McKenzie Twin Storage Beds
GAC = Glazed Antique Cherry finish
CAF = Caffè finish
Assembly Instructions
IMPORTANT NOTES:
•For normal household use only. Not recommended for commercial use.
•Remove items before you move this unit.
•Do not overload the drawers.
•This assembly requires two people.
WARNING
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
CUSTOMER SERVICE
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
Fax: 541-687-2060• Email: info@whittierwood.com
Model #
1300GACf
1300CAFf
McKenzie
Twin Storage
Bed
Model #
1359GACf
1359CAFf
McKenzie
Twin Bookcase
Storage Bed
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
1300GACf 1300CAFf McKenzie Twin Storage Bed
& 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed
Parts List
1300GACf_1300CAFf_1359GACf_1359CAFf — Page 2 — 08/17
Please identify the parts and check that quantities received match those on this list.
If you need to replace a part, refer to the following letter and part name.
1301GACf 1301CAFf
Footboard, Pedestal and Side Panel Kit (x1)
Part
Description
Quantity
B
Left Bracket (attached)
6
C
Right Bracket (attached)
6
D
#8 x 1" Black Screw (inserted)
48
Ie
#8 x 7/8" Black Lo-Profile Screw (inserted)
16
V
#8 x 1-1/4" Black Screw (inserted)
60
(40 inserted)
XC
#8 x 1-1/2" Machine Screw Tuscan (installed)
3
XD
#10 x 3/4" Pan Head Screw (inserted)
8
YB
Footboard Assembly
1
YC
Pedestal Kit
1
YD
Small Drawer Box (assembled)
1
YE
Large Drawer Box (assembled)
2
YF
Small Drawer Face (attached)
1
YG
Large Drawer Face (attached)
2
YH
Side Panel
1
YI
Trestle with T-Nuts
4
YJ
Center Deckboard
1
YK
Notched Deckboard (not attached)
1
YL
Attached Deckboard (attached to pedestal)
1
YM
Assembled Foot
2
YN
Foot Bracket (attached)
2
1300GACf 1300CAFf McKenzie Twin Storage Bed
& 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed
Parts List
1300GACf_1300CAFf_1359GACf_1359CAFf — Page 3 — 08/17
Part
Description
Quantity
YO
Adjustable Glide (installed)
2
YP
Knob (attached)
3
YR
20" Drawer Slides (pre-installed sets)
3
YS
#6 x 1/2" Philtruss Screw
26
(18 inserted)
YT
#6 x 3/4" Philtruss Screw (inserted)
18
YU
1/4" x 1-3/4" Hex Bolt
8
YV
Washer
8
YW
90
o
Bracket (2 holes)
2
YY
1/4” X 20mm Insert Nut (inserted)
6
YZ
1/4" T-Nut (inserted)
8
ZA
#8 x 1-5/8" Black Screw (inserted)
18
ZB
#8 x 2" Black Screw (inserted)
16
ZG
90
o
Bracket (4 holes)
1
Please note this Assembly Instruction is for either the Twin Storage Bed or the Twin
Bookcase Storage Bed. The Parts list for each headboard follows on pages 4, 5 and 6.
1300GACf 1300CAFf McKenzie Twin Storage Bed
& 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed
Parts List
1300GACf_1300CAFf_1359GACf_1359CAFf — Page 4 — 08/17
1302GAC 1302CAF Twin Headboard Kit (x1)
Part
Description
Quantity
A
Headboard Assembly
1
B
Left Bracket (attached)
2
C
Right Bracket (attached)
2
D
#8 x 1" Black Screw (inserted)
16
X
#8 x 1-1/4" Pan Head Screw (inserted)
4
ZD
#12 x 2-1/2" Pan Head Screw (inserted)
6
1300GACf 1300CAFf McKenzie Twin Storage Bed
& 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed
Parts List
1300GACf_1300CAFf_1359GACf_1359CAFf — Page 5 — 08/17
1361GACf 1361CAFf Bookcase Headboard Kit (x1)
Part
Description
Quantity
B
Left Bracket (attached)
2
C
Right Bracket (attached)
2
D
#8 x 1" Black Screw (inserted)
16
Ed
Bookcase Headboard Assembly
1
F
Assembled Door (attached)
1
G
False Bottom
2
Ie
#8 x 7/8" Black Lo-Profile Screw (inserted)
4
J
Wire Clip Screw (attached)
3
K
Door Stay (attached)
1
L
#6 x 5/8" Undercut Screw ZN (inserted)
4
M
Door Stay Support (attached)
1
N
#6 x 1-1/4" Black Pan Head Screw (inserted)
3
O
Hinge (installed)
3
P
#6 x 5/8" Undercut Screw AB (inserted)
22
Q
Magnetic Catch Kit (attached)
2 sets
R
#6 x 5/8" Philtruss Screw (inserted)
9
S
Corner Brace (attached)
2
T
Large Adjustable Glide (installed)
2
U
#8 x 5/8" Pan Head Screw (inserted)
8
V
#8 x 1-1/4" Black Screw (inserted)
4
W
#8 x 2-1/4" Black Screw (inserted)
6
X
#8 x 1-1/4" Pan Head Screw (inserted)
4
XA
Top Assembly (attached)
1
XB
Power Bar and USB (installed)
1
1300GACf 1300CAFf McKenzie Twin Storage Bed
& 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed
Parts List
1300GACf_1300CAFf_1359GACf_1359CAFf — Page 6 — 08/17
Part
Description
Quantity
YA
Tack Glide (attached)
4
ZI
#8 x 1-3/8" Lo-Profile Screw (inserted)
6
1300GACf 1300CAFf McKenzie Twin Storage Bed
& 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed
Assembly Instructions
This assembly requires two people.
