Wells HC-125 User manual

WELLS MANUFACTURING
10 Sunnen Dr., St. Louis, MO 63143
telephone: [phone]
fax: [phone]
www.wellsbloomfield.com
IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
223
p/n 2M-303755 Rev. D M223 120120
OWNERS MANUAL
for
COUNTERTOP
CERAMIC
HOTPLATES
Models:
HC100
HC125
HC225
Includes
INSTALLATION
USE & CARE
EXPLODED VIEW
PARTS LIST
WIRING DIAGRAM
Model HC225

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
Unless otherwise specied, all commercial cooking
equipment manufactured by WELLS MANUFACTURING is
warranted against defects in materials and workmanship
for a period of one year from the date of original installation
or 18 months from the date of shipment from our factory,
whichever comes rst, and is for the benet of the original
purchaser only.
THIS WARRANTY IS THE COMPLETE AND ONLY
WARRANTY, EXPRESSED OR IMPLIED IN LAW
OR IN FACT, INCLUDING BUT NOT LIMITED TO,
WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE, AND/OR FOR
DIRECT, INDIRECT OR CONSEQUENTIAL DAMAGES
IN CONNECTION WITH WELLS PRODUCTS. This
warranty is void if it is determined that, upon inspection
by an authorized service agency, the equipment has been
modied, misused, misapplied, improperly installed, or
damaged in transit or by re, ood or act of God. It also
does not apply if the serial nameplate has been removed,
or if service is performed by unauthorized personnel. The
prices charged by Wells Manufacturing for its products are
based upon the limitations in this warranty. Seller’s obligation
under this warranty is limited to the repair of defects without
charge by a Wells Manufacturing factory authorized service
agency or one of its sub-service agencies. This service
will be provided on customer’s premises for non-portable
models. Portable models (a device with a cord and plug)
must be taken or shipped to the closest authorized service
agency, transportation charges prepaid, for service. In
addition to restrictions contained in this warranty, specic
limitations are shown in the Service Policy and Procedure
Guide. Wells Manufacturing authorized service agencies are
located in principal cities. This warranty is valid in the United
States and Canada and void elsewhere. Please consult your
classied telephone directory, your foodservice equipment
dealer or contact:
Wells Manufacturing
10 Sunnen Dr., St. Louis MO 63143 USA
phone [phone] or fax [phone]
for information and other details concerning warranty.
LIMITED WARRANTY STATEMENT
SERVICE POLICY AND PROCEDURE GUIDE and ADDITIONAL WARRANTY EXCLUSIONS
NOTE: For your protection, please note that equipment
in this shipment was carefully inspected and packaged
by skilled personnel before leaving the factory. Upon
acceptance of this shipment, the transportation company
assumes full responsibility for its safe delivery.
IF SHIPMENT ARRIVES DAMAGED:
1. VISIBLE LOSS OR DAMAGE: Be certain that any
visible loss or damage is noted on the freight bill or
express receipt, and that the note of loss or damage is
signed by the delivery person.
2. FILE CLAIM FOR DAMAGE IMMEDIATELY:
Regardless of the extent of the damage.
3. CONCEALED LOSS OR DAMAGE: if damage is
unnoticed until the merchandise is unpacked, notify the
transportation company or carrier immediately, and le
“CONCEALED DAMAGE” claim with them. This
should be done within fteen (15) days from the date
the delivery was made to you. Be sure to retain the
container for inspection.
Wells Manufacturing cannot assume liability for damage or
loss incurred in transit. We will, however, at your request,
supply you with the necessary documents to support your
claim.
SHIPPING DAMAGE CLAIM PROCEDURE
xi
1. Resetting of safety thermostats, circuit breakers, over
load protectors, and/or fuse replacements are not
covered by this warranty unless warranted conditions
are the cause.
2. All problems due to operation at voltages or phase
other than specied on equipment nameplates are not
covered by this warranty. Conversion to correct voltage
and/or phase must be the customer’s responsibility.
3. All problems due to electrical connections not made
in accordance with electrical code requirements
and wiring diagrams supplied with the equipment are
not covered by this warranty.
4. Replacement of items subject to normal wear, to
include such items as knobs, light bulbs; and, normal
maintenance functions including adjustments of
thermostats, adjustment of micro switches and
replacement of fuses and indicating lights are not
covered by warranty.
5. Damage to electrical cords and/or plug due to exposure
to excessive heat are not covered by this warranty.
6. Full use, care, and maintenance instructions supplied
with each machine. Noted maintenance and
preventative maintenance items, such as servicing
and cleaning schedules, are customer responsibility.
Those miscellaneous adjustments noted are customer
responsibility. Proper attention to preventative
maintenance and scheduled maintenance procedures
will prolong the life of the appliance.
7. Travel mileage is limited to sixty (60) miles from an
Authorized Service Agency or one of its sub-service
agencies.
8. All labor shall be performed during regular working
hours. Overtime premium will be charged to the buyer.
9. All genuine Wells replacement parts are warranted
for ninety (90) days from date of purchase on non-
warranty equipment. This parts warranty is limited only
to replacement of the defective part(s). Any use of
non-genuine Wells parts completely voids any
warranty.
10. Installation, labor, and job check-outs are not
considered warranty and are thus not covered by this
warranty.
11. Charges incurred by delays, waiting time or operating
restrictions that hinder the service technician’s ability
to perform service are not covered by warranty. This
includes institutional and correctional facilities.

