User Manual
Citrus Juicer
MODEL: WJC1BGA
1. READ these instructions carefully before installing and operating the
appliance. Keep them for further reference.
2. Record in the space below the “SERIAL/MODEL NUMBER” found on the back
or bottom of your appliance and retain this information for future reference.
SERIAL NUMBER:
MODEL NUMBER:
DATE OF PURCHASE:
Save and staple your sales receipt to your manual for warranty coverage.

Page 2
SAFETY INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
1. READ ALL INSTRUCTIONS BEFORE USE
2. Before using check that the voltage indicated on the product
corresponds with the voltage of your electrical outlet.
3. To protect against risk of electrical shock do not put the motor unit
in water or other liquid.
4. Unplug from outlet when not use, before putting on or taking off
parts, and before cleaning. Never yank cord to disconnect from
outlet; instead, grasp plug and pull to disconnect.
5. Close supervision is necessary when any appliance is used by or near
children.
6. Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions, or is dropped or damaged in any
manner. Return appliance to the nearest authorized service facility
for examination, repair or electrical or mechanical adjustment.
7. The use of attachments not recommended or sold by the
manufacturer may cause re, electric shock or injury.
8. Do not let supply cord hang over the edge of table or counter.
9. Avoid contacting moving parts.
10. Do not use appliance for other than intended use.
11. The appliance can only be used to squeeze citrus fruit. Never use it
for juicing other kinds of fruits.
12. Do not use outdoors.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
WARNING
When using electrical appliances, basic safety precautions
should be followed, including the following

Page 3
SAFETY INFORMATION
ELECTRICAL REQUIREMENTS
This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to t into a polarized outlet only one way.
If the plug does not t into the outlet, reverse the plug. If it still does not t, contact a
qualied electrician. Do not attempt to modify the plug in any way.
POWER SUPPLY CORD
1. A short power supply cord is provided to reduce the risk of becoming entangled in
or tripping over a longer cord.
2. If the power supply cord is too short, do not use an extension cord. Have a
qualied electrician or serviceman to install an outlet near the appliance.
3. If it is absolutely necessary to use longer cord sets or an extension cord, extreme
care must be exercised.
a) The marked electrical rating of the cord set or extension cord must equal to
or be greater than the electrical rating of the appliance. The longer cord should
be arranged so that it will not drape over the counter top or table top where it
can be pulled on by children or tripped over unintentionally.
NOTE: Neither Westinghouse nor the dealer can accept any liability for damage to the product or
personal injury resulting from failure to observe the electrical connection procedures.

Page 4
SET UP & USE
PARTS & FEATURES
Big Cone
Top Lid
Diagram for instructional purposes only.
OPERATION INSTRUCTION
• Please check whether all parts and accessories are complete and free of damage.
• Clean all removable parts according to the CLEANING AND MAINTENANCE
section.
• Reassemble the parts as follows.
• Put the bowl into the rotating axis of the motor base, making sure the spout aligns
with the groove of the motor base.
• Fit the sieve onto the bowl.
• Assemble the appropriate cone on the rotating axis according to the fruit size.
Small fruit can be squeezed on the smaller cone while for large size fruit the two
cones should be used together, placing the large cone on top of the small cone.
• Make sure the spout is in the closed position by lifting the spout into the up
position.
• When lifting spout, place other hand on top of unit and apply pressure down.
Sieve
Small Cone
Adjustable
Juice Spout
Juice Collecting Bowl
Motor Base
Rotating Axis

Page 5
USING YOUR JUICER
1. Wash and then halve the citrus fruit.
2. Plug the power cord into the outlet.
3. Put the halved fruit on the cone and press lightly. The motor will start and the
extracted juice will ow into the bowl through the sieve. The residue will remain on
the sieve.
CAUTION: Never exert excessive force when pressing the fruit to prevent it from
blocking and damaging the motor.
4. Once squeezing is complete, release your hand from the cone and the motor will
stop. You may restart it again at any time by pressing the cone down.
CAUTION: The maximum operation time should NOT exceed 1 minute. A
minimum 2 minutes rest time must be allowed between cycles.
NOTE: 1) This appliance is suitable to process citrus fruits that range in size from
50~85mm (2 to 3.3 inches).
2) During squeezing, noise will be heard. It is normal. The bigger fruit you
use, the more sound will be heard.
5. Place a cup (not included) underneath the spout and put a nger on the edge of
the spout and press down. The spout is now open and juice will ow out into the
cup.
6. After using, unplug the appliance. The power cord can be stored in the base.
NOTE: If you want the juice to collect in the internal juice collecting bowl, make sure
the top lid is in place. For sanitary reasons, do not leave juice in the internal
juice collecting bowl for long periods of time.
CLEANING AND MAINTENANCE
1. Unplug the appliance and wait until it completely cools down before cleaning.
2. Disassemble all detachable parts.
3. Rinse the top lid, two cones, sieve and bowl in warm soapy water and rinse. To
wash the internal juice collecting bowl and rinse. After cleaning, dry the parts
thoroughly.
NOTE: Only the sieve is dishwasher safe. It should be washed in the top rack of the
dishwasher.
4. Wipe the rotating axis with a soft damp cloth.
WARNING: Do NOT immerse the motor base in water or any other liquid.
CAUTION: Do NOT use rough, abrasive cleaning materials or scouring pads on parts.
5. Assemble all parts back together. The power cord can be wrapped around the
groove under the motor base for easy storage when not in use.
SET UP & USE

