Operating Instructions for Telestart T91
General Information
Dear Webasto customer!
We are delighted that you have selected this Webasto product.
We presume that the principle and mode of operation of this product has been
explained to your complete satisfaction by the workshop/service centre which in-
stalled it. In these operating instructions we would like to once again provide you
with an overview of the safe use of this product.
The Telestart T91 heater control complies with the homologation approval in
accordance with the directive 72/245/EEC (EMC).
Note: The battery used is fully operational, however is
subject to function-dependent discharging when installed.
Therefore, we expressly recommend observing the
information on Page 32 when the Telestart is not used for
longer periods.
1314649B_BA_T91.book Page 18 Tuesday, January 31, 2012 9:42 AM

19
GB
Care and Handling
Note the following points to avoid damage to the Telestart T91:
• Do not expose to heat above 70 °C (e.g. direct sunlight).
• Operating temperature between 0 °C and +50 °C.
• Only store in a dry place where there is little dust.
• Do not immerse in water.
The heater must not be operated:
• In filling stations and tank farms.
• At locations at which highly flammable gases
or dusts can form, and at locations at which
highly flammable liquids or solid materials are
stored (e.g. near fuel, coal and wood dust,
grain warehouses, dry grass and leaves, card-
board, paper, etc.)
• In enclosed rooms (e.g. garages), not even via
the timer or Telestart.
Danger of fire, explosion
and suffocation
1314649B_BA_T91.book Page 19 Tuesday, January 31, 2012 9:42 AM

20
GB
Use
With the Webasto Telestart T91, the Webasto heaters of the Thermo Top series or
the vehicle fan can be switched on and off wirelessly from a great distance.
With the Thermo Top Evo heater which is connected to the Telestart T91 via W bus
communication, a change in the mode must be carried out on the transmitter to
switch on the parking ventilation (ventilation of the vehicle interior) (see the point
"Setting Mode").
For Thermo Top E and C heaters with an analogue connection to the Telestart T91,
the parking ventilation function (ventilation of the vehicle interior) can only be en-
sured by also installing a summer/winter switch (option). A mode change on the
transmitter is not required for this purpose, as the "parking heating" or "parking
ventilation" function is determined by the switch position of the summer/winter
switch.
Restrictions of the range of functions can occur when factory-installed heaters are
retrofitted. Please have these explained by your installation partner.
1314649B_BA_T91.book Page 20 Tuesday, January 31, 2012 9:42 AM

21
GB
Optimum signal transmission is achieved out in the open or from a position higher
than the vehicle. In this case, the parking heater can be operated at a distance of
approx. 1000 m from the vehicle. When operating the transmitter, please hold it
vertically pointing upward and do not cover the upper side (see illustration).
If you determine from the lack of feedback that the operating signal has not
reached the vehicle, then you must change your position by a few metres. Recep-
tion quality is impaired accordingly in heavily built-up areas.
After the selected switch-on duration expires, the transmission of the switch-on
signal to the heater is interrupted and the function currently running (parking
heating or parking ventilation) is ended automatically.
1314649B_BA_T91.book Page 21 Tuesday, January 31, 2012 9:42 AM

22
GB
Teaching In Telestart Transmitter for Thermo Top E and C
1. Insert the battery in the battery compartment of the transmitter.
2. Remove the 1 A fuse (black) from the heater's fuse holder (voltage interruption
of receiver).
3. Wait at least 5 seconds and refit the fuse.
4. After approximately 2 seconds, however within 6 seconds, press the OFF but-
ton on the transmitter for at least 1 second.
5. Teaching is completed.
A maximum of 4 hand-held transmitters can be taught in this way. During addi-
tional teaching processes, the "oldest" transmitter will be deleted each time.
min. 5 s. min. 2 s.
max. 6 s. min.
1s.
1314649B_BA_T91.book Page 22 Tuesday, January 31, 2012 9:42 AM

23
GB
Teaching in Telestart Transmitter for Thermo Top Evo
As described above for the Thermo Top E and C, however remove either 1 A fuse
(black, vehicle interior) or 30 A fuse (green, engine compartment) (voltage inter-
ruption for receiver).
or
min.
5s.
min.
5s.
min. 2 s.
max. 6 s.
min. 1 s.
1314649B_BA_T91.book Page 23 Tuesday, January 31, 2012 9:42 AM

