Welch Allyn SureTemp Plus 690 Series Manual

SureTemp®Plus
690 and 692 Series
Directions for use

ii Welch Allyn SureTemp
© 2018 Welch Allyn, Inc. To support the intended use of the product described in this
publication, the purchaser of the product is permitted to copy this publication, for internal
distribution only, from the media provided by Welch Allyn.
Welch Allyn assumes no responsibility for any injury, or for any illegal or improper use of
the product, that may result from failure to use this product in accordance with the
instructions, cautions, warnings, or indications for use published in this manual.
Welch Allyn is a registered trademark of Welch Allyn, Inc.
Patent information
For patent information, please visit www.welchallyn.com/patents.
Welch Allyn Technical Support:
http://www.welchallyn.com/about/company/locations.htm
106701 (CD)
Material No. 412895
80022663 Ver. A
Revision date: 2018-05
www.welchallyn.com
901053 ELECTRONIC THERMOMETER
For all GTIN numbers, see the list of “SureTemp Plus Global Trade Item
Numbers (GTIN)” on page 27.
Welch Allyn, Inc.
4341 State Street Road
Skaneateles Falls, NY 13153 U.S.A.
Regulatory Affairs Representative
Welch Allyn Limited
Navan Business Park
Dublin Road, Navan
County Meath, Republic of Ireland

Directions for use iii
TABLE OF CONTENTS
Conforms With ........................................1
Symbols and Descriptions ................................1
Safety and Warnings ....................................3
Introduction ...........................................5
SureTemp Plus Model Comparison Chart ....................6
Indications/Contraindications..............................6
Latex Statement .......................................7
Parts and Features......................................7
Button Functions .......................................8
Set-Up ...............................................8
Display Indicators .....................................10
Oral Temperature Measurement..........................12
Axillary Temperature Measurement .......................13
Rectal Temperature Measurement ........................14
Monitor Mode Temperature Measurement .................16
Instrument Security ....................................17
Maintenance .........................................18
Cleaning and Disinfection ...............................18
Disposal .............................................19
Performance and Technical Specifications ..................20
Guidence and Manufacturer’s Declaration ..................21
EMC compliance ...................................21
Emissions and Immunity Information ...................22
Replacement Parts and Accessories .......................25
Accessories List ......................................26
SureTemp Plus Global Trade Item Numbers (GTIN) ...........27
Service..............................................27
Welch Allyn Service Policy ............................27
Contacting Welch Allyn ..............................28
Limited Warranty ......................................28
Service Centers .......................................29

iv Welch Allyn SureTemp Plus

Directions for use 1
Conforms With
Symbols and Descriptions
IEC/UL/CSA/EN 60601-1
Australian Communications and Media Authority (ACMA) Radio
Compliance Mark (RCM)
Consult directions for use (DFU). A copy of the DFU is available on this website.
A printed copy of the DFU can be ordered from Welch Allyn for delivery within 7
calendar days.
Type BF Applied Part
Fragile
Temperature Limit
Humidity Limitation
Internally Powered Alkaline Battery - AA 1.5V
IPXØ Not protected against the ingress of water.
Does not contain natural rubber latex.
Keep Dry
Do not re-use, Single use device
Recyclable
Separate collection of Electrical and Electronic Equipment. Do not dispose as
unsorted municipal waste.
Product Identifier.
Reorder Number
Global Trade Item Number
+5
-
95%
15%

2Welch Allyn SureTemp Plus
Meets essential requirements of European Medical Device Directive 93/42/EEC
Intertek Testing Laboratories Approved (ETL)
Manufacturer
Serial Number

