Weslo Pursuit easy 100 bike User manual

CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USER'S MANUAL
Serial Number
Decal
Model No. WLEVEX71808.0
Serial No.
Write the serial number in the
space above for reference.
QUESTIONS?
As a manufacturer, we are commit-
ted to providing complete customer
satisfaction. If you have questions,
or if there are missing parts, please
contact us:
Call: 08457 089 009
Outside UK: 0 (44) 113 3877133
Fax: [phone]
E-mail: [email protected]
Write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road, Beeston
Leeds, LS11 8 G
UK

2
TABLE OF CONTENTS
WARNINGDECA P ACEMENT ..............................................................2
IMPORTANTPRECAUTIONS ................................................................3
BEFOREYOUBEGIN ......................................................................4
ASSEMB Y ...............................................................................5
HOWTOUSETHEEXERCISECYC E........................................................11
MAINTENANCEANDTROUB ESHOOTING ...................................................16
EXERCISEGUIDE INES ...................................................................17
PART IST ..............................................................................18
EXP ODEDDRAWING ....................................................................19
ORDERINGREP ACEMENTPARTS ..................................................BackCover
WES O is a registered trademark of ICON IP, Inc.
WARNING DECAL PLACEMENT
This drawing shows the location(s) of the
warning decal(s). If a decal is missing or
illegible, call the telephone number on the
front cover of this manual and request a
free replacement decal. Apply the decal in
the location shown. Note: The decal(s) may
not be shown at actual size.
This product should
alwaysbe used on a
level su
rface.
This produc t is not
intended for
therapeutic use.
Misuse of this machine
may result in serious
injury .
Read user’s manual
prior to use and foll ow
all warnings and
inst ruc tions .
Do not allow children
on or around machin e.
User weight must not
ex
c
eed 250 pound s.
Replac e label if
damaged, illegible ,
or removed.

3
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over the age of 35 or
persons with pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of the exercise cycle are ade-
quately informed of all precautions.
3. Your exercise cycle is intended for home use
only. Do not use your exercise cycle in a
commercial, rental, or institutional setting.
4. Keep your exercise cycle indoors, away from
moisture and dust. Place your exercise cycle
on a level surface, with a mat beneath it to
protect the floor or carpet. Make sure that
there is enough clearance around your exer-
cise cycle to mount, dismount, and use it.
5. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
6. Keep children under age 12 and pets away
from your exercise cycle at all times.
7. Your exercise cycle should not be used by
persons weighing more than 250 lbs.
(113 kg).
8. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
9. Wear appropriate exercise clothes while
exercising; do not wear loose clothes that
could become caught on your exercise
cycle. Always wear athletic shoes for foot
protection while exercising.
10. Keep your back straight while using your
exercise cycle; do not arch your back.
11. When you stop exercising, allow the pedals
to slowly come to a stop.
12. If you feel pain or dizziness while exercising,
stop immediately and cool down.
13. Use your exercise cycle only as described in
this manual.
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your exercise cycle before using your exercise
cycle. ICON assumes no responsibility for personal injury or property damage sustained by or
through the use of this product.
IMPORTANT PRECAUTIONS

4
Congratulations for selecting the new WES O®
PURSUIT EASY 100 exercise cycle. Cycling is one of
the most effective exercises for increasing cardiovas-
cular fitness, building endurance, and toning the body.
The PURSUIT EASY 100 exercise cycle offers a
selection of features designed to let you enjoy this
healthful exercise in the convenience and privacy of
your home.
For your benefit, read this manual carefully before
you use the exercise cycle. If you have questions
after reading this manual, please see the front cover
of this manual. To help us assist you, note the product
model number and serial number before contacting
us. The model number and the location of the serial
number decal are shown on the front cover of this
manual.
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
Resistance Knob
Seat
Seat Post Knob
Pedal/Strap
eveling Cap
Console Pulse Sensor
Handlebar
Pivot Handle
BEFORE YOU BEGIN
Seat Knob

5
M8 Split
Washer (42)–3
M4 x 15mm
Screw (48)–5
M8 x 16mm Patch
Screw (34)–3
M10 x 70mm Patch Screw (33)–2
M8 x 60mm Patch Screw (30)–4
ASSEMBLY
Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the pack-
ing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tools, assembly requires a Phillips screwdriver , an adjustable
wrench , and pliers .
Use the drawings below to identify the small parts used in assembly. The number in parentheses below each
drawing is the key number of the part, from the PART IST near the end of this manual. The second number is
the quantity needed for assembly. Note: Some small parts may have been preassembled. If a part is not in
the hardware kit, check to see if it has been preassembled.

