Weslo Cadence 85 User manual

USER'S MANUAL
Serial
Number
Decal
Model No. WETL26140C
Serial No.
CAUTION
Read all precautions and in-
structions in this manual before
using this equipment. Save this
manual for future reference.
Class HC Fitness Product
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts,
please call:
or write:
ICON Health & Fitness, Ltd.
Customer Service Department
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
email: [email protected]
08457 089 009

TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
OPERATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
Note: An EXPLODED DRAWING and a PART LIST are attached in the centre of this manual.
WESLO is a registered trademark of ICON IP, Inc.
2

3
1. It is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
2. Use the treadmill only as described.
3. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
4. Place the treadmill on a level surface, with at
least 2.5 m (8 ft.) of clearance behind it and
0.5 m (2 ft.) on each side. Do not place the
treadmill on a surface that blocks any air
openings. To protect the floor or carpet from
damage, place a mat under the treadmill.
5. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
6. Keep children under the age of 12 and pets
away from the treadmill at all times.
7. The treadmill should be used only by persons
weighing 113 kg (250 lbs.) or less.
8. Never allow more than one person on the
treadmill at a time.
9. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended for
both men and women.
Always wear athletic
shoes. Never use the treadmill with bare feet,
wearing only stockings, or in sandals.
10. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 6, and HOW TO FOLD
AND MOVE THE TREADMILL on page 14.)
You must be able to safely lift 20 kg (45 lbs) to
raise, lower, or move the treadmill.
11. When connecting the power cord (see page 9),
plug the power cord into an earthed circuit.
No other appliance should be on the same cir-
cuit. When replacing the fuse, an ASTA ap-
proved BS1362 type should be fitted to the
fuse carrier. A 13 amp fuse should be used.
12. If an extension cord is needed, use only a 3-
conductor, 1mm2(14-gauge) cord that is no
longer than 1.5 m.
13. Keep the power cord away from heated
surfaces.
14. Do not change the incline of the treadmill by
placing objects under the treadmill.
15. Never move the walking belt whilst the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See BE-
FORE YOU BEGIN on page 5 if the treadmill is
not working properly.)
16. Never start the treadmill whilst you are stand-
ing on the walking belt. Always hold the
handrails whilst using the treadmill.
17. The treadmill is capable of high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
18. The pulse sensor is not a medical device.
Various factors, including your movement,
may affect the accuracy of heart rate readings.
The sensor is intended only as an exercise aid
in determining heart rate trends in general.
19. Never leave the treadmill unattended whilst it
is running. Always remove the key, unplug
the power cord, and move the on/off switch to
the off position when the treadmill is not in
use. (See the drawing on page 5 for the loca-
tion of the on/off switch.)
20. When folding or moving the treadmill, make
sure that the storage latch is fully closed.
WARNING: Toreduce the risk of burns, fire, electric shock, or injury to persons, read the
following important precautions and information before operating the treadmill.
IMPORTANT PRECAUTIONS

4
39%
The decal shown have been placed on the treadmill. If a decal is missing, or if it is not legible, please call
our Customer Service Department to order a free replacement decal (see the back cover of this manual).
Apply the decal in the location shown. Note: The decals may not be shown at actual size.
21. Inspect and properly tighten all parts of the
treadmill regularly.
22. Never insert any object into any opening.
23. DANGER: Always unplug the power
cord immediately after use, before cleaning the
treadmill, and before performing the mainte-
nance and adjustment procedures described in
this manual. Never remove the motor hood un-
less instructed to do so by an authorised ser-
vice representative. Servicing other than the
procedures in this manual should be performed
byan authorised service representative only.
24. The treadmill is intended for in-home use
only. Do not use the treadmill in a commer-
cial, rental, or institutional setting.
WARNING: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
SAVE THESE INSTRUCTIONS