Directions for use 3
Safety and Warnings
WARNING No modification of this equipment allowed.
WARNING Patient injury risk. Prior to taking a temperature, instruct the patient
not to bite down on the probe as patient injury and damage to the probe may
result.
WARNING Patient injury risk. Use only Welch Allyn single-use disposable probe
covers. A new probe cover needs to be used with each new temperature
taken. Never take a temperature measurement without a single-use probe cover
securely attached. Failure to use a probe cover can cause patient discomfort from
a heated probe, patient cross-contamination, and inaccurate temperature
readings.
WARNING Patient injury risk. Inaccurate measurement risk. Oral/axillary probes
(blue ejection button at top of probe) and blue removable probe wells are used for
taking oral and axillary temperatures only. Rectal probes (red ejection button) and
red removable probe wells are used for taking rectal temperatures only. Use of
the incorrect removable probe well could result in patient cross-contamination.
Use of the probe at the wrong site will result in temperature errors.
WARNING Patient injury risk. When taking rectal temperatures, insert the probe
tip only 5/8 inch (approximately 1.5 cm) inside the rectum of adults and only 3//8
inch (approximately 1 cm) inside the rectum of children to avoid the risk of bowel
perforation.
WARNING Inaccurate measurement risk. Never take an axillary temperature
through the patient’s clothing. Carefully place the probe in the axilla, avoiding
contact with other objects or material.
WARNING Patient injury risk. Continuous measurement durations of 3 minutes
at the oral and rectal sites and 5 minutes at the axillary site are recommended for
accurate measurement. Do not continuously measure beyond 10 minutes in any
mode.
WARNING To ensure patient safety and temperature measurement accuracy,
use only accessories and supplies recommended or supplied by Welch Allyn.
WARNING Never use a damaged temperature probe. The thermometer consists
of high-quality precision parts and should be protected from severe impact or
shock. Do not use the thermometer if you notice any signs of damage to the
probe or instrument. If the thermometer probe is dropped or damaged, remove it
from use and have it inspected by qualified service personnel.
WARNING Equipment is not suitable for use in the presence of a flammable
anesthetic mixture with air or with oxygen or nitrous oxide.
WARNING Inaccurate measurement risk. For rectal measurements, apply a thin
layer of lubricant to probe cover, if necessary, for patient comfort. Use of
excessive lubricant may affect reading accuracy.
WARNING Inaccurate measurement risk. To ensure optimal accuracy, always
confirm that the correct mode and site are selected.

4Welch Allyn SureTemp Plus
Caution Liquids can damage electronics inside the thermometer. Prevent
liquids from spilling on the thermometer. If liquids are spilled on the
thermometer, dry off the thermometer with a clean cloth. Check for proper
operation and accuracy. If liquids possibly entered the thermometer, remove the
thermometer from use until it has been properly dried, inspected, and tested by
qualified service personnel.
Caution Welch Allyn recommends that batteries are removed for long term
storage since alkaline batteries can deteriorate and leak over extended periods of
time, and possibly cause damage to the thermometer.
Caution Do not autoclaveany component of this product. Please note the
cleaning procedures described on page 18 of this manual.
Caution Do not use this instrument for any purpose other than that specified in
this booklet. Doing so will invalidate the instrument’s warranty.
Caution This thermometer complies with current required standards for
electromagnetic interference and should not present a problem to other
equipment nor is it effected by other devices. As a precaution, avoid using this
device in close proximity to other equipment.
Caution Inaccurate measurement risk. Patient activites such as strenuous
exercise, ingesting hot or cold liquids, eating, chewing gum or mints, brushing
teeth, or smoking may effect oral temperature measurements for up to 20
minutes.
Caution Probe covers are disposable, nonsterilized, and single-use. Probes are
also nonsterilized. Do not autoclave probes and probe covers. Ensure that probe
covers are disposed of according to facility requirements or local regulations.