6
1.
Insert the Rear Stabilizer (6) into the Frame (1).
Attach the Rear Stabilizer with four M8 x 60mm
Patch Screws (30).
6
30
1
2. Orient the Front Stabilizer (2) so that the large
holes face the Frame (1). Attach the Front
Stabilizer to the Frame with two M10 x 70mm
Patch Screws (33).
1
1
2
33
2
arge
Holes
To make assembly easier, read the
information on page 5 before you begin
assembling the exercise cycle.

7
3
3. While another person holds the Upright (13)
near the Frame (1), connect the Extension Wire
(23) to the Reed Switch Wire (39). Next, con-
nect the Resistance Cable (19) to the ower
Cable (29) in the following way:
•See drawing A. Pull upward on the metal
bracket on the ower Cable (29), and insert
the tip of the Resistance Cable (19) into the
wire clip inside the metal bracket as shown.
•See drawing B. Firmly pull the Resistance
Cable (19) upward and slide it into the top of
the metal bracket as shown.
•See drawing C. Using pliers, squeeze the
prongs on the upper end of the metal bracket
together.
Push the Wires (23, 39) and the Cables (19, 29)
downward into the Frame (1).
Tip: Do not pinch the wires and cables. Insert
the Upright (13) into the Frame (1). Attach the
Upright with three M8 x 16mm Patch Screws
(34) and three M8 Split Washers (42).
Do not pinch the
wires and cables
42
39
19
29
42
34
23
13
1
34
ABC
29
19
19 Metal
Bracket
Metal
Bracket
29

8
5. The Console (16) requires four AA batteries (not
included); alkaline batteries are recommended.
IMPORTANT: If the Console has been
exposed to cold temperatures, allow it to
warm to room temperature before inserting
batteries. Otherwise, you may damage the
console displays or other electronic compo-
nents. Remove the screw, remove the battery
cover, and insert the batteries into the battery
compartment. Then, reattach the battery cover.
Make sure to orient the batteries as shown
by the diagram inside the battery compart-
ment.
5
Batteries
Screw Battery
Cover
16
4
4. While another person holds the Handlebar (50)
near the Upright (13), insert the Pulse Wires
(59) into the Upright and pull them upward out
of the top of the Upright.
Tip: Do not pinch the wires. Attach the
Handlebar (50) to the Upright (13) with the Pivot
Clamp (54), the Rear Cover (3), and the Pivot
Handle (55).
Note: The Pivot Handle (55) functions like a
ratchet. Turn the Pivot Handle clockwise, pull it
away from the Upright (13), turn it counterclock-
wise, push it toward the Upright, and then turn it
clockwise again. Repeat this process until the
Pivot Handle is tight.
Attach the Rear Cover (3) to the Upright (13)
with an M4 x 15mm Screw (48).
Do not pinch
the wires
59
3
13
54
55
48
50

9
7
6
6. While another person holds the Console (16)
near the Upright (13), connect the console wire
to the Extension Wire (23). Next, connect the
console pulse wires to the Pulse Wires (59).
Then, connect the console ground wire to the
ground wire on the Upright (13).
Insert the excess wire downward into the
Upright (13).
Tip: Avoid pinching the wires. Attach the
Console (16) to the Upright (13) with four M4 x
15mm Screws (48).
48
Console Wire
16
Ground Wires
Pulse Wires
59
13
23
7. oosen and remove the Seat Knob (56) from
the Seat Carriage (58), which is located on the
underside of the Seat (12).
See the inset drawing. ook underneath the
Seat (12) and locate the Seat Carriage (58).
Next, locate the Seat Block (57) inside the Seat
Carriage.
Set the Seat Carriage (58) in the bracket on the
Seat Post (5). Next, insert the Seat Knob (56)
upward through the bracket on the Seat Post
into the hole in the Seat Block (57). Then, tight-
en the Seat Knob.
12
5
58
56
12
57
57
58

10
10. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly
is completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
9. Identify the eft Pedal (24), which is marked
with an “ .” Using an adjustable wrench, firmly
tighten the eft Pedal counterclockwise into the
left arm of the Crank (21).
Tighten the Right Pedal (not shown) clockwise
into the right arm of the Crank (not shown).
IMPORTANT: Tighten both pedals as firmly
as possible. After using the exercise cycle
for one week, retighten the pedals. For best
performance, keep the pedals tightened.
Adjust the strap on the eft Pedal (24) to the
desired position, and press the end of the strap
onto the tab on the side of the eft Pedal.
Adjust the strap on the Right Pedal (not
shown) in the same way.
9
24
Strap
Tab
21
8. oosen and remove the Seat Post Knob (9)
from the Frame (1).
Insert the Seat Post (5) into the Frame (1).
Adjust the Seat Post to the desired height and
insert the Seat Post Knob (9) through the indi-
cated hole in the Frame into one of the
adjustment holes in the Seat Post.
Tighten the Seat Post Knob (9). Make sure that
the Seat Post Knob is firmly engaged in one
of the adjustment holes in the Seat Post (5).
8
5
1
9
Hole
Adjustment
Holes
