Withings Move ECG User manual

EN-1
Move ECG
v1.0 | August, 2019
Move ECG
Installation and Operating Instructions

EN-2
Move ECG
v1.0 | August, 2019
Table of contents
Minimum requirements.....................................................................4
Internet access......................................................................................................................................4
Smartphone or device ......................................................................................................................4
OS version...............................................................................................................................................4
Health Mate app version..................................................................................................................4
Description ............................................................................................ 5
Overview..................................................................................................................................................5
Box Contents.........................................................................................................................................5
Setting up my watch .........................................................................6
Installing the Health Mate app ......................................................................................................6
Installing my watch.............................................................................................................................6
Setting the time ................................................................................................................................ 26
Wearing my watch........................................................................................................................... 26
Tracking my activity.........................................................................27
Overview............................................................................................................................................... 27
Checking my progress................................................................................................................... 28
Changing my activity goal........................................................................................................... 28
Tracking my swimming sessions...............................................................................................30
Tracking my sleep..............................................................................31
Overview................................................................................................................................................ 31
Retrieving my sleep data............................................................................................................... 31
Setting an alarm................................................................................................................................ 32
Multi-sport / Connected GPS.......................................................35
Getting more active .........................................................................37
Competing with my friends......................................................................................................... 37
Competing with myself ................................................................................................................. 38
Syncing your data.............................................................................39
Dissociating your watch................................................................40
Cleaning and maintenance........................................................... 42

EN-3
Move ECG
v1.0 | August, 2019
Cleaning my watch.......................................................................................................................... 42
Replacing the battery..................................................................................................................... 42
Replacing the wristband............................................................................................................... 42
Calibrating the hands .....................................................................................................................43
Updating the firmware version.................................................................................................. 47
User guide copyright...................................................................... 49
Legal notice........................................................................................ 49
Safety instructions........................................................................... 50
Use and storage................................................................................................................................50
Water resistance ...............................................................................................................................50
Service and maintenance .............................................................................................................50
Specifications ......................................................................................51
Document release overview .........................................................53
Warranty.............................................................................................. 54
Regulatory statements ...................................................................55

EN-4
Move ECG
v1.0 | August, 2019
Important Notice
By using your Move ECG, you expressly agree to the Withings Services Terms
and Conditions available on our website.
Minimum requirements
Internet access
Access to the Internet is required to:
• Download the Health Mate app,
• Set up your Move ECG,
• Upgrade the firmware.
For more details, refer to “Specifications” on page51.
Smartphone or device
An iOS device or an Android device (with operational Bluetooth Low Energy and
Wi-Fi or 3G/4G) is required to:
• Set up your Move ECG,
• Retrieve data from your Move ECG,
• Interact with your Move ECG,
• Interact with people.
For more details, refer to ““Specifications” on page51.
OS version
You need iOS 10 (or higher) or Android 6 (or higher) on your device to install and
run the Health Mate App.
For any device, BLE (Bluetooth Low Energy) compatibility is required to install
your Move ECG.
Health Mate app version
You always need the latest version of the Health Mate app to have all the latest
features available.

EN-5
Move ECG
v1.0 | August, 2019
Description
Overview
Move ECG is the world’s first analog watch to record an electrocardiogram (ECG)
on demand and detect atrial fibrillation (AFib) via the Health Mate app. AFib is a
serious form of irregular heart rhythm, known to be a major risk factor for stroke.
To record an ECG, simply press the button once and touch both sides of the
stainless steel ring on the top of the watch.
Move ECG is also packed with the advanced activity and sleep tracking features
users have come to expect from Withings, including the ability to track calories
burned,pace, and distance. But also, for the first time in a Withings activity watch,
stairs climbed are tracked via an altimeter. Move ECG also oers connected GPS
to map your route, plus automatic recognition of daily activities including walking,
running, and swimming, as well as cycling.
Move ECG is water resistant up to 50 meters, features a battery life of up to 12
months, and syncs automatically with the Health Mate app (iOS & Android).
Box Contents
• Move ECG
• CR2430 Battery (already inserted)
• Quick Installation Guide
Refer to “Replacing the battery” on page42 for more information on battery
replacement.

