Wenglor weCat3D MLWL Series User manual

weCat3D MLSL & MLWL
2D-/3D Profile Sensors
Operating Instructions
Translation of the Original Operating Instruction
Subject to change without notice
Available as PDF version only
Status: 28.06.2018
Version: 1.2.0
www.wenglor.com
EN

2Table of Contents
Table of Contents
1. General.....................................................................................................................................................4
1.1 Information Concerning these Instructions .......................................................................................... 4
1.2 Explanations of Symbols ...................................................................................................................... 4
1.3 Limitation of Liability.............................................................................................................................. 5
1.4 Copyrights............................................................................................................................................. 5
2. For Your Safety.........................................................................................................................................6
2.1 Use for Intended Purpose..................................................................................................................... 6
2.1.1 Function Principle...................................................................................................................... 6
2.2 Use for Other than the Intended Purpose............................................................................................. 7
2.3 Personnel Qualifications ...................................................................................................................... 7
2.4 Modification of Products ....................................................................................................................... 7
2.5 General Safety Precautions .................................................................................................................. 8
2.6 Laser/LED Warnings ............................................................................................................................. 8
2.7 Approvals and protection class ............................................................................................................ 9
3. Technical Data..........................................................................................................................................9
3.1 Fields of Vision .................................................................................................................................... 12
3.2 Dimensional Drawings ........................................................................................................................ 18
3.3 Connection Diagram ........................................................................................................................... 24
3.4 Layout.................................................................................................................................................. 25
3.5 LED Display......................................................................................................................................... 26
3.6 Control panel....................................................................................................................................... 27
4. Transport and Storage...........................................................................................................................27
4.1 Transport ............................................................................................................................................. 27
4.2 Scope of Delivery ................................................................................................................................ 27
4.3 Storage................................................................................................................................................ 27
5. Installation and Initial Start-Up .............................................................................................................28
5.1 General Installation Instructions ......................................................................................................... 28
5.1.1 The Sensor’s Coordinate System ........................................................................................... 28
5.1.2 Shadows.................................................................................................................................. 28
5.1.3 Tilting Around the a-Axis ......................................................................................................... 29
5.1.4 Tilting Around the b-Axis ......................................................................................................... 29
5.2 Complementary Products ................................................................................................................... 30
5.3 System Overview................................................................................................................................. 31
5.4 Installation ........................................................................................................................................... 33
5.4.1 Electrical Connection ............................................................................................................. 33
5.4.2 Connecting External 24 V Laser Shutdown ............................................................................ 33
5.4.3 Initial Start-Up at the PC .......................................................................................................... 33
5.4.4 Adjusting the Sensor’s Network Settings................................................................................ 34
5.5 Default Settings ................................................................................................................................... 35
5.6 Programming Interfaces ..................................................................................................................... 36

3
2D-/3D Profile Sensors
6. Integrated Web Server...........................................................................................................................36
6.1 Accessing the Integrated Website ...................................................................................................... 36
6.2 Page Layout ........................................................................................................................................ 37
6.2.1 Device, General ....................................................................................................................... 39
6.2.2 Device Settings........................................................................................................................ 39
6.2.3 2D/3D Profile Settings ............................................................................................................. 41
6.2.4 I/O Settings.............................................................................................................................. 47
6.3 Using More than One Sensor (synchronization) ................................................................................ 50
7. OLED Display.........................................................................................................................................51
7.1 Settings ............................................................................................................................................... 52
7.2 Run ...................................................................................................................................................... 52
7.3 Encoder............................................................................................................................................... 53
7.4 Display................................................................................................................................................. 53
7.4.1 Rotate....................................................................................................................................... 53
7.4.2 Intensity ................................................................................................................................... 53
7.4.3 Mode........................................................................................................................................ 53
7.5 Configuration....................................................................................................................................... 54
7.5.1 Load......................................................................................................................................... 54
7.5.2 Save ......................................................................................................................................... 54
7.6 Interface............................................................................................................................................... 54
7.6.1 IP adress.................................................................................................................................. 55
7.6.2 MAC address ........................................................................................................................... 55
7.6.3 Network reset........................................................................................................................... 55
7.7 Language ............................................................................................................................................ 56
7.8 INFO .................................................................................................................................................... 56
7.9 Restart ................................................................................................................................................. 56
7.10 Reset ................................................................................................................................................... 56
7.11 Password............................................................................................................................................. 57
8. Maintenance Instructions......................................................................................................................57
9. Proper Disposal .....................................................................................................................................57
10. Appendix ................................................................................................................................................58
10.1 Change Index, Operating Instructions................................................................................................ 58
10.2 EU Declaration of Conformity ............................................................................................................. 59