1300GACf_1300CAFf_1359GACf_1359CAFf — Page 7 — 08/17
Tools Required: Phillips screwdriver, Slotted Screwdriver, 7/16" open end or box end wrench.
1. Remove the Assembled Feet (YM) from the back of the Footboard (YB) as seen in Figure 1 and
place them off to the side.
2. The orientation of the drawer opening will be based on facing the backside of the footboard.
Decide if you want the drawers to open on the left side or the right side of the bed. Figure 2
below shows the drawers opening on the right side. If you want the drawers to open on the left
side, move the Footboard (YB) to the opposite end of the Pedestal Kit (YC). To attach the
Footboard (YB) to the Pedestal Kit (YC), align the brackets and slide the Pedestal Kit down on
to the Footboard (YB). See Figures 2 and 2a.
Fig. 2
Fig. 2a
YC
YB
YB
Fig. 1
YM
1300GACf 1300CAFf McKenzie Twin Storage Bed
& 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed
Assembly Instructions
This assembly requires two people.
1300GACf_1300CAFf_1359GACf_1359CAFf — Page 8 — 08/17
3. To attach the Side Panel (YH) to the Footboard (YB), align the brackets and slide the Side
Panel (YH) down on to the Footboard (YB). See Figures 3 and 3a.
4. Move your Twin Headboard (A) or Twin Bookcase Headboard (Ed) into position. Make sure the
drawers are opening on the side you desire. If you are satisfied, align and slide the brackets of
the Bed Assembly on to the brackets of the Headboard (A or Ed). If you are not satisfied with
the drawer position, remove the Footboard (YB) from the Bed Assembly and install at the
opposite end. Attach the Headboard (A or Ed). See Figures 4 or 4a.
Fig. 4
A
Ed
Fig. 4a
Fig. 3
Fig. 3a
C
YH
YB
1300GACf 1300CAFf McKenzie Twin Storage Bed
& 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed
Assembly Instructions
This assembly requires two people.
1300GACf_1300CAFf_1359GACf_1359CAFf — Page 9 — 08/17
5. Place one end of a Trestle with T-Nuts (YI) facing towards the Headboard, behind the rib in the
pedestal closest to the Headboard. Place the other end of the Trestle into the notched bracket in
the Side Panel (YH). See Figure 5. Place a Washer (YV) onto a 1/4" x 1-3/4" (YU) and insert
through the holes in the rib and Trestle as seen in Figure 5a, threading into the T-Nut. Repeat
for a second Trestle with T-Nuts (YI).
6. Attach two more Trestles with T-Nuts (YI) that face the Footboard (YB) as seen in Figure 6 and
6a.
Fig. 6a
Fig. 6
YI
YU
YV
x 2
x 2
YU
YV
YB
Fig. 5a
Fig. 5
YI
YU
YV
YI
YU
YV
x 2
x 2
YH
1300GACf 1300CAFf McKenzie Twin Storage Bed
& 1359GACf 1359CAFf McKenzie Twin Bookcase Storage Bed
Assembly Instructions
This assembly requires two people.
1300GACf_1300CAFf_1359GACf_1359CAFf — Page 10 — 08/17
7. Using the 90° brackets with two holes (YW) attach the two middle Trestles to the notched
brackets in the Side Panel (YH) with four #6 x 1/2" Philtruss Screws (YS).
See Figures 7 and 7a.
8. NOTE: There are blocks mounted on the back side of the Footboard to support the end of
the pedestal eliminating the need for an Assembled Foot in this position where it would
be easily visible. Do not attach an Assembled Foot in the position near the footboard.
Locate the holes and T-nuts in the horizontal stretchers of the Pedestal Assembly. In the sets of
stretcher holes nearest the Headboard, attach the two Assembled Feet (YM) to the stretchers
using four 1/4" x 1-3/4" (YU) and four Washers (YV). See Figure 8 and 8a.
Fig. 8
YM
YV
YU
Fig. 8a
YU
YV
x 4
x 4
YW
YS
x 2
x 4
YW
YS
Fig. 7
Fig. 7a
