WITTUR Beamer 2 Series User manual

Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 1
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
Reprinting, translation or reproduction in any form -
whether in part or in full - requires the prior written
permission of WITTUR Holding GmbH.
Wittur Holding GmbH reserves the right to make
changes in the information and pictures contained in
these operating instructions without prior notice.
WITTUR Holding GmbH
Rohrbachstraße 26-30 • D-85259 Wiedenzhausen, Germany
Tel. [phone] • Fax [phone]
http://www.wittur.com, E-mail: [email protected]
58 00 000 0361 ba_wsg19_e17 28.01.2013
English
Gearless Lift Machines
WSG-19.1
WSG-19.2
WSG-19.4
beamer 2

Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 2
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
These operating instructions are
applicable to lift machines:
WSG - 19. ....
with twin shoe brake
WITTUR Electric Drives GmbH reserves the right to
correct or change the contents of this manual and
these product details without prior notice. We
expressly reserve the right to make technical changes
which improve the lift machines or their safety stan-
dards without prior notice. No liability can be accept-
ed for damage, injuries or expense arising therefrom.
We cannot guarantee the correctness and complete-
ness of the details.
Offenburger Str. 3
D-01189 Dresden
Germany
Tel. [phone]
Fax [phone]
[email protected]
www.wittur-edrives.de

Gearless Lift Machine
WSG-19
Operating Instructions
1. General safety instructions.....................................................................................................................4
2. Product description...................................................................................................................................5
3. Nameplate...................................................................................................................................................6
4. Scope of supply .........................................................................................................................................6
5. Transport and storage ..............................................................................................................................7
6. Installation..................................................................................................................................................8
7. Electrical connection ................................................................................................................................9
7.1. General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
7.2. Motor connection / Winding protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
7.3. Speed/Position measuring system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
7.3.1. Measuring system E N 1313 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
7.3.2. Measuring system ERN 1387 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
7.4. Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
8. Commissioning...........................................................................................................................................15
9. Operation and maintenance...................................................................................................................16
9.1. General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
9.2. Maintenance intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
9.3. Lubricating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
9.4. Fan filter mats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
9.5. Replacing the traction sheave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
9.6. Emergency evacuation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
9.7. Testing the brake system to EN 81-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
9.8. Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
9.9. Replacing the measuring system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
9.10. Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
10. Type code ..................................................................................................................................................25
11. Technical data..........................................................................................................................................26
12. Dimension drawing.................................................................................................................................28
13. Accessories ...............................................................................................................................................29
13.1. onnecting cable for measuring systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
13.2. Rope clamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
13.3. Return motion device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
13.4. able set for motor and brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
13.5. Option anti-condensation heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
14. Spare parts ...............................................................................................................................................32
Annex
EC Declaration of Conformity
EC type-examination certificate
Type-examination certificate (acc. EN 81-1 + A3)
Seite/page 3
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
Contents

1. General safety instructions
Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 4
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
Explanation of symbols used in these instructions
means that death or serious injury to persons or
serious damage to property will occur unless
the appropriate precautions are taken.
means that death or serious injury to persons or
serious damage to property may occur unless
the appropriate precautions are taken.
means that injuries to persons or damage to
property may occur unless the appropriate pre-
cautions are taken.
points out important information and operat-
ing instructions. If these are not observed,
damage, hazards or faults may result.
Intended use
The WSG-29 lift machines have been manufactured in compli-
ance with the latest state of the art and recognised safety reg-
ulations. They may only be used for the purpose for which
they are intended, and with all safety devices in proper work-
ing order.
The WSG-29 may only be used for driving lifts. "Intended use"
also requires that the instructions contained in the documen-
tation supplied with the machine and the commissioning
instructions be observed, and that the specified inspection and
maintenance work be carried out.
Warranty and liability
Our " onditions of Sale and Delivery" shall apply for all our
supplies and services.
We do not accept any warranty or liability claims for personal
injury or property damage resulting from one or more of the
following causes:
• Improper use of the lift machine
• Improper installation, commissioning, operation or mainte-
nance
• Operation of the WSG-29 with defective and/or inoperative
safety or protective devices
• Non-compliance with the instructions contained in the
operating instructions or other documentation supplied
• Unauthorised construction modifications to the WSG-29
• Insufficient monitoring of parts subject to wear
• Repairs carried out improperly
• Emergencies caused by external forces or force majeure
Safety precautions
Only qualified personnel are authorised to perform any plan-
ning, installation or maintenance work, and this must be done
in accordance with the relevant instructions.
The personnel must be trained for the job and must be familiar
with the installation, assembly, commissioning and operation
of the product.
The WSG-29 lift machines are intended for use in an enclosed,
lockable machine room to which only qualified personnel and
personnel authorised by the customer have access..
Danger
Warning
Caution
• WSG-29 lift machines are not ready-to-use products; they
may only be operated after they have been installed in lift
systems and their safe operation has been ensured by taking
the appropriate measures.
• heck the proper functioning of the motor and the brake
after installing the machine.
• Repairs may only be carried out by the manufacturer or an
authorised repair agency. Unauthorised opening and tam-
pering may result in injuries to persons and property.
• The machines are not designed for direct connection to the
three-phase system but are to be operated via an electronic
frequency inverter. Direct connection to the mains may
destroy the motor.
• High surface temperatures may occur on the external parts
of the machine. Therefore, no temperature-sensitive parts
may be in contact with these parts or attached to them.
Protection against accidental contact should be provided, if
required.
• The E type-examined fail-safe brakes provided are designed
only for a limited number of emergency braking operations.
They must not be used as working brakes.
• If the motor is not energised, no torque is produced. This
may result in uncontrolled acceleration of the lift, if the
brakes are released. Therefore, the motor winding should be
short-circuited to produce a speed-dependent braking
torque while the motor is not supplied with current. (Use
the main contacts for short-circuiting as rated motor cur-
rent may be flowing.) The motor must never be short-
circuited while it is energised.
• High voltages are applied at the terminal connections during
the operation of synchronous motors.
Note