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
3
WARRANTY xi
SPECIFICATIONS 1
FEATURES & OPERATING CONTROLS 2
PRECAUTIONS & GENERAL INFORMATION 3
INSTALLATION 4
OPERATION 5
CLEANING INSTRUCTIONS 6
SPECIAL CARE INSTRUCTIONS 7
TROUBLESHOOTING 8
EXPLODED VIEW & PARTS LIST 9-14
WIRING DIAGRAM 15-16
PARTS & SERVICE 21
CUSTOMER SERVICE DATA 21
Thank You for purchasing this
Wells Manufacturing appliance
Proper installation, professional
operation and consistent
maintenance of this equipment
will ensure that it gives you the
very best performance and a long,
economical service life.
This manual contains the
information needed to properly
install this equipment, and to use
and care for the equipment in
a manner which will ensure its
optimum performance.
TABLE OF CONTENTS
SPECIFICATIONS
MODEL ELEMENT WIDTH DEPTH VOLTS AMPS kW PLUG LEG HEIGHT
HC100 Single 7” 12-5/8” 12-5/8” 120 V 11.7 A 1.4 kW NEMA 5-15P 1”
HC125 Single 9” 14-3/4” 14” 208 V 1ø 9.0 A 1.9 kW NEMA 6-15P 1”
240 V 1ø 10.4 A 2.5 kW NEMA 6-15P 1”
HC225 Dual 9” 14-3/4” 24-5/8” 208 V 1ø 18.1 A 3.8 kW NEMA 6-30P 1”
240 V 1ø 20.8 A 5.0 kW NEMA 6-30P 1”
SPECIFICATIONS - EXPORT MODELS
MODEL ELEMENT WIDTH DEPTH VOLTS AMPS kW LEGS
HC125EU Single 9” 14-3/4” 14” 220-240V 1ø 10.4 A 2.5 kW 1”
HC225EU Dual 9” 14-3/4” 24-5/8” 220-240V 1ø 20.8 A 5.0 kW 1”
Refer to the Export Manual for this equipment (p/n 2M-301399) for specic information.

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
4
Ceramic Top Provides smooth, low maintenance heating surface
Heating Element Provides heat for food preparation
Note: elements located under ceramic top
Hot Surface Indicator Glows whenever ceramic top is above 150ºF (66ºC)
Light
Temperature Control Innite switch to control temperature of heating element
Power Indicator Light Glows any time temperature control is on
Name Plate Lists manufacturer, model number and serial number
Also lists voltage and wattage rating
Power Cord Connects hotplate to electrical power
Adjustable Legs Provides ventilation under hotplate
Allow hotplate to be leveled
FEATURES & OPERATING CONTROLS
CERAMIC TOP
NAMEPLATE
POWER CORD
ADJUSTABLE LEGS
HOT SURFACE
INDICATOR LIGHT
TEMPERATURE
CONTROL KNOBS
HEATING ELEMENT
(Under Ceramic Top)
POWER
INDICATOR LIGHT
IL2991

