Wells H-33 User manual

WELLS MANUFACTURING
265 Hobson Street, Smithville, Tennessee 37166
telephone: [phone]
fax: [phone]
www.wells-mfg.com
IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
OWNERS MANUAL
for
COUNTER TOP
ELECTRIC
HOTPLATES
Models:
H33
H63
H65
H70
H115
Includes
INSTALLATION
USE & CARE
EXPLODED VIEW
PARTS LIST
WIRING DIAGRAM
221
2M-303733 Rev. F10/18
Model H70

WARRANTY EXCLUSIONS
THE FOLLOWING WILL NOT BE COVERED UNDER WARRANTY.
•Any product which has not been installed, cleaned, maintained,
or used in accordance with the directions published in the appropriate
installation sheet and/or owner’s manual as well as national and local
codes, including incorrect gas or electrical connection. Wells is not liable
for any unit which has been mishandled, abused, misapplied, subjected
to chlorides, harsh chemicals, or caustic cleaners, damaged from
exposure to hard water, modified by unauthorized personnel, damaged
by flood, fire, or other acts of nature [or God], or which have an altered
or missing serial number.
•Installation, labor, and job checkouts, calibration of heat controls, air
and gas burner/bypass/pilot adjustments, gas or electrical system
checks, voltage and phase conversions, cleaning of equipment,
or seasoning of griddle surface.
•Replacement of fuses or resetting of circuit breakers, safety controls,
or reset buttons.
•Replacement of broken or damaged glass components, quartz heating
elements, and light bulbs.
•Labor charges for all removable parts in gas charbroilers and hotplates,
including but not limited to burners, grates, and radiants.
•Any labor charges incurred by delays, waiting time, or operating
restrictions that hinder a service technician’s ability to perform service.
•Parts that fail or are damaged due to normal wear or labor for
replacement of Items that can easily be replaced during a daily cleaning
routine. such as but not limited to silicone belts, PTFE non-stick sheets,
knobs, control labels, bulbs, fuses, quartz heating elements, baskets,
racks, and grease drawers.
•Components that should be replaced when damaged or worn, but have
been field-repaired instead [eg. field-welded fry pots].
•Any loss of business or profits.
ADDITIONAL WARRANTIES
Specialty/chain specific versions may also have additional and/or
extended warranties.
LIMITED EQUIPMENT WARRANTY
Wells Manufacturing warranties new products to be free from defects
in material and/or workmanship for a period of one [1] year from the
date of original installation, except as noted below. Defects that occur
as a result of normal use, within the time period and limitations defined
in this warranty, will at Wells’ discretion have the parts replaced or
repaired by Wells or a Wells-authorized service agency.
THIS WARRANTY IS SUBJECT TO ALL LISTED CONDITIONS.
Repairs performed under this warranty are to be performed by a Wells-
authorized service agency. Wells will notberesponsible for charges
incurred orservice performed bynon-authorized repair agencies.
In all cases, the nearest Wells-authorized service agency must be used.
Wells will be responsible for normal labor charges incurred in the repair
or replacement of a warrantied product within 50 miles (80.5 km) of
an authorized service agency. Time andexpense charges for anything
beyond that distance will be the responsibility of the owner. All labor
will need to be performed during regular service hours. Any overtime
premium will be charged to the owner. For all shipments outside the
U.S.A. and Canada, please see the International Warranty for specific
details.
It is the responsibility of the owner to inspect and report any shipping
damage claims, hidden or otherwise, promptly following delivery.
No mileage or travel charges will be honored on any equipment that is
deemed portable. In general, equipment with a cord and plug weighing
less than 50 lb. (22.7 kg) is considered portable and should be taken or
shipped tothe closest authorized service agency, transportation prepaid.
CONTACT
Should you require anyassistance regarding the operation or
maintenance of any Wells equipment; write, phone, fax or email
our service department. Inall correspondence mention the
model number and the serial number of your unit, as well as
the voltage or type of gas you are using.
Business hours are 8:00 a.m. to 4:30 p.m. Central Standard Time
Telephone [phone]
Fax [phone]
Email [e-mail]
www.wells-mfg.com
PRODUCTS PARTS LABOR
universal ventless hoods 2 years 1 year
canopy hoods 2 years 1 year
“Cook’n Hold” equipment [HW10,
HWSMP, LLSC7, LLSC7WA, LLSC11,
and LLSC11WA]
2 years 1 year
cast iron grates, burners, and burner
shields 1 year
original Wells parts sold to repair
Wells equipment 90 days
Service First 1 year
The foregoing warranty is in lieu of any and all other warranties expressed or implied and constitutes the entire warranty. 2M-Z22393 • Rev A • 02.2018

