weBoost Connect RV 65 User manual

User Manual
RV Cellular Signal Booster
With Telescoping Pole
CONNECT RV 65
A WILSON ELECTRONICS BRAND
NEED HELP? support.weboost.com 866.294.1660
a
a

______
Index
Package Contents
1
STEP 1: Mount Outside Antenna
2
STEP 2: Mount Telescoping Pole To RV
3
STEP 3: Booster Location
5
STEP 4: Mount Inside Antenna
7
STEP 5: Connect Power Supply
9
Test System: Lights
10
Safety Guidelines
12
Specifications
14
Warranty
15

CONNECT RV 65 RV CELLULAR SIGNAL BOOSTER 1
________
Package
Contents
Booster
Telescoping
Pole
Ground
Mount
Wall
Mounts
Inside
Antenna
Outside
Antenna
Power
Supply
Coax Cables
2 - 15ft. 1 - 30ft.
+ Flat Cable
Contents of Box 1
Contents of Box 2

2RV CELLULAR SIGNAL BOOSTER CONNECT RV 65
______
Step 1: Mount Outside
Antenna To Telescoping Pole
Mount outside antenna to telescoping pole (using the included
hardware). See examples below.
Connect coax cable to outside antenna after mounting to
telescoping pole.
NOTE: Do not over tighten.
Run the coax cable through
L-Bracket and mount using the
phillips screws and lock washers.
Drip hole

CONNECT RV 65 RV CELLULAR SIGNAL BOOSTER 3
______
Step 2: Mount Telescoping
Pole To Side Of RV
Determine where you want to mount telescoping pole on your
RV. Extend pole to maximum height. Use wall mount plates
and ground mount to secure pole. We recommend mounting
near slider or toy hauler ramp door on the side.
WARNING: Check for and avoid any powerlines or overhead obstructions
there may be.
NOTE: DO NOT INSTALL POLE ON RV UNTIL STABILIZER JACKS AND
WHEELS CHOCKS ARE IN PLACE AND RV IS IMMOBILIZED.
Stabilizer
jacks down Wheel chocks in
place
Recommended
placement

4RV CELLULAR SIGNAL BOOSTER CONNECT RV 65
Clean the flat surface of the RV where wall mounts will be
placed. Fully extend the pole and attach the wall mount to
the top black ‘foot’ mount located on the pole. Remove the
adhesive backer and, making sure the pole is level at a 90°
angle, firmly attach the wall mount to the RV near the top.
There must be at least 4’ of separation between the top and
bottom mounts for best performance. Next, attach the other
wall mount to the bottom foot mount located on the pole and
insert the attached pin. Then remove the adhesive backer and
stick to the clean, flat surface.
RVs With Corrugated Sides
We recommend using the side of a slider. Just ensure the following:
• There is enough clearance for the wall mount to
be retracted into the slider.
• There is still 4’ of separation.
Outside Antenna
Extend
Pole
Min. 4 ft.
separation
between wall
plates
Ground Mount
(stakes can be used to secure to ground, not included)
______
(STEP 2 Mounting Telescoping Pole cont.)

CONNECT RV 65 RV CELLULAR SIGNAL BOOSTER 5
______
Step 3: Booster Location
NOTE: We recommend in a cabinet near a power source. Be sure it’s in a
location that the 30’ RG-6 cable can reach.
Find a location to place the booster inside the RV and
connect cable from outside antenna to port on booster
labeled ‘Outside Antenna’. We recommend routing the
cable through the slider gasket OR through the back door
of a toy hauler using the flat cable provided.
Connect cable from outside
antenna to port on booster
labeled ‘Outside Antenna’.
NOTE: Do not over tighten.

6RV CELLULAR SIGNAL BOOSTER CONNECT RV 65
______
(STEP 3 Booster Location cont.)
Run cable through the slider on your RV (using the slider
gasket as a seal) OR through the back door of a toy hauler
using the flat cable provided. For toy haulers, we recommend
using the flat cable and closing this in the back ramp door.
NOTE: Do not fully extend your slide until
you route the cable through, then it may
be fully extended.
TIP: It’s easiest to create a loop with the
coax cable, lift up the gasket, and push
the loop through the other side.