Gearless Lift Machine
WSG-19
Operating Instructions
The compact flat-type gearless WSG-19 lift machines are
designed for gearless traction sheave lifts with machine
room. They are intended for operation with a 2:1 or 1:1
suspension and are distinguished by their high efficiency,
extremely low noise and excellent operating characteris-
tics.
The WSG-19 gearless lift machines are designed solely for
use with electronic frequency converters.
The synchronous motor has been designed for various
rated torques, based on a number of overall widths. It
can also be supplied for several rated speeds, which can
then be further adapted to meet individual customer
requirements.
The machine comprises a grey cast iron frame (11), the
three-phase motor, traction sheave (4) and shoe brake
(1).
The shaft is very sturdily designed to accommodate the
high loads acting on the traction sheave. At the D end, it
is supported in a robust self-aligning roller bearing (6).
Six threaded holes (6) are provided on the front end
periphery, permitting a mechanical return motion device
to be fitted in case of an emergency.
The stable D end shield (5) is of spheroidal cast iron. At
the ND end the shaft is also carried in a self-aligning
roller bearing (15) which is preloaded by means of a cup
spring. The bearing is incorporated in ND end shield (13)
of grey cast iron. The two bearings are sealed with inter-
nal and external shaft sealing rings.
A separately driven low-noise fan (10) is mounted on top
of the ND end shield. The terminal box is arranged on
the right-hand side (viewed facing the shaft).
The mounting flange on the ND end shield incorporates
the speed/position measuring system (16).
The brake is connected to a A - system via a control unit
which is included in the scope of supply. This over-exci-
tation rectifier can be installed, for example, in the con-
trol cabinet. The terminals for the brake monitoring con-
tacts, the motor terminals and the temperature detector
monitoring contacts are accommodated in the terminal
box.
The brake can be released manually, if required, by oper-
ating the manual release lever. The braking torque can
be adapted to the specific needs, if necessary, by adjust-
ing the two brake springs.
No brake lining wear occurs, since in modern drive equip-
ment such brakes are under friction only in an emer-
gency. Normally they are only applied when the machine
is at rest.
Seite/page 5
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
2. Product description
Änderungen vorbehalten! Subject to changes without notice!
1
2
3
4
5
6
7
8
9
10 11 12
13
14
15
16
1 Shoe brake
2 Rope slip-off guard
3,14 Hydraulic-type lubricating
nipple
4 Traction sheave
5 D end shield
6 Self-aligning roller bearing
7 heese head bolt
8 Brake hub
9 Key
10 Fan
11 Machine frame
12 Rotor
13 ND end shield
15 Self-aligning roller bearing
16 Measuring system
DEN DE

Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 6
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
4. Scope of supply
•Lift machine WSG-19 according to order specification
•Brake control unit KUS4.51
•Operating instructions
•Delivery note
Options:
•Return motion device
•Rope clamp
•onnecting cable for measuring system
•able set for motor and brake
•UL- SA approved
3. Nameplate
Type code of
lift machine
Rated current Rated speed
Rated torque
Serial no.
E type-examination
certificate
Rated frequency Weight
The nameplate of the lift machine is on the motor frame.

Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 7
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
5. Transport and storage
The lift machines leave the factory in perfect condition
after being tested.
Make a visual check for any external damage immediate-
ly upon their arrival on site. If any damage incurred in
transit is found, make a notice of claim in the presence
of the carrier. If necessary, do not put these machines
into operation.
Transport
Observe the relevant safety regulations and
take the centre of gravity into account
when handling the lift machines.
The motor has to be hung up at the 4 carrying rings that
way, that the load angle ais always £45° between the
ropes.
The eyebolts are designed for the specified machine
weight, i.e. it is not permitted to suspend additional
loads.
Storage
Store the motors only in closed, dry, dust-free, well-ven-
tilated and vibration-free rooms (storage temperature:
-20° to 60° ). Do not store lift machines in the open air.
Bright parts are not sufficiently preserved to withstand
extended periods of exposure.
Avoid excessive storage periods (recommendation: max.
one year).
After prolonged storage (>3months), rotate the motor in
both directions at a low speed (< 20min-1) to allow the
grease to distribute evenly in the bearings.
Measure the insulation resistance before initial operation
of the machine. If the value has dropped below < 1kW
per volt of rated voltage, the winding needs to be dried
(insulation meter voltage: 1,000V D ).
Unpacking
Dispose of the packaging material in an
environmentally friendly manner or reuse
it.
Any special transport aids or shipping
braces are left with the customer.
Warning
Note
This can be done, for instance, with heated air, in a dry-
ing oven, or by applying a d.c.voltage to the motor con-
nections.
Make sure that the voltage selected does not exceed the
values shown in the figure
"Drying the winding" . Let the
temperature rise to about 70 – 80° and maintain it for
several hours.
u
v
w
A
I≈45% IN
-
U
Drying the winding

Gearless Lift Machine
WSG-19
Operating Instructions
Be sure to check the base frame or founda-
tion loads by calculation before installing
the lift machine.
The lift machine may only be installed if the relevant
safety precautions have been met. The machines can be
used in lift systems with a machine room.
The machines may only be installed, electrically connect-
ed and put into operation by trained specialist personnel.
The system-specific conditions and the requirements of
the system manufacturer or plant constructor must be
met.
over the machine and especially the
brakes when doing any machining or dust-
producing work in the shaft or machine
room.
The measuring system is only accessible
from the rear side. Therefore, leave enough
space between the wall and the rear side of
the machine or ensure that the machine
can be moved away from the wall.
Degree of protection
The lift motors are designed with degree of protection
IP23 M / IP125, i.e. M : during operation
S: at rest.
The traction sheaves are provided with holes for the
cooling air circuit and with external fins for stiffening.
Therefore, take special care.
When making the electrical installation, make sure the
cable connections to the terminal boxes are sealed tight-
ly.
Ambient conditions
The following ambient conditions must be ensured on
site:
Altitude: max. 1,000m a.s.l.
Ambient temperature: - 5... 40°
Max. rel. humidity: 85% at 20° (no moisture con-
densation)
Install the machine so that ventilation is not obstructed,
i.e. sufficient heat dissipation by convection and radia-
tion must be ensured.
The torque and power values indicated in the Technical
Data apply to the above ambient temperatures and alti-
tudes. In case of a deviating altitude and/or ambient
temperature, the reduction factors k shown in the dia-
gram below must be used.
Mpermiss. = k * MN
Ppermiss. = k * PN
Fastening the machine
The rope force can be applied to the lift
machine in any direction.
The machine or base frame should be mount-
ed on rubber pads for vibration damping.
The machine is fastened using 8 bolts for:
WSG-19: M 24 - 8.8; tightening torque: 680Nm or
WSU-19: M 24 - 12.9; tightening torque: 1,150Nm.
The permissible uneveness of the mounting surface is
0.1mm. The mounting surface must be sufficiently dis-
tortion-resistant and stable to accommodate the forces
occurring in the system.
After completing the adjusting work or after a
breakdown, tighten all the fastening bolts of
the machine, using the specified torque.
No welding work may be performed on the
lift machine, nor is it permissible to use the
machine as a mass point for welding work.
This could destroy the bearings and the
magnets.
Lift machines are generally equipped with rope slip-off
guards. After putting the ropes in place, adjust them so
that the distance between the rope and the rope slip-off
guard does not exceed 1.5mm.
If the machine is not installed in the machine room "on top"
of the shaft, the installation of the rope slip-off guards may
have to be modified. In this case, optional rope slip-off
guards are available that can be fitted to the foot area of the
machine.
Seite/page 8
Datum/date 28.01.2013
Stand/version 0.17
6. Installation
Änderungen vorbehalten! Subject to changes without notice!
Danger
Warning
Note
Note
Danger
Warning

