WIKA TR30 User manual

DE
EN
Operating instructions
Betriebsanleitung
Resistance thermometer, compact design
Model TR30
Widerstandsthermometer, Kompaktausführung
Typ TR30
Model TR30
with circular connector
Model TR30
with angular connector

2
11377551.09 03/2018 EN/DE
WIKA operating instructions model TR30
DE
EN
Operating instructions model TR30 Page 3 - 26
Betriebsanleitung Typ TR30 Seite 27 - 50
Further languages can be found at www.wika.com.
© 04/2010 WIKA Alexander Wiegand SE & Co. KG
All rights reserved. / Alle Rechte vorbehalten.
WIKA®is a registered trademark in various countries.
WIKA®ist eine geschützte Marke in verschiedenen Ländern.
Prior to starting any work, read the operating instructions!
Keep for later use!
Vor Beginn aller Arbeiten Betriebsanleitung lesen!
Zum späteren Gebrauch aufbewahren!

EN
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
3
1. General information 4
2. Safety 6
3. Specications 10
4. Design and function 13
5. Transport, packaging and storage 15
6. Commissioning, operation 16
7. Conguration model TR30-W 19
8. Connecting PU-548 programming unit 22
9. Maintenance and cleaning 24
10. Dismounting, return and disposal 25
Contents
Contents
Declarations of conformity can be found online at www.wika.com.

EN
4
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
1. General information
■
The resistance thermometer described in the operating instructions
has been designed and manufactured using state-of-the-art
technology. All components are subject to stringent quality and
environmental criteria during production. Our management systems
are certied to ISO 9001 and ISO 14001.
■
These operating instructions contain important information on
handling the instrument. Working safely requires that all safety
instructions and work instructions are observed.
■
Observe the relevant local accident prevention regulations and
general safety regulations for the instrument's range of use.
■
The operating instructions are part of the product and must be kept
in the immediate vicinity of the instrument and readily accessible to
skilled personnel at any time.
■
Skilled personnel must have carefully read and understood the
operating instructions prior to beginning any work.
■
The manufacturer's liability is void in the case of any damage caused
by using the product contrary to its intended use, non-compliance
with these operating instructions, assignment of insuciently qualied
skilled personnel or unauthorised modications to the instrument.
■
The general terms and conditions contained in the sales
documentation shall apply.
■
Subject to technical modications.
■
Further information:
- Internet address: www.wika.de / www.wika.com
- Relevant data sheet: TE 60.30
- Application consultant: Tel.: [phone]
inf[email protected]
1. General information

EN
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
5
Explanation of symbols
WARNING!
... indicates a potentially dangerous situation that can result
in serious injury or death, if not avoided.
CAUTION!
... indicates a potentially dangerous situation that can result
in light injuries or damage to equipment or the environment,
if not avoided.
Information
… points out useful tips, recommendations and information
for ecient and trouble-free operation.
DANGER!
... identies hazards caused by electrical power. Should the
safety instructions not be observed, there is a risk of serious
or fatal injury.
WARNING!
... indicates a potentially dangerous situation that can result
in burns, caused by hot surfaces or liquids, if not avoided.
Abbreviations
2-wire The lead resistance is recorded as an error in the measurement.
3-wire With a cable length of 30 m or longer, measuring errors can
occur.
4-wire The lead resistance can be neglected.
1. General information

EN
6
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
2. Safety
WARNING!
Before installation, commissioning and operation, ensure
that the appropriate resistance thermometer has been
selected in terms of measuring range, design, specic
measuring conditions and appropriate wetted parts' materials
(corrosion).
Non-observance can result in serious injury and/or damage
to the equipment.
Further important safety instructions can be found in the
individual chapters of these operating instructions.
2.1 Intended use
The resistance thermometer model TR30 is used as general-purpose
thermometer for the measurement of temperatures from -50 … +150 °C
(without neck tube) and -50 … +250 °C (with neck tube) in liquid and
gaseous media. It can be used for pressures up to 40 bar (special
designs to 400 bar dependent on insertion length and diameter).
The instrument has been designed and built solely for the intended use
described here, and may only be used accordingly.
The technical specications contained in these operating instructions
must be observed. Improper handling or operation of the instrument
outside of its technical specications requires the instrument to be taken
out of service immediately and inspected by an authorised WIKA service
engineer.
If the instrument is transported from a cold into a warm environment, the
formation of condensation may result in the instrument malfunctioning.
Before putting it back into operation, wait for the instrument temperature
and the room temperature to equalise.
The manufacturer shall not be liable for claims of any type based on
operation contrary to the intended use.
2. Safety