4General
1. General
1.1 Information Concerning these Instructions
• These instructions apply to the weCat3D product series.
• They make it possible to use the product safely and efficiently.
• These instructions are an integral part of the product and must be kept on hand for the entire duration of
its service life.
• Local accident prevention regulations and national work safety regulations must be complied with as well.
• The product is subject to further technical development, and thus the information contained in these
operating instructions may also be subject to change. The current version can be found at
www.wenglor.com in the product’s separate download area.
NOTE!
The operating instructions must be read carefully before using the product and must be
kept on hand for later reference.
1.2 Explanations of Symbols
• Safety precautions and warnings are emphasized by means of symbols and attention-getting words.
• Safe use of the product is only possible if these safety precautions and warnings are adhered to.
The safety precautions and warnings are laid out in accordance with the following principle:
ATTENTION-GETTING WORD
Type and Source of Danger!
Possible consequences in the event that the hazard is disregarded.
• Measures for averting the hazard.
The meanings of the attention-getting words, as well as the scope of the associated hazards, are listed below.
DANGER!
This word indicates a hazard with a high degree of risk which, if not avoided, results in death
or severe injury.
WARNING!
This word indicates a hazard with a medium degree of risk which, if not avoided, may result
in death or severe injury.
CAUTION!
This word indicates a hazard with a low degree of risk which, if not avoided, may result in
minor or moderate injury.
ATTENTION:
This word draws attention to a potentially hazardous situation which, if not avoided, may
result in property damage.

5
2D-/3D Profile Sensors
NOTE!
A note draws attention to useful tips and suggestions, as well as information regarding
efficient, error-free use.
1.3 Limitation of Liability
• The product has been developed in consideration of the current state-of-the-art and applicable standards
and guidelines. Subject to change without notice.
• A valid declaration of conformity can be accessed at www.wenglor.com in the product’s separate
download area.
• wenglor sensoric elektronische Geräte GmbH (hereinafter referred to as “wenglor”) excludes all liability in
the event of:
• Non-compliance with the instructions
• Use of the product for purposes other than those intended
• Use by untrained personnel
• Use of unapproved replacement parts
• Unapproved modification of products
• These operating instructions do not include any guarantees from wenglor with regard to the described
procedures or specific product characteristics.
• wenglor assumes no liability for printing errors or other inaccuracies contained in these operating
instructions, unless wenglor was verifiably aware of such errors at the point in time at which the operating
instructions were prepared.
1.4 Copyrights
• The contents of these instructions are protected by copyright law.
• All rights are reserved by wenglor.
• Commercial reproduction or any other commercial use of the provided content and information, in
particular graphics and images, is not permitted without previous written consent from wenglor.

