Westcott Lunagrip User manual

WARRANTY
One year against manufacturer defect.
Westcott’s warranty obligations for this product are limited to the terms
set forth below: The F.J. Westcott Co. (“Westcott") warrants this Westcott
branded product against defects in materials and workmanship under
normal use for a period of ONE (1) YEAR from the date of retail purchase
by the original end-user purchaser (“Warranty Period"). If a defect arises
and a valid claim is received within the Warranty Period, at its option and
to the extent permitted by law, Westcott will either (1) repair the defect at
no charge, using new or refurbished replacement parts, or (2) exchange
the product with a product that is new or which has been manufactured
from new or serviceable used parts and is at least functionally equivalent
to the original product. This Limited Warranty applies only to products
manufactured by or for Westcott that can be identified by the “Westcott”
trademark, trade name, or logo affixed to them.
This warranty does not apply: (a) to damage caused by accident, abuse,
misuse, flood, fire, earthquake or other external causes; (b) to damage
caused by operating the product outside the permitted or intended uses
described by Westcott; (c) to a product or part that has been modified
to alter functionality or capability without the written permission
of Westcott.; or (d) to cosmetic damage, including but not limited to
scratches, dents and broken plastic.
Please contact Westcott’s Repair Department for a Return Authorization
Number “RMA" prior to requesting warranty service. This RMA must be
clearly written on the outside of the box to the left of the shipping label.
Items sent in without pre-authorization or that do not fall under the ONE
(1) YEAR limited warranty will be returned at the expense of the sender.
Register this product at FJWESTCOTT.COM/WARRANTY
Repair Dept.: 800-886-1689 / 419-243-7311 (International)
E-Mail: [e-mail] SUBJECT: ATTN: REPAIR DEPT.
Shipping: F.J. Westcott Co, 1425-B Holland Rd, Maumee, OH 43537
©F.J. WESTCOTT CO. ALL RIGHTS RESERVED.
QUICK START GUIDE
11. Slightly loosen both the
LunaGrip bracket’s bolt knob
and the cold shoe mount’s
lower knob. Adjust the
bracket’s height and depth
until your speedlight’s flash is
located just inside the LunaGrip’s opening.
Re-tighten these knobs to secure position.
Please note: For most efficient use of the LunaGrip
as a speedlight modifier, set your speedlight’s flash
zoom angle between 24mm and 28mm.
SETUP USAGE
TO DISASSEMBLE
1. Remove your speedlight and set aside.
2. Gently disconnect each mounting arm along
the perimeter of the LunaGrip.
3. Disconnect the mounting arms from your disc.
Warning: Failure to tighten the adjustable cold
shoe mount and the LunaGrip bracket can lead
to damage of your speedlight.

3. Loosen and remove
the bolt knob and
washer while holding
the bolt in place.
Position the bracket
on the LunaGrip
handle with the handle’s bolt placed in the
bracket’s channel.
4. Reattach the bolt knob and
washer. Tighten to secure
the LunaGrip bracket on the
LunaGrip handle. This bolt
can also be used to adjust the
height of the bracket.
Please note: For unusually tall speedlight transceivers,
a second bolt receptacle is available for use and is
located lower on the LunaGrip handle.
5. Unfold each LunaGrip
arm to a straight
position. The interior
tethers will spring
each arm into a
secure position.
6. The LunaGrip is intended
for use with any diffusion or
reflection disc sized between
20" and 42". Locate your
preferred disc and hook each
of the LunaGrip arms equal-distance apart
along the edge of the disc. Roll each arm
toward the center of the disc to secure.
SETUP USAGE
LUNAGRIP ASSEMBLY
1. To begin, remove all
components from the
LunaGrip carry case.
2. To attach the LunaGrip bracket to the
LunaGrip handle, begin by holding the
LunaGrip handle
in one hand with
your index finger
positioned over the
rear of the LunaGrip
bracket’s bolt.
7. Locate the small “S”, medium
“M”, and large “L” markings
along the perimeter of the
LunaGrip.
8. Place each arm in a
corresponding arm receptacle
intended for the disc size
being used: S = 20" to 29",
M = 30" to 39", L = 40"+.
9. Gently press on
each arm toward
center of LunaGrip
handle to ensure the
mounting is secure.
Please note: LunaGrip
arms are flexible and
will curve slightly when
mounted properly.
10. You may now place your preferred
speedlight on the LunaGrip
handle by loosening the cold
shoe mount’s thumb screw
and sliding your speedlight
onto this bracket. Your
speedlight’s flash should face
the opening of the LunaGrip.
CONTENTS
LUNAGRIP
HANDLE
REMOVABLE
MOUNTING ARMS
ADJUSTABLE SHOE-MOUNT
BRACKET
CARRY
CASE
40" 5-IN-1 REFLECTOR KIT
(INCLUDED WITH LUNAGRIP KIT ONLY)
