Winners Only DP521S User manual

ALR-17452-SHNWU MADE IN MALAYSIAPage 1 of 2
DP521S / DB521S
DP521S-01/
DB521S-01
DP521S-02/
DB521S-02
DP521S-02/
DB521S-02
DP521S-03/
DB521S-03
DP521S-03/
DB521S-03
DP521S-05/
DB521S-05
DP521S-05/
DB521S-05
Thank you for purchasing this quality product.Be sure to check all packaging material
carefully for small parts that may have come loose inside the carton during shipment.
COMPONENT LIST: HARDWARE LIST:
Flat Washer
Allen Key
Lock Washer
1 pce
JCBC Bolt(Short)
JCBC Bolt(Long)
2 pcs
8 pcs
10 pcs
10 pcs
PART NO FIGURE DESCRIPTION QTY
1
2
3
4
5
Hardware Bag 1 pce
1 pce
1 pce
2 pcs
PART NO FIGURE DESCRIPTION QTY
This product will take 15-20
minutes to assemble.
Reminders
1.Use only the hardware supplied.
2.Once the product is assemble,level and tighten all the bolts.
3.Do not over-tighten bolts.
4.This item may require periodic tightening
NOTE:
1.Two or two people are needed for assembly
2 please keep all hardware parts out of the reach of children.
WINNERS ONLY
Wood Seat
Chair Back
Front Legs

ALR-17452-SHNWU
DP521S / DB521S
MADE IN MALAYSIA
Page 2 of 2
CARE INSTRUCTION
~ Be sure to use the same type of polish consistenly.
Your furniture will appear cloudy or streaky if oil
based or wax based polishes are interchanged.
~ Spray your furniture surface evenly. Wipe in a
circular motion with a soft clean cloth.
3.1- Turn the chair to standing position.
3.2-
ASSEMBLY :
STEP 3
STEP 2
STEP 1
Assembly is now Completed.
WINNERS ONLY
Check it's balance and tighten all screw and bolts to complete the assembly.
Flat Washer
Lock Washer
JCBC Bolt (Long)
Allen Key
(Fig.2)
Allen Key
JCBC Bolt (Long)
Lock Washer
Flat Washer
Allen Key
JCBC Bolt (Short)
Lock Washer
Flat Washer
(Fig.1.1)
(Fig.1.2)
Step1: Attached wood seat to the chair back using the provided hardware as shown on Fig.1.1 and Fig.1.2.
Step2: Attached front legs (Left and Right) to wood seat using the provided hardware as shown in Fig.2.