5
Congratulations for selecting the new WESLO®
CADENCE 85 treadmill. The CADENCE 85 treadmill
combines advanced technology with innovative design
to help you get the most from your exercise, in the pri-
vacy of your home. And when you’re not exercising, the
unique CADENCE 85 treadmill can be folded up, re-
quiring less than half the floor space of other treadmills.
For your benefit, read this manual carefully before
using the treadmill.If you have questions after read-
ing this manual, please call our Customer Service
Department at 08457 089 009.To help us assist you,
please note the product model number and serial num-
ber before calling. The model number of the treadmill
is WETL26140C. The serial number can be found on a
decal attached to the treadmill (see the front cover of
this manual for the location).
Before reading further, please familiarise yourself with
the parts that are labelled in the drawing below.
BEFORE YOU BEGIN
Handrail
Upright
Storage Latch
Key/Clip
Circuit Breaker
Walking Belt
Walking Platform
Foot Rail
RIGHT SIDE
Rear Roller
Adjustment Bolts
Console
Bookrack
Accessory Tray
On/Off Switch
BACK

ASSEMBLY
Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is
coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the
top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill perfor-
mance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild,
non-abrasive cleaner.
Assembly requires the included hex keys and your own phillips screwdriver , wire cutters
and needlenose pliers .
For help identifying the assembly hardware, refer to the PART IDENTIFICATION CHART in the centre of
this manual. Note: The assembly hardware and other small parts are packaged in separate part bags. Do
not open the part bags until instructed to do so.
1. Make sure that the power cord is unplugged.
Place the Base (79) in the position shown, with the indi-
cated small holes on top (only one small hole is shown).
Place a Wheel (63) in each Wheel Housing (62), and
slide the Wheel Housings onto the ends of the Base that
have bolt holes.
Open part bag A. Attach the Wheels (63) to the Wheel
Housings (62) with 2 1/2” Bolts (61) and Wheel Nuts
(64). Make sure that the Wheel Nuts are on the sides
shown; do not overtighten the Bolts.
Slide the two Base Endcaps (75) onto the other ends of
the Base (79) (only one Base Endcap is shown). Attach
the four Base Pads (73) to the Base Endcaps and the
Wheel Housings (62) with four 1 1/4” Tek Screws (60).
2. Raise the Base (79) to a vertical position, and hold it
near the treadmill Frame (96) as shown. Make sure that
the Wheels (63) are in the indicated position.
Identify the Right Upright (104), which has a large round
hole in the indicated location. Feed the Wire Harness
(65) into the hole and out of the top of the Right Upright.
Make sure that there are two U-Nuts (74) in the lower
end of the Right Upright (see drawing 2a). Hold the Right
Upright against the Base (79) as shown. Make sure that
the Right Upright is oriented so the pivot hole is in the
position shown. Hand tighten two 3” Bolts (58) with two
5/16” Star Washers (57) into the bottom of the Base and
the lower end of the Right Upright.
Attach the Left Upright (47) to the Base (79) in the same
way. Note: There is not a wire harness on the left side.
With the help of a second person, raise the Uprights (47,
104) to a vertical position.
60
73
Small Hole
75
61
73
63
62
Bolt
Hole 64
79
60
63
60
1
Pivot
Holes
79
63
63
58
57
47
58
57
65
2a
74
104
6
104
2
61
64
62
73
96
Round
Hole

