Wellis Eclipse-A17 User manual

T AINS ALL TION GUIDE
INFRARED SAUNA
WS00156
Eclipse-Hemlock infrared sauna
INSTALLATION GUIDE 2
Eclipse-Hemlock infrarot sauna
AUFBAUANLEITUNG 17
Sauna infrarouge Eclipse-Hemlock
GUIDE D’INSTALLATION 33
Eclipse-Hemlock infravörös szauna
TELEPÍTÉSI ÚTMUTATÓ 49
EN
DE
FR
HU WS00156
EclipsE-HEmlock
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

EN
2/16
PREFACE
Thank you very much for purchasing our product.
Please read this manual carefully before assembling and save it afterwards. Please write down the control
box serial number of the cabin as this number will be required in case of repair or order of spare parts.
ATTENTION
Installation and repair should only be done by a qualified electrician!
Check power supply rating and make sure the grounded outlet is correctly connected before installation.
Use original parts only. Do not share the outlet with any other appliances.
When not in use, turn off the cabin's power unit.
Locate your cabin indoors and on a flat, level and dry surface.
DANGER
Heaters shall not be subjected to water spray; shower heads shall not be installed within the infrared cabin.
Covering the radiator causes a fire hazard due to overheating. Do not cover the heaters !
Keep flammable or easily combustible materials/objects (eg.towels) away from the radiator at all times.
Do not touch the radiator during and shortly after use as a burning hazard exists due to hot parts.
The light bulb heats in use. If the bulb needs to be changed, unplug the cabin and let the bulb cool down
before changing it.
Should the electrical connection get damaged, it must be replaced-either by the manufacturer or by a
licensed electrician!
WARNING
If you suffer from illness or other health-related problems, especially heart conditions or circulatory
disturbances or if you take medication, you should consult a doctor before using the infrared cabin.
Children and frail persons should never be in the cabin without supervision.
If you feel uncomfortable while using the infrared cabin, stop immediately and consult with your doctor.
Never go to a hot infrared cabin if you have taken alcohol, strong medicines or narcotics.
Technical data
Model
Cabin material
Length
Width(depth)
Height
Voltage
Radiators Type
Total output
Back panel
Side panel
Calves
Eclipse-A17
Regular hemlock
2043 mm
2008mm
2055 mm
230volt 50Hz
Ruby halogen tube radiator
2800W 12.2 A
350W x 3
350W x 3
350W x 2
3/16
Cabin Individual parts (variations possible)
NO NAME Q'TY
1
3
4
6
8
10
1
1
1
1
1
1
11 1
12
1
13
4
Box No
1
1
1
1
2
2
2
4
2 1 2
5 1 3
912
1
14
4
712
2
EN
Back panel 1(1988*1190*43.5mm)
Back panel 2(1988*890*43.5mm)
connecting bar 1 (1908*90*20mm)
Side panel 2 (1995.5*890*48mm)
Side panel 1 (1995.5*1190*48mm)
connecting bar 2 (1270*90*20mm)
Upright column 2 (2050*90*40mm)
Upright column 1 (2050*90*40mm)
PARTS LIST
1
4
7
8
9
13 11
12
5
14
24
10
15
22
23
21
20
19
18
17
16
2
3
6
25
26
27
28
29
31
36
30
32
3334
35
Door cross beam(lower,1863*60*40mm)
Side cross beam(lower,1820*60*40mm)
Front upright column (2050*90*40mm)
Front (*651*6mm) glass 1920
Front (with hole, *651*6mm) glass 1920
Side glass 1920(*883*6)
2 3
All manuals and user guides at all-guidesbox.com

NO NAME Q'TY
15
17
18
20
22
24
1
1
2
2
1
1
1
25
2
26
1
27
2
Box No
2
2
2
3
1
1
2
3
2
16
12
19
13
23
11
1
28
2
21
13
2
4/16
EN
30
1
31
1
32
1
33
4
2
2
2
29
11
1
34
35
36
2
3
2
2
Door cross beam(upper,1863*105*40mm)
Side cross beam (upper,1941*90*40mm)
Top decorative bar 1 (1959*30*30mm)
Top decorative bar 2 (1856*30*30mm)
Top panel 1 (1958*967*40.5mm)
Top panel 2 (1958*967*40.5mm)
Bench support panel 1(1000*925*48mm)
Bench support panel 2(925*600*48mm)
Calves guardrail (670*250*43mm)
Bench support panel 3(1910*90*40mm) with hole,
Bench support panel 4(1273*90*40mm) with hole,
Bench support panel 5(1910*90*40mm)
Bench surface panel 1(1910*600*33mm)
Bench surface panel 2(1910*400*33mm)
Bench surface panel 3(1267*600*33mm)
Side guardrail (1861*643*54mm)
Back guardrail (1958*643*54mm)
Floor panel (966*890*33mm)
Door handle (300*40*45mm)
Glass door (1888*572*6mm)
MDF cover (1958*967*3mm,1958*947*3mm)
Side upright column 1900*90*40 ( mm)
5/16
ASSEMBLE INSTRUCTIONS
Assemble tips
Tools
Spiral drill (kit)
Screwdriver (kit)
Allen Wrench (kit)
Spirit level
Tape measure Electric drill
Cutter
Pencil
Hammer
Stepladder
Hardware parts (variations possible)
Please remove transport packaging and inspect that your infrared cabin has been delivered complete and
intact before beginning assemble.
A least 2 persons are required for assemble of the cabin
Please check the countersink and hole diameter of the drill holes to avoid damaging the wood..
The minimum room height required for installation is 2175mm
28x 70x
Φ4*50
Φ4*40
2x
Φ6*60
22x
Φ4*60
EN
Rubber
22m
Strip Glass clip
1x 12x
Mixed Screw
4 5
All manuals and user guides at all-guidesbox.com

