sleeve A over post Bwith sticker I
pointing up as shown.

6
10)Remove countersunk screws Jfrom head Kwith
Torx 25 tool (supplied by WE-EF).
9) Align sleeve ALQWRƃDQJHSODWHE
(good and bad engagement).
12)Placehead KoversleeveAandcheckfor
alignment.
ƃXVK
11)Hold head Kunder arm. Grab socket L, connect
and tighten with plug M.

7
13)Tighten recessed screws Ngradually in
alternating sequence (6 Nm) with Torx 30 tool
(supplied by WE-EF).
14)Return countersunk screws Jinto head and
tighten.

www.we-ef.com
WE-EF LEUCHTEN
Germany
Tel [phone]
Fax [phone]
[e-mail]
WE-EF LUMIERE
France
Tel [phone]
Fax [phone]
[e-mail]
WE-EF HELVETICA
Switzerland
Tel [phone]
Fax [phone]
[e-mail]
WE-EF LIGHTING
Thailand
Tel [phone]
Fax [phone]
LQIRDVLDSDFLƂF#ZHHIFRP
WE-EF LIGHTING
Australia
Tel [phone]
Fax [phone]
[e-mail]
WE-EF LIGHTING
United States of America
Tel [phone]
Fax [phone]
[e-mail]
TO9245W0520 © WE-EF 2020
7HFKQLFDOVSHFLƂFDWLRQVDUH
subject to change.

WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Planted Root
ESV4
ESV2
ESV6

2
Planted Root
ESV4 300-0461
ESV4 300-0586
ESV4 300-0464
ESV4 300-0459
Suitability
1. KTX234
2. KTY234
3. ZFY230
4. GRY224
5. Short post
Suitability
1. XRY334
2. XRZ334
3. RRY334
4. RRZ334
Suitability
1. CFY259
2. GRY234
3. RRY324
4. RRZ324
5. XRY324
6. XRZ324
Suitability
1. QSI254

3
Planted Root
ESV2 300-9115
ESV6 300-0824
ESV6 300-0457
Suitability
1. PSY414/424
Suitability
1. AML-C
2. FLA461
Suitability
1. LTM440
2. LTM444
3. AMW-C
4. AMF-C
5. AMF-S
6. AML-C
240
200
600

4
Installation Instruction
1) Note: It is the responsibility to installer to
ensure the suitability of the ESV planted root
for any local or national structural requirements
for installation, and that planted root is suitable
IRUVLWHVSHFLƂFFRQGLWLRQV
Instructions are a guideline for installation to
these requirements and provide detail for
installation orientation and mounting details.
4) For ESV2 please orientate planted root as
shown (base plate is parallel to the pathway).
For this installation, use 30 mm long M12
bolts supplied.
2) Please note, ESV4 and ESV6 must be
orientated correctly for different products.
In both instances conduit entry can be rotated
to match cable routing.
When the ESV is being installed for following
products: KTY234/KTX234/ZFY230/CFY259/
FLA461, please orientate the planted root
as shown (base plate is at an angle of 45°
to the pathway). For this installation,
use the 40 mm long M8 bolts supplied.
3) For all other product that use ESV4 please
orientate planted root as shown (base plate is
parallel to the pathway). For this installation,
use 25 mm long M8 bolts supplied.

5
 2ULHQWDWH(69DVUHTXLUHGDQGƂWHOHFWULFDO
connections/conduit.
5) For all other product that use ESV6 please
orientate planted root as shown (base plate
is parallel to the pathway). For this installation,
use 40 mm long M16 bolts supplie.
7) Place the ESV in the form work for concrete
pad, ensuring orientation, position and levels
are correct. Ensure all openings on ESV are
blanked off, including mounting plate hole.
8) Fit the nominated bolts through mounting
ƃDQJH(QVXUHVHYHUDOWKUHDGVIHHGWKURXJK
the plate and tape off top and bottom. Bolts are
inserted to protect threads off plate and need to
EHUHPRYHGIRUƂWWLQJLQVWDOODWLRQDIWHUVHWWLQJ
the ESV.

6
9) Pour concrete to desired level depending on
requirement of soil, paver or concrete. Ensure
WKDWIRUDQ\LQVWDOODWLRQPRXQWLQJƃDQJHPXVWEH
ƃXVKRUKLJKHUWKDQVXUURXQGLQJVXUIDFHOHYHO
$IWHUFRQFUHWHKDVFXUHGIRUVSHFLƂHGWLPH
UHPRYHEODQNLQJDQGEROWV,QVWDOOƂWWLQJ
(as per luminaire instructions) onto mounting
ƃDQJH
Concrete
Paver
Soil