1
221 p/n 2M-303733 Owners Manual CT Hotplate
WARRANTY
SPECIFICATIONS 1
FEATURES & OPERATING CONTROLS 2
PRECAUTIONS & GENERAL INFORMATIOS 3
AGENCY APPROVAL INFORMATION 3
INSTALLATION 4
OPERATION 5
CLEANING INSTRUCTIONS 6
TROUBLESHOOTING 7
EXPLODED VIEW & PARTS LIST 8 - 17
WIRING DIAGRAMS 18 - 19
PARTS & SERVICE 21
CUSTOMER SERVICE DATA
Thank You for purchasing this Wells Manufacturing appliance.
Proper installation, professional operation and consistent maintenance of this equipment will ensure that
it gives you the very best performance and a long, economical service life.
This manual contains the information needed to properly install this equipment, and to use and care for
the equipment in a manner which will ensure its optimum performance.
TABLE OF CONTENTS
SPECIFICATIONS
INTRODUCTION
MODEL ELEMENT WIDTH DEPTH VOLTS AMPS kW PLUG LEG HEIGHT
H33 Single 6” Coil 12-5/8” 12-5/8” 120 V 1ø 12.5 A 1.5 kW NEMA 5-15P
4”
H63 Dual 8” Coils 14-3/4” 23-1/2” 208 V 1ø 18.8 A 3.9 kW NEMA 6-30P
240 V 1ø 21.7 A 5.2 kW NEMA 6-30P
H65 Dual 8” Coils 13” 29-9/16” 208 V 1ø 18.8 A 3.9 kW None
240 V 1ø 21.7 A 5.2 kW None
H70 Dual 9”
french plates 14-3/4” 23-1/2” 208 V 1ø 14.4 A 3.0 kW None
240 V 1ø 16.7 A 4.0 kW None
H115 Dual 6” Coils 14-3/4” 23-9/16” 120 V 1ø 13.8 A 1.7 kW NEMA 5-15P 1”

2
221 p/n 2M-303733 Owners Manual CT Hotplate
FEATURES & OPERATING CONTROLS
ELEMENT SUPPORT
TEMPERATURE
CONTROLS
INDICATOR LIGHT
NAME PLATE
ADJUSTABLE LEGS
POWER CORD
HEATING ELEMENT DRIP PAN
HEATING ELEMENT
(LIFTED / ROTATED)
IL2818
Heating Element
Provides heat for food preparation
Coil-type elements rotate for access to drip pan
Note: Solid (french plate) elements on model H-70 do not lift
Element Support* Holds coil-type element in proper position
Drip Pan* Collects drippings and holds element support
Also deects heat from element for more efcient cooking
Temperature Control Innite switch to control temperature of heating element
Indicator Light Glows any time temperature control is on
Name Plate Lists manufacturer, model number and serial number
Also lists voltage and wattage rating
Power Cord
(when provided)
Connects hotplate to electrical power
Some units require wiring directly into electrical circuit
Adjustable Legs Provide ventilation under hotplate
Allow hotplate to be leveled
* not used on model H70

3
221 p/n 2M-303733 Owners Manual CT Hotplate
This appliance is intended for use in commercial establishments only.
This appliance is intended to prepare food for human consumption.
No other use is recommended or authorized by the manufacturer or its
agents.
Operators of this appliance must be familiar with the appliance use,
limitations and associated restrictions. Operating instructions must be
read and understood by all persons using or installing this appliance.
Cleanliness of this appliance is essential to good sanitation. Read and
follow all included cleaning instructions and schedules to ensure the
safety of the food product.
Hotplates with coil-type heating elements must be operated with drip
pan and element support properly installed.
Disconnect the hotplate from electrical power before performing any
maintenance or servicing.
DO NOT submerge hotplate in water. DO NOT splash or pour water
over, onto or into controls, control panel or wiring.
The technical content of this manual, including any wiring diagrams,
schematics, parts breakdown illustrations and/or adjustment
procedures, is intended for use by qualied technical personnel.
Any procedure which requires the use of tools must be performed by a
qualied technician.
This manual is considered to be a permanent part of the appliance.
This manual and all supplied instructions, diagrams, schematics,
parts breakdown illustrations, notices and labels must remain with the
appliance if it is sold or moved to another location.
This appliance is made in the USA. Unless otherwise noted, this
appliance has American sizes on all hardware.
This appliance complies with NSF Standard 4 only when maintained
and operated per the instructions in this manual.
This appliance is UL listed under E6070.
WARNING:
ELECTRIC
SHOCK HAZARD
All servicing requiring
access to non-insulated
electrical components must
be performed by a factory
authorized technician.
DO NOT open any access
panel that requires the use
of tools. Failure to follow this
warning can result in severe
electrical shock.
CAUTION:
RISK OF
DAMAGE
DO NOT connect and/or
energize this appliance until
all installation instructions are
read and followed. Damage
to the appliance will result
if these instructions are not
followed.
PRECAUTIONS AND GENERAL INFORMATION
AGENCY APPROVAL INFORMATION
STD 4
E6070