Directions for use 5
Introduction
Please follow the operating and maintenance instructions provided in this manual to
ensure years of accurate and reliable service. Please read these instructions thoroughly
before using the instrument, and then store these instructions in a safe place for future
reference.
The Welch Allyn SureTemp Plus is a portable thermistor thermometer used for accurately
measuring body temperatures at oral, axillary, or rectal sites. The device measures
temperature by default in predictive (Normal) mode, during which it uses a predictive
algorithm to calculate patient temperature. If you cannot correctly measure the patient’s
temperature in Normal Mode, the unit will automatically enter Monitor (Direct) Mode.
Normal body temperature is a range, which varies from person to person and is
influenced by factors such as time of day and an individual’s level of activity, ingested
medications, age, and gender. A person’s normal temperature tends to decrease with
age.
The following table shows that ranges of normal also vary by site. Do not directly compare
measurements from different sites.
This booklet provides informative tips and instructions for using the SureTemp Plus model
690 and model 692 thermometers. The chart on the following page provides details about
the differences between these SureTemp Plus instruments.

6Welch Allyn SureTemp Plus
SureTemp Plus Model Comparison Chart
This manual describes features found in SureTemp Plus model 690 and 692
thermometers. Certain features are not available to users of the model 690 thermometer.
Indications/Contraindications
The Welch Allyn SureTemp Plus thermometer measures patient’s temperature in the oral,
axillary, and rectal body sites of adult, pediatric, and newborn patients. The device is not
designed, sold, or intended for use except as indicated.
SureTemp Plus Model
690
SureTemp Plus Model
692
Probe Cover Storage XX
F/C Conversion XX
Last Temperature Recall XX
Monitor Mode XX
Detachable Probe XX
Oral / Axillary / Rectal
Modes on Each
Thermometer
XX
Color-Coded Removable
Probe Well
XX
Wall-Holder Standard X
Pulse Timer X
Backlight X
Security (Electronic) X
Configurable On-Screen
Labeling for
Identification of
Instrument
X
Sold in U.S./Canada XX
Sold Internationally XX
Instrument Warranty 2 years 3 years
Removable Probe Well 90 days 90 days
Probe Warranty 1 year 1 year

Directions for use 7
Latex Statement
The components of the SureTemp Plus device that could contact the user or patient were
not made with natural rubber latex. This includes all items that could be contacted during
normal operation, and all other functions, such as user maintenance and cleaning, as are
defined in the Directions for use.
No internal components are known to be made with natural rubber latex.
Parts and Features
You can find the serial number of your device on a label affixed to the rear housing inside
the unit’s probe cover storage compartment. Please note the parts of your Welch Allyn
SureTemp Plus thermometer as shown below:
Thermometer
LCD Display
Probe
Ejection Button (blue or red)
Removable Probe Well
(blue or red)
Latching Probe
Connector
Battery Door/Probe Cover
Storage Compartment
C/F (Celsius/
Fahrenheit)
Button
Pulse Timer Button/
Monitor Mode
(692 Only)
Mode
Selection
Button
Recall Button
Box of Probe Covers

8Welch Allyn SureTemp Plus
Button Functions
Set-Up
ASSEMBLING THE UNIT
Your SureTemp Plus thermometer is shipped to you with three 1.5V AA batteries installed.
1. Install the oral/axillary probe (blue ejection button) or optional rectal probe (red Ejec-
tion button) by inserting the latching probe connector on the end of the coiled cord
into the unit’s plug receptacle. Ensure that the connector snaps into place. The LCD
will illuminate for approximately 7 seconds and will then turn off.
2. Connect the appropriate removable probe well to the thermometer. Note that the cut-
out in the probe well fits over the probe cord strain relief. Ensure that the removable
probe well “snaps” into position and is completely seated to the thermometer. Place
the probe into the well.
3. Insert the box of Welch Allyn disposable probe covers into the probe cover storage
holder. To open the box of probe covers, remove and discard the tear-away corner. You
will see the ends of the probe covers in the box.
MOUNTING THE UNIT
Mount the wall-mount bracket in a location such as an interior wall or wall divider so that
the thermometer remains at ambient room temperature. Mounting the unit on an
Buttons Procedure
C/F Press and release the C/F (Celsius/Fahrenheit) button to toggle
between temperature scales any time a temperature is displayed
on the LCD.
Pulse Timer/Monitor
Mode (692 Only)
Press and release the Pulse Timer/Monitor Mode button to
activate the timer. Audible beeps sound at 0, 15, 30, 45, and 60
seconds. The timer turns off automatically after 60 seconds. You
can stop the timer at any time by pressing the Pulse Timer/
Monitor Mode button or by removing the probe from the probe
well.
For Monitor Mode, press and release the Pulse Timer button
after you have withdrawn the probe from the probe well to
switch the device into Monitor Mode.
Mode Selection Press and release the Mode Selection button after you have
withdrawn the blue probe from the probe well to change the
current measurement site to Oral, Adult Axillary, or Pediatric
Axillary. The selected measurement site is displayed by a
flashing body site icon. Note that no other measurement sites
are available when using the red probe in the Rectal Mode.
Recall Press and release the Recall button when the display is blank to
recall the last completed predicted temperature. The LCD will
display the recalled temperature for five seconds along with the
battery icon, temperature scale, mode selection, and probe-
position icon (if applicable).