6For Your Safety
2. For Your Safety
2.1 Use for Intended Purpose
The product is based on the following functional principle:
2D/3D Profile Sensors project a laser line (1) onto the object to be detected (2) and generate an accurate,
linearized height profile with an internal camera (3) which is set up at a triangulation angle (4).
Thanks to its uniform, open interface, the weCat3D series can be incorporated by means of the DLL (Win-
dows)/so (Linux) or the GigE Vision standard without an additional control unit. Alternatively, wenglor offers
its own software packages for implementing your application. Individualized selection from a great variety of
working ranges, laser classes and light types (red and blue light) ensures maximized flexibility for two and
three-dimensional object detection.
The weCat3D range of sensors is subdivided into two performance classes: weCat3D MLSL and weCat3D
MLWL. Whereas the weCat3D MLSL provides for high performance in standard applications with its compact
design, the weCat3D MLWL assures maximized, top performance.
The weCat3D MLSL is distinguished by minimal weight and a space-saving housing. Up to 3.6 million
measuring points per second, an output rate of up to 4000 Hz, visual field widths from 27 to 1350 mm, high
resolution (down to 22 µm in visual field width X and down to 3.3 µm in working distance Z) deliver outstand-
ing performance.
The weCat3D MLWL is distinguished by previously unparalleled performance characteristics: up to 12 million
measuring points per second, an output rate of up to 6000 Hz, visual field widths from 30 to 1300 mm and
high resolution (down to 17 µm in visual field width X and down to 2.0 µm in working distance Z) impressively
demonstrate the breathtaking high performance and precision of this product range.
2.1.1 Function Principle
= Laser line
= Object
= Integrated camera
= Triangulation angle

7
2D-/3D Profile Sensors
This product can be used in the following industry sectors:
• Special machinery manufacturing
• Heavy machinery manufacturing
• Logistics
• Automotive industry
• Food industry
• Packaging industry
• Plastics industry
• Woodworking industry
• Consumer goods industry
• Paper industry
• Electronics industry
• Glass industry
• Steel industry
• Printing industry
• Construction industry
• Other
2.2 Use for Other than the Intended Purpose
• The product is not a safety component in accordance with the EG Machinery Directive.
• The product is not suitable for use in potentially explosive atmospheres.
DANGER!
Risk of personal injury or property damage in case of use for other than the
intended purpose!
Use for other than the intended purpose may lead to hazardous situations.
• Instructions regarding use for intended purpose must be observed.
2.3 Personnel Qualifications
• Suitable technical training is a prerequisite.
• In-house electronics training is required.
• Trained personnel who use the product must have uninterrupted access to the operating instructions.
• Valid laser protection requirements must always be adhered to.
ATTENTION!
Risk of personal injury or property damage in case of incorrect initial start-up
and maintenance!
Personal injury and damage to equipment may occur.
• Adequate training and qualification of personnel.
2.4 Modification of Products
ATTENTION!
Risk of personal injury or property damage if the product is modified!
Personal injury and damage to equipment may occur. Non-observance may result in
loss of the CE marking and the guarantee may be rendered null and void.
• Modification of the product is impermissible.

