Westerbeke WPDS Series Quick setup guide

\.
DEPENDABLE ELECTRIC POWER FOR ALL SEAGOING CHORES
C A BIN
AIR CONDITIONING
HEAT
LIGHTS
FAN
TELE V IS I ON
GALLEY
RANGE
O V EN
REFRIGERATOR
I- L- _______ -r- TOASTER
M IX ER
LIGHTS
EX H A UST FAN
C OFFEE MAKER
NAVIGATION
RADAR
DEPTH RECORDER
AUTOMATIC PILOT
DIRECTION FINDER
RADIO
LORAN
CONSOLAN
EN G INE ROOM
HOT W ATER HEATER BLOWER
DEEP FREEZE P U MPS
Westerbeke marine diesel senerator sets have been selected for
use aboa rd f ine yachts deSigned or built by J ohn G. Alden Co m-
pany, Bristol Boats, Burger Boa t Company, Cen tury Boa t Company,
Robert
E. Derecktor, Eldredge-Mcinnis, Equitable Equipment Co m-
pany, Fred S. Ford, Jr., Gibbs Corporation, Hodgdon Brothers,
Huckins
Yach t Corporation, T he Ma tthews Company, Philip Rhodes,
Stephens Marine Inc., John Trumpy &
Sons, and many others, bo th
in this country and ab road.
Import an t reasons for selection of these generator sets have b ee n:
light weight, co mpact size, smooth and quiet operation, superior
design and equi
pm en t, quick and unfailing starts, and excellent
performance records.
Today's sophisticat
ed electrical equipment requires closely regu-
lated frequency and voltage to operate correctly and for protec-
tion as:ainst sudden surges. WPDS static-excited generator se ts
are unique
in this respect. Voltage is regu lated electronically and
restored to rated value almost instantly. Voltage fluctuations w
it h
load changes are insignificant compared to those of inherently
regulated machines. T
he frequency is regulated by a precise
mechanical governor
so that over the full range of loads, fre-
quency is maintained at ::!:: 1 %. When you use sophisticated elec-
tronic equipment, you need this dependably constant source of
electricity power.
W INDLASS
AIR COMPRESSORS
H EA D
LI G HTS
D.C . REQUIREMENTS
BATTERY CHARGING
-'f- ';""'STARTING
~
RIDING LIGHTS
INSTRUMENT LIGHTS
PANEL LIGHTS
HO R N
SEAR C HLIGHT
ELECTRIC RAZOR
ELE C TRIC TOOTHBRUSH
FAN
J. H. WESTERBEKE CORP.
35 TENEAN STREET , BOSTON , MASSACHUSETTS 02122
Manufacturers of the FOUR-l07 and FOUR-236 auxi liary d i esel engines .

TYPE: Diesel, 4 cylinder in tine, 4 cycle
DISPLACEMENT: 107 cu. in . Bore 3.125
11
• Stroke
3.5"
COMPRESSION: 22 to 1
POWER: Rated output at shaft 26 h.p. at 1800
r. p.m .
STARTING: 12 volt posit iv e engaging heavy duty
starting motor
FUEl INJECTION Distributor.type fuel pump
EQUIPMENT: wi th a solenoi d·operated fuel
valve
COOLING: Fresh
water through heat exchanger
MOUNTING: Engine-g enerator assemb ly rubber
mounted to elim i nate 95% of all
vibra tion . Base has i nte gral drip
pan
FUEL CONSUMPTION: Approximately 0.1 g allon
per ki lowatt·hour
CONTROL: Complete co ntrol panel either
mounted on engine or remote
RATED OUTPUT
LENGTH OVERALL
GENERATOR-10.12.5,15,30KW
VOLTS:
OUTPUT:
FREQUENCY:
PH ASE:
120/240 static re gulated to within ± 1%
10 KW, 12.5
KW, 15 KW, or 30 KW, as rated, for con·
tinuous ope rati on
60 cycles governed to within ± 112 cycle, no load to
full load. 50 cycles available for export requi rements .
Single
POWER FACTOR: Unity
CURRENT OPTIONS: 120 or 120/240 volt (A simple reconnection makes the
change.)
ACCESSORIES: Accessory
D.C. requi rements may be supplied either
by the generator throu gh rectifYing equipment or by
12 , 24 or 32 volt alternators in 40, 60 , or 100 amp size
mounted on the engi ne .
42·
825 I
FEAT
STATIC EXCITER:
REGULATOR:
CONSTRUCTION:
SIMPLICITY:
SERVICE:
ADJUSTMENTS:
VOLTAGE RECTIFIER:
VOLTA GE
FLUCTUATIONS:
PRECISION
GOVERNOR:
HIGH CRANKING
SPEED:
COMPLETE
PROTECTION:
Eliminates rotating exciter used in othe r generators.
No moving
parts - No delicate multiple contac t
points.
Only rugged coils and windings - Wilt not go out of
adjustment.
Elim in ates hundreds of electrical connections, com·
mutator and its brush ri g and many other break·
down points .
All components easily accessible - no need to com ·
pletely dismantle lJenerator for exciter repairs, as is
necessary
for rotatin g exciters.
No extra·sensit iv e adjustments necessary -regula·
tion and stability are built in.
Rated
voltage restored within two seconds after (
maximum load change compared with f iv e seconds
for rotating exc it ers.
Voltage
fluctuation is less than half that of rotating
exciters.
Regulates
frequency within one cycle, making your
electronic deVices funct io n better.
Ma kes cold weather starting easy. Time delay
r
elays are unnecessary wh en operating with DYNA·
MONITOR automatic switchg ear.
Standard equipment includ es hi gh water tempera-
ture and low oil pressure protection, tied in with the
fuel solenoid. (30 KW set also has overspeed pro-
tection.)