Directions for use 9
uninsulated exterior wall, in an area directly hit by sunlight, above heat radiators or
powered equipment (including computers and lights), or below air conditioning outlets is
not recommended.
Proper mounting of the unit will prevent tangling of the probe cord with other equipment
at the patient’s bedside.
1. Mount the instrument
so that all other objects
are no closer than 4
inches (10.25 cm) from
the sides and bottom
of the unit.
2. Mount the wall mount
a maximum of 48
inches (122 cm) from
the floor.
3. Install the wall mount
to allow at least 12
inches 30.5 cm)
clearance on top of the
instrument. This
provides ease of
removing and installing
the probe and probe
well or installing probe
covers onto the probe.

10 Welch Allyn SureTemp Plus
Display Indicators
Instrument Malfunction
The device is not working properly. Contact Welch Allyn’s
Customer Service Department for assistance.
Broken Probe
The probe is broken. Replace probe or contact Welch Allyn’s
Customer Service Department for assistance.
Loss of Tissue Contact
The probe has lost contact with the patient’s tissue. The icon
will disappear once proper contact is achieved. The icon will
later reappear at the end of the temperature measurement.
It is recommended that you take a new temperature reading.
ID Field
This is a seven-character field that allows customized
identification of the instrument via user-selected letters and
numbers. See the Model 690/692 Service Manual for set-up
instructions.
Walking Segments
The dark bar will move around the display when the
thermometer is in the process of taking a temperature.
Oral Mode
This flashing icon and/or word are displayed to show that the
Oral Mode is selected.
Adult Axillary Mode
This flashing icon and/or words are displayed to show that
the Adult Axillary Mode is selected.
Ped Axillary Mode
This flashing icon and/or words are displayed to show that
the Pediatric Axillary Mode is selected.

Directions for use 11
Rectal Mode
This flashing icon and/or word are displayed to show that the
Rectal Mode is selected.
Monitor Mode
This icon is displayed while in Monitor Mode. Monitor Mode
is used for continuous temperature monitoring when difficult
situations prevent accurate temperatures in the Normal
Mode. For oral and rectal sites, three minutes of continuous
monitoring is recommended for an accurate temperature
reading. For axillary sites, five minutes of continuous
monitoring is recommended.
Patient Temperature Exceeds Upper Measurement
Range Limit of 110.0 °F (43.3 °C)
Patient Temperature Is Lower than Measurement Range
Limit of 80.0 °F (26.7 °C)
Ambient Temperature Exceeds Upper Measurement
Range Limit of 104.0 °F (40.0 °C)
Ambient Temperature Is Lower than Measurement
Range Limit of 50.0 °F (10.0 °C)
Pulse Timer
This icon indicates that the device is in the Pulse Timer
Mode.
Low Battery
A single flashing segment appears on the battery symbol.
Normal operation is not affected. Replace the batteries.
Dead Battery
An open battery symbol remains on the LCD and the device
will not operate. Replace the batteries.
Security Mode
The instrument is in Security Mode. Return the thermometer
to the wall holder to resume normal operation See page 17
to set the instrument in Security Mode (Model 692 only).