7
5. Feed the Wire Harness (65) up into the bracket on one of
the Handrails (40) and out of the large hole in the left
side. (Note: It may be helpful to use needlenose pliers to
pull the Wire Harness out of the hole.) Remove any plas-
tic ties from the bracket.
Insert the bracket on the Handrail (40) into the upper end
of the Right Upright (104). Attach the Handrail with two 1”
Bolts (43), two 1/4” Washers (44), two 1/4” Star Washers
(45), a 4” Bolt (117), and a 5/16” Washer (122) as
shown. Do not tighten the Bolts yet.
See drawing 5a. Insert the included nylon tie through the
indicated hole in the Handrail (40).
See drawing 5b. Look into the Handrail (40) and make
sure that the Wire Harness (65) is secured to the side
shown. Tighten the nylon tie and cut the excess off the
end.
Attach the other Handrail (not shown) in the same way.
Note: You may need to tip the Handrail to one side as
you insert the bracket. There is not a wire harness in the
left Upright (not shown).
4. Attach the Latch Housing (46) to the Left Upright (47)
with two 3/4” Screws (38). Make sure that the large hole
in the Latch Housing is on the side shown.
Remove the Latch Knob (48) from the Latch Pin (52).
Make sure that the Latch Pin Collar (49) and the Spring
(50) are on the Latch Pin. Insert the Latch Pin into the
Storage Latch (46), and then tighten the Latch Knob
back onto the Latch Pin.
46
38
52
50
47
Large Hole
48
49
4
3. Open part bag B. Hold an Upright Spacer (59) against
one side of the Frame (96) as shown. Insert a 3 1/2” Bolt
(54) into the indicated hole in the Upright Spacer and the
Frame. Next, tighten a Crossbar Screw (37) into the
Upright Spacer and the Frame. Remove the 3 1/2” Bolt.
Repeat on the other side of the Frame.
Have a second person lift the front end of the Frame
(96). Insert a 3 1/2” Bolt (54) with a 3/8” Star Washer (55)
into the Right Upright (104) and the right Upright Spacer
(59), and tighten the Bolt into the Frame. Do not over-
tighten the Bolt. Repeat on the left side of the Frame.
3
55
96
Hole
54
104
37
59
65
43 44
104
45
43
44
45
40
40
117
122
Large
Hole
Bracket
5
5a 5b
Tie Tie
65
40

9. Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may
be included. Keep the included hex keys in a secure place. The large hex key is used to adjust the walking
belt (see page 17). To protect the floor or carpet, place a mat under the treadmill.
5
67
84
65
40
8. Press the Wire Harness (65) into the recessed track on
the back of the Console Base (67). Note: There may be a
cylinder on the Wire Harness preventing it from being in-
serted into the track. Press as much Wire as possible
into the track.
Insert the excess Wire Harness (65) into the large hole in
the side of the right Handrail (40). Securely tighten the
nylon tie to prevent the Wire Harness from slipping.
Then, cut off the end of the nylon tie.
Attach the Access Door (84) to the Console Base (67) with
the 1/2” Screw (5).
Tighten, but do not overtighten, the bolts used in
step 5. With the help of a second person, lower the
uprights. Make sure the Frame (96) is centred be-
tween the Uprights (47, 104), and firmly tighten the
bolts used in steps 2.
8
Tie
Tie
7. Place the Console Base (67) on the right Handrail (40)
and the Left Handrail (not shown).
Insert the Wire Harness (65) through the indicated nylon tie
on the Console Base (67). Next, touch the right Handrail
(40) to discharge any static. See drawing 7a. Find the
connector on the end of the Wire Harness. Insert the con-
nector into the red socket beneath the Console (69). The
connector should slide easily into the socket and snap
into place. If the connector does not slide easily and snap
into place, turn the connector and then insert it. IF THE
CONNECTOR IS NOT INSERTED PROPERLY, THE
CONSOLE MAY BE DAMAGED WHEN THE POWER
IS TURNED ON.
Identify the 3/4” Screws (38); be careful not to confuse
the 3/4” Screws with the 1/2” Screw (5). Attach the
Console Base (67) to the right Handrail (40) and the Left
Handrail (not shown) with eight 3/4” Screws (only four
Screws are shown). Start all eight Screws before tight-
ening them. Do not overtighten the Screws.
Tighten the Crossbar Screws (37).
65
67
7
40
6. Attach the end of the ground wire to the small hole in the
side of the right Handrail (40) with a Silver Ground Screw
(66).
Open part bag C. Attach the Crossbar (39) to the right
Handrail (40) and the left Handrail (40) with two Crossbar
Screws (37). Do not tighten the Crossbar Screws yet.
Make sure that the rectangular hole in the Crossbar is on
the indicated side.
6
8
7a
65
69
Ground Wire Hole
66
39
40
37
37
38
38
37
Track
40