Gearless Lift Machine
WSG-19
Operating Instructions
7.1. General
The electrical connection may only be made
by a qualified electrician.
Before starting any work on the machines,
ensure that the lift machine or system is
properly isolated.
Before making any connections check that
•the connecting cables are suitable for their specific
application and for the relevant voltages and currents.
•the sufficiently dimensioned connecting cables and
torsion, strain and shear relief as well as anti-kink pro-
tection are provided
•the protective conductor (Protection lass I only) is
connected to the earthing terminal
•there are no foreign bodies, dirt or moisture in the ter-
minal boxes
•cable entries not in use and the terminal box itself are
tightly sealed to prevent the ingress of dust or splash
water.
The insulation system of the motors is
designed such that they can be connected
to a converter with a maximum d.c. link
voltage Ulink max up to max. 700 Volt.
Note: Ulink max is the maximum value of the
d.c. link voltage which is only transient and
approximately equivalent to the inception
voltage of the braking chopper or of the
energy recovery unit.
The maximum permissible rate of voltage
rise (dU/dt) at the motor terminals may be
max. 4 kV/ms.
The overvoltage at the motor terminals
must not exceed 1.56 kV. It may be neces-
sary to use motor current filters or reactors
to achieve these values.
7.2. Motor connection / Winding protection
The electrical connection of the motor and the winding
monitoring devices is made in the terminal box on top of
the machine.
The motor cable must be shielded. Ensure that the cable
shield contacts the frame over a large area at both ends.
The motor phases U1, V1 and W1 must be connected cor-
rectly to the corresponding phases of the converter; they
must not be interchanged.
The thermocouples installed in the winding
such as PT thermistor detectors and ther-
mostatic switches must be evaluated in the
control system or frequency converter to
protect the motor from overtemperature.
The separately driven fan must be properly
connected and operated. It can be switched
in dependence of temperature by the ther-
mal switch S4, if required (relay must be
used).
Seite/page 9
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
7. Electrical connection
Danger
Note
Cable cross-section required:
The currents specified under the machine
data for the series WSG-19 refer to duty
type S3-40%. This must be taken into
account when selecting the cable cross-
section required. The continuous Ir.m.s.
value required for the selected cable is
approximated from:
Ir.m.s. (cable) »IN (motor, S3-40%) / 1.58
The following table gives the recommended values for
the current-carrying capacity of PV cables at a maxi-
mum ambient temperature of 40 ° :
Note
Caution
able cross-
section
Permissible max.
current
(r.m.s. value)
Permissible max.
motor current IN
(S3 - 40%)
2.5 mm222.6A 35.7 A
4.0 mm229.6A 46.7 A
6.0 mm238.3A 60.5 A
10.0 mm253.1A 83.9 A
16.0 mm271.3A 112.6 A
25.0 mm294.0A 148.5 A
35.0 mm2117.4A 185.6 A
50.0 mm2146.2A 230.9 A

Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 10
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
Motor connection diagram
terminal strip for brake
connection
WAGO 261;
able cross-section:
...2.5mm2;
Stripping length required:
8...9mm
running capacitor
for fan
motor terminals
(M10)
terminal strip for fan and
winding protection con-
nections
WAGO 260;
able cross-section:
...1.5mm2;
Stripping length required:
8...9mm
M
3~
U1 V1 W1
T1
T3
T2
T4
S1
S3
S2
S4
(Z)
L
N
υυυ
υυυ
υ
Terminal box
screwed cable entry
1 x tapped hole M 50
1 x tapped hole M 40
PTC-thermistor T
3 x STM-150.ES... (150°C)
- integrated in the motor windings
- for motor protection Thermostatic switch S1
3 x S01.130.05.... (130°C)
(250 V AC / 2,5 A / cos ϕ = 1)
- integrated in the motor windings
- pre-warning overtemperature
M
Fan F
D2E 133-AM47-A5
230 V / 50/60 Hz / 0,84/0,88 A
Thermostatic switch S4
1 x S02.60.05.... (60°C)
(250 V AC / 2,5 A / cos ϕ = 1)
- integrated in the motor windings
- f.e. for fan controlling
PE
M10
Motor terminals
M10 (max. tightening
torque: 10 Nm)
M 40
M 50
PE connection (M10)