4
221 p/n 2M-303733 Owners Manual CT Hotplate
INSTALLATION
NOTE: DO NOT discard
the carton or other packing
materials until you have
inspected the appliance for
hidden damage and tested it
for proper operation.
Refer to SHIPPING DAMAGE
CLAIM PROCEDURE on the
inside front cover of this
manual.
CAUTION:
ELECTRIC SHOCK
HAZARD
The ground prong of the
power cord is part of a
system designed to protect
you from electric shock
in the event of internal
damage to the appliance.
NEVER CUT OFF THE
GROUND PRONG (large
round prong). NEVER
TWIST A PRONG TO FIT
AN EXISTING
RECEPTACLE.
Contact a licensed
electrician to install an
electrical receptacle
appropriate to the voltage
and amperage requirements
of the hotplate.
IMPORTANT:
Damage due to being plugged
into the wrong voltage or
phase is NOT covered by
Warranty.
UNPACKING & INSPECTION
Carefully remove the hotplate from the carton. Remove all protective
plastic lm, packing materials and accessories from the hotplate
before plugging the hotplate into electrical power or otherwise
performing any installation procedure.
Carefully read all instructions in this manual and the Installation
Instruction Sheet packed with the hotplate before starting any
installation.
Read and understand all labels and diagrams attached to the hotplate.
Carefully account for all components and accessories before
discarding packing materials. Store all accessories in a convenient
place for later use.
SETUP
Supplied legs must be properly installed.
Setup the hotplate only on a rm level surface. Non-combustible
material (e.g. metal, terrazzo) is recommended.
Maintain at least 1” from adjacent surfaces.
ELECTRICAL
Refer to the nameplate. Verify the electrical service power. Voltage
and phase must match the nameplate specications. Connecting the
hotplate to the wrong voltage can severely damage the equipment or
cause noticeably decreased performance.
If your hotplate is equipped with a grounded electric power cord, this
cord must be plugged into a properly grounded electrical receptacle.
If your hotplate is not supplied with a cordset, the hotplate must be
installed by a licensed electrician in accordance with all applicable
codes and ordinances.

5
221 p/n 2M-303733 Owners Manual CT Hotplate
OFF
0
LO
HI
2
3
4
5
6
7
8
Fig 2. Temperat ure Cont rol
OPERATION
GENERAL OPERATIONAL NOTES
Carefully read the description of the hotplate operation on the
specication sheet.
DO NOT attempt to perform any maintenance or service unless the
hotplate is disconnected from electrical power.
DO turn the circuit breaker for the hotplate off before cleaning,
servicing or performing any maintenance.
DO NOT use sharp objects or metal implements to clean the heating
elements.
DO use a plastic spatula or plastic scouring pad to remove burned-on
food product.
OPERATION
Each heating element is controlled by an innite switch temperature
control:
OFF removes power from the element
LOW thru 8 are temperature settings
Higher numbers indicate higher temperatures
There is a continuous range of settings between LOW and HI
HI is a continuous ON setting
The indicator light will glow any time the temperature control is on.
Cooking Recommendations:
Save energy by turning the temperature control off any time the
hotplate is not in use. The coil-type heating elements will provide full
heat within 30 seconds, while french plate heating elements will reach
full heat within 2 minutes, making it unnecessary to leave the unit on
during intermittent use.
Each heating element can hold up to a 16 quart pot or pan. For
efcient heating of food product, pots and pans should be no more
than 10” in diameter.
Maximize the efciency of solid (french plate) elements by using
at-bottom pots and pans.
Stir thick liquids frequently to maintain a consistent temperature.
CAUTION:
HOT SURFACE
Exposed surfaces can be hot
to the touch and may cause
burns.
Temperature Control Knob
IMPORTANT:
The dial markings are an
INDICATION of temperature
only. The temperature of the
food product depends on many
factors, including the size,
shape and material of the food
container, and the quantity
and consistency of the food
product.

