weinor PergoTex II Manual

weinor PergoTex II / PergoTex II LED
Maintenance Instructions and Directions
for Use
PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 1/16
Pergola awning with electric drive
ENGLISH
Important guidelines for the end user.
Please read these instructions and observe their contents and warnings before using the
equipment for the first time.

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 2/16
Contents
1Notes on Maintenance Instructions and Directions for Use.....................................3
1.1 Depiction ............................................................................................................................... 3
1.1.1 Warnings............................................................................................................................3
1.1.2 Tips and recommendations ...............................................................................................3
1.1.3 Illustrations.........................................................................................................................3
1.1.4 Instructions requiring action...............................................................................................3
2Product description......................................................................................................4
2.1 Schematic diagram of the weinor PergoTex II Basic/ LED.................................................... 4
2.2 Schematic diagram of the weinor PergoTex II / LED ............................................................ 5
2.3 Description of construction and function ............................................................................... 6
3General safety notes ....................................................................................................7
3.1 Use ........................................................................................................................................ 7
3.2 Use in winds .......................................................................................................................... 8
3.3 Explanation of Beaufort classes ............................................................................................ 8
3.4 Use in rain ............................................................................................................................. 9
3.5 Important guidelines for the winter season............................................................................ 9
3.6 Automatic controls................................................................................................................. 9
3.7 General notes on the fabric ................................................................................................... 9
4Specific safety notes..................................................................................................10
4.1 Checking and monitoring the weinor PergoTex II ............................................................... 10
4.2 Operation............................................................................................................................. 10
4.3 Disassembly and disposal................................................................................................... 10
5Cleaning and care (By the user) .................................................................................11
5.1 Cleaning and maintenance work in the opening space of the weinor PergoTex II.............. 11
5.2 Cleaning .............................................................................................................................. 11
5.3 Foliage and foreign bodies .................................................................................................. 11
5.4 weinor PergoTex II care ...................................................................................................... 11
5.5 Cleaning the powder-coated aluminium parts ..................................................................... 12
5.5.1 In saltwater areas ............................................................................................................12
5.5.2 In non-saltwater areas .....................................................................................................12
5.6 Cleaning PVC fabrics .......................................................................................................... 12
6Maintenance and rectifying faults (by a suitable specialist retailer)..........................13
6.1 Maintenance........................................................................................................................ 13
6.2 Rectifying faults................................................................................................................... 14
7Retrofits.......................................................................................................................14
8Noise level...................................................................................................................14

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 3/16
1 Notes on Maintenance Instructions and Directions for Use
You have chosen a high-quality weinor product. Many years of experience and the use of
low-wear, corrosion-resistant metals and high-strength plastics vouch for the product.
Care and quality are fundamental principles that weinor applies in making its products
and which have made them so popular.
To ensure you enjoy our product for many years to come, please observe the following
guidelines and instructions.
weinor, quality from the very beginning!
1.1 Depiction
1.1.1 Warnings
The warnings differentiate between personal injury and damage to property. The signal word
"Danger" is used for personal injury, and "Caution" for property damage.
Immediate danger to life and limb!
Immediate danger to the product and environment!
1.1.2 Tips and recommendations
Highlights tips and information that make for correct use of the product.
1.1.3 Illustrations
Notes on item numbers can be found in the text in parentheses, e.g. (1).
1.1.4 Instructions requiring action
Instructions requiring action are written in bold print. If the instruction requiring action consists of
several individual steps, these have been numbered in the order in which they are to be carried
out, e.g. :
1.
Mount wall brackets
Determine position
Prepare and drill holes
DANGER
IMPORTANT

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 4/16
2 Product description
2.1 Schematic diagram of the weinor PergoTex II Basic/ LED
Figure 1: Schematic diagram of the weinor PergoTex II Basic/ LED
1
Transom 45x60 mm
4
Wall bracket
2
LED spotlight
5
Fabric
3
Transom 80x60 mm
6
Side channel

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 5/16
2.2 Schematic diagram of the weinor PergoTex II / LED
Figure 2: Schematic diagram of the weinor PergoTex II Basic/ LED
1
Post
6
Transom 80x60 mm
2
Guttering
7
Wall bracket
3
Post plate
8
Safety shield with guttering safety shield
4
LED spotlight
9
Fabric
5
Transom 45x60 mm
10
Side channel