9
THE PERFORMANT LUBETM WALKING BELT
Your treadmill features a walking belt coated with PERFORMANT LUBETM,ahigh-performance lubricant. IMPOR-
TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such
substances will deteriorate the walking belt and cause excessive wear.
HOW TO PLUG IN THE POWER CORD
This product must be earthed. If it should malfunction or break
down, earthing provides a path of least resistance for electric cur-
rent to reduce the risk of electric shock. This product is equipped
with a power cord having an equipment-earthing conductor and an
earthing plug. Important: If the power cord is damaged, it must
be replaced with a manufacturer-recommended power cord.
See drawing 1. Plug the indicated end of the power cord into the
socket on the treadmill. Lift the tab on the ferrite box and clamp the
ferrite box around the power cord. Fasten the included plastic tie just
behind the ferrite box and cut off the excess plastic tie. The plastic tie
will prevent the ferrite box from sliding along the power cord.
See drawing 2. Press the pins on the power cord into the metal clips
in the Adaptor as shown. Close the Adaptor cover over the end of
the power cord and tighten the screw in the Adaptor. Important:
Make sure that the Adaptor cover is secure and the screw has
been tightened before using the power cord.
See drawing 3. Plug the power cord into an appropriate outlet that is
properly installed and earthed in accordance with all local codes and
ordinances. Important: The treadmill is not compatible with
GFCI-equipped outlets.
DANGER: Improper connection of the equipment-earthing conductor can result in an in-
creased risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as
to whether the product is properly earthed. Do not modify the plug provided with the product—if it will
not fit the outlet, have a proper outlet installed by a qualified electrician.
Socket on treadmill
Metal
Clips
1
2
Ferrite Box
Tab
Plastic Tie
Pins
Screw
Adaptor
Outlet
3
Adaptor
Cover
OPERATION AND ADJUSTMENT

10
FEATURES OF THE CONSOLE
The treadmill console offers a selection of features
designed to help you get the most from your workouts.
When the manual mode of the console is selected, the
speed and incline of the treadmill can be changed with
the touch of a button. As you exercise, the displays will
provide continuous exercise feedback. You can even
measure your heart rate using the built-in pulse sensor.
Two speed programs are also offered. Each program
automatically controls the speed of the treadmill as it
guides you through an effective workout.
HOW TO TURN ON THE POWER
Note: If there is a sheet of clear plastic on the face of
the console, remove the plastic.
Plug in the power cord (see page 9).
Locate the on/off
switch on the right side
of the treadmill near
the right upright. Make
sure that the switch is
in the “on” position.
2
1
On
Position
Key Clip

11
Stand on the foot rails
of the treadmill. Find
the clip attached to the
key, and slide the clip
onto the waistband of
your clothes. Next, in-
sert the key into the
console. After a mo-
ment, the track and the
displays will light. Test
the clip by carefully
taking a few steps
backward until the key is pulled from the con-
sole. If the key is not pulled from the console,
adjust the position of the clip as needed.
HOW TO USE THE MANUAL MODE
Insert the key fully into the console.
See HOW TO TURN ON THE POWER on pages
10 and 11.
Select the manual mode.
When the key is in-
serted, the manual
mode will be selected
and the Manual Control
indicator will light. If
you have selected a
speed program, press the Program button repeat-
edly to reselect the manual mode.
Press the Start button or the Speed increase
button to start the walking belt.
Amoment after the button is pressed, the walking
belt will begin to move at 1 mph. Hold the handrails
and begin walking.
As you exercise,
change the speed of
the walking belt as de-
sired by pressing the
Speed increase and
decrease buttons.Each
time a button is pressed, the speed setting will
change by 0.1 mph. If a button is held down, the
speed setting will change in increments of 0.5
mph. Note: The console can display speed and
distance in either miles or kilometres (see
SPEED DISPLAY on page 12). For simplicity,
all instructions in this section refer to miles.
To stop the walking belt, press the Stop button.
The Time/Pace display will begin to flash. To
restart the walking belt, press the Start button or
the Speed increase button.
Note: During the first few minutes that the treadmill
is used, inspect the alignment of the walking belt,
and align the walking belt if necessary (see page
17).
Change the incline of the treadmill as desired.
To change the incline of the treadmill, hold down
the Incline increase or decrease button until the
desired incline level is reached.
Follow your progress with the track and the
displays.
The track—The track in
the centre of the console
represents a distance of
400 meter (1/4 mile). As
you walk or run on the
treadmill, the indicators
around the track will light
in succession until the entire track is lit. The track
will then darken and the indicators will again begin
to light in succession. The centre of the track will
show the number of laps that you have com-
pleted.
Distance display—This
display shows the dis-
tance that you have
walked or run.
Time/Pace display—
When the manual mode
is selected, this display
will show the elapsed
time and your pace (pace
is measured in minutes
per mile). The display will
alternate between one number and the other
every few seconds, as shown by the indicators in
the display. When a speed program is selected,
the display will show the time remaining in the pro-
gram and your pace.
5
4
3
2
1
3
Indicator
Clip