6
221 p/n 2M-303733 Owners Manual CT Hotplate
CLEANING INSTRUCTIONS
PREPARATION
Unplug or disconnect hotplate from electrical power before cleaning.
Allow hotplate to cool completely before cleaning.
FREQUENCY
Daily
TOOLS
Plastic Spatula and Plastic Scouring Pad
Clean Cloth or Sponge
Mild Detergent or Cleaner Formulated for Stainless Steel
Warm Water
CLEANING
Unplug or disconnect hotplate from electrical power and allow heating
element to cool completely before cleaning.
COILED HEATING ELEMENTS:
Lift coiled heating elements and remove drip pans. Clean drip pans
with a plastic spatula or plastic scouring pad, mild detergent and warm
water. DO NOT use metal implements, steel wool or metal scouring
pads to clean drip pans. Rinse drip pans by wiping with a clean cloth
or sponge dampened with clean water.
Clean heating elements with a plastic spatula or plastic scouring pad,
mild detergent and warm water. DO NOT use metal implements, steel
wool or metal scouring pads to clean elements. Rinse by wiping with a
clean cloth or sponge dampened with clean water.
Reinstall drip pans and gently lower heating element.
FRENCH PLATE HEATING ELEMENTS:
French plate elements do not lift. Clean heating elements with
a plastic spatula or plastic scouring pad, mild detergent and warm
water. DO NOT use metal implements, steel wool or metal scouring
pads to clean elements. Rinse by wiping with a clean cloth or sponge
dampened with clean water.
CABINET:
Wipe the outer portions of the hotplate cabinet with a clean soft cloth
or sponge dampened with warm water and a mild detergent or cleaner
formulated for cleaning stainless steel. DO NOT use steel wool to
clean hotplate cabinet.
Rinse by wiping hotplate cabinet with a clean soft cloth or sponge
moistened with clean warm water.
Dry cabinet and elements by wiping with a clean soft dry cloth.
CAUTION:
ELECTRIC
SHOCK HAZARD
Disconnect hotplate from
electric power before
cleaning.
CAUTION:
BURN HAZARD
Allow hotplate element and
cabinet to cool completely
before cleaning.
CAUTION:
ELECTRIC
SHOCK HAZARD
Do not submerge hotplate in
water.
IMPORTANT: DO NOT spill
or pour water into interior of
hotplate.
IMPORTANT: DO NOT spill
or pour water into controls,
control panel or wiring.
DO NOT submerge hotplate
in water. Damage to internal
components will occur.
Damage to internal
components from water
damage is NOT covered by
warranty.
DO NOT use metal
implements, steel wool or
metal scouring pads to clean
heating elements.

7
221 p/n 2M-303733 Owners Manual CT Hotplate
TROUBLESHOOTING
SYMPTOM POSSIBLE CAUSE SUGGESTED REMEDY
Hotplate won’t heat Not plugged in, damaged plug or cord
or circuit breaker tripped
Check plug and cord
Check / reset circuit breaker
One or more sections won’t
heat
Temperature control not on Turn temperature control to
desired setting
Damaged temperature control,
element or other internal component
Contact Authorized Wells Service
Agency for repairs
Hotplate not hot enough
Temperature control not set Adjust for desired temperature
Operating 208/240V unit at 120V Be sure supply voltage matches
nameplate voltage
Damaged temperature control,
element or other internal component
Contact Authorized Wells Service
Agency for repairs
NOTE: There are no user serviceable components in this appliance.
In all cases of damage or component malfunction, contact your
Authorized Wells Service Agency for repairs.