7.3. Speed/Position measuring system
The basic version of the lift machines is equipped with a
E N 1313 sine-cosine encoder from Heidenhain GmbH.
The encoder is connected via a 17-pole signal plug con-
nector which is fitted to the measuring system housing.
Alternatively, the machines can be equipped with the
encoder types ERN1387 also from Heidenhain GmbH.
These measuring systems are connected via a 17-pole
signal coupling fitted to the motor.
We can also provide other measuring systems on request.
We recommend the use of an appropriate
cable set to connect the measuring system
to the converter system. able sets can be
supplied as accessories.
The measuring system of the WSG-19 lift
machines is matched to the associated con-
verter. Do not change the adjustment as
this may make it impossible to use the
motor.
On the measuring system housing there is a
label showing the "offset angle" deter-
mined at the factory.
Note: This value depends on the converter.
Warning
Note
Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 11
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
Earthing
For safety reasons, it is very important that the motor be
properly and carefully earthed.
It is essential to use the earthing terminal
in the terminal box. In addition, an earth-
ing screw is provided on the motor frame
for the connection of a protective or earth-
ing conductor as specified in VDE 0100 and
VDE 0141 respectively.
When using shielded power cables, make sure the cable
shield metal contacts the motor frame over a large area.
This is achieved, for example, by special cable glands pro-
vided for shield contact.
Short-circuiting
The motor terminals of the synchronous lift
machines, type WSG, can be short-circuit-
ed, if required, to brake the lift machine
faster. This is, however, only permissible at
speeds less than the rated speed of the
respective motor.
Warning
Note
PTC-thermistor
The operating voltage of the PT thermis-
tors is not allowed to exceed 25VD .
Caution
3 x 4000
3 x 1330
3 x 550
3 x 250
-20°C
130°C
145°C
150°C
Widerstand / Resistance [Ω]
Temperatur
155°C
165°C

Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 12
Datum/date 28.01.2013
Stand/version 0.17
7.3.1. Measuring system ECN1313
Number of sine-cosine
periods per rotation: 2048
Operating voltage: 5V
Data interface: SSI or ENDAT
7.3.2. Measuring system ERN1387
Number of sine-cosine
periods per rotation: 2048
Operating voltage: 5 V
ommutation signals: 1 sine and cosine signal
with 1 period/rotation
(Z1 track)
Pin Signal
1UpSensor
11
5
6
7
13
9
8
10 16
17
15 14
12 2
1
4
3
4 0V Sensor
7Up
8 lock +
9 lock -
10 0V (Up)
11 inner shield
12 B +
13 B -
14 DATA +
15 A + Pin contacts of flanged con-
nector socket (exterior)
16 A -
17 DATA -
Pin Signal
1 A +
11
5
6
7
13
9
8
10 16
17
15 14
12 2
1
4
3
2 A -
3 R +
4 D -
5 +
6 -
70V (Up)
10 Up
11 B +
12 B -
13 R - Pin contacts of flanged con-
nector socket (exterior)
14 D +
15 0V Sensor
16 UpSensor
Änderungen vorbehalten! Subject to changes without notice!

TL / ms TS~ / ms TS= / ms
WSG-19.1 ~ 200 ~ 630 ~ 110
WSG-19.2 ~ 230 ~ 340 ~ 85
WSG-19.4 ~ 270 ~ 150 ~ 35
Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 13
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
7.4. Brake
The brake magnets are supplied with d.c. voltage by the
overexcitation rectifier, which is supplied separately. The
rectifier should be installed in the control cabinet of the
lift system.
The logic output of a PL (24 V control voltage) can be
used for controlling the brake.
If the control voltage [15..35 V(D )] is applied, the mag-
net is excited (provided the supply voltage is applied) and
the brake released.
The overexcitation time and the holding
voltage are factory-set for the specific
machine. Do not change the holding volt-
age and the overexcitation time as this can
destroy the brake magnet through over-
heating.
This digital PL input could be deactivated
if needed. Please contact the manufacturer
in this case.
To reduce the switch-off time, switching
can be effected from the d.c. side. (refer
„ ircuitry suggestion for brake control“ )
Repeated switching of the brake magnets
during the overexcitation period must be
avoided as this will result in overloading of
the brake control unit. Therefore, a mini-
mum brake operating time of approx. 1.5 –
2s should be maintained during an
inspection or commissioning drive.
The control, input and output cables have
to be installed separately.
Note on the use of d.c./a.c. side switching:
A.c. side switching is recommended for nor-
mal operation, since the lift machine is
then decelerated in a controlled manner to
zero speed and the switching noise of the
brake is negligible.
When braking in the event of a breakdown (emergency
stop) or during an inspection drive, the switching should
be performed from the d.c. side, since this ensures a
faster braking effect with the car being stopped earlier.
It is therefore recommended to use 2 separate contactors
for the brake control circuitry, one of which switching at
the d.c. side, the other one at the a.c. side.
Note
Note TLtime for releasing the brake
TS~ switching-off time - A.c. side switching
TS= switching-off tim - D.c. side switching
Note: The above switching times are guide values under
reference conditions.
Switching times WSG-19
A.c. side switching
•Low-noise switching of the brake
•No protective measures required for switching contact
•Slow application of the brake.
~
+
-
Br
D.c. side switching
•Noisy switching
•Burn-up protection for switching contact required
(e.g. varistor, free-wheeling diode)
•Fast application of the brake.
-
+
Br
~
Attention: schematic diagram!
Attention: schematic diagram!
Warning
Caution

Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 14
Datum/date 28.01.2013
Stand/version 0.17
Circuitry suggestion for brake control WSG-19
Schaltungsvorschlag Bremsenansteuerung
Circuitry suggestion for brake control WSG-19
S20 K460
S20 K460
230 V ±10%
0...60 Hz
8 PE
7 E
6 A
5 SPS -
4 SPS+
3 PE
2 N
1 L1
KUHSE KUS 4.51
K
Bremsmagnet
Brake magnet
A1
gleichstromseitiges Schalten der Bremse D.c. side switching and separate control
wechselstromseitiges Schalten der Bremse A.c. side switching and separate control
Bremsüberwachung
Brake monitoring
LL LL
LB LB
NC NO C NC NO C
RL
RL
RB RB
NC
NO
C
rechts r.h.s.
links l.h.s.
NC
NO
C
Lüften
release
Verschleiß
wear
Lüften release
Verschleiß
wear
Bremsmagnet
Brake magnet
Bremsüberwachung
Brake monitoring
links l.h.s.
rechts r.h.s.
zurSteuerung
to controlcabinet
{
E1
USPS
GND
USPS Wirkung /Effect
0...3 V Bremse abgefallen / brake dropped
15...35 V Bremse gelüftet / brake released
8 PE
7 E
6 A
5 SPS -
4 SPS+
3 PE
2 N
1 L1
KUHSE KUS 4.51
A1
rechts r.h.s.
links l.h.s.
E1
USPS
GND
USPS Wirkung /Effect
0...3 V Bremse abgefallen / brake dropped
15...35 V Bremse gelüftet / brake released
u
u
t
K
USPS
Bremsüberwachung / Brake monitoring
Bremsmagnet / Brake magnet
Bremsenansteuergerät
Brake control unit
- Separat im Schaltschrank
zu installieren!
- Must be installed in the
control cabinet!
Änderungen vorbehalten! Subject to changes without notice!

Dimension drawing brake control unit
8. Commissioning
Gearless Lift Machine
WSG-19
Operating Instructions
The following points should be checked or completed:
•Remove all securing, auxiliary and installation tools
from the danger area.
•heck that the lift machine is used for its intended
purpose and that the permissible ambient conditions
are met.
•heck that the lift machine is properly fastened.
•Are all bolts tightened with the specified torque and
secured?
•heck the motor connection, especially the earthing.
•heck that the temperature monitoring devices are
properly connected and functioning.
•heck that the brakes are properly connected and that
the brake monitoring switches are functioning properly.
•Is the measuring system properly connected?
•heck that the offset value indicated on the measuring
system agrees with the value set on the converter.
•heck the proper functioning of the brake; perform a
braking test using one partial brake.
•Is the rope slip-off guard properly tightened and adju-
sted?
An initial functions test of the motor and
the brake, together with the converter,
should be performed before the ropes are
put in place.
Seite/page 15
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
Note
SPS
+
Versorgung
-
Magnet
100
160
L1 N PE
A1
A2
E1
E2 PE
134567826
100
100
160
171
∅4,5
Monitoring Brake dropped released
Releasing N NO
Wear Brake lining new N N
Brake lining worn NO N
Switching state s of brake monitoring contacts
Monitoring the brakes
The switching state and wear of the brakes are monitored
by means of dust-proof microswitches with gold con-
tacts. The contacts are designed as n.c. contacts, i.e. the
contact is opened if the armature is attracted (brake
released). It is possible to change the micro switch con-
tacts into n.o. contacts, if required.
The switches must be evaluated separately
for each partial brake to ensure compliance
with the requirements of the type examina-
tion.
Danger

Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 16
Datum/date 28.01.2013
Stand/version 0.17
9. Operation and maintenance
9.1. General
The regulations concerning operation, maintenance and
inspection in accordance with the applicable safety regu-
lations in lift construction such as DINEN 81 "Safety rules
for the construction and installation of lifts", Part 1:
"Electric lifts" and other relevant regulations are to be
strictly observed.
The operator is responsible for the proper installation of
the motor with regard to safety requirements as well as
for its inspection and maintenance as specified in the
applicable regulations.
The proper maintenance of gearless lift
machines requires adequately trained spe-
cialist personnel and specialised devices and
tools.
Repairs other than those described in these
operating instructions are not to be carried
out by the lift fitter/maintenance techni-
cian for liability reasons.
Bolt/screw tightening torques
When doing any work on the machine or
replacing parts, make sure that the speci-
fied bolt/screw strength class and the tight-
ening torques are observed (see table).
Secure the bolts/screws with
"omnifit 100"
or a similar product against accidental
loosening.
9.2. Maintenance intervals
heck the thickness
of the brake linings
every six
months see section 9.7.
heck the remaining
play of the brake
every six
months see section 9.7.
heck the brake air
gap
every six
months see section 9.7.
heck the proper
functioning of the
brakes and the brake
monitoring switches
every six
months see section 9.7.
heck the bearing
noise every six months
Relubricate the bear-
ings see section 9.3.
heck the traction
sheave for wear every six months
heck the tightening
torques of the frame,
brake and traction
sheave fastening
bolts/screws
every six
months see section 9.1.
heck the traction
sheave for tight seat-
ing
every six
months see section 9.5.
heck the electrical
cables
every six
months see section 7.
heck the rope slip-
off guard every six months
heck the guards and
safety devices for
their condition and
safe functioning
every six months
lean the external
machine surfaces;
clean the fan filter
mats
as required see section 9.4.
Danger
Warning
dimension tightening torque [Nm]
strength class 8.8 10.9 12.9
M4 2,8 4,1 4,8
M5 5,5 8,1 9,5
M6 9,6 14 16
M8 23 34 40
M10 46 67 79
M12 79 115 135
M16 195 290 340
M20 395 560 660
M24 680 970 1150
Änderungen vorbehalten! Subject to changes without notice!

Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 17
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
9.3. Lubricating instructions
Relubricate the main bearing after about 7,000 hours of
operation, using a KP 2 N-30 to DIN 51 502 grease such
as Wälalit LZ2 or Klüberlub BE 41-542 (approx. 58g on
DE and approx. 16g on NDE).
Use a conventional grease gun and press the grease into
the hydraulic-type grease nipples to DIN71 412 AM 10x1.
The relubricating points are provided on the D and ND
end shields of the machine. The DE grease nipple is
located behind the traction sheave. Turn the traction
sheave until one vent hole coincides with the grease nip-
ple, and the nipple is thus accessible.
traction
sheave
grease
nipple
DE grease nippl
9.4. Fan filter mats
Remove the three screws from the protective screen.
Then remove the screen and filter to clean or replace the
filter mats.
Do this work only with the fan switched off
as the rotating fan wheel could be danger-
ous.
Caution
9.5. Replacing the traction sheave
The traction sheave can work loose if it is
not properly installed.
Disassembly
•Power off the system and safeguard against uninten-
tional reclosing.
•Secure the car and the counter-weight.
•Remove the rope slip-off guards and the rope guards, if
provided.
•Relieve the load on the traction sheave; remove the
ropes.
•Support the traction sheave by means of a hoisting
gear.
•Remove the 12 fastening bolts M16x65-12.9.
•Insert the M16x 70 jack bolts (accessories) into the two
threaded forcing holes and force off the traction sheave.
Assembly
•lean the traction sheave and the rotor flange.
•For better assembly heat up traction sheave.
•Slide the traction onto the rotor flange as far as possi-
ble.
•Insert the fastening bolts and tighten diagonally oppo-
site bolts. Use "omnifit 100" or a similar adhesive to
secure the bolts. Tighten them along the bolt hole circle
(MA=340 Nm) with a torque spanner.
•Replace the ropes and reinstall the rope slip-off guard.
Danger
Seilabsprung-
sicherung
rope slip-off
guard
Befestigungs-
schrauben
fastening bolts
Abdrück-
gewinde
forcing
threads

Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 18
Datum/date 28.01.2013
Stand/version 0.17
9.6. Emergency evacuation
The lift design engineer must always pro-
vide for an electric return motion control
or for a manual rewinder (please note EN
81-1 /12.5.2)
Should a failure occur with the car at rest, the car can be
moved with the drive connected to the mains or to an
uninterruptible power supply (UPS) or mechanically
under its own load with the emergency brakes temporar-
ily released.
These brakes are released electrically either from the
mains or using a UPS. They can, however, also be released
manually.
The manual releasing of the shoe brake can be performed
by using the release lever.
If the brakes are released with the motor deenergised,
the motor windings should be short-circuited. This pre-
vents the lift from accelerating in an
uncontrolled manner since the short-
circuiting produces a speed-dependent
braking torque.
A mechanical return motion device can
be fitted at the operator's own respon-
sibility if the lift needs to be moved
manually in case of a breakdown or if
the car is caught by a safety device.
The use of the return motion device is
shown in the drawing.
Bolt the bearing block to
a cross-beam at the rec-
ommended spacing. The
cross-beam is firmly con-
nected to the lift
machine. When fitting
the device, a switching
command "electrical sup-
ply disconnected" must be
activated.
The specific conditions resulting from
the different traction sheave types and
brake arrangements must be taken into
account in regard to the arrangement
of the return motion device.
Then screw the threaded bolt into an
appropriately positioned threaded hole
in the traction sheave using a spanner.
While releasing the brake magnets, either electrically or
using the brake lever plates, the slide block can be dis-
placed by turning the corresponding nuts. This turns the
traction sheave. The bolt can then be moved to a new
hole in the traction sheave, if required.
The lift must be braked when changing the
bolt.
Return motion device
Note
Danger
Änderungen vorbehalten! Subject to changes without notice!
Treibkranz
Empfehlung für
die Anbringung
der
Rückholeinrichtung
80
120
500 100
(links oder rechts)
Aufzugs-
maschine
Lüfthebel
für Bremse
25
24  (4x)
210
270
70
110
170
180
1000
30M
x1,5
8
4kt
SW24
20
M
30
Muttern (1)
SW36
Schub-
kasten
(2)
52
Æ70
Æ24
±
lift
machine
Recommendation
for mounting the
return motion
device
nut (1)
SW36
traction sheave release
lever
slide
block
(2)
(left or right)
Note

Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 19
Datum/date 28.01.2013
Stand/version 0.17
Änderungen vorbehalten! Subject to changes without notice!
9.7. Testing the brake system to EN 81-1
The brake system should be tested with the
car about halfway down the shaft. If any
motor short-circuit connections have been
made, these should be deactivated so that
the brake effect can be tested indepen-
dently.
Overload
The brake system should be tested by interrupting the
power supply to the motor and brake system with the car
moving downward at rated speed and 1.25 times the
rated load. The brake system must be capable of deceler-
ating the car.
Failure of a brake
If one brake fails, the brake system must still be capable
of decelerating the car sufficiently during its downward
travel at rated load and rated speed.
When simulating the failure of one brake, the other
brakes must be kept open separately, even if the safety
circuit is open. This should preferably be done using suit-
able electric circuitry, but can also be performed manual-
ly.
This state must not be maintained in the long term.
Observe the lift during this test. If it does
not decelerate, close the open brake circuit
immediately.
Separate operation of the individual brakes
There are several possible ways of operating the brakes
separately:
•The preferred method is separate electrical control of
the brakes. The individual brakes can be activated/deac-
tivated quickly by individual control buttons (The con-
nections for the two coils are accessible in the brake
magnet.).
•Block one brake arm in its open position by using a
suitable excentric lever. This lever makes it possible to
release the blocked brake arm immediately in the case
of an emergency.
Note
Note
Monitoring the brakes
heck the brake monitoring switches individually. No car
travel must be permitted if a micro switch signal is miss-
ing or a wrong signal operates.

Example:
Lift machine WSG-19.4
Rated motor torque MN= 2500 Nm
Braking torque of one half Mb= 1.25 x 2500 Nm (125%)
a = 165 - (3200 / 68) = 118mm
•Slacken locknut (30) and turn pull rod (14) until
dimension "a" of the compression spring corresponds
with the required braking torque MBof one side as
specified on the label. The label is on the brake lever
directly under the compression spring.
•Secure pull rod (14) with locknut (30).
Gearless Lift Machine
WSG-19
Operating Instructions
Seite/page 20
Datum/date 28.01.2013
Stand/version 0.17
9.8. Brake
Replacing the brake shoe
Replace the brake linings when they are
worn down to a thickness of less than 3-
4mm or no longer usable.
Before working on the brake secure the
counterweight and the car against any
uncontrolled movement. Disconnect the
motor and the lift system from the mains
supply. No torque may act on the traction
sheave.
•Slacken locknut (30) and screw out pull rod (14). au-
tion! The brake shoe lever will tilt outwards.
•Remove shaft circlip (6) from bolt (5). Remove the bolt
and take off the shoe.
•Slacken locknut (9) and unscrew bolt (10) through
some turns.
•Regrease the sleeve bearing bushes, insert new brake
shoe (4), install bolt (5) and the new shaft circlip (6).
•Tilt brake shoe lever (1) back and install spring (13),
spring plate (12) and pull rod (14).
•Adjust the brake torque. Secure the setting with lock-
nut (30).
•Adjust the remaining play of the magnet to
x=2.6+0.5/-0.8 mm and secure the setting.
•Bed-in the linings.
Adjusting the braking torque
The loaded spring length "a" is used to estimate the brak-
ing torque.
The total braking torque is Mbtotal = 2 x Mb
Mb: braking torque of one half of the twin brake
(recommended setting 125% of the rated motor
torque)
Distance “a” for the braking torque is calculated accor-
ding to the following formula:
a = 165 - (Mb/ 68)
a distance in mm
Mbbraking torque required for one half of
the brake in Nm
Danger
Note
14
a30
143 1500
130 2400
118 3200
Adjusting the brake torque
Änderungen vorbehalten! Subject to changes without notice!
