WLtoys WL911 User manual

CONTENTS OF THE BOX:
• 1 x WL911 RC boat
• 1 x 2.4 GHz Remote control (4 x AA batteries not included)
• 1 x 7.4V 850mAh Li-Po Battery
• 1 x Charger
• 1 x Boat rack
• 1 x User manual
SPECIFICATIONS:
• Vehicle size (l*w*h) [mm] 350*88*70
• Transmitter battery 4*AA
• Boat battery 7.4V 850mAh
• Charging time [minutes] 60
• Operation time [minutes] 7-8
• Control distance [meters] 100
• Speed [km/h] 24+
• Frequency 2.4 GHz
• Motor 370
Battery recycling recommendations
For the sensitive and rational conservation, protection and improvement of the quality of the environment, protection of human
health and the preservation of natural resources, the user must send an unusable product to relevant facilities created to this
purpose in accordance with the law.
The crossed out wheelie bin means that the product must be recycled (WARNING: do not throw it in your bin).
INSTRUCTION MANUAL
WL911 FREEDOM RACING BOAT
Security precautions
DO NOT SAIL:
- Towards people or animals
- Towards large groups of people
- In limited visibility or dark conditions
- In high waves
- Towards other boats or traffic

The user must return used batteries and rechargeable batteries.
It is forbidden to dispose of used batteries in the bins containing
household waste! Batteries / accumulators containing
hazardous substances are marked with the crossed out wheelie
bin. The symbol indicates that the product should be recycled.
The chemical symbols for the respective hazardous substances
are Cd (cadmium), Hg (mercury), Pb (lead). The used batteries
can be disposed for free of charge at collection points in your
community, stores or wherever batteries are sold. You are kindly
requested to conform to your legal obligations and contribute to
the protection of our environment.
1. LED
2. Li-po Battery
Plug the charger into a wall socket and connect the battery to
the charger. This can only be done in one way: by firmly
connecting the charging cable. If the green light is on, the
battery is fully charged and can be disconnected. Then do not
forget to unplug the charger from the wall socket.
Green LED ON = charging battery
Green LED OFF = charged battery
Green LED flashing = damaged battery
Red LED ON = charger
Red LED OFF = damaged charger / not connected to a wall
socket
Input : 220V
Charging Current : 500mA
Full Voltage: 4.2 +/- 0.03V
- Keep the batteries out of reach of children
- Non-rechargeable batteries should not be recharged
- Unequally charged batteries or different battery types should not be used together
- Use recommended batteries or similar
- After using the product, remove the batteries if you will not use it again for a long period of time
- The terminals must not be short-circuited
- This model is equipped with a rechargeable Li-po Battery. Li-po batteries require special attention, follow the manual
- The batteries must be charged with the charger supplied by WLtoys
- When charging the battery, always ensure that you do so on a non-combustible surface
- Do not leave charging without supervision
- Always charge the battery to 100%
- Ensure that the battery wires are not in contact to avoid a short-circuit
- The ignition wires of the battery must not be modified or damaged
- Never damage the battery mechanically (this could cause an explosion)
Li-po Battery instructions
Battery charging
- The battery should not be placed near children (unless you have an adult supervision)
- The technical design of the battery must not be changed
- Touching of damaged batteries can cause injury. If there is contact with skin or eyes, seek medical attention immediately!
- Do not charge directly after the flight or when the battery is warm

