Winmate ARM-11 HMI Series User manual

WinMate Communication INC .
ARM-11 HMI Series Panel PC
Samsung-6410 Series SBC, Low Power, High
Performance Design with AR -11 Series
Platform, TFT LCD, RS232, RS422/485 and 10/100
base-T Ethernet.
User Guide Version 1.0

ARM-11 HMI Series PPC User’s Manual
2
Revision History
Version Date Note
1.0 2010.09.22 First Version
Package List
Before using this Digital Signage Evaluation Kit, please make sure that all the items listed below
are present in your package
1. Box (Packaging)
2. 1 x AR -11 Series H I Panel PC Unit
3. 1 x BSP, SDK, I G and User’s manual CD
4. 1 x AR -11 H I User’s anual
5. 1 x Screw Type Power Supply 100-240 Vac / 12Vdc, 15W
ake sure that all of the items listed above are present. Do not attempt to apply power to the
system if there is damage to any of its components.

ARM-11 HMI Series PPC User’s Manual
3
FCC Statement
This device complies with part 15 FCC rules. Operation is subject to the following two
conditions ：
•This device may not cause harmful interference.
•This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a class "a" digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference at
him own expense.
Copyright Notice
ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or
transmitted in any form or by any means, electronic or mechanical, for any purpose, without
the prior written permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.

ARM-11 HMI Series PPC User’s Manual
4
Disclaimer
We reserve the right to make changes, without notice, to any product, including circuits
and/or software described or contained in this manual in order to improve design and/or
performance. We assume no responsibility or liability for the use of the described product(s),
conveys no license or title under any patent, copyright, or masks work rights to these
products, and makes no representations or warranties that these products are free from
patent, copyright, or mask work right infringement, unless otherwise specified. Applications
that are described in this manual are for illustration purposes only. We Communication Inc.
makes no representation or warranty that such application will be suitable for the specified
use without further testing or modification.
arranty
We warrant that each of its products will be free from material and workmanship defects
for a period of one year from the invoice date. If the customer discovers a defect, We will, at
its option, repair or replace the defective product at no charge to the customer, provided it
is returned during the warranty period of one year, with transportation charges prepaid.
The returned product must be properly packaged in it’s original packaging to obtain
warranty service.
If the serial number and the product shipping data differ by over 30 days, the in-warranty
service will be made according to the shipping date. In the serial numbers the third and
fourth two digits give the year of manufacture, and the fifth digit means the month (e. g.,
with A for October, B for November and C for December).
For example, the serial number 1W07Axxxxxxxx means October of year 2007.

ARM-11 HMI Series PPC User’s Manual
5
Customer Service
We provide service guide for any problem as follow steps ： First, contact with your
distributor, sales representative, or our customer service center for technical support if you
need additional assistance. You may have the following information ready before you call ：
•Product serial number
•Peripheral attachments
•Software (OS, version, application software, etc.)
•Description of complete problem
•The exact wording of any error messages
In addition, free technical support is available from our engineers every business day. We
are always ready to give advice on application requirements or specific information on the
installation and operation of any of our products. Please do not hesitate to call or e-mail us.
Safety Precautions
•Warning!
Always completely disconnect the power cord from your chassis whenever you
work with the hardware. Do not make connections while the power is on. Sensitive
electronic components can be damaged by sudden power surges. Only experienced
electronics personnel should open the Player chassis.
•Caution!
Always ground yourself to remove any static charge before touching the CPU card.
odern electronic devices are very sensitive to static electric charges. As a safety
precaution, use a grounding wrist strap at all times. Place all electronic components
in a static-dissipative surface or static-shielded bag when they are not in the chassis.

ARM-11 HMI Series PPC User’s Manual
6
Safety and arranty
1. Please disconnect this equipment from any AC outlet before cleaning. Do not use liquid
or spray detergents for cleaning. Use a damp cloth.
2. For pluggable equipment, the power outlet must be installed near the equipment and
must be easily accessible.
3. Keep this equipment away from humidity.
4. Put this equipment on a reliable surface during installation. Dropping it or letting it fall
could cause damage.
5. The openings on the enclosure are for air convection. Protect the equipment from
overheating. DO NOT COVER THE OPENINGS.
6. ake sure the voltage of the power source is correct before connecting the equipment
to the power outlet.
7. All cautions and warnings on the equipment should be noted.
8. If the equipment is not used for a long time, disconnect it from the power source to
avoid damage by transient over-voltage.
9. Never pour any liquid into an opening. This could cause fire or electrical shock.
10. Never open the equipment. For safety reasons, only qualified service personnel should
open the equipment.
11. If any of the following situations arises, get the equipment checked by service personnel:
A. Liquid has penetrated into the equipment.
B. The equipment has been exposed to moisture.
C. The equipment does not work well, or you cannot get it to work according to
the user’s manual.
D. The equipment has been dropped and damaged.
E. The equipment has obvious signs of breakage.
12. Do not leave this equipment in an uncontrolled environment where the storage
temperature is below -20° C (-4°F) or above 60° C (140° F). It may damage the
equipment.