8
221 p/n 2M-303733 Owners Manual CT Hotplate
H-33 COUNTERTOP ELECTRIC HOTPLATE - 115V - SPIRAL ELEMENT
EXPLODED VIEW: H33
Model: H33
Countertop Electric Hotplate - 115V - Spiral Element
PL221 IL1747 Rev. A 4/24/09
OFF
0
LO
HI
WELLS
2
3
4
5
6
7
8
WELLS
(Canadian only)
7
8910
1112
13
14
4
5
6
1
2
3

9
221 p/n 2M-303733 Owners Manual CT Hotplate
PARTS LIST: H33
H33 COUNTERTOP ELECTRIC HOTPLATE
Fig No Part No Qty Description
12N-30514ELUL 1ELEMENT 120V 1500WW H33
22D-30514DT 1DRIP TRAY H115 & H33
3I7-30514CR 1ASSY CLIPS & RING H115 & H33
4 2C-33977 AR SCREW 8-32X3/8 PH BND HD
52C-300243 AR SCREW 10-32X1/4 PH BND HD
6 I7-43370 1 COVER TERM H33 115 CSA
72J-30516 1LIGHT SIGNAL AMBER
8 2R-30371 1 KNOB ASSY WARMERS
9D8-30256 1TRIM RING ASSY
10 2E-30570 1 SWITCH INFINITE 120V
11 2K-31217 1 STRAIN RELIEF 90DEG
12 2E-35539 1CORD SET 120V 15A 16GA 4FT
13 2R-Z0314 4FOOT, DIE CAST, METAL 3/8-16
14 2K-31040 1 BUSHING 7/8 OD

10
221 p/n 2M-303733 Owners Manual CT Hotplate
EXPLODED VIEW: H63
H-63 COUNTERTOP ELECTRIC HOTPLATE - 208/240V - SPIRAL ELEMENT
Model: H63
Countertop Electric Hotplate - 208/240V - Spiral Element
PL221 IL1748 Rev. B 1/18/10
OFFOFF
00
LO LO
HI HI
FRONTREAR
2 2
3
3
4
4
5 5
6
6
7
7
8 8
HOTPLATE W/CORD ONLY
WELLS
1
4
2
3
5
6
7
8
12
13
14
15
9
10
11

11
221 p/n 2M-303733 Owners Manual CT Hotplate
PARTS LIST: H63
H63 COUNTERTOP ELECTRIC HOTPLATE
Fig No Part No Qty Description
1 2N-30293ELUL 2 ELEMENT 240V 260W H63
2 I7-30293CR 2 ASSY CLIPS & TRIM RING H-
3 2D-30293DT 2 DRIP TRAY H-63
4 2C-33977 2 SCREW 8-32X3/8 PH BND HD
5 WS-50131 1 TERM BLOCK KIT (RETRO 301)
62C-35736 2 NUT 8-32 HEX KEPS MS GREEN
7 2C-41974 2 NUT 8-32 HEX 7/8 LONG ALU
82E-35259 1CORD SET 250V 30A 12G 6-30P
92A-Z0314 4FOOT, DIE CAST, METAL 3/8-16
10 2R-30583 1 KNOB ASSY FRONT HOTPLATE
11 2R-30584 1 KNOB RR HP91
12 2J-30516 2LIGHT SIGNAL AMBER
13 D8-30256 2TRIM RING ASSY
14 2E-30562 2 SWITCH INFINITE 240V
15 2M-300534 1 TRADEMARK DOMED LABEL WARMER

12
221 p/n 2M-303733 Owners Manual CT Hotplate
EXPLODED VIEW: H65
H-65 COUNTERTOP ELECTRIC HOTPLATE - 208/240V - SPIRAL ELEMENT
Model: H65
Countertop Electric Hotplate - 208/240V - Spiral Element
PL221 IL1749 Rev. A 4/24/09
OFFOFF
00
LO LO
HI
HI
FRONTREAR
2 2
3
3
4
4
5 5
6
6
7
7
8 8
WELLS
1
4
2
3
5
8
7
6
9
14
18
15
16
17
13
11
12
10

13
221 p/n 2M-303733 Owners Manual CT Hotplate
PARTS LIST: H65
H65 COUNTERTOP ELECTRIC HOTPLATE 208/240V
Fig No Part No Qty Description
1 2N-30293ELUL 2 ELEMENT 240V 2600W
2 I7-30293CR 2 ASSY CLIPS & TRIM RING
3 2D-30293DT 2 DRIP TRAY
4 2C-33977 2 SCREW 8-32X3/8 PH BND HD
5 2C-54285 AR SCREW 8-32X3/8 PH 100 FL
6 2C-41974 2 NUT 8-32 HEX 7/8 LONG ALU
72C-35736 AR NUT 8-32 HEX KEPS MS GREEN
8WS-50131 1TERM BLK KIT - 3POLE 85AMP
92A-Z0314 4FOOT, DIE CAST, METAL 3/8-16
10 2J-30516 2LIGHT SIGNAL AMBER
11 2R-30583 1 KNOB ASSY FRONT HOTPLATE
12 2R-30584 1 KNOB ASSY REAR HOTPLATE
13 2C-31697 AR SCREW 8-32X3/16 PH RD HD
14 2C-33935 AR SCREW 6ABX5/16 PH PAN SMS
15 D8-30256 2TRIM RING ASSY
16 2E-30562 2 SWITCH INFINITE 240V
17 2M-300534 1 TRADEMARK DOMED LABEL
18 2K-31040 1 BUSHING 7/8 OD