EN-6
Move ECG
v1.0 | August, 2019
Setting up my watch
Installing the Health Mate app
If the Health Mate app is not already installed on your device, perform the
following steps:
1. Type go.withings.com in your device’s web browser.
2. Tap Download on the App Store or on the Play Store.
3. Tap Get.
The installation process starts.
Installing my watch
I’m new to Health Mate
If you don’t already have a Health Mate account, you have to create one in order
to set up and use your Move ECG.
If you already have an account, refer to “I already have a Health Mate account” on
page16.
To install Move ECG, perform the following steps:
1. Open the Health Mate app.
2. Tap Sign up.

EN-7
Move ECG
v1.0 | August, 2019
3. Tap Watches.
4. Tap Move ECG.
5. Tap Install.

EN-8
Move ECG
v1.0 | August, 2019
6. Press the button on the side of Move ECG and tap Next.
7. Make sure that your Move ECG is placed close enough to your mobile device.
8. Tap Next.

EN-9
Move ECG
v1.0 | August, 2019
9. Tap Pair.
10. Tap Pair again.

EN-10
Move ECG
v1.0 | August, 2019
11. Tap Next.
12. Enter your email address, password, and then confirm your password. Tap
Next.
13. Enter your first name, surname (last name) and birthday. Tap Next.
14. Select your gender and enter your current height and weight. Tap Create.
15. Please wait a few seconds during the initialization of the watch hands and the
update of your Move ECG.
16. Please wait a few seconds during the automatic time configuration.
17. Tap Yes if the hands are well initialized or No if they are not correctly
positioned.
If you select No, you will be prompted to set the hands.

EN-11
Move ECG
v1.0 | August, 2019
18. Slide your finger on the wheel displayed in the app until the minute hand
reaches noon. Tap Next.
19. Slide your finger on the wheel displayed in the app until the hour hand reaches
noon. Tap Next.

EN-12
Move ECG
v1.0 | August, 2019
20.Slide your finger on the wheel displayed in the app until the activity hand
reaches the 0% mark. Tap Next.
21. Tap Done.
Your Move ECG is now properly calibrated and the hands move to their correct
position to display the current time.
22.Tap Done.

EN-13
Move ECG
v1.0 | August, 2019
23.Tap Next twice to set your Activity Goals.
24.Tap and slide the daily step goal up or down to select the goal you want.
25.Tap OK.
26.Tap Next.

EN-14
Move ECG
v1.0 | August, 2019
27. Tap Next to discover the Workout with GPS assist feature.
28.Tap Next four times to watch the tutorial.

EN-15
Move ECG
v1.0 | August, 2019
29. Tap Next to discover the ECG recording.
30. Tap Next three times to watch the tutorial.

EN-16
Move ECG
v1.0 | August, 2019
I already have a Health Mate account
If you already have a Health Mate account, you can get started on the installation
process. To do so, perform the following steps:
1. Open the Health Mate app.
2. Tap Devices.
3. Tap +.
4. Tap Watches.

EN-17
Move ECG
v1.0 | August, 2019
5. Tap Move ECG.
6. Tap Install.

EN-18
Move ECG
v1.0 | August, 2019
7. Press the button on the side of Move ECG and tap Next.
8. Make sure that your Move ECG is placed close enough to your mobile device.
9. Tap Next.

EN-19
Move ECG
v1.0 | August, 2019
10. Tap Pair.
11. Tap Pair again.

EN-20
Move ECG
v1.0 | August, 2019
12. Tap Next.
13. Select the user who will be using the Move ECG.
14. Please wait a few seconds during the initialization of the watch hands and the
update of your Move ECG.
15. Please wait a few seconds during the automatic time configuration.
16. Tap Ye s if the hands are well initialized or No if they are not correctly
positioned.
If you select No, you will be prompted to set the hands.