ARM-11 HMI Series PPC User’s Manual
7
Table of Contents
1 GENERAL INFOR ATION.................................................................................................8
1.1 Introduction .................................................................................................8
1.2 Features .......................................................................................................9
1.3 Dimension and Overview............................................................................10
1.4 Specifications .............................................................................................12
1.5 System Block ..............................................................................................13
1.6 AR -11 Series LCD Selection Table.............................................................13
2 Getting Started..............................................................................................................14
2.1 Input / Output Devices ...............................................................................14
2.2 Starting the Panel PC ................................................................................14
3 Installation User Gui e for SMDK6410 (WinCE6.0 R3)..............................................15
3.1 Overview...................................................................................................15
3.2 Copying BSP an Setting up Visual Stu io 2005 ......................................16
3.3 Creating a New OS Design ........................................................................18
3.4 Buil ing OS Image – Without KITL...........................................................23
4 H I series Panel PC ounting Guide ...........................................................................35
4.1 VESA Mount ..............................................................................................35
4.2 Panel Mount (Clip Design):.......................................................................37
5 Services/ Updates.........................................................................................................39
5.1 H I Official website ...................................................................................39
5.2 Company information.................................................................................39

ARM-11 HMI Series PPC User’s Manual
8
1 GENERAL INFORMATION
1.1 Introduction
The AR -11 H I Series PPC model is compact platform without redundant functions,
which have been designed for small-sized operator interface applications. They have 5.7” VGA
LED backlight and 7" WVGA LCD display which is a cost effective choice for a limited budget. Its
RISC kernel, the Samsung 6410 processor consumes minimum power without sacrificing
performance. The AR -11 H I Series PPC has 10/100Base-T Ethernet port and WIFI 802.11
b/g(Optional) offering solid communication ability and comes bundled with a Windows CE and
Linux 2.6.2 that supports Thin-Client solutions. The built-in Windows CE6.0 and Linux 2.6.2 OS
platform lets AR -11 H I Series PPC become an Open H I solution for system integration.
AR -11 H I Series PPC

ARM-11 HMI Series PPC User’s Manual
9
1. Features
(1) Samsung-6410 Processor on board
(2) 5.7” VGA(640 x 480) LCD(LED backlight) , 7" WVGA(800 x 480) LCD(CCFL backlight)
(3) Super slim and compact design with metal housing
(4) Fanless cooling system
(5) E A4/IP65 compliant front panel
(6) Built-in NAND flash memory
(7) One Standard SD card slot
(8) RS232, RS422/485 and Ethernet for external communication.
It can even browse web sites using the internal browser, which is useful for displaying
diagnostic data or even remote control panels through a web interface.
Depending on which AR -11 H I Series PPC features you choose to access, it can be
used for anything from a user interface panel to the main controller for your automation
equipment.

ARM-11 HMI Series PPC User’s Manual
10
1.3 Dimension and Overview
1.3.1 Dimension
R05SA 0-IPD1HM

ARM-11 HMI Series PPC User’s Manual
11
W07SA 0-IPA HM
1.3.2 Overview

ARM-11 HMI Series PPC User’s Manual
12
1.4 Specifications
System Specification
Processor Onboard Samsung 6410 Processor (533 Hz)
System emory On boar DDR-266 128MB
NAND Flash On board 256 B
Expansion Slot Standard SD Card Slot
Ethernet DAVICO D 9000B
Audio AC97 Audio(Wolfson W 9714L)
USB 2 x USB type-A 1.1(Host)
Serial Ports 1 x RS232, 1 x RS 422 / 485
Power Receptor Screw Type Power Terminal Block
OS support Windows CE 6.0 / Linux 2.6.24
Power Consumption 5.85W
LCD Display
Size / Type 5.7” TFT 7” TFT
Resolutions 640 x 480 800 x 480
Luminance (cd/m2) 400 (typ.) 350 (typ.)
Contrast Ratio 300:1 (typ.) 300:1 (typ.)
Viewing Angle (H/V°) -70~70(H);-50~50(V) -60~60(H);-60~60(V)
ax Colors 262.144(6bits/color) 262.144(6bits/color)
Mechanical Specification
Cooling System Fanless design
ounting Panel ount
Dimension 188 x 148 x 57.8 mm (W x H x D) 218 x 164 x 58 mm (W x H x D)
Environmental Specification
Operation Temperature 0~50°C
Operating Humidity 30%~90% ( non-condensing, RH )
Order Options
Mechanical IP65 (5mm bezel)
Touch 4 Wires Resistive(Optional)
OS Win ows CE6.0 / Linux 2.6.24