EN
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
7
2.2 Personnel qualication
WARNING!
Risk of injury if qualication is insucient!
Improper handling can result in considerable injury and
damage to equipment.
■
The activities described in these operating instructions
may only be carried out by skilled personnel who have the
qualications described below.
■
Keep unqualied personnel away from hazardous areas.
Skilled personnel
Skilled personnel are understood to be personnel who, based on their
technical training, knowledge of measurement and control technology
and on their experience and knowledge of country-specic regulations,
current standards and directives, are capable of carrying out the work
described and independently recognising potential hazards.
Special operating conditions require further appropriate knowledge, e.g.
of aggressive media.
2.3 Special hazards
WARNING!
For hazardous media such as oxygen, acetylene,
ammable or toxic gases or liquids, and refrigeration plants,
compressors, etc., in addition to all standard regulations,
the appropriate existing codes or regulations must also be
followed.
WARNING!
Protection from electrostatic discharge (ESD) required.
The proper use of grounded work surfaces and personal
wrist straps is required when working with exposed circuitry
(printed circuit boards), in order to prevent static discharge
from damaging sensitive electronic components.
2. Safety

EN
8
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
To ensure safe working on the instrument, the operating
company must ensure
■
that suitable rst-aid equipment is available and aid is
provided whenever required,
■
that the operating personnel are regularly instructed in all
topics regarding work safety, rst aid and environmental
protection, and know the operating instructions, in
particular the section on safety instructions.
DANGER!
Danger of death caused by electric current
Upon contact with live parts, there is a direct danger of death.
■
The instrument may only be installed and mounted by
skilled personnel.
■
Operation using a defective power supply unit (e.g. short
circuit from the mains voltage to the output voltage) can
result in life-threatening voltages at the instrument!
WARNING!
Residual media in dismounted instruments can result in a
risk to personnel, the environment and equipment.
Take sucient precautionary measures.
Do not use this instrument in safety or Emergency Stop
devices. Incorrect use of the instrument can result in injury.
Should a failure occur, aggressive media with extremely high
temperature and under high pressure or vacuum may be
present at the instrument.
2. Safety

EN
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
9
ohne
2.4 Labelling, safety marks
Product label (example)
Model
Year of manufacture
Serial number
Electrical connection
Information on version (measuring element, output signal, measuring range...)
■
Thermometer with transmitter and 4 ... 20 mA output signal
■
Thermometer with direct sensor output with Pt100
Before mounting and commissioning the
instrument, ensure you read the operating
instructions!
2. Safety
   


EN
10
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
3. Specications
■
Output signal Pt100, model TR30-P
Measuring element and measuring insert
The Pt100 measuring element is located in the thermometer's probe tip.
Output signal Pt100, model TR30-P
Temperature range
■
Class A
■
Class B
Without neck tube -30 ... +150 °C (-22 ... +302 °F)
With neck tube -30 ... +250 °C (-22 ... +482 °F)
Without neck tube -50 ... +150 °C (-58 ... +302 °F)
With neck tube -50 ... +250 °C (-58 ... +482 °F)
Measuring element Pt100 (measuring current: 0.1 ... 1.0 mA)
Connection method
■
2-wire
■
3-wire
■
4-wire
Sensor tolerance value per
IEC 60751
■
Class B
■
Class A
Electrical connection
■
M12 x 1 circular connector (4-pin)
■
DIN angular connector form A (for cable with
Ø 6 ... 8 mm, cross section max. 1.5 mm²)
For detailed specications for Pt100 sensors, see Technical Information IN 00.17 at www.wika.com.
■
Output signal 4 ... 20 mA, model TR30-W
Measuring element and measuring insert
The Pt100 measuring element is located in the thermometer's probe tip.
The 4 ... 20 mA transmitter is mounted and potted within the tubular body
of the thermometer.
Output signal 4 ... 20 mA, model TR30-W
Temperature range 1)
■
Class A
■
Class B
Without neck tube -30 ... +150 °C (-22 ... +302 °F)
With neck tube -30 ... +250 °C (-22 ... +482 °F)
Without neck tube -50 ... +150 °C (-58 ... +302 °F)
With neck tube -50 ... +250 °C (-58 ... +482 °F)
Measuring element Pt100 (measuring current: 0.5 mA)
Sensor tolerance value per
IEC 60751
■
Class B
■
Class A
Measuring span Minimum 20 K, maximum 300 K
3. Specications