24
GB
Checking Mode
Simultaneously press and hold down the ON- and OFF-but-
tons.
LED lights up:
red = Heating mode
green = Ventilation mode*
LED extinguishes:
– when the buttons are released, or
– after 3 seconds
* Please observe the information under "Use".
Setting Mode
Depress the ON- and OFF buttons simultaneously twice
within one second.
Upon the second actuation, the LED will change its colour
and illuminate until the buttons are released (illuminates for
max. 3 seconds).
The new mode is stored when the button is released.
2 x
1314649B_BA_T91.book Page 24 Tuesday, January 31, 2012 9:42 AM

25
GB
Feedback from Transmitter Upon Turning On/Off
Switching On Heater or Ventilation*
Hold the transmitter with the aerial upright and press the
ON button until the LED lights up (approx. 1 second).
The Telestart receiver in the vehicle transmits a confirmation
of the reception (see overview above: "Feedback").
Then the forwarding of the signal to the heater is confirmed
with brief flashing signals (every 2 seconds).
The operation indicator extinguishes:
– After the preset operating time has elapsed
– After switching off with Telestart.
* Please observe the information under "Use".
The LED on the transmitter
lights up for 2 seconds:
red = Heating mode
green = Ventilation mode*
The signal has been received and the heater /
vehicle fan switched on or off.
The LED on the transmitter
flashes for 2 seconds. Error during signal transmission. Change your location and repeat transmission.
1314649B_BA_T91.book Page 25 Tuesday, January 31, 2012 9:42 AM

26
GB
NOTE:
If no special instructions on adjusting the vehicle heater during parking heating
operation are available, then the vehicle heater must be set to "warm" before
switching on the heater.
In the heating and ventilation modes, the vehicle fan switch is to be turned to po-
sition 1 in the case of 3-speed blower fans, and to position 2 in the case of 4-speed
blower fans.
In the case of infinitely variable fans adjust to at least 1/3 of the fan's capacity.
Switching Off Heater or Ventilation
Hold the transmitter with the aerial upright and press the
OFF button until the LED lights up (approx. 1 second).
The Telestart T91 in the vehicle will send a feedback signal.
Switching Off Using Pushbutton Switch
If the heater was activated by means of Telestart, the pushbutton switch must be
pressed once for deactivation.
1314649B_BA_T91.book Page 26 Tuesday, January 31, 2012 9:42 AM

27
GB
Switching On/Off Using Pushbutton Switch
The parking heating or parking ventilation mode is indicated by a light in the push-
button.
NOTE:
When the pushbutton switch is used for activating the heater, the operating mode
(parking heating or parking ventilation) and the operating duration most recently
used with Telestart T91 will be selected.
Switching On Using a Digital Timer (Immediate Heat Button)
Operation is indicated on the digital timer. The display lighting lights up.
NOTE:
When switching on with the digital timer (immediate heat button), the parking
heating mode is always selected. The switch-on duration is specified by the digital
timer.
1314649B_BA_T91.book Page 27 Tuesday, January 31, 2012 9:42 AM

28
GB
Switching On with Telestart T91 with Digital Timer Installed
Operation is indicated on the digital timer. The display lighting lights up.
NOTE:
This display is only possible with the Thermo Top Evo heater, as it is connected to
the Telestart T91 via W bus communication.
Switching Off Using a Digital Timer
If the heater was activated using Telestart, the immediate heat button must be
pressed twice to deactivate the heater.
When connecting the Telestart T91 and the digital timer to a Thermo Top Evo, only
a single press of the button is required due to the connection via W bus commu-
nication.
Switching On with Telestart T91 with Summer/Winter Switch In-
stalled (Option)
The "parking ventilation" or "parking heating" function is determined by the
switch position of the summer/winter switch. Please also observe the point "Use"
for this purpose.
1314649B_BA_T91.book Page 28 Tuesday, January 31, 2012 9:42 AM

29
GB
Checking and Setting Operating Time
The operating time of the heater or the vehicle's fan can be preset on the trans-
mitter in increments of 10 minutes. The operating time is factory-set at 30 min-
utes.
NOTE:
Make sure that the car battery is recharged sufficiently if you use the system fre-
quently and for a long period.
We recommend setting the heating time according to the drive time.
Example: The vehicle is used for travelling to work and back.
With a driving time of approx. 30 minutes (one way), we recommend setting an
operating time of 30 minutes.
1314649B_BA_T91.book Page 29 Tuesday, January 31, 2012 9:42 AM