8For Your Safety
2.5 General Safety Precautions
NOTE!
• These instructions are an integral part of the product and must be kept on hand for the
entire duration of its service life.
• In the event of possible changes, the respectively current version of the operating
instructions can be accessed at www.wenglor.com in the product’s separate download
area.
• Read the operating instructions carefully before using the product.
• The sensor must be protected against contamination and mechanical influences.
2.6 Laser/LED Warnings
Warning labels are included with the products depending on laser class and type of light. The respective
warning labels must be attached to the system in a plainly visible fashion.
Laser Class IEC EN 60825-1 FDA/CFR
Laser Class 1M (EN 60825-1)
Applicable standards and safety regulations
must be observed.
LASERSTRAHLUNG
NICHT DIREKT MIT OPTISCHEN
INSTRUMENTEN BETRACHTEN
LASER KLASSE 1M
EN60825-1: 2007
Not applicable
Laser Class 2M red (EN 60825-1)
Applicable standards and safety regulations
must be observed.
LASERSTRAHLUNG
NICHT IN DEN STRAHL BLICKEN ODER DIREKT
MIT OPTISCHEN INSTRUMENTEN BETRACHTEN
LASER KLASSE 2M
EN60825-1: 2007
E ≤25 W/m² , λ= 620-690 nm
LASER RADIATION
DO NOT STARE INTO BEAM
Complies with 21 CFR
1040.10 and 1040.11 except
for deviations pursuant to Laser
Notice No. 50, July 2001
CLASS 2 LASER PRODUCT
CAUTION
Laser Class 2M blue (EN 60825-1)
Applicable standards and safety regulations
must be observed.
LASERSTRAHLUNG
NICHT IN DEN STRAHL BLICKEN ODER DIREKT
MIT OPTISCHEN INSTRUMENTEN BETRACHTEN
LASER KLASSE 2M
EN60825-1: 2007
E ≤25 W/m² , λ= 400-460 nm
LASER RADIATION
DO NOT STARE INTO BEAM
Complies with 21 CFR
1040.10 and 1040.11 except
for deviations pursuant to Laser
Notice No. 50, July 2001
CLASS 2 LASER PRODUCT
CAUTION
Laser Class 3R red (EN 60825-1)
Applicable standards and safety regulations
must be observed.
The laser outlet is identified on the device.
LASERSTRAHLUNG
DIREKTE BESTRAHLUNG DER AUGEN VERMEIDEN
LASER KLASSE 3R
EN60825-1: 2007
P0≤5 mW , λ= 620-690 nm
LASER RADIATION -
AVOID DIRECT EYE EXPOSURE
CAUTION
CLASS IIIa LASER PRODUCT
DANGER
Complies with 21 CFR
1040.10 and 1040.11 except
for deviations pursuant to Laser
Notice No. 50, July 2001
620 - 690 nm ≤5 mW
Laser Class 3R blue (EN 60825-1)
Applicable standards and safety regulations
must be observed.
The laser outlet is identified on the device.
LASERSTRAHLUNG
DIREKTE BESTRAHLUNG DER AUGEN VERMEIDEN
LASER KLASSE 3R
EN60825-1: 2007
P0≤5 mW , λ= 400-460 nm
LASER RADIATION -
AVOID DIRECT EYE EXPOSURE
CAUTION
CLASS IIIa LASER PRODUCT
DANGER
Complies with 21 CFR
1040.10 and 1040.11 except
for deviations pursuant to Laser
Notice No. 50, July 2001
≦400 - 460 nm 5 mW
Laser Class 3B blue (EN 60825-1)
Applicable standards and safety regulations
must be observed.
The laser outlet is identified on the device.
LASERSTRAHLUNG
NICHT DEM STRAHL AUSSETZEN
LASER KLASSE 3B
EN60825-1: 2007
P0≤500 mW , λ= 400-460 nm
LASER RADIATION -
AVOID DIRECT EXPOSURE TO THE BEAM
CAUTION
CLASS IIIb LASER PRODUCT
DANGER
Complies with 21 CFR
1040.10 and 1040.11 except
for deviations pursuant to Laser
Notice No. 50, July 2001
400 - 460 nm ≤500 mW

9
2D-/3D Profile Sensors
2.7 Approvals and protection class
RoHS
3. Technical Data
Order No.
Technical Data
MLSL MLWL
Electrical Data
Supply Voltage 18...30 V
Current consumption (Ub = 24 V)* 300 mA 300 mA
Measuring rate 200…4 000 Hz 180…6 000 Hz
Temperature range 0...45 °C
Storage temperature −20…70 °C
Number of I/Os 4
Switching Output Voltage Drop < 1,5 V
Switching Output/Switching Current 100 mA
Can be switched to NC or NO operation yes
PNP / NPN / push-pull yes
Short-circuit proof yes
Reverse polarity protected yes
Overload-proof yes
Interface Ethernet TCP/IP
Transmission speed 100/1000 MBit/s
Protection class III
Integrated web server yes
Mechanical Data
Housing Aluminum/Plastic Aluminum
Degree of Protection IP67
Connection Type M12×1; 12-pin.
Ethernet connector type M12×1; 8-pin.
External 24 V laser shutdown M12×1, 8-pin ** ---
Optic Cover Plastic Glass
* Increased current consumption (1000 mA) for weCat3D MLWL and MLSL2 with laser class 3B.
** Only MLSL2 with laser class 3R and 3B
NOTE!
• The warm-up phase lasts roughly 15 minutes.

