WLtoys L959-B User manual

CONTENTS OF THE BOX:
• 1 x L959-B RC car
• 1 x 2.4 GHz Remote control (4 x AA batteries not included)
• 1 x 7.4V 1800mAh Li-Po battery
• 1 x Charger
• 1 x Crossed spanner
• 1 x User manual
SPECIFICATIONS:
• 2.4 GHz 2-Wheel drive RC car
• Scale: 1:12
• Speed: 60+ km/h
• Motor: Brushless
• Control distance: 100 meters
• Li-Po battery: 7.4V 1800mAh
• Charge time: 150 minutes
• Operation time: 10 minutes
• Length: 348mm
• Width: 230mm
• Height: 115mm
• Wheelbase: 250mm
• Wheel span: 170mm
• Wheel diameter: 76mm
• Wheel width: 36mm
Specifications
Safety precautions
• Children should only use this model under the supervision of an adult
• Stand out of reach of moving parts of the copter
• The model and the transmitter must be switched off after use
• For people without experience, we recommend that you learn to fly with an experienced user during your first flights
• Always follow local laws and regulations! Contact your reseller when in doubt.
• This model is not suitable for children under 14 years and contains small parts
• Keep hands, face, hair and clothes away from blades.
• After using the copter ALWAYS disconnect the battery and remove it from the device
• For the remote control, we recommend AA batteries with a voltage of 1.5 to 1.2 volts
• Keep these instructions safe
• Read the manual carefully and completely
• Always fly in an open and safe environment where you will not cause any danger to others
• Before each flight, test the distance limit of the transmitter
L959-B (L202) 1:12 2WD Off-road buggy RC car
INSTRUCTION MANUAL
Copyright WLtoys.eu | DroneX BV

The user must return used batteries and rechargeable batteries.
It is forbidden to dispose of used batteries in the bins containing
household waste! Batteries / accumulators containing
hazardous substances are marked with the crossed out wheelie
bin. The symbol indicates that the product should be recycled.
The chemical symbols for the respective hazardous substances
are Cd (cadmium), Hg (mercury), Pb (lead). The used batteries
can be disposed for free of charge at collection points in your
community, stores or wherever batteries are sold. You are kindly
requested to conform to your legal obligations and contribute to
the protection of our environment.
Battery recycling recommendations
DO NOT DRIVE:
- Towards people or animals
- Towards large groups of people
- In limited visibility or dark conditions
- On an open road or towards cars or traffic
For the sensitive and rational conservation, protection and improvement of the quality of the environment, protection of human
health and the preservation of natural resources, the user must send an unusable product to relevant facilities created to this
purpose in accordance with the law.
The crossed out wheelie bin means that the product must be recycled (WARNING: do not throw it in your bin).
Li-po Battery instructions
Copyright WLtoys.eu | DroneX BV

- Keep the batteries out of reach of children
- Non-rechargeable batteries should not be recharged
- Unequally charged batteries or different battery types should
not be used together
- Use recommended batteries or similar
- After using the copter, remove the batteries if you will not use
it again for a long period of time
- The terminals must not be short-circuited
- This model is equipped with a rechargeable Li-po Battery. Li-
po batteries require special attention, follow the manual
- The batteries must be charged with the charger supplied by
WLtoys
- When charging the battery, always ensure that you do so on a
non-combustible surface
- Do not leave charging without supervision
- Always charge the battery to 100%
- Ensure that the battery wires are not in contact to avoid a
short-circuit
- The ignition wires of the battery must not be modified or
damaged
- Never damage the battery mechanically (this could cause an
explosion)
- The battery should not be placed near children (unless you
have an adult supervision)
- The technical design of the battery must not be changed
- Touching of damaged batteries can cause injury. If there is
contact with skin or eyes, seek medical attention immediately!
- Do not charge directly after the flight or when the battery is
warm
1. LED
2. Li-po Battery
Plug the charger into a wall socket and connect the battery to
the charger. This can only be done in one way: by firmly
connecting the charging cable. If the green light is on, the
battery is fully charged and can be disconnected. Then do not
forget to unplug the charger from the wall socket.
Green LED ON = charging battery
Green LED OFF = charged battery
Green LED flashing = damaged battery
Red LED ON = charger
Red LED OFF = damaged charger / not connected to a wall
socket
Input : 220V
Charging Current : 500mA
Full Voltage: 4.2 +/- 0.03V
Battery charging
Remote Control / Transmitter
Copyright WLtoys.eu | DroneX BV