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
5
This appliance is intended for use in commercial establishments only.
This appliance is intended to prepare food for human consumption.
No other use is recommended or authorized by the manufacturer or its
agents.
Operators of this appliance must be familiar with the appliance use,
limitations and associated restrictions. Operating instructions must be
read and understood by all persons using or installing this appliance.
Cleanliness of this appliance is essential to good sanitation. Read and
follow all included cleaning instructions and schedules to ensure the
safety of the food product.
Disconnect the hotplate from electrical power before performing any
maintenance or servicing.
DO NOT submerge hotplate in water. DO NOT splash or pour water
over, onto or into controls or wiring.
Hotplate must be operated with the supplied legs properly Installed.
The technical content of this manual, including any wiring diagrams,
schematics, parts breakdown illustrations and/or adjustment
procedures, is intended for use by qualied technical personnel.
Any procedure which requires the use of tools must be performed by a
qualied technician.
This manual is considered to be a permanent part of the appliance.
This manual and all supplied instructions, diagrams, schematics,
parts breakdown illustrations, notices and labels must remain with the
appliance if it is sold or moved to another location.
This appliance is made in the USA. Unless otherwise noted, this
appliance has American sizes on all hardware. This unit complies with
NSF Standard 4 only if maintained and operated per the instructions in
this manual.
This unit is listed under E6070.
Export versions (only) of this unit meet standards.
WARNING:
ELECTRIC SHOCK
HAZARD
All servicing requiring
access to non-insulated
electrical components must
be performed by a factory
authorized technician.
DO NOT open any access
panel that requires the use
of tools. Failure to follow this
warning can result in severe
electrical shock.
CAUTION:
RISK OF
DAMAGE
DO NOT connect and/or
energize this appliance until
all installation instructions are
read and followed. Damage
to the appliance will result
if these instructions are not
followed.
PRECAUTIONS AND GENERAL INFORMATION
AGENCY APPROVAL INFORMATION
E6070
STD 4 E6070
EXPORT
MODELS
ONLY

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
6
INSTALLATION
NOTE: DO NOT discard
the carton or other packing
materials until you have
inspected the appliance for
hidden damage and tested it
for proper operation. Refer to
SHIPPING DAMAGE CLAIM
PROCEDURE on the inside
front cover of this manual.
CAUTION:
ELECTRIC SHOCK
HAZARD
The ground prong of the
power cord is part of a system
designed to protect you from
electric shock in the event
of internal damage to the
appliance.
NEVER CUT OFF THE
GROUND PRONG (large
round prong). NEVER
TWIST A PRONG TO FIT AN
EXISTING RECEPTACLE.
Contact a licensed electrician
to install an electrical
receptacle appropriate to
the voltage and amperage
requirements of the hotplate.
IMPORTANT:
Damage due to being plugged
into the wrong voltage or phase
is NOT covered by warranty
UNPACKING & INSPECTION
Carefully remove the hotplate from the carton. Remove all protective
plastic lm, packing materials and accessories from the hotplate
before plugging the hotplate into electrical power or otherwise
performing any installation procedure.
Carefully read all instructions in this manual and the Installation
Instruction Sheet packed with the hotplate before starting any
installation.
Read and understand all labels and diagrams attached to the hotplate.
Carefully account for all components and accessories before
discarding packing materials. Store all accessories in a convenient
place for later use.
SETUP
Supplied legs must be properly installed.
Setup the hotplate only on a rm level surface. Non-combustible
material (e.g. metal, terrazzo) is recommended.
Maintain at least 1” from adjacent surfaces.
ELECTRICAL
Refer to the nameplate. Verify the electrical service power. Voltage
and phase must match the nameplate specications. Connecting the
hotplate to the wrong voltage can severely damage the equipment or
cause noticeably decreased performance.
Hotplate is equipped with a grounded electric power cord, this cord
must be plugged into a properly grounded electrical receptacle.