12 Welch Allyn SureTemp Plus
Oral Temperature Measurement
Using Probe with Blue Ejection Button and Blue Probe Well
When used correctly, the SureTemp Plus thermometer accurately measures an oral
temperature in approximately 4–6 seconds. The ability of the SureTemp Plus
thermometer to take an accurate oral temperature requires correct user technique.
TAKING AN ORAL TEMPERATURE
1. Ensure that the oral probe (blue ejection button) and the blue probe well are
installed.
2. Holding the probe handle with your thumb and two fingers on the indentations of the
probe handle, withdraw the probe from the probe well.
3. Verify that the oral model icon is selected by observing the flashing head icon on
the instrument’s display. If this icon is not flashing, press the Mode Selection
button until the head icon appears.
4. Load a probe cover by inserting the probe into a probe cover and pressing the
probe handle down firmly. The probe handle will move slightly to engage the probe
cover.
.
5. With the Oral Mode indicator flashing, quickly place the
probe tip under the patient’s tongue on either side of the
mouth to reach the rear sublingual pocket. Have the
patient close his/her lips around the probe.
6. Hold the probe in place, keeping the tip of the probe in
contact with the oral tissue throughout the measurement
process. Rotating “walking” segments appear on the
display, indicating that measurement is in progress.
7. The unit will beep three times when the final temperature
is reached. The measurement site, temperature scale, and
patient temperature will display on the LCD. The final temperature will remain on the
display for 30 seconds.
8. If you cannot correctly measure the patient’s temperature in Normal
Mode, the unit will automatically enter Monitor Mode. In this mode,
measurement time is extended. Either repeat the temperature
measurement in Normal Mode in the opposite sublingual pocket or
keep the probe in place for three minutes in Monitor Mode. The
thermometer will not beep to indicate a final temperature. Record the temperature
WARNING Do not take a patient’s temperature without using a Welch Allyn
disposable probe cover. Doing so can cause patient discomfort, patient cross
contamination, and erroneous temperature readings.
WARNING Use only Welch Allyn probe covers. The use of other
manufacturer’s probe covers or no probe cover may produce temperature
measurement errors and/or inaccuracy.

Directions for use 13
before removing the probe from the site, as the temperature reading is not
maintained in memory.
9. After the temperature measurement is complete, remove the probe from the
patient’s mouth. Eject the probe cover by firmly pressing the ejection button on the
top of the probe.
10. Return the probe to the probe well. The LCD display will go blank.
Axillary Temperature Measurement
Using Probe with Blue Ejection Button and Blue Probe Well
When used correctly, the SureTemp Plus thermometer accurately measures an axillary
temperature for pediatric patients (ages 17 and younger) in approximately 10–13 seconds
and for adult patients (ages 18 and older) in approximately 12–15 seconds.
PLACING THE THERMOMETER INTO AXILLARY MODE
1. Ensure that the axillary probe (blue ejection button) and the blue probe well are
installed.
2. Holding the probe handle with your thumb and two fingers on the indentations of the
probe handle, withdraw the probe from the probe well.
3. Verify that the axillary mode is selected by observing
the correct flashing axillary icon on the instrument’s
display. If this icon is not flashing, press the Mode
Selection button to select the Adult Axillary or
Pediatric Axillary icon is displayed.
WARNING Patient injury risk. Do not exceed the recommended temperature
measurement durations in Direct Mode. Continuous measurement durations of
3 minutes at the oral and rectal sites and 5 minutes at the axillary site are
recommended for accurate measurement. Do not continuously measure
beyond 10 minutes in any mode.
Caution Patient actions may interfere with accurate oral temperature
readings. Ingesting hot or cold liquids, eating food, chewing gum or mints,
brushing teeth, smoking, or performing strenuous activity may affect
temperature readings for up to 20 minutes after activity has ended.
WARNING Do not take a patient’s temperature without using a Welch Allyn
disposable probe cover. Doing so can cause patient discomfort, patient cross
contamination, and erroneous temperature readings.
Caution To ensure optimal accuracy, always confirm that the correct axillary
mode is selected.
Caution After a temperature is taken and the probe is returned to the probe
well, the instrument reverts to the original measurement site mode.
Adult Axillary
Mode Icon
Pediatric Axillary
Mode Icon