1. Power switch
2. Power LED
3. Throttle trigger
4. Steering wheel
5. Throttle trim
6. Steering trim
7. Antenna
Insert the battery by sliding the cover down. Insert 4 x AA
batteries as indicated under the cover.
STEERING
The steering wheel serves to steer the RC car to the left or
the right.
How to drive
- To turn on the remote control press the power switch (1). The power LED will light up, indicating that the remote controller is
switched on.
- Acceleration and reverse can be controlled by the throttle trigger (3). Pull it backwards to accelerate forwards and push it
forwards to reverse.
- Steering left and right can be controlled by the steering wheel (4).
- If the car has a deviation to the left or right side you can use the steering trim (6) to adjust this deviation.
- If the car slowly drives off while not using the throttle you can use the throttle trim (5) to adjust this deviation.
Driving is really simple, but requires some practice. Connect to www.wltoys.eu to watch educational films.
Copyright WLtoys.eu | DroneX BV

THROTTLE
The trigger serves to accelerate forwards or backwards.
The first ride
1. For your first ride make sure to be with a person experienced in operating RC cars. We advise you to make your first ride in an
open environment away from walls and other objects to protect the RC car.
2. Find a location away from people and animals, with a smooth surface and without obstacles
3. Make sure that you do not drive towards moving vehicles or any traffic at all.
4. Place the car on the ground about 10 feet away from you. It is advised to place the car with the front facing away from you. This
will make it easier to control.
5. Switch on the car first and then switch on the remote control. A beeping sound will and light signal will indicate that the remote
is switched on. When the beeping sound stops the control is connected with the RC car.
6. Gently use the throttle trigger to make the car move. You can look if the car has any deviation. If so you can adjust the steering
using the steering trim. 
Adjustments
Spare parts
The RC car is robust and not very sensitive for crashes, but in case of extreme crashes some parts may break. All parts can be
ordered and easily assembled. Please contact your dealer or visit www.wltoys.eu for more information.
CAUTION
- Make sure you never lose the car out of sight when operating.
- Always use a fully charged battery.
- When finished driving, always switch off the car first then the remote control.
- Do not use the RC car when it has visible or mechanical damage.
- Always drive in an area without traffic.
- Never drive towards people or animals.
- Make sure to drive in a controlled and safe environment without obstacles and were no damage can be done.
1. If the car does not operate at all, either the transmitter or receiver is switched off, the batteries are not properly placed or the
batteries are not charged enough. Make sure that the transmitter and receiver are both switched on, the batteries are placed as
described in the manual and the batteries are fully charged in both the transmitter and receiver.
2. If the car does not respond properly, it could be that someone is interfering with the radio frequency that you are using or there
is not enough power in the transmitter or receiver batteries. Switch off the transmitter and receiver and switch them on again to
make a new connection and make sure the batteries in both the receiver and transmitter are fully charged.
3. If the control distance is not reaching the correct distance, the antenna on the transmitter is probably not fully extended or
tightened. Make sure the antenna is fully extended.

If the car has deviations regarding the throttle or steering, you can make adjustments by using the trim buttons on the remote. If
the car is accelerates automatically without using the remote, you can use the throttle trim buttons to adjust it. If the car has a
deviation to the left or right when driving, you can use the steering trim buttons on the remote to adjust it.
Note: The car is pre-adjusted in the factory, it is usually not necessary to adjust it when you receive the product.
Copyright WLtoys.eu | DroneX BV

Imported by: WLtoys.eu / DroneX BV
Bloemstraat 86HS 1016 LE Amsterdam | www.wltoys.eu |
[e-mail]
Our products comply with the standards and criteria of the
European Union and approved by the EC. For your safety, we
recommend that you read the entire manual before your first
flight.
Wltoys
Congratulations on your purchase of this product from wltoys.eu! Wltoys.eu offers its customers a high quality product. All our
products are carefully tested before shipment. If unfortunately a problem persists, contact your dealer or visit www.wltoys.eu. Your
dealer can also assist you in getting spare parts in case you need them. We hope you will enjoy your experience with our product.
You can contact us at any time on : www.wltoys.eu | [e-mail].
You can find instructional videos and buy spare parts on our website www.wltoys.eu.
For technical support contact your reseller.
Warranty
The use of this product is entirely at your own responsibility and at your own risk. Since we have no control beyond this manual on
when and how you use our product (both flying and maintenance), we are not responsible for any damages or costs incurred by
improper use.
This warranty covers manufacturing and material defects in the context of normal use. We take no responsibility for damage
caused indirectly.
• Damage caused by the failure to comply with security measures or instructions
WARNING:
Non-compliance with safety rules may cause damage, injury and / or dangerous situations.
• Extreme treatment which can not be contained in the usual standards
• Normal wear and tear of the device and parts
• The damage caused by the loss of control of the vehicle
• Electric defects due to voltage overload or lightning
The following are excluded from the warranty:
• The costs of transportation, shipping or insurance
• Overloading the vehicle or external influences
• Homemade modifications on the product
• The damage caused by the humidity
• The damage caused by the loss of the product
• After three flights the warranty of brushed engines is void