10 Technical Data
Order No.
Technical Data
MLSL1x1 MLSL1x2 MLSL1x3 MLSL1x4
Optical Data
Working range Z 72…108 mm 65…125 mm 90…280 mm 100…500
Measuring range Z 36 mm 60 mm 190 mm 400 mm
Visual field width X 27…34 mm 40…58 mm 62…145 mm 70…280 mm
Resolution Z 3,3…5,2 µm 4,8…9,6 µm 9,4…49 µm 12,4…160 µm
Resolution X 22…28 µm 33…47 µm 54…123 µm 68…246 µm
Temperature drift 2 µm/K 3 µm/K 10 µm/K 20 µm/K
Linearity deviation 18 µm 30 µm 95 µm 200 µm
0,05 %
Service life (Tu=+25 °C) 20.000 h
max. Ambient Light 5.000 Lux
Order No.
Technical Data
MLSL2x5 MLSL2x6
Optical Data
Working range Z 280…1280 mm 300…1500 mm
Measuring range Z 1000 mm 1200 mm
Visual field width X 200…850 mm 250…1350 mm
Resolution Z 40…570 µm 60…990 µm
Resolution X 190…760 µm 270…1170 µm
Temperature drift 50 µm/K 60 µm/K
Linearity deviation 500 µm 600 µm
0,05 %
Service life (ambient temp. = +25° C) 20.000 h
Max. permissible ambient light 5.000 lux

11
2D-/3D Profile Sensors
Order No.
Technical Data
MLWL1x1 MLWL1x2 MLWL1x3 MLWL1x4 MLWL1x5
Optical Data
Working range Z 70…130 mm 83…213 mm 215…475mm 390…910 mm 600…1 400
mm
Measuring range Z 60 mm 130 mm 260 mm 520 mm 800 mm
Visual field width X 30…52 mm 50…110 mm 150…230 mm 285…455 mm 450…720 mm
Resolution Z 2…4,9 µm 3,2…14 µm 9,6…22 µm 17,8…43 µm 28…67 µm
Resolution X 17…26 µm 26…55 µm 79…120 µm 151…238 µm 235…361 µm
Temperature drift 3 µm/K 6 µm/K 12 µm/K 24 µm/K 37 µm/K
Linearity deviation 15 µm 32,5 µm 65 µm 130 µm 200 µm
0,025 %
Service life (Tu=+25 °C) 20.000 h
max. Ambient Light 5.000 Lux
Order No.
Technical Data
MLWL2x1 MLWL2x2 MLWL2x3 MLWL2x4 MLWL2x5
Optical Data
Working range Z 120…300 mm 120…470 mm 300…1 000
mm
600…2 000
mm
1000…2 500
mm
Measuring range Z 180 mm 350 mm 700 mm 1 400 mm 1 500 mm
Visual field width X 65…145 mm 120…395 mm 280…830 mm 440…1300
mm
850…1300
mm
Resolution Z 5,2…26 µm 8,9…76 µm 27…162 µm 39…289 µm 92…439 µm
Resolution X 36…81 µm 68…198 µm 181…446 µm 251…683 µm 505…1 095
µm
Temperature drift 10 µm/K 16 µm/K 32 µm/K 64 µm/K 70 µm/K
Linearity deviation 45 µm 87,5 µm 175 µm 350 µm 375 µm
0,025 %
Service life (Tu=+25 °C) 20.000 h
max. Ambient Light 5.000 Lux
weCat3D MLSL
weCat3D MLWL x x x Field of Vision
Type of Light, Laser ClassSeries