14 Welch Allyn SureTemp Plus
TAKING AN AXILLARY TEMPERATURE
1. Load a probe cover by inserting the probe into a probe cover and pressing the probe
handle down firmly. The probe handle will move slightly to engage the probe cover.
2. With the correct axillary mode indicator flashing, lift the patient’s arm so that the
entire axilla is easily seen. Place the probe as high as possible in the axilla. Do not
allow the probe tip to come into contact with the patient until the probe is placed in
the measurement site. Before this, any contact between the probe tip and the tissue
or other material may cause inaccurate readings.
3. Verify that the probe tip is completely surrounded by axillary tissue and place the arm
snugly at the patient’s side. Hold the patient’s arm in this position and do not allow
movement of the arm or probe during the measurement cycle. Rotating “walking”
segments appear on the display, indicating that measurement is in progress.
4. The unit will beep three times when the final temperature is reached. The
measurement site, temperature scale, and patient temperature will display on the
LCD. The final temperature will remain on the display for 30 seconds.
5. If you cannot correctly measure the patient’s temperature in Normal
Mode, the unit will automatically enter Monitor Mode. In this mode,
measurement time is extended. Either repeat the temperature
measurement in Normal Mode in the opposite axilla or keep the probe
in place for five minutes in Monitor Mode. The thermometer will not beep to indicate
a final temperature. Record the temperature before removing the probe from the site,
as the temperature reading is not maintained in memory.
6. After the temperature measurement is complete, remove the probe from the
patient’s axilla. Eject the probe cover by firmly pressing the ejection button on the top
of the probe.
7. Return the probe to the probe well. The LCD display will go blank.
Rectal Temperature Measurement
Using Probe with Red Ejection Button and Red Probe Well
When used correctly, the SureTemp Plus thermometer accurately measures rectal
temperature in approximately 10–13 seconds.
TAKING A RECTAL TEMPERATURE
WARNING Do not take an axillary temperature through patient’s clothing.
Direct contact between patient’s skin and the probe is required.
WARNING Use only Welch Allyn probe covers. The use of other
manufacturer’s probe covers or no probe cover may produce temperature
measurement errors and/or inaccuracy.
WARNING Long-term continuous monitoring beyond five minutes is not
recommended in the Axillary Mode.
WARNING Probe contact with electrodes, bandages, etc., poor tissue
contact, taking a temperature over clothing, or prolonged exposure of axilla
to ambient air can cause inaccurate temperature readings.