12
Fat Calories/Calories
display—This display
shows the approximate
numbers of
fat calories
and calories you have
burned (see FAT BURN-
ING on page 18). The display will alternate be-
tween one number and the other every few sec-
onds, as shown by the indicators in the display.
Speed display—This
display shows the speed
of the walking belt.
Note: The console can
display speed and dis-
tance in either miles or
kilometres. The letters
“MPH” or “Km/H” will ap-
pear in the Speed dis-
play to show which unit of measurement is se-
lected. To change the unit of measurement, press
the Stop button whilst inserting the key into the
console. An “E” for English miles or an “M” for met-
ric kilometres will appear in the Speed display.
Press the Speed increase button to change the
unit of measurement. When the desired unit of
measurement is selected, remove the key and
then reinsert it.
Heart Rate display—
This display shows your
heart rate when you use
the pulse sensor (see
step 6).
Measure your heart rate if desired.
To measure your
heart rate, stand on
the foot rails and
place your thumb
on the pulse sensor.
Do not press too
hard, or the circu-
lation in your
thumb will be restricted and your pulse will not
be detected. When your pulse is detected, the
heart-shaped indicator in the Heart Rate display
will flash each time your heart beats, and your
heart rate will be shown. Hold your thumb on the
pulse sensor for about 15 seconds for the most ac-
curate reading.
If the displayed heart rate appears to be too high
or too low, or if your heart rate is not displayed, lift
your thumb off the pulse sensor for a few seconds.
Then, place your thumb on the pulse sensor as de-
scribed above. Remember to stand still whilst
measuring your heart rate.
When you are finished exercising, remove the
key.
Step onto the foot rails, press the Stop button, and
adjust the incline of the treadmill to the lowest
level. The incline must be at the lowest level
when the treadmill is raised to the storage po-
sition or the treadmill will be damaged. Next,
remove the key from the console and put the key
in a secure place.
When you are finished using the treadmill, move
the on/off switch to the off position.
7
6
Pulse Sensor

13
HOW TO USE A SPEED PROGRAM
Insert the key into the console.
See HOW TO TURN ON THE POWER on pages
10 and 11.
Select one of the speed programs.
When the key is in-
serted, the manual
mode will be selected.
To select a speed pro-
gram, press the
Program button repeat-
edly until one of the two speed program indicators
lights. Note: The graphs beside the indicators
show how the speed of the treadmill will change
during the programs.
Each program consists of 30 one-minute periods.
One speed setting is programmed for each period.
Note: The same speed setting may be pro-
grammed for two or more consecutive periods.
Press the Start button or the Speed increase
button to start the program.
When the button is pressed, the treadmill will au-
tomatically adjust to the speed setting for the first
period. Hold the handrails and begin walking.
When the first period of the program ends, three
tones will sound and the Speed display will flash
three times. The speed of the walking belt will
then change if a different speed setting is pro-
grammed for the next period.
The program will continue until all 30 periods are
completed. The walking belt will then slow to a
stop.
Tochange the incline setting during the program,
press the Incline buttons. If the speed setting is
too high or too low during the program, you can
manually override the setting by pressing the
Speed buttons. However, when the next period
begins, the treadmill will automatically adjust
to the speed setting for the next period.
To stop the program, press the Stop button. The
Time/Pace display will begin to flash. To restart
the program, press the Start button or the Speed
increase button. The walking belt will begin to
move at 1 mph. When the next period begins, the
treadmill will automatically adjust to the speed set-
ting for the next period.
Follow your progress with the track and the
displays.
See step 5 on page 11.
Measure your heart rate if desired.
See step 6 on page 12.
When you are finished exercising, remove the
key.
When the program ends, make sure that the
treadmill is at the lowest incline level. Next, re-
move the key from the console and put it in a
secure place.
When you are finished using the treadmill,move
the on/off switch to the off position.
6
5
4
3
2
1

