Wfly RF209S User manual

RF209S Summary Manual
Link: Charge the receiver then press and hold "SET" button for 3
seconds, wait for the link instruction after the orange light flashes slowly.
Mode select:
1 Receiver setting way, press the "SET" to charge, then enter into model
setting, gently click the "SET" into switcher mode, press and hold "SET" to
confirm .
2 Transmitter setting way , please carry out in [Linkage setting]-
[Receiver output] under the normal communication state of transmitter
and receiver .After setting, return to the superior menu and save the
setting (the receiver light color would be changed).
MODE
LED
Action
Status
WORK
Purple
Never
PWM normal work mode
Green
Never
W.BUS normal work mode
Blue
Never
PPM normal work mode
Red
Never
No signal
Slow flash
Low voltage
Orange
Slow flash
Linking
SET
Purple
Slow flash
PWM mode
Green
Slow flash
W.BUS mode
Blue
Slow flash
PPM mode
PPM/PWM/W.BUS/W.BUS2
CH1~7:PWM
PPM/W.BUS
Signal
Positive
Negative
USB port
Link key
Status light
External voltage
inspect port
Red line to the positive pole
1Ω resistor to the negative

Parameter performance
Type: RF209S
Band: 2.4GHz
Voltage: 3.5V-13V
Current: 95mA
Application: Helicopter, Airplane, multicopter,Vehicle, Ship, Robot. Resolution: 4096
PWM: 9channels
W.BUS: Compatible
W.BUS2: Remote sensor input
Two-way transmission: Support
Lost-control protection: Support
Online upgrading: Support
Relay flight: Support
180/270°servo: Support
Receiver port setting: Support
External voltage detection: DC 0~96V
Dimension: 47x14x25mm
Weight: 12g
Shenzhen WFLY Technology Development Co., Ltd
www.wflysz.com
FCCWARNING
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:
(1) Thisdevicemaynotcauseharmfulinterference,and
(2) this device must accept any interference received, including interference that may cause undesiredoperation.
Anychangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoid
theuser'sauthoritytooperatetheequipment.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
This equipment should be installed and operated with minimum distance 20cm between the radiator &you
body.
