West Elm bergen closet wide open shelf User manual

bergen closet wide open shelf
assembly instructions
Page  of 49857 / 986 - 0/07
A B
C D
! Tools required:
! Do not throw away packaging materials until assembly is complete.
! Assemble this item on a soft surface, such as cardboard or carpet, to protect nish.
shelf bracket 2x
screw 2x
felt pad 6x
cam screw 8x cam lock 8x
wooden dowel 8x
mounting plate x
E F
G

bergen closet wide open shelf
assembly instructions
Page 2 of 49857 / 986 - 0/07
.Insert cam locks (B) into holes of side panels. Turn cam locks with a phillips screwdriver so that the arrow on top is pointing out
as shown.
B
2. With a hammer gently tap wooden dowels (D) into holes in side of panels as shown.
3. Insert cam screws (A) into top and bottom panels as shown and tighten with a phillips screwdriver.
A
D

bergen closet wide open shelf
assembly instructions
Page 3 of 49857 / 986 - 0/07
4. Fasten side panels to bottom panel. Fit cam screws into cam locks and tighten using phillips screwdriver.
5. Slide back panel into groove. Make sure panel slides all the way into the bottom panel groove.
6. Fasten top panel to side panels. Fit cam screws into cam locks and tighten using phillips screwdriver.

bergen closet wide open shelf
assembly instructions
Page 4 of 49857 / 986 - 0/07
7. Attach felt pads (G) to base of unit.
8. Insert shelf brackets (C) into holes at desired position. Slide shelf over brackets into cabinet.
9. Multiple units can be attached together as shown using screws (F) and mounting plates (E).
CARE INSTRUCTIONS
Hardware may loosen over time. Periodically check that all connections are tight.
Wipe with a soft, dry cloth. To protect nish, avoid the use of chemicals and household cleaners.
G
C
F
E