14
HOW TO FOLD AND MOVE THE TREADMILL
HOW TO FOLD THE TREADMILL FOR STORAGE
Before folding the treadmill, adjust the incline to the
lowest position. If this is not done, the treadmill may be per-
manently damaged. Next, unplug the power cord. CAUTION:
You must be able to safely lift 20 kg (45 lbs.) to raise, lower,
or move the treadmill.
1. Hold the treadmill with your hands in the locations shown at the
right. To decrease the possibility of injury, bend your legs
and keep your back straight. As you raise the treadmill,
make sure to lift with your legs rather than your back.
Raise the treadmill about halfway to the vertical position.
2. Move your right hand to the position shown and hold the
treadmill firmly. Using your left hand, pull the latch knob to
the left and hold it. Raise the treadmill until the frame is past
the latch pin. Slowly release the latch knob. Make sure that
the frame is securely held by the latch pin.
To protect the floor or carpet from damage, place a mat
under the treadmill. Keep the treadmill out of
direct sunlight. Do not leave the treadmill in the storage
position in temperatures above 30° C (85° F).
HOW TO MOVE THE TREADMILL
Before moving the treadmill, convert the treadmill to the storage
position as described above. Make sure that the frame is se-
curely held by the latch pin.
1. Hold the upper ends of the handrails. Place one foot on the
base as shown.
2. Tilt the treadmill back until it rolls freely on the front wheels.
Carefully move the treadmill to the desired location. To re-
duce the risk of injury, use extreme caution whilst mov-
ing the treadmill. Do not move the treadmill over an un-
even surface.
3. Place one foot on the base, and carefully lower the treadmill
until it is resting in the storage position.
Engaged
Frame
Latch
Knob
Latch Pin
Base
Front Wheels

15
HOW TO LOWER THE TREADMILL FOR USE
1. Hold the upper end of the treadmill with your right hand as
shown. Using your left hand, pull the latch knob to the left
and hold it. Pivot the treadmill down until the frame is past
the latch pin. Slowly release the latch knob.
2. Hold the treadmill firmly with both hands, and lower the tread-
mill to the floor. Do not drop the treadmill frame to the
floor. To decrease the possibility of injury, bend your legs
and keep your back straight.
Latch
Knob

16
TROUBLESHOOTING
Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and
follow the steps listed. If further assistance is needed, please call our Customer Service Department.
PROBLEM: The power does not turn on
SOLUTION: a. Make sure that the power cord is plugged into a properly earthed outlet (see page 9). If an exten-
sion cord is needed, use only a 3-conductor, 1 mm2(14-gauge) cord that is no longer than 1.5 m
(5 ft.). Important: The treadmill is not compatible with GFCI-equipped outlets.
b. After the power cord has been plugged in, make sure that the key is fully inserted into the console.
c. Check the circuit breaker located on the treadmill
near the power cord. If the switch protrudes as
shown, the circuit breaker has tripped. To reset the
circuit breaker, wait for five minutes and then press
the switch back in.
d. Check the on/off switch located on the treadmill
near the power cord. The switch must be in the
“on” position.
PROBLEM: The power turns off during use
SOLUTION: a. Check the circuit breaker located on the treadmill near the power cord (see c. above). If the cir-
cuit breaker has tripped, wait for five minutes and then press the switch back in.
b. Make sure that the power cord is plugged in. If the power cord is plugged in, unplug it, wait for
five minutes, and then plug it back in.
c. Remove the key from the console. Reinsert the key fully into the console.
d. Make sure that the on/of switch is in the “on” position (see d. above).
e. If the treadmill still will not run, please call our Customer Service Department.
PROBLEM: The displays of the console do not function properly
SOLUTION: a. Remove the key from the console and UNPLUG THE
POWER CORD.Remove the four Hood Screws (2)
from the Hood (1), and carefully remove the Hood. 2
1
a
Tripped
c
Reset
On
Position
d