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
7
OPERATION
GENERAL OPERATIONAL NOTES
Carefully read the description of the hotplate operation on the
pecication sheet.
DO NOT attempt to perform any maintenance or service unless the
hotplate is unplugged or disconnected from electrical power.
DO unplug the hotplate from electrical power or turn the circuit
breaker off before cleaning or servicing.
DO NOT use steel wool or abrasive cleansers to clean the ceramic
top.
DO use the supplied scraper to remove burned-on food product.
OPERATION
Each heating element is controlled by an innite switch temperature
control:
OFF removes power from the element
LOW thru 8 are temperature settings
Higher numbers indicate higher temperatures
There is a continuous range of settings between LOW
and HI
HI is a continuous ON setting
The power indicator light will glow any time the temperature control is
on.
The hot surface indicator light will glow any time the ceramic surface
is approximately 150ºF (65ºC) or higher.
Cooking Recommendations:
Save energy by turning the temperature control off any time the
hotplate is not in use. The heating elements will provide full heat
within 30 seconds, making it unnecessary to leave the unit on during
intermittent use.
Each heating element can hold up to a 16 quart pot or pan. For
efcient heating of food product, pots and pans should be no more
than 10” in diameter. Maximize the efciency of the ceramic top by
using at-bottom pots and pans.
Preserve the luster of the ceramic cook surface by wiping up spills
promptly and by cleaning frequently. Allow the hotplate to cool
completely before cleaning. Use only cook-top cleaning crème on
glass-ceramic cooking surfaces.
Stir thick liquids frequently to maintain a consistent temperature.
CAUTION:
HOT SURFACES
Exposed surface scan be hot
to the touch and may cause
burns.
CAUTION:
HOT SURFACES
Ceramic cooking surfaces
are hot anytime the HOT
SURFACE indicator light is lit.
DO NOT touch the cooking
surface if the HOT SURFACE
light is lit.
IMPORTANT:
The dial markings are an
INDICATION of temperature
only. The temperature of the
food product depends on many
factors, including the size,
shape and material of the food
container, and the quantity
and consistency of the food
product.
IL2992

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
8
CLEANING INSTRUCTIONS
PREPARATION
Unplug or disconnect hotplate from electrical power before cleaning.
Allow hotplate to cool completely before cleaning.
FREQUENCY
Daily
TOOLS
Cleaning Creme
Razor Scraper
Clean Cloth or Sponge
Mild Detergent or Cleaner Formulated for Stainless Steel
Warm Water
CLEANING
Unplug or disconnect hotplate from electrical power before cleaning.
Allow the hotplate to cool until the HOT SURFACE indicator light goes
off before cleaning.
Clean food particles from the ceramic cooking surface with a razor
scraper. Hold the edge of blade at
against the surface and at a 15º angle
to avoid scratching the ceramic. DO
NOT use metal implements (other than
the razor scraper), steel wool or metal
scouring pads to clean the ceramic
cooking surface.
Use only cook-top cleaning creme on
glass-ceramic cooking surfaces. Wipe the
ceramic cooking surfaces with cleaning
creme and a clean cloth. The cleaning creme leaves a
protective coating.
Wipe the outer portions of the hotplate cabinet with a clean soft cloth
or sponge dampened with warm water and a mild detergent or cleaner
formulated for cleaning stainless steel. DO NOT use steel wool to
clean hotplate cabinet.
Rinse by wiping hotplate cabinet with a clean soft cloth or sponge
moistened with clean warm water. Dry cabinet by wiping with a clean
soft dry cloth.
CAUTION:
ELECTRIC
SHOCK HAZARD
Unplug hotplate from electric
power before cleaning.
CAUTION:
BURN HAZARD
Allow hotplate to cool
completely before cleaning.
CAUTION:
ELECTRIC
SHOCK HAZARD
Do not submerge hotplate in
water.
IMPORTANT: DO NOT spill
or pour water into controls,
control panel or wiring.
DO NOT submerge hotplate
in water. Damage to
internal components will
occur. Damage to internal
components from water
damage is NOT covered by
warranty.
DO NOT steel wool or metal
scouring pads to clean
ceramic heating surface.
15°
IL2993

