WMF KULT pro Power User manual

Entsafter
KULT pro Power
Operating Manual 10
en

10
Important safety information
▪ Appliances may be used by persons with limited physical,
sensory or mental capabilities and persons lacking expe-
rience and/or knowledge if they are supervised or have
received instructions on how to use the appliance safely
and if they have understood the resulting hazards.
▪ This appliance must not be used by children. The appli-
ance and its connecting cable must be kept out of the
reach of children.
▪ Children must not play with the appliance.
▪ The appliance must always be disconnected from the
mains by means of pulling out the mains plug when there
is no supervision present, if a fault occurs during opera-
tion and prior to any assembly, disassembly or cleaning
work.
▪ If the appliance’s connection cable is damaged, it must be
replaced by the manufacturer, his customer service repre-
sentative or a similarly qualified person to avoid hazards.
▪ You must not operate the appliance if the rotating
sieve (micro filter) and/or the protective cover is/are
damaged and/or if there are any visible cracks.
▪ Attention! The cutting blades on the base of the sieve are
sharp.
▪ Clean all parts immediately after use and remove any
food residue straight away.
▪ The appliance must be switched off and disconnected
from the mains before accessories or additional parts that
move during operation are replaced.
▪ Be careful of the sharp cutting blades when emptying the
container and when cleaning the appliance.
▪ This appliance is designed for use in households and
similar environments such as:
⋅in kitchens – for employees in shops, offices and other
commercial areas;
⋅on agricultural property;
Operating Manual

11
en
en
⋅by customers in hotels, motels and other residential
facilities;
⋅in bed-and-breakfast establishments.
The appliance is not intended for purely commercial
use.
Before use
The appliance may only be used for the intended purpose according to these opera-
ting instructions. Therefore, carefully read the instruction manual before operating
the appliance. It contains instructions for using, cleaning and caring for the appli-
ance. We accept no liability for any damages caused if this manual is not observed.
Keep the operating manual in a safe place and pass it on to any subsequent user
together with the appliance. Please also note the warranty information at the end.
The appliance is not intended for commercial use, but only for the preparation of
household quantities of food.
Observe the safety information when using the appliance.
Technical data
Rated voltage: 220 – 240 V~ 50-60 Hz
Power consumption: 900 W
Protection class: II
Safety instructions
▪ Only connect the appliance to earthed wall sockets that have been installed in
accordance with the regulations. The cable and plug must be dry.
▪ Do not pull or clamp the connecting cable over sharp edges. Do not leave it
dangling and protect it from heat and oil.
▪ Do not place the appliance on hot surfaces, such as on hotplates or similar areas,
and do not operate near naked flames.
▪ Never pull the mains plug out of the socket by the cable or with wet hands.
▪ Do not reach into the appliance when it is in operation.
▪ Also keep long hair, for example, away from the filling opening.
▪ Do not insert any objects such as spoons into the filling opening when the
appliance is in operation.
▪ Do not move the appliance during operation.
▪ The appliance is not suitable for finely chopping or grating nuts, chocolate or
similar ingredients.
▪ Stop using the appliance and/or pull out the mains plug immediately if:
⋅the appliance or mains cable is damaged.
⋅you suspect that there is a defect after the appliance has fallen or suffered a
similar incident.
⋅In such cases, arrange for the appliance to be repaired.
▪ We accept no liability for any damages caused as a result of misuse, incorrect
operation or improper repairs. Claims under warranty are also excluded in such
cases.
▪ The appliance is not intended for commercial use.

12
▪ The appliance is only designed for household use indoors.
▪ The maximum uninterrupted operating time at high speed is 2 minutes.
▪ You must allow the motor to cool down completely between two subsequent operating cycles.
Appliance assembly

13
en
1 Small stopper 8 Safety lock
2 Large stopper 9 Motor base
3Lid with filling opening 10 Non-slip feet
4 Micro filter 11 Drive axle
5 Pulp container 12 On/off switch with 2 speed levels
6Drip stop 13 Cable storage
7Juice spout
Starting up the appliance
Clean all the removable parts before using the appliance for the first time. Ensure
that you do not injure yourself on the sharp blade.
▪ Switch the on/off button to 0to switch the appliance off.
▪ Remove the required length of cable from the appliance cable storage.
▪ Place the pulp container (5) on the motor base (9).
▪ Place the micro filter (4) on the drive axle (11); you can hear the micro filter (4)
lock into place.
Each time before using the appliance, check if the micro filter (4) is damaged. If
you notice any cracks or other damage you must not use the appliance until the
micro filter (4) has been replaced.
▪ Place the lid with the filling opening (3) on the appliance.