14
221 p/n 2M-303733 Owners Manual CT Hotplate
EXPLODED VIEW: H70
H-70 COUNTERTOP ELECTRIC HOTPLATE - 208/240V - SOLID (FRENCH PLATE) ELEMENT
Model: H70
Countertop Electric Hotplate - 208/240V - French Plate
PL221 IL1750 Rev. B 8/20/09
OFFOFF
00
LO LO
HI HI
FRONTREAR
2 2
3
3
4
4
5 5
6
6
7
7
8 8
WELLS
1
2
3
4
6
5
7
8
910
11
12
13
14
15

15
221 p/n 2M-303733 Owners Manual CT Hotplate
PARTS LIST: H70
H70 COUNTERTOP ELECTRIC HOTPLATE 208/240V
Fig No Part No Qty Description
1WS-503973 2 ELEM HOTPLATE UPGRADE FUSED
2 2C-41974 2 NUT 8-32 HEX 7/8 LONG ALU
32C-35736 2 NUT 8-32 HEX KEPS MS GREEN
4WS-50131 1 TERM BLOCK KIT (RETRO 301)
5 2C-34285 4 SCREW 8-32X3/8 PH
62R-Y5092 4 FEET ADJ 4GRAY 3/8-16
72J-30516 2LIGHT SIGNAL AMBER
82R-30583 1 KNOB ASSY FRONT HOTPLATE
92R-30584 1 KNOB ASSY REAR HOTPLATE
10 2C-31697 AR SCREW 8-32X3/16 PH RD HD
11 2C-33935 AR SCREW 6ABX5/16 PH PAN SMS
12 D8-30256 2TRIM RING ASSY
13 2E-30562 2 SWITCH INFINITE 240V
14 2M-300534 1 TRADEMARK DOMED LABEL
15 I7-35031 2 CLAMP ELEM H70

16
221 p/n 2M-303733 Owners Manual CT Hotplate
EXPLODED VIEW: H115
H-115 COUNTERTOP ELECTRIC HOTPLATE - 120V - SPIRAL ELEMENT
Model: H115
Countertop Electric Hotplate - 120V - Spiral Element
PL221 IL1751 Rev. B 7/15/13
OFF
0
LO
HI
FRONTFRONT
2
3
4
5
6
7
8
OFF
0
LO
HI
REARREAR
2
3
4
5
6
7
8
WELLS
1
2
3
4
5
8
9
10
11
76
12
13
14
15
16

17
221 p/n 2M-303733 Owners Manual CT Hotplate
PARTS LIST: H115
H115 COUNTERTOP ELECTRIC HOTPLATE 120V
Fig No Part No Qty Description
1 2C-33977 2 SCREW 8-32X3/8 PH BND HD
2 2N-33573ELUL 2 ELEMENT 120V 825W H115
3 2D-30514DT 2 DRIP TRAY
4 I7-30514CR 2 ASSY CLIPS & RING
5 2C-33935 AR SCREW 6ABX5/16 PH PAN SMS
6 2R-30584 1 KNOB RR HP91
7 2R-30583 1 KNOB ASSY FRONT HOTPLATE
8 2C-31697 AR SCREW 8-32X3/16 PH RD HD
9 D8-30256 2 TRIM RING ASSY
10 2E-30570 2 SWITCH INFINITE 120V
11 2J-30516 2 LIGHT SIGNAL AMBER
12 2E-35539 1 CORD SET 120V 15A 16GA
13 2A-41946 4 LEG ADJUST 1 INCH
14 2C-34285 4 SCREW 8-32X3/8 PH 100 FL
15 2K-31217 1 STRAIN RELIEF 90DEG
16 I7-31103 1 TOP ASSY H115

18
221 p/n 2M-303733 Owners Manual CT Hotplate
WIRING DIAGRAM
WIRING DIAGRAM FOR
ELECTRIC COUNTER TOP HOTPLATES
H-63, H-65, H-70 and H-115