30
GB
Checking Operating Time
Simultaneously briefly press the ON and OFF button three
times consecutively.
The LED flashes in accordance with the preset operat-
ing time.
NOTE:
The first coded flashing signal that is emitted immediately upon the third
actuation of both buttons has to be included into the count.
No. of coded flash-
ing signals
1 2 3 4 5 6
Operating time 10 min. 20 min. 30 min. 40 min. 50 min. 60 min.
No. of coded flash-
ing signals
7 8 9 10 11 12
Operating time 70 min. 80 min. 90 min. 100 min. 110 min. 120min.
3 x
1314649B_BA_T91.book Page 30 Tuesday, January 31, 2012 9:42 AM

31
GB
Setting Operating Time
Press the OFF button to call up the next operating time.
To store the setting:
– do not actuate any button for 10 seconds, or
–actuatetheON button.
Returning to Factory Setting
Simultaneously press the ON and OFF button for at least 15
seconds.
NOTE:
Colour changes on the LED which occur in the process can
be ignored.
Factory setting:
– Mode: Heating
– Operating time: 30 minutes
1314649B_BA_T91.book Page 31 Tuesday, January 31, 2012 9:42 AM

32
GB
Procedure after not using for longer time
When the hand-held transmitter is not used for longer periods, we recommend
removing the battery from the hand-held transmitter to increase battery life.
Caution:
Do not store in the vehicle, but instead in a dry place at room temperature.
Returning to use:
1. Insert the battery in the battery compartment of the transmitter.
2. Press the OFF button six times for 2 seconds at intervals of approx. 2 seconds.
3. Observe a waiting time of approx. two minutes.
If the hand-held transmitter does not function after returning it to use, then an
operating test of the battery (see point "Checking Battery") must be carried out.
1314649B_BA_T91.book Page 32 Tuesday, January 31, 2012 9:42 AM

33
GB
Checking Battery
Press the ON or OFF button.
LED Battery Action
lights up for 2 sec-
onds in green or
red
full Battery OK
ATTENTION:
Heater could be activated or
deactivated in the process.
flashes for 2 sec-
onds in green or
red
full Battery OK
ATTENTION:
Receiver too far away or trans-
mitter not taught.
lights up for 2 sec-
onds in orange
almost spent replace battery as soon as pos-
sible or warm up transmitter
flashes orange very
quickly for 5 sec-
onds
discharged Replace battery.
no display drained Replace battery.
or
1314649B_BA_T91.book Page 33 Tuesday, January 31, 2012 9:42 AM

34
GB
Battery Change/Disposal Information
NOTE:
Batteries and electronic devices are the object of the
European Directive 2006/66/EC or 2002/96/EC in
the current versions and must not be disposed of as
household waste.
Every consumer is therefore legally obligated to
dispose of batteries and used/scrap electronic
devices in the marked recycling containers at a
waste collection point or in the retail trade. Return
is free of charge.
CAUTION:
There is a danger of explosion in case of improper
battery replacement! Ensure proper polarity when
inserting the battery.
1314649B_BA_T91.book Page 34 Tuesday, January 31, 2012 9:42 AM

D
Bei mehrsprachiger Ausführung ist Deutsch verbindlich.
Die Telefonnummer des jeweiligen Landes entnehmen Sie bitte dem Webasto Servicestellenfaltblatt oder
der Webseite Ihrer jeweiligen Webasto-Landesvertretung.
In multilingual versions the German language is binding.
The telephone number of each country can be found in the Webasto service center leaflet or the website
of the respective Webasto representative of your country.
Dans le cas d'une version rédigée en plusieurs langues, l'allemand est alors la langue qui fait foi.
Pour trouver le numéro de téléphone du pays concerné, veuillez consulter le dépliant des points-service
Webasto ou la page web de la représentation Webasto de votre pays.
Nel caso di una versione plurilingue il tedesco è vincolante.
I numeri di telefono dei diversi Paesi sono riportati sul pieghevole relativo ai centri di assistenza Webasto
oppure sul sito Internet del proprio rappresentante di riferimento Webasto.
Este manual esta traducido en varios idiomas, le informamos que sólo la versión en alemán será
vinculante.
Consulte el número de teléfono del país correspondiente en el folleto de los servicios autorizados
Webasto, o en la página web de su representante Webasto.
Ident-Nr. 1314649B04 • 10/12 • Errors and omissions excepted • Printed in Germany
© Webasto Thermo & Comfort SE, 2012
Webasto Thermo & Comfort SE
Postfach 1410
82199 Gilching
Germany
Visitors' address:
Friedrichshafener Str. 9
82205 Gilching
Germany
Internet: www.webasto.com
BA_T91_Back.fm Page 240 Tuesday, October 2, 2012 11:12 AM
