Introduction
Thank you for purchasing this quality product. To minimize t e risk of injury we urge t at our cli-
ents take some basic safety precautions w en using t is device. Please read t e operation in-
structions carefully and make sure you ave understood its content.
Keep these operation instructions safe.
General safety instructions
READ and UNDERSTAND t is manual completely before using t e 40” scarifier.
The operator must read and understand all safety, warning and operating, maintenance and
storage instructions before operating this equipment.
Failure to properly operate and maintain the scarifier could result in serious injury to the oper-
ator or bystanders.
Operation warnings
Do at no time carry passengers, sit or stand on the scarifier.
Do not allow children to play on, stand upon or climb on the scarifier.
lways inspect the equipment before using to assure it is in good working condition.
Replace or repair damaged or worn parts immediately.
lways check and tighten hardware and assembled parts before operation.
Do not exceed equipment maximum tray load capacity of 70>lb.
void large holes and ditches when operating the equipment.
Be careful when operating the scarifier on steep grades (hill).
LW YS operate at reduce speed in rough terrain, along creeks, ditches and on hillsides.
Do not operate close to creeks, ditches and public highways.
To avoid personal injury and/or equipment damage DO NOT EXCEED 5MPH.
lways use caution when loading and unloading extra weight on the tray.
Only tow with recommended vehicles (lawn/garden tractors and TVs).
lways refer to the vehicle owner’s manual for proper towing.
The scarifier is not designed to be used with zero-turn mowers.
lways secure and lock the scarifier thatcher to the vehicle hitch before operating.
Crus and cut azards
lways keep your hands and feet away from moving parts while operating the equipment.
lways wear safety gear, eye protection, gloves and work boots when operating the equip-
ment.
WARNING: The warnings, cautions, and instructions outlined in this instruction manual cannot cover
all possible conditions or situations that may occur. It must be understood by the operator that com-
mon sense and caution are factors which cannot be built into this product and must be supplied by the
operator.
Assembly is required
This product requires assembly before use. See “ ssembly” section for instructions. Because of the
weight and/or size of the 40” scarifier, it is recommended that another adult be present to assist with
the assembly. INSPECT ALL COMPONENTS closely upon receipt to make sure no components are
missing or damaged.
© by WilTec Wildanger Technik GmbH Item 51705 Page 3
http://www.WilTec.de
http://www.aoyue.eu 01 2021-1
http://www.teichtip.de

About your 40” scarifier
This 40” scarifier has a roughed steel construction and is designed to remove dead grass, matted
thatch, debris and large clippings. The 40” scarifier features a fully enclosed weight tray to increase
the penetration depth. Never exceed the rated loaded capacity of the tray of 70>lbs when operating the
scarifier.
Technical specifications on the 40” scarifier are provided in the “Specifications” section of this manual.
Controls and features identification
Read t is owner’s manual before operating t e equipment. Familiarize yourself wit
t e location and function of t e controls and features.
Save t is manual for future reference.
№ Name Comment
1Scarifier tray Do not exceed maximum load capacity 70>lbs.
2Lift handle Positions tines up or down.
3Tines Removes debris from the ground.
4Hitch Pin-type design use only with approve vehicles.
5Tyres/wheels ll-terrain for easy manoeuvring.
CAUTION
Read and follow all instructions for assembly and operation. Failure to properly assemble this
equipment could result in serious injury to the user or bystanders, or cause equipment damage.
© by WilTec Wildanger Technik GmbH Item 51705 Page 4
http://www.WilTec.de
http://www.aoyue.eu 01 2021-1
http://www.teichtip.de

