Welch Allyn 88530 User manual

Assembly Instructions
Electrosurgical Unit/Smoke Evacuator Cart
Model No. 88530
1. Align the shipping box so that it is facing up as indicated by the labels.
2. Remove the cart by simply allowing it to roll out of the shipping box.
CAUTION: Do not use the handles to pick the cart up out of the ship-
ping box. The handles are not designed to accommodate
the full weight of the cart.
3. After removing the cart from the shipping box, lock the front two casters.
Face the Electrosurgical Unit toward the front of the cart and drop the cord
through the cutout located at the top of the cart.
4. Align the pins on the bottom of the unit with the corresponding holes
located on the top of the cart. (See Figure)
5. Next, remove the screws on the base of the cart in preparation of attaching
the Electrosurgical Unit.
6. Align the pivot hinges on the Smoke Evacuator with the screw holes on the
cart itself and fasten the unit to the cart. Verify the screws are tight but DO
NOT OVERTIGHTEN.
7. Remove the screws on the side of the Smoke Evacuator and then fasten
down the bracket of the drop hinge to the smoke unit. (See Figure)
8. Plug in the cord running from the Electrosurgical Unit to the receptacle at
the back of the Smoke Evacuator.
9. Finally, attach the power cord to the receptacle at the back of the Electro-
surgical Unit and then into a hospital-grade outlet to assume power.
NOTE: The controls for the Smoke Evacuator are located at the top front
of the Electrosurgical Unit cart for easy access.
Part Number 882541 Rev. A Printed in the USA
Assembly Instructions
Electrosurgical Unit/Smoke Evacuator Cart
Model No. 88530
1. Align the shipping box so that it is facing up as indicated by the labels.
2. Remove the cart by simply allowing it to roll out of the shipping box.
CAUTION: Do not use the handles to pick the cart up out of the ship-
ping box. The handles are not designed to accommodate
the full weight of the cart.
3. After removing the cart from the shipping box, lock the front two casters.
Face the Electrosurgical Unit toward the front of the cart and drop the cord
through the cutout located at the top of the cart.
4. Align the pins on the bottom of the unit with the corresponding holes
located on the top of the cart. (See Figure)
5. Next, remove the screws on the base of the cart in preparation of attaching
the Electrosurgical Unit.
6. Align the pivot hinges on the Smoke Evacuator with the screw holes on the
cart itself and fasten the unit to the cart. Verify the screws are tight but DO
NOT OVERTIGHTEN.
7. Remove the screws on the side of the Smoke Evacuator and then fasten
down the bracket of the drop hinge to the smoke unit. (See Figure)
8. Plug in the cord running from the Electrosurgical Unit to the receptacle at
the back of the Smoke Evacuator.
9. Finally, attach the power cord to the receptacle at the back of the Electro-
surgical Unit and then into a hospital-grade outlet to assume power.
NOTE: The controls for the Smoke Evacuator are located at the top front
of the Electrosurgical Unit cart for easy access.
Part Number 882541 Rev. A Printed in the USA
Assembly Instructions
Electrosurgical Unit/Smoke Evacuator Cart
Model No. 88530
1. Align the shipping box so that it is facing up as indicated by the labels.
2. Remove the cart by simply allowing it to roll out of the shipping box.
CAUTION: Do not use the handles to pick the cart up out of the ship-
ping box. The handles are not designed to accommodate
the full weight of the cart.
3. After removing the cart from the shipping box, lock the front two casters.
Face the Electrosurgical Unit toward the front of the cart and drop the cord
through the cutout located at the top of the cart.
4. Align the pins on the bottom of the unit with the corresponding holes
located on the top of the cart. (See Figure)
5. Next, remove the screws on the base of the cart in preparation of attaching
the Electrosurgical Unit.
6. Align the pivot hinges on the Smoke Evacuator with the screw holes on the
cart itself and fasten the unit to the cart. Verify the screws are tight but DO
NOT OVERTIGHTEN.
7. Remove the screws on the side of the Smoke Evacuator and then fasten
down the bracket of the drop hinge to the smoke unit. (See Figure)
8. Plug in the cord running from the Electrosurgical Unit to the receptacle at
the back of the Smoke Evacuator.
9. Finally, attach the power cord to the receptacle at the back of the Electro-
surgical Unit and then into a hospital-grade outlet to assume power.
NOTE: The controls for the Smoke Evacuator are located at the top front
of the Electrosurgical Unit cart for easy access.
Part Number 882541 Rev. A Printed in the USA
Assembly Instructions
Electrosurgical Unit/Smoke Evacuator Cart
Model No. 88530
1. Align the shipping box so that it is facing up as indicated by the labels.
2. Remove the cart by simply allowing it to roll out of the shipping box.
CAUTION: Do not use the handles to pick the cart up out of the ship-
ping box. The handles are not designed to accommodate
the full weight of the cart.
3. After removing the cart from the shipping box, lock the front two casters.
Face the Electrosurgical Unit toward the front of the cart and drop the cord
through the cutout located at the top of the cart.
4. Align the pins on the bottom of the unit with the corresponding holes
located on the top of the cart. (See Figure)
5. Next, remove the screws on the base of the cart in preparation of attaching
the Electrosurgical Unit.
6. Align the pivot hinges on the Smoke Evacuator with the screw holes on the
cart itself and fasten the unit to the cart. Verify the screws are tight but DO
NOT OVERTIGHTEN.
7. Remove the screws on the side of the Smoke Evacuator and then fasten
down the bracket of the drop hinge to the smoke unit. (See Figure)
8. Plug in the cord running from the Electrosurgical Unit to the receptacle at
the back of the Smoke Evacuator.
9. Finally, attach the power cord to the receptacle at the back of the Electro-
surgical Unit and then into a hospital-grade outlet to assume power.
NOTE: The controls for the Smoke Evacuator are located at the top front
of the Electrosurgical Unit cart for easy access.
Part Number 882541 Rev. A Printed in the USA

Electrosurgical Unit
Smoke Evacuator
Pivot Hinge
Drop Hinge
Electrosurgical Unit
Smoke Evacuator
Pivot Hinge
Drop Hinge
Electrosurgical Unit
Smoke Evacuator
Pivot Hinge
Drop Hinge
Electrosurgical Unit
Smoke Evacuator
Pivot Hinge
Drop Hinge