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 6/16
2.3 Description of construction and function
The weinor PergoTex II is a sun and rain protection unit with a fabric that opens to protect
against the sun and rain.
The weinor PergoTex II can be fitted to any angle of pitch ranging between 0° and 25°
depending on the projection and installation height of the awning. However, optimum rain drain
can only be guaranteed with a pitch of more than 8°.
The wind resistance class 3 to wind strength 6 is applicable for the weinor PergoTex II.
When the awning is closed, the protective roof extensively protects the fabric against
weathering.
The weinor PergoTex II with LED provides an appealing outside lighting due to the LED
spotlights integrated in the transoms.
Only high-quality corrosion resistant materials are used in the weinor PergoTex II. The profiles
are made of extruded aluminium, end caps and other cast parts are made of aluminium. All
connecting parts, such as screws, are made of stainless steel.

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 7/16
3 General safety notes
Product and property damage
Risk of damage to the product and property due to improper use of the weinor PergoTex II.
Please read and observe the general safety notes contained in this section.
3.1 Use
•Your weinor PergoTex II has been made with great care; however, your weinor PergoTex II
is and always will be a sun and rain protection unit and must therefore be retracted
immediately during storms, snowfalls or strong winds (at and above wind strength 6). The
leafs on the glazing elements must be fully opened.
•The drive that is supplied as standard with the weinor PergoTex II has been designed to run
for a maximum of four minutes switch-on-time. If the running time is exceeded – e.g. by
frequently opening and retracting the awning – the internal thermo protector may
automatically switch off the motor. In this case, please wait until the motor has cooled down
(approx. 15 – 20 minutes depending on the outside temperature) and is ready for operation
again.
•If your weinor PergoTex II is fitted with a sun, wind or rain controller, the controls will switch
to automatic control after a loss of power depending on the type of controls. Awning systems
that had previously been set to manual operation may therefore run automatically after a loss
of power.
•If there is a risk of frost, or snow, the awning system must be switched from automatic to
manual control to prevent it from moving automatically. The system must not be used if there
is a risk of frost or snow.
•The PVC fabric must be retracted and the unit must not be set into operation if there is a risk
of frost or snow. The PVC fabric is not designed to withstand extreme snow load or
avalanching snow.
•The weinor PergoTex II can be opened to any position up to its maximum length.
•Reference to offset of staves in multi-section units
oManufacturing tolerances in the fabric could lead to staves in multi-section units being
minimally staggered in reverse.
oDifferent effects of solar radiation can lead to staggering of the staves as the fabrics
can expand due to exposure to the sun.
IMPORTANT

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 8/16
3.2 Use in winds
The weinor PergoTex II complies with the requirements of the wind resistance class shown on
the EC declaration of conformity printed in the instructions for assembly Instructions. The wind
resistance class achieved after assembly of the awning is heavily dependent on the type and
number of fixings used as well as the installation surface involved.
The weinor PergoTex II may only be used up to the wind resistance class specified by the
company fitting the awning. This may deviate from the wind resistance class stated by the
manufacturer.
3.3 Explanation of Beaufort classes
Wind resistance class
0
1
2
3
Beaufort
< 3
4
5
6
Maximum wind speed
in km/h
19,0
28,0
38,0
49,0
in m/s
5,4
7,9
10,7
13,8
in mp/h
12,6
18,3
25,3
32,2
Wind force
acc. to
the
Beaufort
scale
Description of
wind force
Effect on land
0
Calm
Calm, smoke rises vertically
1
Light air
Barely noticeable, smoke drift indicates wind direction, still
wind vanes
2
Light breeze
Leaves rustle, wind felt on face
3
Gentle breeze
Leaves and small twigs constantly moving, light flags
extended
4
Moderate breeze
Small tree branches move, loose paper lifted
5
Fresh breeze
Larger twigs and trees in leaf move, wind clearly audible
6
Strong breeze
Larger tree branches moving, telegraph masts whistle in the
wind
7
Near gale
Trees sway, resistance felt walking against wind
8
Gale
Large trees moving, shutters opening, twigs breaking off
trees, generally impedes progress
9
Storm
Broken branches, minor damage to houses, tiles and smoke
hoods are blown from roofs, garden furniture is blown over
and away, considerable difficulties walking
10
Severe storm
Trees are uprooted, tree trucks break, garden furniture
blown away, considerable damage to houses, seldom away
from the coast
11
Gale-force storm
Heavy gusts of wind, severe storm damage, severe forest
damage (Wind break), roofs are uncovered, cars are thrown
from their lane, thick walls are damaged, walking is
impossible; extremely rare away from the coast
12
Hurricane
Severest storm damage and devastation; extremely rare
away from the coast

