Wilfa HU-35W User manual

HU-35W
Wilfa CLOUD
Ultrasonic Humidifier
Bruksanvisning
Bruksanvisning
Betjeningsvejledning
Käyttöohje
Operating Instructions
EN ·Instruction manual NL ·Instructies
NO ·Bruksanvisning PL ·Instrukcje
SE ·Bruksanvisning FR ·Instructions
DK ·Betjeningsvejledning IT ·Manuale di istruzioni
FI ·Käyttöohje ES ·Manual de instrucciones
DE ·Anleitung
Wilfa CLOUD
HUMIDIFIER HU-35W, HU3-35W

NO
SE
DK
FI
EN
NL
PL
FR
IT
ES
DE
LES ALLE ANVISNINGER FØR BRUK
LÄS IGENOM ALLA INSTRUKTIONER INNAN PRODUKTEN ANVÄNDS
LÆS ALLE VEJLEDNINGER INDEN BRUG
LUE OHJEET HUOLELLISESTI ENNEN KÄYTTÖÄ
READ ALL INSTRUCTIONS BEFORE USE
LEES VÓÓR GEBRUIK ALLE INSTRUCTIES
PRZED UŻYCIEM ZAPOZNAĆ SIĘ ZE WSZYSTKIMI ZALECENIAMI
PRENEZ CONNAISSANCE DE TOUTES LES INSTRUCTIONS AVANT UTILISATION
LEGGERE TUTTE LE ISTRUZIONI PRIMA DELL’USO
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR
LESEN SIE DIE ANLEITUNG VOR DEM GEBRAUCH GRÜNDLICH DURCH

EN
2
INSTRUCTION MANUAL · WILFA CLOUD
ENEN

EN
3
CONTENTS
4 IMPORTANT SAFETY INSTRUCTIONS
7 PRODUCT OVERVIEW
8 PLACEMENT
8 FUNCTION AND FEATURES
8 OPERATION INSTRUCTION
9 CLEANING & MAINTENANCE
10 TROUBLESHOOTING
12 GUARANTEE
13 PRODUCT SPECIFICATIONS
13 SUPPORT AND SPARE PARTS
13 RECYCLABILITY
EN
HUMIDIFIER ·HU-35W, HU3-35W

EN
4
INSTRUCTION MANUAL · WILFA CLOUD
IMPORTANT SAFETY INSTRUCTIONS
•Please read this manual carefully before operation
and save it for future reference.
•Check the voltage carefully to ensure your
homepower voltage ts the product
•Ensure the plug exactly inserts to the right socket.
Make sure there is a good contact.
• Do not extend the wire.
•Pull out the plug by hand rather than pulling on
the wire.
•Do not use the product in dusty, oily or smoky
environments, as this may cause electric shock
and re.
•Do not use the product in a wet environment,such
as a bathroom, as this may cause electricshock
and re.
•In some cases, such as in areas of high humidity
or if the unit is used at maximum capacity, this can
eventually cause steam to be emitted, resulting
in the area where the unit is situated becoming
moist. Regular monitoring of the unit is therefore
recommended, and if this occurs, the unit should
be stopped.
ENEN

EN
5
•Do not use the product near a window, to avoid
rain or curtains covering the air inlet or mist outlet.
This will cause the temperature to rise and may
cause re.
•Do not place your hands or appliances on topof
the product as this may damage the deviceor
result in the device not functioning properly.
•Remove the water tank before moving the device.
•Do not touch the plug or wire with wet hands as
this may cause electric shock.
•Please place the device on an even surface. If the
surface is uneven, this may cause the water to
ood out.
• Do not clean your machine while it is operating.
•Do not expose the machine to sunshine or place
it to close to a heater.
•Please disconnect the unit from the electrical
socket while you ll it with water, clean the unit, or
if the unit is left unused for a long time.
•Do not place metal or easily combustible material
close to the air intake or mist outlet areas.
•If the unit is damaged or does not work, pleasetake
to a certied repair shop or back to the shop
EN
HUMIDIFIER ·HU-35W, HU3-35W

EN
6
INSTRUCTION MANUAL · WILFA CLOUD
from which you bought the unit. Do not perform
disassembly or assembly by yourself.
•Care should be taken when using the appliance
due to the emission of hot water vapor.
•If the supply cord is damaged, it must be replaced
by the manufacturer, the manufacturer’s service
agent or similarly qualied persons in order to
avoid a hazard.
•This appliance may be used by children aged 8
years and above and by persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved.
• Children must not play with the appliance.
•Children must not perform cleaning or user
maintenance without supervision.
ENEN

EN
7
PRODUCT OVERVIEW
1. Nozzle
2. Water tank
3. Aroma pad
4. Knob
5. Water tank cover
6. Indicating light
7. Power cord
1
2
3
4
5
6
7
5
6
7
1
2
3
4
EN
HUMIDIFIER ·HU-35W, HU3-35W

