WeTech DP1-681USB User manual

© WEMPE Elektronic GmbH, created: 27.04.2022 Made in Germany
USER MANUAL
DP1-681USB
Article number: 600162
Thank you for purchasing a WeTech® product. This user manual contains important safety
and operating instructions for your desk programming station (DP). Before using your DP, read
this manual and all warning instructions with care in order to avoid possible danger.
This product is suitable for charging and programming SEPURA STP8000 and STP9000
radios with an original rechargeable battery.

2
Safety instructions
1. Installation and the first start of the system should only be done by qualified technicians.
2. Using rechargeable batteries not explicitly listed in this document may lead to fire.
3. The contacts of the product should be cleaned at regular intervals with a dry cloth. Do not
use water or other liquids.
Scope of delivery
The following items are included in the scope of delivery:
1x DP1-681USB
1x USB A to USB B cable
1x Power supply for 230V
Start of the system
1. Place the DP at a suitable place. Ensure a safe stand!
2. Connect the delivered power cable to the power connection (D) at the device and a
socket.
3. Connect the delivered USB A to USB B cable to USB B socket (E) at the device and
USB A socket at your PC.
4. After Windows installed all drivers the usage of DP is possible on condition defaults of
programming software provider
Advice
If Windows do not find any driver, please download at https://ftdichip.com/drivers/vcp-drivers/.
Advice
Please observe technical specifications of radio producer for programming of radio devices.

3
Functions
The charging bracket is used for quick charging and maintaining charge. The table below
provides information about the function of the displays and the connections of the unit.
Pos.
Designation
Status
Description
A
Green LED
on
Battery detected.
off
Battery not detected. Contact with the radio
unit may not have been established properly.
B
Red LED
on
Quick charging active. Battery capacity under
80%
off
Quick charging inactive. Battery capacity over
80%
C
Red LED
on
Electricity supply is given
D
Power
connection
Power connection for delivered power cable
E
USB B socket
Data interface to PC
Schematic drawing DP1-681USB

4
Technical data
Designation
Value
Working voltage (car kit)
12V / 24V
Working voltage (Power supply)
230V
Output current
max. 1050mA
Power consumption of car kit
Max. 10W
Degree of protection
IP20
Measurements in mm
70 x 230 x 145
Weight without accessory
0,602 kg
Additional instructions
CE conformity declaration
For this product, we confirm that it meets the requirements set forth in the Directive of the Council for Conformity
of Legal Regulations of Member States regarding Electromagnetic Compatibility. This declaration applies to all
units manufactured in accordance with the production drawings included as a component of this declaration.
WEEE (this symbol applies only in the European Union)
This symbol indicates that the product so labelled may not be disposed of with normal household waste. If you
want to dispose of this product, obey the corresponding national laws and regulations in your country or
community. The correct disposal of this product supports environmental protection and prevents possible
damage to the environment and human health.
