Whitewood Furniture CU-140 User manual

ITEM NO.: CU-140
REVISED JUL 07, 2018
Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item
No.
: WINE CABINET
:
CU-140

ITEM NO.: CU-140
REVISED JUL 07, 2018
Printed in Vietnam
- 2 -
Thank you for purchasing this quality product. This product has been designed for easy assembly
and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to
assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the
finish of your product. Protect the surface of the product with cloth if you are using any
product with rubber feet or base.
BEFORE ASSEMBLY
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: CU-140
REVISED JUL 07, 2018
Printed in Vietnam
- 3 -
PART LIST CU-140
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Top 1
B
Right Side
panel
1
C
Left Side
panel 1
D
Bottom
1
E
Fixed shelf 1
F
Back panel
1
G
Back 1
H
Drawer front
1
I Drawer back
1
J
Drawer side
(L-R)
2
K
Drawer
bottom 1
L
Support bar
1
M
Door 1
N
Glass rack
1
O
Wine rack 2
P
Adjustable
shelf
1

ITEM NO.: CU-140
REVISED JUL 07, 2018
Printed in Vietnam
- 4 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1 Short Bolt
(M6 x 30mm) 14
8 Magnet
1
2 Long Bolt
(M6 x 55mm) 2
9 Bracket
16
3 Spring Washer
(F6.5 x 11mm) 16
10
Long P
an head screw
2
4 Flat Washer
(F6.5 x 13mm) 16
11
Wooden Knob
(F38 x 30mm)
2
5 Long Screw
(M4 x 35mm) 12
12
Steel band
2
6
Short Pan head
screw
(M3 x 15mm)
3
13
Allen key
(M4 x 30mm x 110mm)
1
7 Short Screw
(M3.5 x 15mm) 34
14
Hinge
2

ITEM NO.: CU-140
REVISED JUL 07, 2018
Printed in Vietnam
- 5 -
STEP 1
Attach right side panel (B) to top (A) with bolts (1), and washers (3) and (4) as shown below. Tighten
with Allen key (13).
STEP 2
Attach back panel (F) to top (A) with bolts (1), and washers (3) and (4) as shown below. Tighten with
Allen key (13).
Attach side panels (B) and (C) to top (A), shelf (E) and bottom (D) with bolts (1), and washers (3) and
(4) as shown below. Tighten with Allen key (13).
Attach shelf (E) to back panel (F) with bolts (2), and washers (3) and (4) as shown below. Tighten with
Allen key (13).









ITEM NO.: CU-140
REVISED JUL 07, 2018
Printed in Vietnam
- 6 -
STEP 3
Slide back panel (G) into the grooves as shown below, then attach back panel (G) to bottom (D)
with screws (6). Tighten with a screwdriver.
STEP 4
Attach drawer sides (J) to drawer front (H) with screws (5) as shown below. Tighten with a screwdriver.
Insert drawer bottom (K) into the grooves at bottom of drawer sides (J) and drawer front (H) as shown below.
Attach drawer back (I) to drawer sides (J) with screws (5) as shown below. Tighten with a screwdriver.
Attach support bar (L) to bottom drawer (K) with screws (5) as shown below. Tighten with a screwdriver.











ITEM NO.: CU-140
REVISED JUL 07, 2018
Printed in Vietnam
- 7 -
STEP 5
Carefully put the drawers into the unit.
Attach knobs (11) to front of drawer and door with pan head screws (10) as shown below. Tighten with a
screwdriver.
Attach hinges (14) to door (M) and side panel (B) with screws (7) as shown below. Tighten with a
screwdriver.
Attach magnets (8) side panel (C) with screws (7) as shown below. Tighten with a screwdriver.
STEP 6
Insert brackets (9) into the unit as shown below. Place glass rack (N), wine rack (O) and shelf (P) on
the brackets and attach with screws (7). Tighten with a screwdriver.
Attach steel bands (12) to the unit with short screws (7) and attach the steel band to the wall with
long screws (5) as shown below (to secure the product and prevent tipping). Tighten with a
screwdriver.







 