EN
8
INSTRUCTION MANUAL · WILFA CLOUD
PLACEMENT
•Place the product on rm, at surface. The humidier should be placed on at
horizontal surface and keep it steady.
•Do not place the product near or close to any heat sources. The humidier
should be far away from any heat sources, such as stoves or re places. Do not
expose the product to direct sunlight.
• Do not place the product near or close to furniture or electric appliances. The
mist outlet from the humidier should not be directed towards furniture and
the electronic appliances, to avoid damage. Particles in water, such as calcium,
can be part of the vapour and be deposited on objects in the vicinity.
• It is recommended that the unit be placed on a table or other surface at
least 70 cm above the oor level, to ensure that the vapour will be optimally
distributed throughout the room.
• Air draft and temperature changes can impact the distribution of the
vapor. To avoid water damage it’s recommended to always check for moist
accumulations on the oor or other nearby surfaces
FUNCTION AND FEATURES
• Adjustable mist output by knob, easy operation
• With aroma diffuser function
• Big tank cover design for easy cleaning by hand
• Automatic shut-off protection with warning when waterless
• Automatic shut-off protection when take off the water tank
• Optional demineralization cartridge to prolong useful life.
• Integrated body design for noise suppression, super quiet when operating
• Ceramic glass glaze transducer can resist water scale effectively to prolong
useful life.
OPERATION INSTRUCTION
OPERATION CONDITION
•The working environment for humidier is in temperatures between 5˚C to
45˚C, with a relative humidity level below than 80% RH.
• Set the machine to operate on low mist level when room relative humidity is
higher than 70% or in an enclosed room space.
•Use fresh water with a temperature that not exceed 40 ˚C.
•Clean water tank and water ume when taking the product into use after a
long time.
ENEN

EN
9
OPERATION STEPS
1. Unmount the tank from the base, unscrew the water tank cover and ll the
tank with water, screw the water tank cover back, make sure it sits tightly.
Replace the water tank on the base.
2. Check that the mist outlet nozzle is correctly mounted on the water tank.
3. Plug in the power; turn the knob clock wise to start the machine. Adjust
preferred mist output from minimum to maximum by turning the knob
clockwise. To decrease the output or turn off the machine please turn the
knob counter clockwise.
4. When the water level is too low the indicating light turns red and the machine
will stop work. Rell the tank and turn on the machine to continue operate.
5. The machine will stop work if the water tank is removed during operation.
6. The machine will resume operation when the water tank is replaced correctly.
CLEANING & MAINTENANCE
Before cleaning, turn the functional knob anti clockwise until it points to “OFF”
and disconnect the plug from the outlet.
WATER TANK INSIDE
Clean water tank inside and water sink twice per week at least when using the
on a daily basis. Water residuals may form along the tank’s inside and can be
removed with soft dish brush. A soft cloth can also be used to wipe the insides of
the water tank. Don’t put acid, alkalescency, bleacher detergent into water tank
to avoid damage.
WATER SINK INSIDE
The water quality in some regions can be rich of calcium (hard water). This can re-
sult in increased calcium deposits inside water tank or transducer. Users in areas
with high content a minerals should perform maintenance as often as needed.
• Add cleaning agent on the transducer surface (The amount of detergent is
directly dependent on the amount of calcium deposits).
• Fill water into the space that is located under the water tank placement (water
sink). Let the machine rest for 10-15 min.
• Then gently brush the transducer area free of calcium deposits. Clean the
entire sink area free of detergent and mineral deposits by using a dish brush.
•Rinse with fresh water and repeat at least two times. Don’t use acid detergents
to wash the water sink inside to avoid damage on the transducer.
EN
HUMIDIFIER ·HU-35W, HU3-35W

EN
10
INSTRUCTION MANUAL · WILFA CLOUD
Problem Possible reasons Solutions
No steam Check plug Plug into socket
Check power switch Turn on power switch
No water in tank Add water
Not enough water in the
tank
Add water
Peculiar smelling
steam
New machine Take off tank cover, place
the water tank in cool and
dry place for 12 hours
Too dirty water, or water in
tank too long time
Clean water tank, replace
with clean water
Noise Tank in incorrect position Put the tank in correct
position
Not enough water in the
tank
Add water
Uneven level for machine Place it on even at or
ground
Steam out
from outlet
surroundings
Clearance between steam
outlet and water tank
Sink the steam outlet cap in
water and use it again
TROUBLESHOOTING
If the machine is still not working after checking the possible reasons above,
contact the store where the product was purchased from.
BODY AND WATER TANK OUTSIDE
Wipe it gently with a soft cloth mixed with a small amount of detergent.
STORAGE
Drain the water in tank and body, remove any stains or dirt. Make sure that the
product has dried completely before it is put into storage. Store the product in a
dry environment.
ENEN