Directions for use 15
1. Ensure that the rectal probe (red ejection button) and the red probe well are
installed. The instrument will only operate in Rectal Mode when the red rectal probe
and probe well are installed.
2. Holding the probe handle with your thumb and two fingers on the indentations of the
probe handle, withdraw the probe from the probe well.
3. Observe the flashing lower-body icon on the unit’s display. Load a probe cover by
inserting the probe into a probe cover and pressing the probe handle down
firmly. The probe handle will move slightly to engage the probe cover.
4. With the Rectal Mode indicator flashing, separate the patient’s buttocks with one
hand. Using the other hand, gently insert the probe only 1.5 cm (5/8 in.) inside the
rectum (less for infants and children). The use of a lubricant is optional.
5. Tilt the probe so that the tip of the probe is in contact with tissue. Keep the hand
separating the buttocks in place, and hold the probe in place throughout the
measurement process. Rotating “walking” segments appear on the display,
indicating that measurement is in progress.
6. The unit will beep three times when the final temperature is reached. The
measurement site, temperature scale, and patient temperature will display on the
LCD. The final temperature will remain on the display for 30 seconds.
7. If you cannot correctly measure the patient’s temperature in Normal
Mode, the unit will automatically enter Monitor Mode. In this mode,
measurement time is extended. Either repeat the temperature
measurement in Normal Mode or keep the probe in place for three
minutes in Monitor Mode. The thermometer will not beep to indicate a
final temperature. Record the temperature before removing the probe from the site,
as the temperature reading is not maintained in memory.
8. After the temperature measurement is complete, remove the probe from the
patient’s rectum. Eject the probe cover by firmly pressing the ejection button on the
top of the probe.
9. Return the probe to the probe well. The LCD display will go blank.
WARNING Cross contamination or nosocomial infection risk. Thorough hand-
washing greatly reduces the risk of cross-contamination and nosocomial
infection.
WARNING Do not take a patient’s temperature without using a Welch Allyn
disposable probe cover. Doing so can cause patient discomfort, patient cross
contamination, and erroneous temperature readings.
WARNING Use only Welch Allyn probe covers. The use of other
manufacturer’s probe covers or no probe cover may produce temperature
measurement errors and/or inaccuracy.
WARNING Patient injury risk. When taking rectal temperatures, insert the
probe tip only 5/8 inch (approximately 1.5 cm) inside the rectum of adults and
only 3/8 inch (approximately 1 cm) inside the rectum of children to avoid the
risk of bowel perforation.
WARNING Long-term continuous monitoring beyond three minutes is not
recommended in Rectal Mode.

16 Welch Allyn SureTemp Plus
10. Wash your hands.
Monitor Mode Temperature Measurement
Using Probe with Blue Ejection Button (Oral/Axillary) or Red Ejection Button
(Rectal)
Monitor Mode continuously displays the temperature of the probe for as long as the
probe remains in place at the measurement site and remains within the operating patient
temperature range. The patient’s oral and rectal temperature will reach final equilibrium in
approximately three minutes in the Monitor Mode. Axillary temperature will reach
equilibrium in approximately five minutes in the Monitor Mode.
TAKING A TEMPERATURE USING MONITOR MODE
1. Ensure that both the appropriately colored probe and matching probe well for the
intended measurement site (oral/axillary or rectal) are installed.
2. Holding the probe handle with your thumb and two fingers on the indentations of the
probe handle, withdraw the probe from the probe well.
3. Load a probe cover by inserting the probe into a probe cover and pressing the probe
handle down firmly. The probe handle will move slightly to engage the probe cover.
4. For Model 692, press and release the Pulse Timer / Monitor Mode
button after you have withdrawn the probe from the probe well to
switch the device into Monitor Mode. The Monitor Mode indicator
appears on the LCD.
5. For Model 690, take the patient’s temperature using the normal Oral, Rectal, Pediatric
Axillary, or Adult Axillary Mode as previously described.
a. Continue to hold the probe in position after the temperature is displayed.
b. Press the Mode Selection button until the Monitor Mode indicator
appears on the LCD.
WARNING Washing hands greatly reduces the risk of cross-contamination
and Nosocomial Infection.
Caution Monitored temperatures are not stored in memory for recall.
WARNING Do not take a patient’s temperature without using a Welch Allyn
disposable probe cover. Doing so can cause patient discomfort, patient
cross contamination, and erroneous temperature readings.
WARNING Use only Welch Allyn probe covers. The use of other
manufacturer’s probe covers or no probe cover may produce temperature
measurement errors and/or inaccuracy.
WARNING The unit will automatically enter Monitor Mode if the probe is
withdrawn from the probe well and is not replaced within 60 seconds of
inactivity.