Page 6
BEFORE YOU CALL FOR SERVICE
IF THE APPLIANCE FAILS TO OPERATE:
A) Check to make sure that the appliance is plugged in securely. If it is not, remove
the plug from the outlet, wait 10 seconds and plug it in again securely.
B) Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to
be operating properly, test the outlet with another appliance.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, CONTACT A QUALIFIED
TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE APPLIANCE YOURSELF.
CUSTOMER SERVICE
IMPORTANT
DO NOT RETURN THIS Appliance TO THE STORE
If you have a problem with this appliance, please contact the
W Appliance Co. Customer Satisfaction Center at 1-855-855-0294.
DATED PROOF OF PURCHASE, MODEL # AND DATE CODE
REQUIRED FOR WARRANTY SERVICE
TROUBLESHOOTING
Troubleshoot your problem by using the chart below. If the appliance still does not
work properly, contact W Appliance Co. customer service center or the nearest
authorized service center. Customers must never troubleshoot internal components.
SPECIFICATIONS
• Unit Dimensions (W x D x H): 7.5" x 8" x 10.5"
• Net Weight: Approx. 4.8 lbs.
TROUBLESHOOTING & WARRANTY
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Appliance does not turn on
Appliance is not plugged in Check that appliance is
plugged into a working outlet
Unit overheated Unplug and allow to cool.

Page 7
TROUBLESHOOTING & WARRANTY
LIMITED WARRANTY
Westinghouse brand is used under license.
Any repair, replacement, or warranty service,
and all questions about this appliance should
be directed to W Appliance Co. at 1 (855)
855-0294 from the USA or Puerto Rico.
W Appliance Co. warrants to the original purchaser
that the appliance will be free from defects in material,
parts and workmanship for the period designated for
this appliance. The warranty commences the day the
appliance is purchased and covers up to a period of
1 year (12 months) for labor/1 year (12 months) for
parts (manufacturing defects only)/carry in service.
W Appliance Co. agrees that it will, at its option,
replace the defective appliance with either a new or
remanufactured appliance equivalent to your original
purchase during the warranty period.
Exclusions: This warranty does not apply to the
below:
1. If the appearance or exterior of the
appliance has been damaged or
defaced, altered or modied in design or
construction.
2. If the appliance original serial number
has been altered or removed or cannot
be readily determined.
3. If there is damage due to power line
surge, user damage to the AC power
cord or connection to improper voltage
source.
4. If damage is due to general misuse,
accidents or acts of God.
5. If repair attempts are done by
unauthorized service agents, use of
parts other than genuine parts or parts
obtained from persons other than
authorized service companies.
6. On units that have been transferred
from the original owner.
7. On appliances that have been purchased
as refurbished, like new, second-hand, in
a “As-Is” or “Final Sale” terms.
8. To appliances used in a commercial or
rental setting.
9. To appliances used in settings other
than ordinary household use or used
other than in accordance with the
provided instructions.
10. To damages for service calls for
improper installations.
11. To glass parts and other accessory
items that are included with the unit.
12. Transportation and shipping costs
associated with the replacement of
the unit.
13. Food loss for loss due to appliance
failure or delay in service, repair or
replacement.
14. Service calls to instruct you how to use
your slow cooker.
15. Service calls to repair or replace the
house fuse, reset the circuit breaker or
correct the wiring in the house.
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CUSTOMER; W Appliance Co. SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS Appliance, EXCEPT
TO THE EXTENT PROHIBITED BY APPLICABLE LAW.
ANY IMPLIED WARRANTY OF MERCHANTABILITY
OF FITNESS FOR A PARTICULAR PURPOSE ON THIS
Appliance IS LIMITED TO THE DURATION OF THE
WARRANTY.
Some states do not allow the exclusion or limitations
of incidental or consequential damages, or limitations
on how long the warranty lasts. In these cases the
above exclusions or limitations may not apply to you.
This warranty gives you specic legal rights and you
may also have other rights which vary from state to
state.
Obtaining Service: To obtain service, appliance
literature, supplies or accessories please call
1 [phone] to create a ticket for exchange/
repair. Please make sure to provide the date of
purchase, model number and a brief description of
the problem. Our customer service representative will
contact you or send detailed return instructions.
W Appliance Co. does not warrant that the appliance will work
properly in all environmental conditions, and makes no warranty
and representation, either implied or expressed, with respect
to the quality, performance, merchantability, or tness for a
particular purpose other than the purpose identied within this
user’s manual. W Appliance Co. has made every effort to ensure
that this user’s manual is accurate and disclaims liability for any
inaccuracies or omissions that may have occurred. Information
in this user’s manual is subject to change without notice and
does not represent a commitment on the part of W Appliance
Co.. W Appliance Co. reserves the right to make improvements
to this user’s manual and/or to the appliances described in this
user’s manual at any time without notice. If you nd information
in this manual that is incorrect, misleading, or incomplete, please
contact us at 1- 855-855-0294.
W Appliance Co.,
1356 Broadway
New York, NY 10018

Page 8
, WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF
are trademarks of Westinghouse Electric Corporation. Used under
license by W Appliance Company. All Rights Reserved.
020316