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
9
DO NOT use the hotplate surface as a cutting board.
DO NOT cook directly on the glass-ceramic surface.
Check glass and ceramic cookware to verify suitability for use on
hotplates.
DO NOT drop cookware onto glass-ceramic cook surface.
Carefully place heavy pots and skillets on glass-ceramic cook surface
to avoid damage.
Avoid sliding cookware across hotplate surface.
Remove stains and metal marks from the glass-ceramic cook surface
after use by cleaning with cleaning creme. Allow hotplate surface to
cool completely before cleaning
DO NOT leave empty cookware on a hot cooking surface.
Avoid contacting the hot glass-ceramic surface with plastic or aluminum
foil, which may melt.
SPECIAL CARE INSTRUCTIONS
CAUTION:
BURN HAZARD
Allow hotplate to cool
completely before cleaning.
CAUTION:
CUT HAZARD
DO NOT attempt to cook on
a broken hotplate surface.
Severe injury may result.
Contact an Authorized Wells
Service Agency immediately
for repairs.
CAUTION:
CUT HAZARD
DO NOT attempt to repair
a broken hotplate surface.
The glass-ceramic surface
is impossible to repair
successfully. A broken
surface can cause severe
injury. Contact an Authorized
Wells Service Agency
immediately for repairs.

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
10
TROUBLESHOOTING
SYMPTOM POSSIBLE CAUSE SUGGESTED REMEDY
Hotplate won’t heat Not plugged in, damaged plug or
cord or circuit breaker tripped
Check plug and cord
Check / reset circuit breaker
One or more sections
won’t heat
Temperature control not on Turn temperature control to desired
setting
Damaged temperature control,
element or other internal
component
Contact Authorized Wells Service
Agency for repairs
Hotplate not hot enough
Temperature control not set Adjust for desired temperature
Operating 208/240V unit at 120V Be sure supply voltage matches
nameplate voltage
Damaged temperature control,
element or other internal
component
Contact Authorized Wells Service
Agency for repairs
Hot surface indicator does
not light, or stays on
Damaged temperature control,
element or other internal
component
Contact Authorized Wells Service
Agency for repairs
NOTE: There are no user serviceable components in this appliance. In all cases of damage or
component malfunction, contact your Authorized Wells Service Agency for repairs.

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
11
NOTES

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
12
EXPLODED VIEW: HC100
HC-100 COUNTERTOP ELECTRIC CERAMIC HOTPLATE
22328 HC100 COUNTERTOP
CERAMIC HOTPLATE 120VAC
Model: HC100
Countertop Electric Ceramic Hotplate
PL223 IL1814 Rev. B 3/20/14
OFF
0
LO
HI
2
3
4
5
6
7
8
2
3
4
7
18
5
6
8
9
10
11
12
13
14
15
16
17
6
19
20
1

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
13
PARTS LIST: HC100
HC100 COUNTERTOP ELECTRIC CERAMIC
Fig No Part No Qty Description
1WS-501686 1 TOP ASSY HC-100 120V
2 I7-301686 1 TOP ASSY
3 2Q-301661 1 GLASS CERAMIC HC100
4 2H-301213 6FT INSUL LYTHERM HP 1/4X5/8
52J-301121 1 LIGHT SIGNAL CLEAR 120V
62C-31053 11 NUT 8-32 KEPS MS NICKEL
72C-34285 4 SCREW 8-32X3/8 PH 100 FL
82M-300534 1 TRADEMARK DOMED LABEL
92C-33935 2SCREW 6ABX5/16 PH PAN SMS
10 2J-70309 1 LIGHT PILOT RED 125V 1/3W
11 2R-30371 1 KNOB ASSY WARMERS
12 2C-31697 2 SCREW 8-32X3/16 PH RD HD
13 D8-30256 1TRIM RING ASSY
14 2E-30570 1 SWITCH INFINITE 120V A
15 2A-41946 4 LEG ADJUST 1IN
16 2E-70017 1 CORD SET 6FT 5-15P
17 2K-70215 1 STRAIN RELIEF STR
18 2N-301660 1 ELEM HC100 120V 1400W
19 I7-301664 1 RETAINER ELEMENT HC-100

