Whitewood Furniture T-6P User manual

ITEM
NO
:
T
-
6P
REVISED JUL 23, 2012
Printed in Vietnam
- 1 -
Description
Item No.
: 6 IN PEDESTAL EXTENSION
: T-6P
ASSEMBLY INSTRUCTIONS

ITEM
NO
:
T
-
6P
REVISED JUL 23, 2012
Printed in Vietnam
- 2 -
BEFORE ASSEMB
LY
Thank you or purchasing this quality product. This product has been designed or easy assembly and
constructed or durability. All parts were checked prior to packaging to insure quality. Prior to beginning
assembly, however, make sure all parts and hardware are included and ree o obvious de ect. I a part is
missing or de ective, please contact the store where purchased. I hardware is missing, or you need help with
assembly, please call toll ree 888-944-8396
IMPORTANT NOTE:
- Place all wooden parts on a clean and smooth sur ace such as a rug or carpet to avoid the parts rom
being scratched.
- Remove all wrapping material, including staples & packing straps be ore you start to assemble.
- DO NOT tighten all screws and bolts until completely assembled.
- Keep all hardware parts out o reach o children.
PART
LIST
When unpacking, please be care ul not to discard any parts with the packaging. Be ore continuing,
please make sure you have the ollowing parts:
NO
Descri tion
Qty
Sketch
E Pedestal extension 1
HARDWARE LIST
When unpacking, please be care ul not to discard any parts with the packaging. Be ore continuing,
please make sure you have all o the ollowing hardware:
NO
Descri tion
Qty
Sketch
NO
Descri tion
Qty
Sketch
10 Long bolt
(M6x190mm) 2
11 Lock washer
(Φ6.5x11mm) 2
12 Flat washer
(Φ6.5x13mm) 2

ITEM
NO
:
T
-
6P
REVISED JUL 23, 2012
Printed in Vietnam
- 3 -
STEP
1
Attach mounting plate (B) and pedestal extension (E) to the column (D) with long bolts (10), short
bolts (1), washers (2) , (4) , (11) and (12) as shown below. Tighten with allen key (9).
STEP 2
Attach pedestal extension (E) to the column (D), with long bolts (10 ), washers (11) and (12) as shown
below. Tighten with allen key (9).
Attach mounting plate (B) and pedestal extension (E) to the column (D), with long bolts (10), short
bolts (1), washers (2), (4) , (11) and (12) as shown below. Tighten with allen key (9).

ITEM
NO
:
T
-
6P
REVISED JUL 23, 2012
Printed in Vietnam
- 4 -
STEP
3
Care ully put the pedestal block on the bottom side o the table top, attach the top (A) to mounting
plate (B) with bolts (1) washers (3) and (4) .Tighten with the allen key (9).
