Winners Only AC101E User manual

OLS-16032-SNNWU1 MADE IN MALAYSIA
Page 1 of 2
AC101E-01
AC101E-07
AC101E-07
AC101E-13
AC101E-13
AC101E-22
AC101E-22
AC101E
4 pcs
14” CHAIR SIDE TABLE
PART NO
Legs
Thank you for purchasing this quality product.Be sure to check all packaging material
carefully for small parts that may have come loose inside the carton during shipment.
COMPONENT LIST: HARDWARE LIST:
Flat Washer
Allen Key
Lock Washer
1 pce
JCBC Bolt (Long)
JCBC Bolt (Short)
8 pcs
4 pcs
12 pcs
12 pcs
FIGURE DESCRIPTION QTY
Table Top 1 pce
1 pce
1
2
3
4
5
Hardware Bag 1 pce
Fixed Shelf
PART NO FIGURE DESCRIPTION QTY
This product will take 15-20
minutes to assemble.
Reminders
1.Use only the hardware supplied.
2.Once the product is assemble,level and tighten all the bolts.
3.Do not over-tighten bolts.
4.This item may require periodic tightening
NOTE:
1.Two or two people are needed for assembly
2 please keep all hardware parts out of the reach of children.
WINNERS ONLY

OLS-16032-SNNWU1 MADE IN MALAYSIA
Page 2 of 2
CARE INSTRUCTION
~ Be sure to use the same type of polish consistenly.
Your furniture will appear cloudy or streaky if oil
based or wax based polishes are interchanged.
~ Spray your furniture surface evenly. Wipe in a
circular motion with a soft clean cloth.
Allen Key
Allen Key
JCBC Bolt
(Short)
JCBC Bolt
(Long)
Lock Washer
Lock Washer
Flat Washer
Flat Washer
3.1- Turn table to uprigtht position.
3.2-Once lamp table is fully balance fully tighten all bolts.
STEP 2
Assembly is now Completed.
Fig.1
Fig.3
Fig.2
14” CHAIR SIDE TABLE
AC101E
WINNERS ONLY
1.1-Turn the Table Top upside down on a protective surface such as carpet or other soft material.
1.2-insert the three legs into the corner of the apron by insert the Flat Washer(4),Lock Washer(3) and JCBC Bolt(1) into pre-drilled
holes on the corner block and tighten it using Allen key(5).
1.3-Insert the Fixed Shelf into the leg assembly, then install the fourth leg using Flat Washer(4), Lock Washer(3)
and JCBC Bolt(1) into the pre-drilled holes on the corner block and tighten using Allen key(5).
1.4-
ASSEMBLY :
STEP 1
Insert the Flat Washer(4), Lock Washer(3) and JCBC Bolt(2) into pre-drilled holes on the corner block of Fixed Shelf and
tighten using Allen key(5).