12 Technical Data
Where type of light and laser class are concerned, the “X” in the order number stands for the following
variants:
x Light Source Laser Class
0 Laser (Red 660 nm) 1M
2 Laser (Red 660 nm) 2M
3 Laser (Blue 405 nm) 2M
4 Laser (Red 660 nm) 3R*
5 Laser (Blue 405 nm) 3R*
7 Laser (Blue 450 nm) 3B*
* Only available for weCat3D MLWL and MLSL2
3.1 Fields of Vision
weCat3D MLSL
weCat3D MLSL1x1
MLSL1x1
X/mm
Z/mm
0
120110100
90
80
70
60
5040
30
30
30
20
20
20
10
10
10
weCat3D MLSL1x2
4030
20 120 130
110
100 140
10 150
20
30
40
0
10
10
20
30
40
X/mm
Z/mm
MLSL1x2
90
8070
60
50

13
2D-/3D Profile Sensors
weCat3D MLSL1x3
100 200 250
50 300
100
50
0
50
100
X/mm
Z/mm
MLSL1x3
150
weCat3D MLSL1x4
200 400 500
100 600
200
100
0
100
200
X/mm
Z/mm
MLSL1x4
300
weCat3D MLSL2x5
400300
200 1200 1300
1100
1000 1400
100
1500
200
300
400
0
100
100
200
300
400
X/mm
Z/mm
MLSL2x5
900
800700
600
500

14 Technical Data
weCat3D MLSL2x6
MLSL2x6
0
250
500
750
750
500
250
X/mm
Z/mm
weCat3D MLWL
weCat3D MLWL1x1
4030
20 120 130
110
100 140
10 150
20
30
40
0
10
10
20
30
40
X/mm
Z/mm
MLWL1x1
90
8070
60
50
weCat3D MLWL1x2
8060
40 240 260
220
200 280
20 300
40
60
80
0
20
20
40
60
80
X/mm
Z/mm
MLWL1x2
180
160140
120
100

15
2D-/3D Profile Sensors
weCat3D MLWL1x3
MLWL1x3
0
50
100
150
150
100
50
X/mm
Z/mm
weCat3D MLWL1x4
MLWL1x4
0
100
200
300
300
200
100
X/mm
Z/mm
weCat3D MLWL1x5
400300
200 1200 1300
1100
1000 1400
100 1500
200
300
400
0
100
100
200
300
400
X/mm
Z/mm
MLWL1x5
900
800700
600
500

16 Technical Data
weCat3D MLWL2x1
100 200 250
50 300
100
50
0
50
100
X/mm
Z/mm
MLWL2x1
150
weCat3D MLWL2x2
200 400 500
100 600
200
100
0
100
200
X/mm
Z/mm
MLWL2x2
300
weCat3D MLWL2x3
400300
200 1200 1300
1100
1000 1400
100 1500
200
300
400
0
100
100
200
300
400
X/mm
Z/mm
MLWL2x3
900
800700
600
500

17
2D-/3D Profile Sensors
weCat3D MLWL2x4
MLWL2x4
0
250
500
750
750
500
250
X/mm
Z/mm
weCat3D MLWL2x5
MLWL2x5
0
600 900 1200 1500 1800 2100 2400
300 2700
3000
300
600
900
900
600
300
X/mm
Z/mm

18 Technical Data
3.2 Dimensional Drawings
weCat3D MLSLxxx
weCat3D MLSL1xx
weCat3D MLSL2xx
1= only MLSL2 with laser class 3R and 3B

19
2D-/3D Profile Sensors
weCat3D MLWLxxx
weCat3D MLWL1x1
weCat3D MLWL1x2

20 Technical Data
weCat3D MLWL1x3
weCat3D MLWL1x4
1 = recommended mounting
position based on the
sensor’s center of gravity
1 = recommended mounting
position based on the
sensor’s center of gravity