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 9/16
3.4 Use in rain
To achieve the best rain drainage, the weinor PergoTex II should be set at an angle of more
than 8°.
3.5 Important guidelines for the winter season
The weinor PergoTex II is not designed to withstand extreme snowfalls or avalanching snow
loads. These have to be removed from the safety shield surface. As necessary, a snow guard
may need to be installed.
Figure 3: Removing avalanching snow
3.6 Automatic controls
A weinor PergoTex II must never be left unattended when open. The automatic controls may
fail under extreme conditions (e.g. power failures, defects, sudden storms). There is a risk that
the weinor PergoTex II could be damaged.
Our recommendation: if you vacate the area, switch the weinor PergoTex II from automatic
system control to manual control and leave it retracted.
3.7 General notes on the fabric
It is perfectly normal for a small amount of condensation to form on the fabric according to the
weather. This does not form grounds for complaint, non-acceptance or price reductions.
A PVC fabric which has been extended for a prolonged period can lose its tautness due to the
outside temperature and the effects of sun radiation.

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 10/16
4 Specific safety notes
Personal injury
Risk of personal injury due to improper use of the weinor PergoTex II.
Please read and observe the specific safety notes contained in this section.
4.1 Checking and monitoring the weinor PergoTex II
For personal safety, it is important that these safety notes are complied with and kept in a safe
place.
•The performance of a product depends on how it is assembled and installed.
•Check the awning system for signs of wear or damage.
•On motorised systems, check the electrical leads for damage.
•Do not use units that are in need of repair.
•The repair work may only be performed by trained personnel.
Guidelines for systems with automatic controls
•When performing maintenance or installation work, disconnect the weinor PergoTex II from
the power supply.
4.2 Operation
It must be ensured that no children or people unable to properly assess the risks of improper or
incorrect use are able to operate the weinor PergoTex II.
Remote controls must be kept out of reach of children.
The setting and operating instructions supplied separately by the manufacturer of the motor,
switches and controls must also be observed.
4.3 Disassembly and disposal
Always secure the awning system before dismantling and disposing of it. A suitably qualified
company should be engaged to perform this task.
DANGER

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 11/16
5 Cleaning and care (By the user)
5.1 Cleaning and maintenance work in the opening space of the weinor PergoTex II
There is a risk of motorised sun protection units being activated unintentionally. Always ensure
that the weinor PergoTex II is completely switched off (e.g. by disconnecting the fuse) before
performing maintenance and cleaning work (e.g. building cleaners).
If the weinor PergoTex II is operated by several users, a steering priority locking device must be
installed (controlled interruption of the power supply from outside), making it impossible to open
or retract the weinor PergoTex II at all.
5.2 Cleaning
The following points should be carried out at least twice a year, in spring and the autumn and
after longer downtime:
Intensive cleaning of the construction, in particular the side channel, gutters and fabric
Even a low-maintenance product needs to be cared for. For this reason, please carry out the
following maintenance and care tasks as required, once every spring, or whenever the awning
has not been in use for a long time. Performing these tasks will extend the operating life of your
awning system. Foliage and other foreign bodies as well as heavy dirt must be removed
immediately.
5.3 Foliage and foreign bodies
Foliage and other foreign bodies as well as heavy dirt
•in the guttering
•in the side gutters to the left and right of the side channels
•on the fabric, etc.
must be removed immediately.
In general, all the water drainage gutters on the roof and side channels should be regularly
checked for dirt and cleaned accordingly.
Any cleaning work not carried out may lead to the premature wear of gaskets and to
leaks.
Rainwater outlet holes
•in the posts
•in the gutter,
•in the guttering safety shield
must be kept unblocked at all times to ensure that water can drain off. It is recommended that
this is checked and cleaned accordingly twice a year, in spring and the autumn.
5.4 weinor PergoTex II care
Our recommendation:
Your weinor PergoTex II has been designed for low-maintenance. In the unlikely event that it
should fail, the service work should be performed by a specialist company.
If lubricants are required during the service work, use greases, sprays or liquids that contain
elements of Teflon, PTFE or comparable agents. For best, long-lasting effects, the lubricant
must be water- and dirt-repellent. The manufacturer's guidelines must be observed at all times.
Do not use lubricants that corrode plastics.