17
Locate the Reed Switch (16) and the Magnet (10) on
the left side of the Pulley (101). Turn the Pulley until
the Magnet is aligned with the Reed Switch. Make
sure that the gap between the Magnet and the
Reed Switch is about 3 mm (1/8 in.). Ifnecessary,
loosen the indicated Screw (78), move the Reed
Switch slightly, and then retighten the Screw.
Reattach the Hood (not shown), and run the treadmill
for a few minutes to check for a correct speed reading.
PROBLEM: The walking belt slows when walked on
SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm2(14-gauge) cord that is no longer
than 1.5 m (5 ft.).
b. If the walking belt is overtightened, treadmill perfor-
mance may decrease and the walking belt may be-
come damaged. Remove the key and UNPLUG THE
POWER CORD.Using the hex key, turn both rear
roller adjustment bolts counterclockwise, 1/4 of a turn.
When the walking belt is properly tightened, you
should be able to lift each side of the walking belt
8–10cm (3–4 in.) off the walking platform. Be careful
to keep the walking belt centred. Plug in the power
cord, insert the key, and run the treadmill for a few
minutes. Repeat until the walking belt is properly tight-
ened.
c. If the walking belt still slows when walked on, call our Customer Service Department.
PROBLEM: The walking belt is off-centre or slips when walked on
SOLUTION: a. If the walking belt is off-centre, remove the key and
UNPLUG THE POWER CORD.If the walking belt
has shifted to the left, use the hex key to turn the left
rear roller bolt clockwise 1/2 of aturn; if the walking
belt has shifted to the right, turn the left rear roller
bolt counterclockwise 1/2 of a turn. Be careful not to
overtighten the walking belt. Plug in the power cord,
insert the key, and run the treadmill for a few minutes.
Repeat until the walking belt is centred.
b. If the walking belt slips when walked on, first remove
the key and UNPLUG THE POWER CORD.Using
the hex key, turn both rear roller bolts clockwise, 1/4
of a turn. When the walking belt is correctly tightened,
you should be able to lift each side of the walking belt
8–10cm (3–4 in.) off the walking platform. Be careful
to keep the walking belt centred. Plug in the power
cord, insert the key, and walk on the treadmill for a
few minutes. Repeat until the walking belt is properly
tightened.
b
a
Rear Roller Adjustment Bolts
8–10 cm
b
10
16
78
Top View
3mm
101