CONNECT RV 65 RV CELLULAR SIGNAL BOOSTER 7
______
Step 4: Mount Inside Antenna
Mount inside antenna using included 3M command strips and
connect coax cable. Be sure to have adequate distance from
outside antenna.
Apply 3M Command
Strips on wall bracket
Wall Bracket
3M Command Strips
connect to booster
Have adequate distance from outside antenna

8RV CELLULAR SIGNAL BOOSTER CONNECT RV 65
Connect coax cable to inside
antenna and to booster port
labeled ‘Inside Antenna’.
______
(STEP 4 Mount Inside Antenna cont.)

CONNECT RV 65 RV CELLULAR SIGNAL BOOSTER 9
______
Step 5: Connect Power
Supply
Connect power supply to booster. Plug the power supply
into a 120V power outlet in the RV. If your Connect RV 65 is
working correctly, the lights will be green (for blinking lights
see ‘Test System: Lights’ section).
Power Outlet
Power Supply
NOTE: Use Open Signal App to point the outside antenna toward the
nearest cell phone tower. Twist the telescoping pole to prevent the cable
from ‘clinking’ against the pole.

10 RV CELLULAR SIGNAL BOOSTER CONNECT RV 65
______
Test System: Lights
Fix Any Red Light Problems (red indicates oscillation)
• If you are happy with coverage, red lights don’t have to be resolved.
• Solid Red = Band has shut o
• Blinking Green/Red = Band has reduced gain
Each light corresponds to a frequency band.
No Lights
Booster does not have power. Un-plug and securely re-plug in power supply.
IMPORTANT: To get an accurate reading of the lights, unplug and re-plug
the power supply from the Booster.
Band 4
Band 5
Band 2
Band 12/13/17
skinny side
facing Cell Tower
!
1Verify Outside Antenna faces away from the
Inside Antenna. Un-plug and re-plug in power
supply.
2Verify the Inside Antenna is at least 18” from the
Booster and pointed away from the Booster. Un-
plug and re-plug in power supply.
3Tighten all cable connections. You may want to
undo and redo the connection completely. Un-
plug and re-plug in power supply.
4BEST: Increase the distance (horizontally or
vertically) between the Outside and Inside
Antenna. Add cable if needed. Un-plug and re-
plug in power supply.

CONNECT RV 65 RV CELLULAR SIGNAL BOOSTER 11
Fix Any Orange Light Problems (orange indicates a cell
tower is close by)
If you are happy with coverage, orange lights don’t have to be resolved
• Solid Orange = Band has shut o
• Blinking Green/Orange = Band has reduced gain.
1If the light is solid orange, the Outside Antenna must be adjusted (see below). Wait
10 seconds between adjustments for the lights to reset.
• Rotate the Outside Antenna away from the strongest cellular signal in small
increments (45°) until the light turns green. Un-plug and re-plug power supply.
2If the light is blinking green/orange, re-locate the Outside Antenna. Un-plug and
re-plug power supply.
If you have green lights, but poor coverage:
• Rotate the Outside Antenna in small increments. Un-plug and re-plug power supply.
• Move the Outside Antenna to a dierent location. Un-plug and re-plug power
supply.
______
(TEST SYSTEM: LIGHTS cont.)
NEED HELP? support.weboost.com 866.294.1660
All Green Lights? = Band is set up optimally. Verify you
have good coverage.

12 RV CELLULAR SIGNAL BOOSTER CONNECT RV 65
______
Safety Guidelines
!
Warnings
To uphold compliance with network protection standards, all active cellular devices
must maintain at least six feet of separation distance from Inside Panel and Dome
antennas and at least four feet of separation distance from desktop Antenna.
Use only the power supply provided in this package. Use of a non-weBoost product
may damage your equipment.
The Signal Booster unit is designed for use in an indoor, temperature-controlled
environment (less than 100 degrees Fahrenheit). It is not intended for use in attics or
similar locations subject to temperatures in excess of that range.
RF Safety Warning: Any antenna used with this device must be located at least 8
inches from all persons.
This device complies with Part 15 of FCC rules. Operation is subject to two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by weBoost could void the authority to operate this equipment.
FOR MORE INFORMATION ON REGISTERING YOUR SIGNAL BOOSTER WITH YOUR
WIRELESS PROVIDER, PLEASE SEE BELOW:
Sprint: http://www.sprint.com/legal/fcc_boosters.html
T-Mobile/MetroPCS: https://support.t-mobile.com/docs/DOC-9827
Verizon Wireless: http://www.verizonwireless.com/wcms/consumer/register-signal-booster.html
AT&T: https://securec45.securewebsession.com/attsignalbooster.com/
U.S. Cellular: http://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp
This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have
your provider’s consent. Most wireless providers consent to the use of signal boosters.
Some providers may not consent to the use of this device on their network. If you are
unsure, contact your provider.
In Canada, BEFORE USE you must meet all requirements set out in ISED CPC-2-1-05.
You MUST operate this device with approved antennas and cables as specified by the
manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from (i.e., MUST
NOT be installed within 20 cm of) any person.
You MUST cease operating this device immediately if requested by the FCC (or ISED in
Canada) or licensed wireless service provider.
WARNING. E911 location information may not be provided or may be inaccurate for calls
served by using this device.
This device may be operated ONLY in a fixed location (i.e..may operate in a fixed location
only) for in-building use.