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 12/16
5.5 Cleaning the powder-coated aluminium parts
5.5.1 In saltwater areas
Damage to the product
Particularly in saltwater areas, there is a possibility that salt may disperse or accumulate on the
product.
Wash off any salt deposits at regular intervals or as required, but no less than twice a
year.
Recommendation: Call in a specialist company to do the work for you.
This is a good way to protect the aluminium parts and their surface from being
corroded by salty water.
5.5.2 In non-saltwater areas
Clean the aluminium parts at least once a year, and even more often if heavily soiled. To clean,
use clean water and add a few drops of pH-neutral or very slightly alkaline detergent.
5.6 Cleaning PVC fabrics
If the PVC-coated fabric is dirty, this impairs the durability, favours the formation of mould and
leads to an increased absorption of dirt.
Therefore, clean the PVC-coated fabric on a regular basis and/or in case of excessive pollution.
Product damage due to improper cleaning of the PVC fabrics!
Adhere to the following measures during cleaning to prevent product damage.
Clean PVC-coated fabrics only with plain water and a neutral, liquid cleaning agent.
Avoid straining the fabric material unnecessarily during the cleaning process. Always
adapt the concentration of the cleaning agent, the water temperature, as well as the
pressure to be applied to the degree of pollution of the fabric and only use soft
cleaning cloths (alternatively: hand brushes/ rotating brushes with soft bristles)
Never use solvents such as turpentine, saltpeter solution, acetate, aromatic
compounds, hydrocarbons (benzine/ diesel) or corrosive products (acids/strong
bases), as these can damage the surface of the fabric, impair the protection against
outside impacts or destroy the fabric material.
At the end of the washing operations, rinse the PVC-coated fabric with abundant water
in order to remove every trace of cleaning agent. The last rinse has to be carried out
with a diluted 2% solution of sodium hypochlorite.
IMPORTANT
IMPORTANT

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 13/16
6 Maintenance and rectifying faults (by a suitable specialist retailer)
6.1 Maintenance
Caution! Non-regular maintenance and unprofessional troubleshooting of malfunction
can impair the functioning and safety of the construction!
Have maintenance carried out regularly 1x per year by a specialist company!
Non-regular maintenance and unprofessional troubleshooting leads to loss of warranty
claims.
Inspect the weinor PergoTex II at regular intervals for signs of wear and tear or
damage to the cables and leads. Do not use units that are in need of repair.
- Check the electronics and control units
- Touch up/repair any damage to the paintwork on the aluminium profiles
- Check that all rubber gaskets and permanently elastic seals are correctly
positioned
- Check the grouting and repair if necessary
- Check all gaskets, seals, etc. between the PergoTex II and the on-site connections,
and repair as necessary
Inspect the weinor PergoTex II at regular intervals for signs of wear and tear or
damage to the cables and leads.
The following points should be carried out at least twice a year, in spring and the
autumn and after longer downtime:
- Greasing the pulley blocks in the front and wall support caps
- Checking the toothed belt's tension force
- Checking the end position of the motor
- Checking the fabric for visible damage
- Check the seal at the wall connection and the gutter and repair if necessary
In addition the following points should be carried out at least four times a year:
- General check that everything is working
- Checking the fabric tension force so that rainwater can be drained off properly
Do not operate or use any constructions that are in need of repair.
IMPORTANT

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 14/16
6.2 Rectifying faults
Error
Cause
Remedy
•System not running
•No power supply
•Drive incorrectly connected
•Motor is too hot and has
been shut down by the
thermo protector
•Connect to the mains
•Connect to the mains
(authorised personnel only)
•Wait approx. 15 to 20
minutes until the motor has
cooled down
•Squeaking
•Bearing surfaces not
lubricated
•Maintenance and care (fitter)
•Light off
•No power
•Establish a power supply
voltage
•Notify your retailer and
partner (rectification by
specialist)
7 Retrofits
Your weinor PergoTex II can also be retrofitted with automatic control units, e.g. with sun and
rain sensors and glazing elements. For more details, contact your specialist retailer,
who will be happy to advise you.
8 Noise level
During ascending and retraction, the noise level of the weinor PergoTex II has been measured at
below 70 dB(A).

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 15/16

PergoTex II/ PergoTex II LED
Maintenance Instructions and Directions for Use
Version 7
2020-05-08
We reserve the right to make technical changes
Item number
118702-0000
Page 16/16
weinor GmbH & Co. KG
Mathias-Brüggen-Straße 110
50829 Cologne (Germany)
www.weinor.com
Hotline: [phone]
Fax: [phone]