CONTROLS
MOUNTING: Control box mounted on top of generator, or remote
if des ired.
STARTER CONTROL: Relays and resistors prov i de either manual electric
start at selected locations , or control from DYNA·
M ONf T OR automatic demand control panel.
INSTRUMENTATION: Water temperature gauge, oil pressure gauge, battery
char ge ammete r.
SAFETY DEVICES:
JRES
FUEL SOLENOID:
WfSTERBEKE
INSTRUCTION
BOOK:
LIGHT WEIGHT :
MOST COMPACT:
EXTRA VALUE
ACCESSORIES:
High temperature shut-off -low oil pressure shut-off.
Over-speed limiter is provided on 30 KW model only.
Designed and built by Westerbeke, makes possi ble
both manual and automat ic c ontrol as well as the
operation of the safety device s.
180 pag es of instruction for en gi ne and generato r
wi th drawin gs, exploded views, parts list, and helpful
information .
The li g htest wei g ht g enerator ' sets per rated output
in the industry .
Fits in where others will not .
The follow ing accessor ies are standard equ i pment
on WPDS g enerators ;
1. High
capac i ty primary fuel oil filter, wi th lar ge
s
ump for water , replacea bl e filter element and a
c
on veni ent draincock for removal of water and
s ediment.
2. Your cho i ce of exhaust flan ges - bored for
tu b in g, threaded for 1 V0211 pipe , or wi th drop elbow
a nd water dischar ge connect ion for 2" rubber
exhau st hose.
3.
Flexi ble fuel line connect io ns - for fuel oil
supply and return.
4. Handy s ump pump - for mak ing oi l chang es .
5.
Runnin g ti me meter - for foll owing recom-
mended service procedures .
TYPE:
Diesel, 4 cylinder in line, 4 cycle
DISPLACEMENT: 2.36 cu. in. Bore 3.875". Stroke
S"
COMPRESSION: 16 to 1
POWER: Rated output at shaft 56 h.p. at 1800
r.p.rn
STARTING: 12 volt positive engaging heavy duty
start i nl motor
FUEL INJECTION Distributor-type fuel pump
EQUIPMENT : with a soleno i d-operated fuel
valve
COOLING: Fresh water through heat exchanger .
MOUNTING : Engine-generator assembly rubber
mounted on sturdy box-type base
with drip pan and drain fitling
included
FUEL CONSUMPTION: Approximately 0.1 gallon
per kilowatt· hour
CONTROL: Complete control panel as with
smaller sizes but with over·speed
protection added

Close voltage regulation by static-excited
generators protects delicate electronic
eQuipment and gives better service.
Test results made
on a fast chart show
the remarkable voltage regulation under
severe instantaneous load changes of up
to 150% of normal maximum load. This is
an actual tape from the test of a Wester-
beke Model WPDS 30 KW marine diesel
generator. Horizontal lines are spaced at
sill seconds. Vertical lines are spaced at
two volts.
OYNA MONIITOA
Th e Weste r beke DYNA - MONITOR is a heavy duty de-
mand contr ol wi th features which ma ke it unique
among con troller s. Its contactor, the load carrying co m-
ponen t, is ex tra large for long life. Ci rcuitry is basically
a simple t wo-wi re co ntr ol sys tem ope rating on full
battery voltage. Th e react or component has been ca r e-
fully designed to allow a high differential in wattage
between starting
and ru nning relays. Both starting and
runn ing re lays are single function units, hermetically
se al ed against dirt or m ois ture.
T
his co mb ination of parts fo rm s a demand swi tch
which,
when u sed with Westerbeke gen erat ors , will
start th e ge nerator when a load is applied, st op the
ge nerator when a loa d is rem oved, and pr event annoy-
ing false start s.
DYNA - MONITOR goes to wo rk instantly, automatically,
if a light is turned on, or if a refr ige rat or calls for elec-
tricit y, or when you plug in th e coffee maker for that
first cup of coffee. It
stops t he se t automatically as soon
as the cu rrent is no longe r req ui r ed.
An ot he r feature for th ose who prefer times of absolute
si lence is the abi li ty to cut out the automatic featu re
at will by means of si mple t ogg le switches co nveniently
pla ced.
The Wester be ke WPDS se r ies
gene rator, when used wi th
DYNA - MONITOR , is a su per io r
automatic elect ri c al supply
sys t em f or any di ese l-p owe red
yacht
The Westerbeke diesel generator set
was first introduced in 1960 as
a 10 KW model, WPD-I0, and rapidly established a world-wide repu-
tation for design excellence and reliable operation_ Since its intro-
duction, improvements have been made upon the original model,
expanding the line from 10 KW to 30 KW and culminating in the
static-excited
WPDS series_ Since their introduction, Westerbeke
diesel generators have been recognized as superior units for diesel
powered yachts_Many of the finest modern yachts have their electri-
cal requirements satisfied by Westerbeke generators_ In addition to
shipboard installations, Westerbeke generators have been used in
aids to navigation and in many shoreside locations where depend-
ability and fuel economy count These shoreside units are radiator
cooled and are made to special order.