EN
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
11
Output signal 4 ... 20 mA, model TR30-W
Basic conguration Measuring range 0 ... 150 °C, other measuring
ranges are adjustable
Analogue output 4 ... 20 mA, 2-wire
Measuring error per
IEC 60770, 23 °C ±5 K
1 % (Transmitter) 2)
Linearisation Linear with temperature per DIN EN 60751
Linearisation error ±0.1 % 3)
Switch-on delay, electrical < 10 ms
Current signal for fault
signal
Congurable in accordance with NAMUR NE43
downscale ≤ 3.6 mA upscale ≥ 21.0 mA
Sensor short-circuit Not congurable, generally NAMUR downscale
≤ 3.6 mA
Load RARA ≤ (UB - 9 V) / 0.023 A with RA in Ω and UB in V
Eect of load ±0.05 % / 100 Ω
Power supply UBDC 10 ... 35 V
Max. permissible residual
ripple
10 % at 24 V / maximum 300 Ω Load
Power supply input Protected against reverse polarity
Power supply eect ±0.025 % / V
Electromagnetic
compatibility (EMC)
EN 61326 emission (Group 1, Class B) and
immunity (industrial application) 4), and also per
NAMUR NE21
Temperature units Congurable °C, °F, K
Info data TAG No., descriptor and message can be stored
in transmitter
Conguration and
calibration data
Permanently stored in EEPROM
Electrical connection
■
M12 x 1 circular connector (4-pin)
■
DIN angular connector form A (for cable with
Ø 6 ... 8 mm, cross section max. 1.5 mm²)
Readings in % refer to the measuring span
For a correct determination of the overall measuring error, both sensor and transmitter
measuring deviations have to be considered.
1) The temperature transmitter should therefore be protected from temperatures over 85 °C (185 °F).
2) For measuring spans smaller than 50 K additional 0.1 K
3) ±0.2 % for measuring ranges with a lower limit less than 0 °C
4) Use resistance thermometers with shielded cable, and ground the shield on at least one end of the lead, if the
cables are longer than 30 m or leave the building.
3. Specications

EN
12
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
Voltage UBin V
Load RA in Ω
0 10 24 30 36
1182
909
636
Load diagram
For setting the measuring range see chapter 7 “Conguration
model TR30-W”.
For further specications see WIKA data sheet TE 60.30.
The permissible load
depends on the loop
supply voltage.
3. Specications

EN
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
13
4. Design and function
4.1 Description
The resistance thermometer model TR30 consists of a thermowell with
xed process connection, and is screwed directly into the process.
It is designed to be resistant to shock and vibration and all electrical
components are protected against splashed water.The vibration
resistance of the standard version complies with DIN EN 60751 (up to
3 g); specic designs can withstand up to 10 g. The impact resistance
for all versions meets the requirements of DIN EN 60751. The electrical
connection is made via an angular DIN connector, Form A or M12 x 1
circular connector.
4.2 Dimensions in mm
■
Process connection with parallel threads (or without process
connection)
≥≥
Version with
compression tting
Version without
process connection
Circular connector
4-pin M12 x 1
Angular connector
DIN EN 175301-803
Version with
tapered tip
Legend:
U1Insertion length
NNeck tube length (70 mm)
Ød Sensor diameter
Version with
neck tube
11176688.06
4. Design and function

EN
14
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
■
Process connection with tapered threads
4.3 Scope of delivery
Cross-check scope of delivery with the delivery note.
≥
Version with
compression tting
Circular connector
4-pin M12 x 1
Angular connector
DIN EN 175301-803
Version with
tapered tip
Legend:
U2Insertion length
NNeck tube length (70 mm)
Ød Sensor diameter
Version with
neck tube
11318708.01
4. Design and function

EN
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
15
5. Transport, packaging and storage
5.1 Transport
Check the instrument for any damage that may have been caused during
transportation. Obvious damage must be reported immediately.
5.2 Packaging
Do not remove packaging until just before mounting.
Keep the packaging as it will provide optimum protection during transport
(e.g. change in installation site, sending for repair).
5.3 Storage
Permissible conditions at the place of storage:
■
Storage temperature: 0 ... 70 °C
■
Humidity: 35 ... 85 % relative humidity (no condensation)
Avoid exposure to the following factors:
■
Direct sunlight or proximity to hot objects
■
Mechanical vibration, mechanical shock (putting it down hard)
■
Soot, vapour, dust and corrosive gases
■
Potentially explosive environments, ammable atmospheres
Store the instrument in its original packaging in a location that fulls the
conditions listed above. If the original packaging is not available, pack
and store the instrument as described below:
1. Wrap the instrument in an antistatic plastic lm.
2. Place the instrument, along with shock-absorbent material, in the
packaging.
3. If stored for a prolonged period of time (more than 30 days), place a
bag containing a desiccant inside the packaging.
WARNING!
Before storing the instrument (following operation), remove
any residual media.This is of particular importance if
the medium is hazardous to health, e.g. caustic, toxic,
carcinogenic, radioactive, etc.
5. Transport, packaging and storage