Scarifier components and assembly
Take all parts out of the shipping crate and inspect components to ensure there are no missing pieces
before starting to assemble the scarifier, follow the steps below.
Component and ardware parts
№ Name Qty. № Name Qty.
1Tine shield 1 6Lift plate 1
2Spring tines 10 7Hitch bracket 2
3Lift handle 1 8Hitch mount arms 2
4xle bracket 1 9Spring alignment wires 2
5Wheels 2
№ Name Qty. № Name Qty.
AShoulder bolt 2 HHexagonal nut M8 14
BHexagonale bolt M8×50 2 IHexagonal lock nut M8 19
CHexagonal bolt M8×30 2 JHexagonal lock nut M10 2
DHexagonal bolt M8×20 15 KLock washer Ø8 14
ECarriage bolt M8×25 14 LBig flat washer Ø8 10
FHitch pin Ø10 1 Mngle bracket 4
GHair cotter pin Ø3 1 NHitch arm Mounting bracket 3
© by WilTec Wildanger Technik GmbH Item 51705 Page 5
http://www.WilTec.de
http://www.aoyue.eu 01 2021-1
http://www.teichtip.de

Assembly instructions
Tools required for assembly (1 of each):
13>mm wrench
14>mm wrench
djustable wrench
Pliers
Before assembling the scarifier, lay out all of the parts and hardware as shown on the previous pages.
The 40” scarifier is show in the following drawings. The assembly of the 40” and 48” is the same ex-
cept as noted in the instructions.
1. ssemble the lift plate (1) to the top of the tine
shield using four M8×20 hex bolts (2) and M8 hex
lock nuts (3) as shown in figure. Tighten.
2. Turn the tine shield upside down.
3. ssemble two (tall) hitch arm mount brackets
(5) and two (short) angle brackets (4) to the bot-
tom of the tine shield. Fasten the brackets to the
four round holes at the rear of the tine shield us-
ing four M8×20 hex bolts (3) and M8 hex lock
nuts (1). Do not tighten yet.
4. ssemble two angle brackets (4) to the round
holes in the bottom of the tine shield at the front.
Use two M8×20 hex bolts (3) and M8 hex lock
nuts (1). Do not tighten yet.
5. Fasten the hitch mount arms (2) to the outside
of the angle brackets at the front of the tine
shield. Use two M8×20 hex bolts (3) and M8 hex
lock nuts (4). Tighten and then loosen the nuts
slightly.
6. Fasten the hitch mount arms to the outside of
the hitch arm mount brackets (2) at the rear of the
tine shield. Use two M8×25 carriage bolts (1), Ø8
lock washers (6) and M8 hex nuts (5). Do not
tighten yet.
© by WilTec Wildanger Technik GmbH Item 51705 Page 6
http://www.WilTec.de
http://www.aoyue.eu 01 2021-1
http://www.teichtip.de

7. ssemble the front ends of the hitch mount
arms together using two M8×30 hex bolts (6) and
M8 hex lock nuts (1). Do not tighten yet.
8. ssemble the hitch brackets (3) to the top and
bottom of the hitch mount arms using two M8×50
hex bolts (5) and M8 hex lock nuts (1). Do not
tighten yet.
9. ssemble the Ø10 hitch pin (4) through the
hitch brackets and secure it with a Ø3 hair cotter
pin (2).
10. Tighten the bolts and nuts assembled in the
previous steps in the following order: 8 – 7 – 3 – 4
– 5 (slightly re-loosen afterwards) – 6.
11. ssemble the axle bracket (1) on the outside
of the angle brackets using two M8×20 hex bolts
(3) and M8 hex lock nuts (2). The ends of the axle
bracket must point as shown in the figure. Tighten
and then slightly re-loosen the bolts and nuts.
12. ssemble the wheels to the axle bracket us-
ing two shoulder bolts (2) and two M10 hex lock
nuts (1). Tighten.
13. Fasten ten spring tines (4) to the square holes
in the bottom of the tine shield. Use a M8×25 car-
riage bolt (5), Ø8 big flat washer (3), Ø8 lock
washer (2) and M8 hex nut (1) for each spring
tine. Tighten.
NOTE: Spring tines must seat between dimples.
14. ssemble the spring align wires (1) through
the front and rear rows of spring tines, passing
the wires in between the hitch mount arms and
the tine shield. Bend the ends of the wires to se-
cure them.
© by WilTec Wildanger Technik GmbH Item 51705 Page 7
http://www.WilTec.de
http://www.aoyue.eu 01 2021-1
http://www.teichtip.de