CONNECT RV 65 RV CELLULAR SIGNAL BOOSTER 13
______
Antenna Kit Options
The following accessories can used with the Connect RV 65.
INSIDE ANTENNA EXPANSION KITS
Kit 309900-50N
2- Wall Panel antennas
1- 50 ohm 3-Way Splitter
Kit 309905-50N
3 - Wall Panel Antennas
3- 2-Way 50 Ohm Splitters
Kit 309902-75F
2 - Wall Panel Antennas
1-3-Way 75Ohm Splitter
Kit 309903-75F
3 - Wall Panel Antennas
3- 2-Way 75Ohm Splitters
Kit 309904-75F
1 - Wall Panel Antenna
1- 2-Way 75 Ohm Splitter
Kit 301213
Desktop Antenna w/ 5’ RG174
INSIDE ANTENNAS
Kit 311155-0630
75 Ohm Wall Mount Panel Antenna
30’ RG6 Cable
Kit 311135-5820
50 Ohm Wall Mount Panel Antenna
20’ RG58 Cable
Kit 311135-40060
50 Ohm Wall Mount Panel Antenna
60’ LMR400 Cable
Kit 311155-1150
75 Ohm Wall Mount Panel Antenna
50’ RG11 Cable
Kit 311155-40060
75 Ohm Wall Mount Panel Antenna
60’ LMR400 Cable
Kit 304412-40010
50 Ohm 4G Dome Antenna
10’ Wilson400 Cable
Kit 304412-5810
50 Ohm 4G Dome Antenna
10’ RG58 cable
Kit 304419-1110
75 Ohm 4G Dome Antenna
10’ RG 11 cable
Kit 304419-17410
75 Ohm 4G Dome Antenna
10’ RG174 cable
*May need separate adapter
Kit 304419-0610
75 Ohm 4G Dome Antenna
10’ RG6 cable
50 OHM OUTSIDE ANTENNA KITS
Kit 314453-5825
50 Ohm Pole Mount Panel Antenna
25’ RG58 Cable
Kit 314411-5825
50 Ohm Wide Band Directional
25’ RG58 Cable
Kit 301111-5850
Yagi Directional Antenna
50’ RG58 Cable
Kit 311203-5820
Omni-Directional Antenna
20’ RG58 Cable
Kit 314411-40075
50 Ohm Wide Band Directional
75’ LMR400 Cable
Kit 311203-40020
Omni-Directional Antenna
20’ LMR400 Cable
Kit 301111-400170
Yagi Directional w/ N-Female
170’ LMR400
Kit 314453-40075
50 Ohm Pole Mount Panel Antenna
75’ LMR400 Cable
Kit 304422-40020
50 Ohm 4G Omni Antenna
20’ Wilson400 cable
Kit 304422-5810
50 Ohm 4G Omni Antenna
10’ RG58 cable
*May need separate adapter
Kit 304422-1120
50 Ohm 4G Omni Antenna
20’ RG11 cable
*May need separate adapter
Mini-Mag
301126 w/ 12.5 RG174 cable- SMA
75 OHM OUTSIDE ANTENNA KITS
Kit 301111 – 0675
Yagi Directional Antenna
75’ RG6 Cable
N-Male to F-Female adapter
Kit 314473 -0640
75 Ohm Pole Mount Panel Antenna
40’ RG6 Cable
Kit 314475 – 0630
75 Ohm Wide Band Directional
30’ RG6 Cable
Kit 311141 - 0620
75 Ohm Grey Brick Antenna
20’ RG6 Cable
Kit 301111 – 11140
Yagi Directional Antenna
140’ RG11 Cable
N-Male to F-Female adapter
Kit 314473 -1175
75 Ohm Pole Mount Panel Antenna
75’ RG11 Cable
Kit 314475 – 1175
75 Ohm Wide Band Directional
75’ RG11 Cable
Kit 311141 - 1120
75 Ohm Grey Brick Antenna
20’ RG11 Cable
Kit 304421-1120
75 Ohm 4G Omni Antenna
20’ RG 11 cable
Kit 304421-17410
75 Ohm 4G Omni Antenna
10’ RG174 cable
*May need separate adapter
Kit 304421-0610
75 Ohm 4G Omni Antenna
10’ RG6 cable
Kit 304421-5810
75 Ohm 4G Omni Antenna
10’ RG58 cable
*May need separate adapter

