Weidmüller IE-CDM-V14MRJSCP/VAPM-C Manual

FreeCon Active
PROFINET POF Media Converter
IE-CDM-V14MRJSCP/VAPM-C
132444000
Hardware Installation Guide
Second Edition, August 2018
Doc no. 1346050000 (02)
Copyright Notice
Copyright 2018 Weidmüller Interface GmbH & Co. KG
All rights reserved.
Reproduction without permission is prohibited.

- 2 -
Overview
The FreeCon Active Series supports PROFINET IRT with diagnosis functionality.
The devices provides 18 to 30 VDC power input that can be connected simultaneously to a live DC power
source.. The IP65 metal housing makes them rugged enough for any harsh industrial environment.
Package Checklist
Your FreeCon Active is shipped with the following items. If any of these items are missing or damaged, please
contact your Weidmüller customer service for assistance.
FreeCon Active device
Hardware Installation Guide (This document)
Features
PROFINET IRT Repeater with diagnostic functions
PROFINET Power Push Pull connector
PROFINET Data PushPull connector with POF and RJ45
Temperature range from -20 to 55°C
Input voltage from 18 to 30 VDC
Typical input current from 150 mA
Power througput 2x24VDC/16A (at 20°C)
IP65 metal housing
Panel mounting ability

- 3 -
Mounting Dimensions (unit = mm)
Wall Mounting
Mounting the FreeCon Active on the wall requires 4 screws. Use the FreeCon Active device as a guide to mark
the correct locations of the 4 screws. We recommend M4x10mm (or longer), torque 2,5 Nm.

- 4 -
Wiring Requirements
WARNING
Safety First!
Calculate the maximum possible current in each power wire and
common wire. Observe all electrical codes dictating the
maximum current allowable for each wire size.
If the current goes above the maximum ratings, the wiring could
overheat, causing serious damage to your equipment.
You should also pay attention to the following points:
Use separate paths to route wiring for power and devices. If power wiring and device wiring paths must cross,
make sure the wires are perpendicular at the intersection point.
NOTE: Do not run signal or communications wiring and power wiring in the same wire conduit. To avoid
interference, wires with different signal characteristics should be routed separately.
It is strongly advised that you label wiring to all devices in the system when necessary.
Pin Assignement:
1: L1 (24 VDC, US1+)
2: N1 (0 VDC, US1-)
3: L2 (24 VDC, US2+)
4: N2 (0 VDC, US2-)
5: FE (Functional earth)
Use power plug:
2465440000 / IE-PS-VAPM-5P-2,5
Grounding the Ethernet Switch
Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run the
ground connection from the ground screw to the grounding surface prior to connecting devices.
ATTENTION
This product is intended to be mounted to a well-grounded
mounting surface such as a metal panel.

- 5 -
100BaseFX POF Ethernet Port Connection
The concept behind the SC port and cable is quite straightforward. Suppose you are connecting devices I and II;
contrary to electrical signals, optical signals do not require a circuit in order to transmit data. Consequently, one
of the optical lines is used to transmit data from device I to device II, and the other optical line is used transmit
data from device II to device I, for full-duplex transmission.
Remember to connect the Tx (transmit) port of device I to the Rx (receive) port of device II, and the Rx
(receive) port of device I to the Tx (transmit) port of device II.
TX RX
ATTENTION
This is a Class 1 Laser/LED product. To avoid causing serious
damage to your eyes, do not stare directly into the Laser Beam.
Use PushPull data plug:
1) 1191550000 IE-PS-V14M-2SC-POF
2) 1012170000 IE-PS-V14M-RJ45-FH-P 1) 2)
LED Indicators
The front panel of the Ethernet Switch contains several LED indicators. The function of each LED is described
in the table below.
LED
Color
State
Description
US1/2
green
On
- Power is being supplied to power input P1/2.
Off
- Power is not being supplied to power input P1/2.
BF
red
On
- Not connected to network. (FO1 and FO2)
- Rx power alarm
Blinking
- Not connected to IO controller
- HW configuration error
Off
- Connection established
SF
red
On
- FO transceiver not OK
- Configuration error
- Station name not assigned
- IP number not assigned
- FO attenuation < 2 dB
Off
OK
P1/2
yellow
On
- TP port’s 100 Mbps link is active.
Blinking
- PROFINET IO Flash/Blink identification.
Off
- No link
- FO RX power out of range

- 6 -
Quick Start
Take the GSDML file and fit it in the PLC configuration (Standard procedure of PROFINET engineering)
OR
Access via Internet browser with default IP address 0.0.0.0
OR
1: Connect Power PushPull to the power port of FreeCon
2: Connect Data (FO) PushPull to the data port of FreeCon
3: Start Config tool (FreeCon CFG) on your PC (which is connected to the same Profinet)
4: Click on IP-address to change it (the shown IP is a sample)
5: Push set buttom to adopt the new values
Actual Soft-/Firmware: www.weidmueller.de -> downloads -> software -> Industrial_Ethernet

- 7 -
Specifications
Technology
Standards
100BaseFX POF, PROFINET IRT
Interface
Fiber Ports
RJ45 port
100BaseFX POF ports (PROFINET PushPull
(V14) connector, POF)
100BaseT (PROFINET PushPull (V14) connector
RJ45)
Optical Fiber
100BaseFX (POF)
POF
Wavelength
650 nm
Max. TX
-2 dBm
Min. TX
-8,5 dBm
Min. RX Sensitivity
-23 dBm
Link Budget
15 dB
Typical Distance
50m*
* using P980/1000 POF cable (160dB/km)
Power
Input Voltage
18…30 VDC
Input Current
0,15 A/24VDC
Power throughput
2x24VDC/16A at 20°C
Connection
Power PushPull connector
Reverse Polarity Protection
Present
Physical Characteristics
Housing
IP65 protection, metal case
Dimensions
112x52x130mm
Weight
780g
Installation
Wall Mounting, 4x M4x10
Environmental Limits
Operating Temperature
-20 to 55°C
Storage Temperature
-40 to 70°C
Ambient Relative Humidity
5 to 95% (non-condensing)
Regulatory Approvals
Emission
EN 61000-6-4 Class A
ESD
RF
Burst
Surge
CRFI
EN61000-4-2 Level 3
EN61000-4-3 Level 3
EN61000-4-4 Level 3
EN61000-4-5 Level 3
EN61000-4-6 Level 3
Shock
IEC 60068-2-27
Hammer
IEC 60068-2-75
Vibration
IEC 60068-2-6

- 8 -