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
14
EXPLODED VIEW: HC125
HC-125 COUNTERTOP ELECTRIC CERAMIC HOTPLATE
22305 HC-125 COUNTERTOP
CERAMIC HOTPLATE 120VAC
Model: HC125
Countertop Electric Ceramic Hotplate
PL223 IL1815 Rev. A 7/10/09
WELLS
OFF
0
LO
HI
WELLS
2
3
4
5
6
7
8
2
3
4
7
5
6
8
9
10
11
12
13
14
15
16
17
18
6
19
20
1

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
15
PARTS LIST: HC125
HC-125 COUNTERTOP ELECTRIC CERAMIC
Fig No Part No Qty Description
1WS-501649 1TOP ASSY REPLACEMENT HC-125
2 I7-301214 1 TOP DRAWN HC-125 1256
3WS-501109 1GLASS CERAMIC HC-125 1256
4 2H-301213 6FT INSUL LYTHERM HP 1/4X5/8
52J-301121 1 LIGHT SIGNAL CLEAR 120V
62C-31053 11 NUT 8-32 KEPS MS NICKEL
7 2N-301120 1 ELEM 240V 2500W HC-125
82M-300534 1 TRADEMARK DOMED LABEL
92C-33935 2SCREW 6ABX5/16 PH PAN SMS
10 2J-31157 1 LIGHT SIGNAL RED
11 2R-30371 1 KNOB ASSY WARMERS
12 2C-31697 2 SCREW 8-32X3/16 PH RD HD
13 D8-30256 1TRIM RING ASSY
14 2E-30562 1 SWITCH INFINITE 240V A
15 2A-41946 4 LEG ADJUST 1IN
16 2E-35540 1CORD SET 6-15P 16/3W 4FT
17 2C-34285 4 SCREW 8-32X3/8 PH
18 2K-70215 1 STRAIN RELIEF STR HEYCO
19 I7-301144 1 RETAINER ELEMENT HC-125
20 I7-301119 1 BRKT ELEMENT HC-125

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
16
EXPLODED VIEW: HC225
HC-225 COUNTERTOP ELECTRIC CERAMIC HOTPLATE
22307 HC-225 COUNTERTOP
CERAMIC HOTPLATE
208/240VAC
Model: HC225
Countertop Electric Ceramic Hotplate
PL223 IL1816 Rev. A 4/27/15
FRONTREAR
WELLS
OFF
0
LO
HI
2
3
4
5
6
7
8
OFF
0
LO
HI
2
3
4
5
6
7
8
2
3
4
22
5
6
7
8
9
10
13
11
12
14
15
16
18
17
19
20
21
6
1

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
17
PARTS LIST: HC225
HC-225 COUNTERTOP ELECTRIC CERAMIC
Fig No Part No Qty Description
12Q-501650 1TOP ASSY REPLACEMENT HC-225
2I7-301215 1TOP ASSY HC-225
3WS-501110 1GLASS CERAMIC HC-225 & 2256
4 2H-301213 6FT INSUL LYTHERM HP 1/4X5/8
52J-301121 1 LIGHT SIGNAL CLEAR 120V
62C-31053 17 NUT 8-32 KEPS MS NICKEL
7 2N-301120 2 ELEM 240V 2500W
8 I7-301119 2 BRKT ELEMENT
92M-300534 1 TRADEMARK DOMED LABEL
10 2C-33935 4SCREW 6ABX5/16 PH PAN SMS
11 2R-30583 1 KNOB ASSY FRONT HOTPLATE
12 2R-30584 1 KNOB RR HP91
13 2C-31697 4 SCREW 8-32X3/16 PH RD HD
14 D8-30256 2TRIM RING ASSY
15 2E-30562 2 SWITCH INFINITE 240V A
16 2J-31157 2 LIGHT SIGNAL RED
17 2E-35259 1CORD SET 250V 30A 12G 6-30P
18 2A-41946 4 LEG ADJUST 1IN
19 2C-34285 4 SCREW 8-32X3/8 PH
20 2C-35736 1 NUT 8-32 HEX KEPS MS GREEN
21 2K-45788 1 STRAIN RELIEF SR7W-2 LLF
22 I7-301145 1RETAINER ELEMENT HC225

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
18
WIRING DIAGRAM

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
19
WIRING DIAGRAM

223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
223 p/n 2M-303755 Owners Manual Counter Top Ceramic Hotplates
20
NOTES