18
CONDITIONING GUIDELINES
The following guidelines will help you to plan your ex-
ercise program. For more detailed exercise informa-
tion, obtain a reputable book or consult your physician.
EXERCISE INTENSITY
Whether your goal is to burn fat or to strengthen your
cardiovascular system, the key to achieving the
desired results is to exercise with the proper intensity.
The proper intensity level can be found by using your
heart rate as a guide. The chart below shows recom-
mended heart rates for fat burning and aerobic exercise.
To find the proper heart rate for you, first find your age
near the bottom of the chart (ages are rounded off to
the nearest ten years). Next, find the three numbers
above your age. The three numbers define your “train-
ing zone.” The lower two numbers are recommended
heart rates for fat burning; the higher number is the
recommended heart rate for aerobic exercise.
To measure your heart rate during exercise, use the
pulse sensor on the console.
Fat Burning
To burn fat effectively, you must exercise at a relatively
low intensity level for a sustained period of time.
During the first few minutes of exercise, your body
uses easily accessible carbohydrate calories for en-
ergy. Only after the first few minutes does your body
begin to use stored
fat calories for energy. If your goal
is to burn fat, adjust the speed and incline of the tread-
mill until your heart rate is near the lowest number in
your training zone.
For maximum fat burning, adjust the speed and incline
of the treadmill until your heart rate is near the middle
number in your training zone.
Aerobic Exercise
If your goal is to strengthen your cardiovascular sys-
tem, your exercise must be “aerobic.” Aerobic exercise
is activity that requires large amounts of oxygen for
prolonged periods of time. This increases the demand
on the heart to pump blood to the muscles, and on the
lungs to oxygenate the blood. For aerobic exercise,
adjust the speed and incline of the treadmill until your
heart rate is near the highest number in your training
zone.
WORKOUT GUIDELINES
Each workout should include the following three parts:
AWarm-up—Start each workout with 5 to 10 minutes
of stretching and light exercise. A proper warm-up in-
creases your body temperature, heart rate and circula-
tion in preparation for exercise.
Training Zone Exercise—After warming up, increase
the intensity of your exercise until your pulse is in your
training zone for 20 to 60 minutes. (During the first few
weeks of your exercise program, do not keep your
pulse in your training zone for longer than 20 minutes.)
Breathe regularly and deeply as you exercise—never
hold your breath.
ACool-down—Finish each workout with 5 to 10 min-
utes of stretching to cool down. This will increase the
flexibility of your muscles and will help prevent post-ex-
ercise problems.
EXERCISE FREQUENCY
To maintain or improve your condition, complete three
workouts each week, with at least one day of rest be-
tween workouts. After a few months, you may com-
plete up to five workouts each week if desired. The key
to success is to make exercise a regular and enjoyable
part of your everyday life.
WARNING: Before beginning this
or any exercise program, consult your physi-
cian. This is especially important for individu-
als over the age of 35 or individuals with pre-
existing health problems.
The pulse sensor is not a medical device.
Various factors, including your movement,
may affect the accuracy of heart rate readings.
The sensor is intended only as an exercise aid
in determining heart rate trends in general.

19
SUGGESTED STRETCHES
The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce.
1.Toe Touch Stretch
Stand with your knees bent slightly and slowly bend forward from
your hips. Allow your back and shoulders to relax as you reach
down toward your toes as far as possible. Hold for 15 counts, then
relax. Repeat 3 times. Stretches: Hamstrings, back of knees and
back.
2. Hamstring Stretch
Sit with one leg extended. Bring the sole of the opposite foot toward
you and rest it against the inner thigh of your extended leg. Reach
toward your toes as far as possible. Hold for 15 counts, then relax.
Repeat 3 times for each leg. Stretches: Hamstrings, lower back and
groin.
3. Calf/Achilles Stretch
With one leg in front of the other, reach forward and place your
hands against a wall. Keep your back leg straight and your back
foot flat on the floor. Bend your front leg, lean forward and move
your hips toward the wall. Hold for 15 counts, then relax. Repeat 3
times for each leg. To cause further stretching of the achilles ten-
dons, bend your back leg as well. Stretches: Calves, achilles ten-
dons and ankles.
4. Quadriceps Stretch
With one hand against a wall for balance, reach back and grasp
one foot with your other hand. Bring your heel as close to your but-
tocks as possible. Hold for 15 counts, then relax. Repeat 3 times for
each leg. Stretches: Quadriceps and hip muscles.
5. Inner Thigh Stretch
Sit with the soles of your feet together and your knees outward. Pull
your feet toward your groin area as far as possible. Hold for 15
counts, then relax. Repeat 3 times. Stretches: Quadriceps and hip
muscles.
1
2
3
4
5

Wheel Nut (64)–2
1” Bolt (43)–4
Silver Ground
Screw (66)–1
3 1/2” Bolt (54)–2
3/4” Screw (38)–10
Crossbar Screw/Spacer Screw
(37)–4
1/4” Washer (44)–4 1/4” Star Washer
(45)–4
3/8” Star Washer
(55)–2
3” Bolt (58)–4
4” Bolt (117)–2
1/2” Screw (5)–1
5/16” Star Washer
(57)–4
2 1/2” Bolt (61)–2
5/16” Washer (122)–2
1 1/4” Tek Screw (60)–4
Remove this chart and use it to identify small parts during assembly. Save
this chart and the EXPLODED DRAWING/PART LIST for future reference.
PART IDENTIFICATION CHART