15. ssemble a hitch arm mount bracket to the
axle bracket using two M8×25 carriage bolts (3),
Ø8 lock washers (6) and M8 hex nuts (5). Do not
tighten yet.
16. Insert the lift handle (2) down through the tine
shield. ttach it to the hitch arm mount bracket
just assembled using an M8×20 hex bolt (4) and
an M8 hex lock nut (7). Tighten.
17. Position the hitch arm mount bracket so that
there is side tension on the lift handle (2) with grip
(1) when it is locked in the up position. Tighten
the nuts.
Operation and adjustments
Regular removal of thatch is critical to maintenance of a healthy lawn. Thatch is a layer of stems, clip-
pings, runners, roots and leaves that have not decayed. Excessive thatch prevents air, water and fertil-
izer from reaching the roots. The scarifier effectively dislodges excessive thatch from your lawn. Read
these instructions to help avoid improper adjustment and operation.
Proper adjustment of the tine shield and spring tines is important for effective performance. Refer to
the following steps for the proper adjustment before operating the scarifier.
1. Move the towing vehicle onto a level surface,
such as a driveway or garage floor and attach the
tine scarifier to the vehicle hitch.
2. To adjust the spring tine shield, lower the scari-
fier into operating position using the lift handle (2).
Loosen the two hex nuts and carriage bolts (1)
which fasten the rear of the hitch mount arm to
the hitch arm mount brackets. djust the tin shield
until it is level and both the front and rear spring
tines are in contact with the ground. Re-tighten
the hex nuts.
© by WilTec Wildanger Technik GmbH Item 51705 Page 8
http://www.WilTec.de
http://www.aoyue.eu 01 2021-1
http://www.teichtip.de

3. If the scarifier appears to be “jumping” during
use, then extra weight should be added to the tine
shield. In most conditions extra weight will be
needed. Concrete patio blocks are recommended
for weight because of their low profile; however
any type of weight is suitable if it can be tied
down to the shield. Secure weight by using suit-
able binding material such as rubber tie down
straps or wire, fastening to the holes in the shield
flange.
Maintenance
1. Before each use check all nuts and bolts for tightness.
2. Lubricate wheels as needed.
3. If rust appears on the shield or spring tines, sand lightly and coat with enamel paint.
4. lways store in a dry area, and coat exposed metal with light oil when not in use.
© by WilTec Wildanger Technik GmbH Item 51705 Page 9
http://www.WilTec.de
http://www.aoyue.eu 01 2021-1
http://www.teichtip.de

Explosion view and parts list
№ Name Qty. № Name Qty.
1Hitch arm mount bracket 3 13 Hex lock nut M10 2
2Hitch bracket 2 14 Big flat washer Ø8 10
3Spring tine 10 15 Hex bolt M8×20 15
4Spring alignment wire 2 16 Lock washer Ø8 14
5Wheel 2 17 Hex nut M8 14
6Tine shield (40”) 1 18 Hex lock nut M8 19
7Hitch mount arm 2 19 Carriage bolt M8×25 14
8Lift plat 1 20 Handle grip 1
9xle bracket 1 21 Hex bolt M8×50 2
10 Lift handle 1 22 Hex bolt M8×30 2
11 Shoulder bolt 2 23 Hitch pin M8 (flat head) 1
12 ngle bracket 4 24 Hair cotter pin Ø3 1
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
© by WilTec Wildanger Technik GmbH Item 51705 Page 10
http://www.WilTec.de
http://www.aoyue.eu 01 2021-1
http://www.teichtip.de