14 RV CELLULAR SIGNAL BOOSTER CONNECT RV 65
______
Specifications
Connect RV 65
Model Number 460020
FCC ID PWO460020
IC 4726A-460020
Connectors F-Female
Antenna Impedance 75 Ohms
Frequency 698-716 MHz, 746-787 MHz, 824-894 MHz, 1850-1995 MHz, 1710-1755/2110-2155 MHz
Power output for single cell
phone (Uplink) dBm
700 MHz
Band17
700 MHz
Band13
800 MHz
Band 5
1700 MHz
Band 4
1900 MHz
Band 25/2
23.94 24.19 23.49 24.55 23.61
Power output for single cell
phone (Downlink) dBm
700 MHz Band17
Band17
700 MHz Band13
Band13
800 MHz
Band 5
2100 MHz
Band 4
1900 MHz
Band 25/2
11.64 11.92 12.1 11.9 9.5
Noise Figure 5 dB nominal
Isolation > 110 dB
Power Requirements AC / DC 5V, 4.0A, w/2.5x5.5mm Jack
The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met.
Each Signal Booster is individually tested and factory set to ensure FCC compliance. The Signal Booster cannot be adjusted without
factory reprogramming or disabling the hardware. The Signal Booster will amplify, but not alter incoming and outgoing signals in order
to increase coverage of authorized frequency bands only. If the Signal Booster is not in use for five minutes, it will reduce gain until a
signal is detected. If a detected signal is too high in a frequency band, or if the Signal Booster detects an oscillation, the Signal Booster
will automatically turn the power o on that band. For a detected oscillation the Signal Booster will automatically resume normal
operation after a minimum of 1 minute. After 5 (five) such automatic restarts, any problematic bands are permanently shut o until the
Signal Booster has been manually restarted by momentarily removing power from the Signal Booster. Noise power, gain, and linearity
are maintained by the Signal Booster’s microprocessor.
This device complies with Part 15 of FCC rules. Operation is subject to two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by weBoost could void the authority to operate this equipment.

CONNECT RV 65 RV CELLULAR SIGNAL BOOSTER 15
2 YEAR WARRANTY
weBoost Signal Boosters are warranted for two (2) years against defects in
workmanship and/or materials. Warranty cases may be resolved by returning the
product directly to the reseller with a dated proof of purchase.
Signal Boosters may also be returned directly to the manufacturer at the
consumer’s expense, with a dated proof of purchase and a Returned Material
Authorization (RMA) number supplied by weoost. weBoost shall, at its option,
either repair or replace the product.
This warranty does not apply to any Signal Boosters determined by weBoost
to have been subjected to misuse, abuse, neglect, or mishandling that alters or
damages physical or electronic properties.
Replacement products may include refurbished weBoost products that have been
recertified to conform with product specifications.
RMA numbers may be obtained by contacting Customer Support
DISCLAIMER: The information provided by weBoost is believed to be complete
and accurate. However, no responsibility is assumed by weBoost for any business
or personal losses arising from its use, or for any infringements of patents or other
rights of third parties that may result from its use.

16 RV CELLULAR SIGNAL BOOSTER CONNECT RV 65
______
Notes

CONNECT RV 65 RV CELLULAR SIGNAL BOOSTER 17
______
Notes

3301 East Deseret Drive, St. George, UT
866.294.1660 www.weboost.com support.weboost.com
Copyright © 2016 weBoost. All rights reserved.
weBoost products covered by U.S. patent(s) and pending application(s)
For patents go to: weboost.com/us/patents
NOT AFFILIATED WITH WILSON ANTENNA GDE000078_Rev01_04.06.18