1. Power switch
2. Power LED
3. Throttle trigger
4. Steering wheel
5. Throttle trim
6. Steering trim
7. Antenna
Insert the battery by sliding the cover down. Insert 4 x AA
batteries as indicated under the cover.
Remote control/ transmitter
- To turn on the remote control press the power switch (1). The power LED will light up, indicating that the remote controller is
switched on.
- Acceleration and reverse can be controlled by the throttle trigger (3). Pull it backwards to accelerate forwards and push it
forwards to reverse.
- Steering left and right can be controlled by the steering wheel (4).
- If the boat has a deviation to the left or right side you can use the steering trim (6) to adjust this deviation.
- If the boat slowly accelarates while not using the throttle you can use the throttle trim (5) to adjust this deviation.
First time sailing
1. For your first time sailing make sure to be with an experienced person in operating RC boats. We advise to make your first sail
in an open environment, away from any obstacles.
2. Find a location away from people and animals, with calm water and without obstacles.
3. Make sure that you do not sail toward any moving vehicles or any other water traffc.
4. Swith on the RC boat and place it in the water,about 10 feet away from you. It is advised to place the boat with facing away
from you. this will make it easier to control.
5. Switch on the remote control. A beeping sound will indicate that the remote is switched on. Be aware that the boat has a water
sensor and therefore will not move its blade until placed in water.
6. Gently use the throttle trigger to make the boat move. You can look if the boat has any deviation. If so, you can adjust the
steering using the steering trim.
How to use

STEERING
The steering is wheel is used to steer the RC boat to the
left or the right
THROTTLE
The trigger is used to move the boat forwards or backwards
FLIP-OVER SYSTEM
If the RC boat is turned upside down in the water the flip-
over system can be used to get it the right side up. The flip-
over system is enabled by pushing the throttle stick
backwards and forwards quickly.
Wltoys
CAUTION
- Make sure you never lose sight of the boat when operating.
- Always use fully charged batteries
- When you are done, always switch off the boat and then the remote
- Do not use the RC boat when it has visible or mechanical damage
- Always sail in an area without traffic
- Never sail towards people or animals
- Make sure to sail in a controlled and safe envirotment without obstacles and were no damage can be done
Troubleshooting
1. If the boat does not operate at all, either the transmitter or receiver is switched off, the batteries are not properly placed or the
batteries are not charged enough. Make sure that the transmitter and receiver are both switched on, the batteries are placed as
described in the manual and the batteries are fully charged in both the transmitter and receiver.
2. If the boat does not respond properly, it could be that someone is interfering with the radio frequency that you are using or there
is not enough power in the transmitter or receiver batteries. Switch off the transmitter and receiver and switch them on again to
make a new connection and make sure the batteries in both the receiver and transmitter are fully charged.
3. If the control distance is not reaching the correct distance, the antenna on the transmitter is probably not fully extended or
tightened. Make sure the antenna is fully extended.
Spare parts
This product is not sensitive to crashes, but in case of extreme drops it is possible that some parts may break. All parts can be
ordered and easily assembled. Please contact your dealer or visit www.wltoys.eu for more information.

Imported by: WLtoys.eu / DroneX BV
Bloemstraat 86HS 1016 LE Amsterdam | www.wltoys.eu |
info@wltoys.eu
Our products comply with the standards and criteria of the
European Union and approved by the EC. For your safety, we
recommend that you read the entire manual before your first
flight.
• The damage caused by the humidity
• The damage caused by the loss of the product
• After three flights the warranty of brushed engines is void
• Homemade modifications on the product
• The damage caused by the loss of control of the vehicle
• Electric defects due to voltage overload or lightning
• Normal wear and tear of the device and parts
• The costs of transportation, shipping or insurance
The following are excluded from the warranty:
• Damage caused by the failure to comply with security measures or instructions
• Extreme treatment which can not be contained in the usual standards
• Overloading the vehicle or external influences
This warranty covers manufacturing and material defects in the context of normal use. We take no responsibility for damage
caused indirectly.
Congratulations on your purchase of this product from wltoys.eu! Wltoys.eu offers its customers a high quality product. All our
products are carefully tested before shipment. If unfortunately a problem persists, contact your dealer or visit www.wltoys.eu. Your
dealer can also assist you in getting spare parts in case you need them. We hope you will enjoy your experience with our product.
You can contact us at any time on : www.wltoys.eu | support@wltoys.eu.
You can find instructional videos and buy spare parts on our website www.wltoys.eu.
For technical support contact your reseller.
WARNING:
Non-compliance with safety rules may cause damage, injury and / or dangerous situations.
Warranty
The use of this product is entirely at your own responsibility and at your own risk. Since we have no control beyond this manual on
when and how you use our product (both flying and maintenance), we are not responsible for any damages or costs incurred by
improper use.