EN
11
EN
HUMIDIFIER ·HU-35W, HU3-35W

EN
12
INSTRUCTION MANUAL · WILFA CLOUD
GUARANTEE
Wilfa issues a 5 year guarantee on this product from the day of purchase is
done. The guarantee covers production failure or defects that arise during
the guarantee period. Your purchase receipt works as proof towards retailer if
claiming your guarantee.
The guarantee is valid only for products that are bought and used in private
households. The guarantee is not valid if the product is used commercially.
The guarantee is not valid if the product is misused, used by negligence, if not
following instructions given by Wilfa, if modied or if unauthorized reparation
is done. The guarantee is also not valid for normal wear of the product, misuse,
lack of maintenance, use of wrong electrical voltage or:
• Not descaled according to instruction manual
• Overloading of product
• Damage on glass
• Parts which are normally worn down
ENEN

EN
13
HUMIDIFIER ·HU-35W, HU3-35W
PRODUCT SPECIFICATIONS
100 - 240V~ 50/60Hz 25W
SUPPORT AND SPARE PARTS
For support please visit us at wilfa.com, and see our customer service/support
page. Here you will nd frequently asked questions, spare parts, tips and tricks
and all our contact information.
RECYCLABILITY
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was purchased.
They can take this product for environmentally safe recycling free of charge.
EN
AS Wilfa Sandakerveien 114A, 0484 Oslo, Norge

14
BRUKSANVISNING · WILFA CLOUD
NO

15
LUFTFUKTER ·HU-35W, HU3-35W
NO
INNHOLD
16 VIKTIGE SIKKERHETSANVISNINGER
19 PRODUKTOVERSIKT
20 PLASSERING
20 FUNKSJONER
20 BRUK
21 RENGJØRING OG VEDLIKEHOLD
23 FEILSØKING
24 GARANTI
25 PRODUKTSPESIFIKASJONER
25 SUPPORT OG RESERVEDELER
25 GJENVINNING

16
BRUKSANVISNING · WILFA CLOUD
NO
VIKTIGE SIKKERHETSANVISNINGER
• Les denne bruksanvisningen nøye før du tar
apparatet i bruk, og ta vare på det til senere bruk.
• Kontroller spenningen nøye for å sikre at
strømspenningen hjemme er tilpasset apparatet.
• Påse at støpselet settes inn i rett kontakt. Sørg for
at det er god kontakt.
• Ikke bruk skjøteledning.
• Ikke dra i ledningen når du trekker ut støpselet fra
stikkontakten!
• Apparatet skal ikke brukes i støvete, oljerike
eller røykfylte miljøer ettersom dette kan føre til
elektrisk støt og brann.
• Apparatet skal ikke brukes i våte miljøer, slik som
bad, ettersom dette kan føre til elektrisk støt eller
brann.
• I enkelte tilfeller, slik som ved høy fuktighet eller
hvis apparatet brukes ved maksimal kapasitet, kan
føre til at apparatet avgir damp, noe som fører til
at området rundt apparatet kan bli fuktig.
• Vi anbefales derfor regelmessig overvåking av
apparatet, og hvis slik fuktighet skulle oppstå, må
apparatet stoppes.

17
LUFTFUKTER ·HU-35W, HU3-35W
NO
• Apparatet skal ikke brukes i nærheten av et
vindu for å unngå at regn eller gardiner dekker
luftinntaket eller tåkedamputtaket. Dette kan føre
til at temperaturen øker og kan forårsake brann.
• Ikke legg hender eller husholdningsapparater på
apparatet ettersom dette kan føre til at apparatet
skades og vil dermed ikke fungere slik det er
tiltenkt.
• Fjern vannbeholderen før du ytter apparatet.
• Støpselet eller ledningen skal ikke berøres med
våte/fuktige hender ettersom dette kan føre til
elektrisk støt.
• Plasser apparatet på et jevnt og stabilt underlag.
• Vannet kan renne ut av apparatet hvis underlaget
er ustabilt.
• Apparatet skal ikke rengjøres under drift.
• Apparatet skal ikke utsettes for direkte sollys eller
plasseres i nærheten av et varmeapparat.
• Apparatet skal frakobles stikkontakten mens
du fyller på vann, rengjør apparatet, eller hvis
apparatet ikke har vært brukt på en stund.
• Metallellerbrennbarematerialerskalikkeplasseres
i nærheten av luftinntaket eller tåkedamputtaket.

18
BRUKSANVISNING · WILFA CLOUD
NO
•Hvisapparateterskadetellerikkefungerer,skaldet
tas med til et sertisert verksted eller til butikken
der du kjøpte apparatet. Du skal ikke demontere
eller montere apparatet på egenhånd.
•Vær forsiktig når du bruker apparatet på grunn av
varm damp.
•Hvis strømledningen er ødelagt, må den skiftes
av produsenten, en servicetekniker eller lignende
kvalisert person for å unngå risiko.
•Dette apparatet kan brukes av barn fra 8 år og
oppover samt personer med nedsatte fysiske,
sansemessige eller mentale evner eller mangel
på erfaring og kunnskap, hvis de er under tilsyn
av eller har fått anvisninger om sikker bruk av
apparatet og er klar over farene forbundet med
bruk.
• Ikke la barn leke med produktet.
•Rengjøring og vedlikehold skal ikke utføres av
barn uten at de er under tilsyn.