EN
16
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
Insertion
length A
Installation on pipes
a on elbows
b in small pipes, inclined
c perpendicular to ow direction
6. Commissioning, operation
WARNING!
Avoid putting mechanical stress on the electrical connections
or on the enclosures.The maximum temperatures of
-50 … +150 °C (without neck tube) and -50 … +250 °C (with
neck tube) must not be exceeded. Connections must only
be opened when the instrument is depressurised and has
cooled down.
6.1 Mounting
These resistance thermometers are designed for screw-tting directly
into the process. The insertion length, along with the ow velocity and
viscosity of the process media, may reduce the max. loading on the
thermowell.
Installation examples
For information on tapped
holes, please refer to DIN 3852,
or for NPT threads ANSI B 1.20.
6. Commissioning, operation

EN
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
17
6.2 Electrical connection
6.2.1 Output signal Pt100, model TR30-P
6.2.2 Output signal 4 ... 20 mA, model TR30-W
DANGER!
Danger to life caused by electric current
Upon contact with live parts, there is a direct danger to life.
■
The instrument may only be installed and mounted by
skilled personnel.
■
Operation using a defective power supply unit (e.g. short-
circuit from the mains voltage to the output voltage) can
result in life-threatening voltages at the instrument!
■
Carry out mounting work only with power disconnected.
This is protection class 3 equipment for connection at low voltages,
which are separated from the power supply or voltages of greater than
AC 50 V or DC 120 V. Preferably, a connection to an SELV or PELV circuit
is recommended; alternatively protective measures from HD 60346-4-41
(DIN VDE 0100-410).
Circular connector M12 x 1 (4-pin)Angular connector DIN EN 175301-803,
Form A
6. Commissioning, operation

EN
18
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
Alternatively for North America
The connection can be made in line with “Class 2 Circuits” or “Class 2
Power Units” in accordance with CEC (Canadian Electrical Code) or
NEC (National Electrical Code).
Version with angular connector (DIN EN 175301-803)
For the cable leads we recommend the use of
crimped ferrules.
To ensure IP65 ingress protection:
■
Always use the silicon seals
■
Tighten the locking screw
■
Ensure the cables are inserted carefully
DC 10 ... 35 V
Circular connector M12 x 1 (4-pin)
Angular connector DIN EN 175301-803,
Form A
6. Commissioning, operation

EN
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
19
7. Conguration model TR30-W
7. Conguration model TR30-W
Conguration is carried out via a USB interface with a PC via the model
PU-548 programming unit (accessories, order no. 14231581).
The connection with the thermometer is made via the appropriate
adapter cable.
■
Accessories, M12 x 1 circular connector: order no. 14003193
■
Accessories, angular DIN connector: order no. 14005324
Measuring range, signalisation and also further parameters are
congurable; see conguration software.
Screenshot from the conguration software
■
Easy to use
■
LED status display
■
Compact version
■
No further power supply is needed for
either the programming unit or for the
transmitter
■
Measuring the loop current of resistance
thermometers are possible
(replaces programming unit model PU-448)

EN
20
WIKA operating instructions model TR30
11377551.09 03/2018 EN/DE
The lower limit of the measuring range is congurable between
-50 ...+150 °C.
The possible upper limit of the measuring range is dependent on
the respective lower limit of the measuring range. For possible
combinations of lower and upper limits of the measuring range, see
diagram. For clarity, this dependency has been shown in 50 °C steps
in the examples in this diagram. The conguration software checks
the required measuring range and will only accept permissible values.
Intermediate values are congurable; the smallest increment is 0.1 °C.
The thermometers are delivered with a basic conguration (0 ... 150 °C,
downscale) or congured to customer specications within the
congurable limits.
With conguration to customer specications, the measuring range
will be shown clearly on the instrument label. The conguration and
the choice of parameters is described in the menu-driven conguration
software. Changes to the conguration must be noted on the label using
a water-resistant felt-tip pen.
Possible combinations of the lower and upper limits of the
measuring range
The upper limit of the measuring range is dependent on the respective
lower limit of the measuring range. For clarity, this dependency has
been shown in 50 °C steps in the examples in these diagrams.The
conguration software checks the required measuring range and will
only accept permissible values. Intermediate values are congurable; the
smallest increment is 0.1 °C.
7. Conguration model TR30-W