ARM-11 HMI Series PPC User’s Manual
13
1.5 System Block
1.6 ARM-11 Series LCD Selection Table
The H I series Panel PCs support form 5.7-inch and 7-inch TFT Panel w/ touch screen
function, please refer to the below:
2.
3.
4.
Size Model Name Resolution Display Color
5.7” R05SAEU-IPD1H 640 x 480 262k
7” W07SAEU-IPA2H 800 x 480 262k

ARM-11 HMI Series PPC User’s Manual
14
Getting Started
.1 Input / Output Devices
The following figure shows the I/O arrangement of the W07SAEU-IPA1H . The rear side of the
chassis contains most of the connectors as below.
. Starting the Panel PC
1. Connect the power to 12V DC power supply to 3 pins Terminal block (Phoenix Type)
2. Press the power on switch to start the Panel PC.
3. We recommend a Start Kit for your initial development purchase, and the bare devices for
later production quantities.

ARM-11 HMI Series PPC User’s Manual
15
3Installation User Guide for SMDK6410 (WinCE6.0 R3)
3.1 Overview
This Installation anual guides you to install the Samsung S DK6410 Windows Embedded CE
6.0 BSP. The manual explains the following topics:
• Copyin BSP and Settin up Platform Builder
• Creatin a New OS Desi n
• Buildin OS Ima e – Without KITL
• Runnin NK.nb0 Ima e
• Fusin WinCE Ima e on NAND Flash via USB with DNW tools
The detail information of each topic is explained in the following chapters. and about
connectivity
to platform builder, please read “S DK6410_Platform_builder_Connectivity.doc” document.
This help you how to download and connect your device with OS image to platform builder.

ARM-11 HMI Series PPC User’s Manual
16
3.2 Copying BSP an Setting up Visual Stu io 2005
In this chapter, you can understand how to copy the Samsung S DK6410 Windows Embedded
CE 6.0
BSP and setup the Platform Builder.
(1) To start the BSP installation, Extract zip-archived file into $(WINCEROOT)\PLATFOR . See
the
picture describes folder structure. In archives, PLATFOR folder has two sub folders. One is
S DK6410, and another one is CO ON/SRC/SOC/S3C6410_SEC_V1.
For example, copy extracted S DK6410_WinCE60_XX_XX\PLATFOR BSP folder to
X:\WINCE600\PLATFOR directory on your host PC. ake sure that catalog file and batch file
in X:\WINCE600\PLATFOR \S DK6410 directory has the same name as that of the BSP, i.e.
S DK6410.pbcxml and S DK6410.bat.
Note: About PQOAL & SOC Folder Structure, Please refer to porting guide, If you don’t know the
difference between PQOAL and non-PQOAL structure, read first porting guide.
S DK6410 BSP Files

ARM-11 HMI Series PPC User’s Manual
17
(2) To start S DK6410 Windows Embedded CE 6.0 BSP Porting, on your host PC click Start,
point to
All Programs, point to icrosoft Visual Studio 2005 and then click on icrosoft Visual Studio
2005. The following window appears on your screen.
Visual Studio 2005 Window

ARM-11 HMI Series PPC User’s Manual
18
3.3 Creating a New OS Design
In this chapter, you can understand how to create a new OS Design using the Visual Studio 2005.
(1) On the File menu in the Visual Studio 2005 window, click New /Project as shown in below
Creating New Project

ARM-11 HMI Series PPC User’s Manual
19
(2) The following window appears on your screen. Click OK button to continue.
New Project for WinCE6.0
(3) The Windows Embedded CE 6.0 OS Design Wizard appears on your screen as below figure.
Click NEXT button to continue .
Windows Embedded CE 6.0 OS Design Wizard

ARM-11 HMI Series PPC User’s Manual
20
(4) The Board Support Packages (BSPs) window appears on your screen. Select S DK6410:
AR V4I and then click Next button.
Windows Embedded CE 6.0 OS Design Wizard – Step 1
(5) The Design Template Wizard window appears on your screen. Please select PDA Device from
Available design templates list and then click Next button.
Windows Embedded CE 6.0 OS Design Wizard – Step 2