6/16
ASSEMBLE INSTRUCTIONS
Assemble steps
(3)(4)
EN
4-Φ4*40
1
2
10-Φ4*50
3
4-Φ4*40
4
5
(1) (2)
8-Φ4*50
6
7/16
EN
ASSEMBLE INSTRUCTIONS
Assemble steps
18-Φ4*60
87
9
10
11
12
16 17
13
15
14 X2
(7)(8)
(5) (6)
X4
X1 X5
6 7
All manuals and user guides at all-guidesbox.com

8/16
EN
ASSEMBLE INSTRUCTIONS
Assemble steps
16-Φ4*40
4-Φ4*40
Note: connecting bar(No.13 & No.14)
should be 40mm lower than the
top of four walls.
40mm
19 18X2
X2
20
21
(9)
(10)
9/16
EN
ASSEMBLE INSTRUCTIONS
Assemble steps
22
14-Φ4*50 Make sure the temperature sensor should be out about
2cm from the silicon pipe
（pipe/3cm+sensor/2cm=5cm away from ceiling）.
(11)
(12)
2-Φ4*60
2-Φ4*60
23
8 9
All manuals and user guides at all-guidesbox.com

10/16
EN
ASSEMBLE INSTRUCTIONS
Assemble steps
8-Φ4*50
6-Φ4*50
8-Φ4*50
24
26
25
27
X2
X2
(15)(16)
(13) (14)
29
30 28
X2X2
11/16
EN
ASSEMBLE INSTRUCTIONS
Assemble steps
8-Φ4*50
8-Φ4*50
31
32
Note: back guardrail distance away
from bench surface panel about 20mm.
Note: side guardrail distance away
from bench surface panel about 20mm.
(17)
(18)
10 11
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

12/16
EN
ASSEMBLE INSTRUCTIONS
Assemble steps
34
33
36
2-Φ6*60
Wood cover
35
Glass clip
Rubber
Strip
Note: connect all cables on the roof of the cabin
(19)
Hinge surface
Rubber fitting
Glass door
Hinge bottom
Rubber fitting
Hex screw
13/16
EN
To Heater
AC230V/15A
MAX:10A/1PCS
Power box
Temperature
Sensor
Antenna Speaker
4Ω/3W
4Ω/3W
OUTPUT DC12V/3A
INPUT AC230V
Color light
DC12V/8W
105°C
Temperature Control
FKF-603
Input Voltage
Power Rating
Current Rating
Safety Grade
Model
I
12.2A
2800W
AC230V/50HZ
CIRCUIT DIAGRAM
AC230V/350W
AC230V/350W
AC230V/350W
AC230V/350W
AC230V/350W
AC230V/350W
AC230V/350W
AC230V/350W
USB
R
FM/MP3/BLUETOOTH PLAYER
MP3
12 13
All manuals and user guides at all-guidesbox.com

SERVICE
Use instructions
Drink plenty of liquids before and after use of the infrared cabin.
Dry yourself off completely.
The optimal cabin temperature for a pleasant session lies between 35 and 60℃.
After a heating period of an hour at the latest, the cabin should be switched off and a heating brake of
at least 30 minutes should be taken.
Maintenance instructions
Clean the cabin with a damp cotton towel, dry with a clean dry towel.
Clean the glass with a window/glass cleaner and a soft cloth.
Do not pour water in the control panel or clean it with wet cloth. For cleaning purposes, use a cleaning
cloth that has been only slightly moistened with a mild soapy solvent (dish detergent).
Do not use chemical detergents to clean the cabin.
Please fasten the screws of the bench once every three months, avoid the loose or drop off.
15/16
It is recommended to take a warm shower and relax after use.
Notes:
EN
14 15