14
Then fasten both safety locks (8) on the lid (3) by pushing them upwards until
you hear them lock into place.
▪ Place a catch container below the juice spout (7).
▪ Note: The appliance only functions when all the parts are completely and
correctly assembled and when the safety lock (8) on the lid has locked correctly
into place.
▪ Wash the required fruit/vegetables and chop them into small pieces so that they
fit in the filling opening (3) without getting stuck.
▪ Fold the juice spout (7) downwards so that the drip stop (6) is not active.
▪ Connect the mains plug to a mains socket and switch the on/off button to the
required position.
▪ Level 1: For soft fruit and vegetables such as watermelon, grapes,
tomatoes, cucumbers and raspberries.
▪ Level 2: For all types of fruit and vegetable.
▪ Insert the chopped pieces of fruit and vegetable into the filling opening (3).
Depending on the size of the food pieces use the small (1) or large (2) stopper.
▪ Press the stopper (1 or 2) downwards slowly and steadily in order to obtain as
much juice as possible.

15
en
If you press too hard this can hamper the quality of the juice. It can also cause
the micro filter (4) to stop and can damage it.
Attention: You must always keep your hands, spoons or other objects (e.g. hair,
items of clothing, brushes and cloths) away from the filling opening (3) when the
mains plug is in the mains socket.
▪ Once you have juiced all the pieces of fruit and vegetable and no more juice is
running into the juice jug, switch the appliance off and pull out the mains plug.
Wait until the micro filter (4) stops rotating.
▪ If the motor sticks, rotates slowly or stops during operation, switch the appliance
off immediately and pull the mains plug out of the mains socket.
Remove the micro filter and clean it immediately.
General information
▪ Pineapples, beetroot, celery, cucumbers, carrots, spinach, melons, tomatoes,
pomegranates, oranges and grapes are all suitable for juicing.
▪ Very hard and/or fibrous fruit and vegetables such as sugar cane are not suitable
for use in the juicer.
▪ Fruits with a thick consistency such as bananas, papayas, avocados, figs and
mangos are not suitable for use in the juicer. To process these fruits, use a food
processor or a blender.
▪ To obtain as much juice as possible, press the stopper (1 or 2) downwards slowly
and with very little pressure.
▪ Make sure that the pulp container (5) and the catch container do not overfill,
otherwise the appliance may not work properly.
Cleaning and care
After use turn the appliance off and pull out the mains plug. Wait until the micro
filter stops rotating.
Under no circumstances should you immerse the motor base (9) in water. Simply
wipe the outside with a damp cloth. Do not use any abrasive cleaning agents.
Remove the stopper (1 or 2) and then open the safety lock (8). Remove the lid with
the filling opening (3) and carefully remove the micro filter (4). Now remove the pulp
container (5).
Clean the lid (3), pulp container (5) and micro filter (4) with a brush in warm rinsing
water. Then rinse the parts thoroughly under running water.
Make sure you do not touch the blade and always hold the micro filter by its edge.

16
For UK use only
▪ This product is supplied with a 13 A plug conforming to BS 1363 fitted to the
mains lead. If the plug is unsuitable for your socket outlets or needs to be repla-
ced, please note the following. If the plug is a non-rewireable one, cut it from the
mains lead and immediately dispose of it. Never insert it into a socket outlet as
there is a very great risk of an electric shock.
▪ The replacement of the plug at the mains lead has to be done according to the
following instructions:
Important: The wires in this mains lead are coloured in accordance with the
following code:
blue Neutral
brown Live
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
⋅the wire which is coloured blue must be connected to the terminal which is
marked with the letter N or coloured black,
⋅the wire which is coloured brown must be connected to the terminal which
is marked with the letter L or coloured red.
Do not connect any wire to the terminal which is marked
with the letter E or by the earth symbol , or coloured green or green and yellow.
▪ If a 13 A (BS 1363) plug is used it must be fitted with a 13 A fuse conforming to
BS 1362 and be ASTA approved. If any other type of plug is used, the appliance
must be protected by a 10 A fuse either in the plug or adapter or at the distribu-
tion board.
If in doubt - consult a qualified electrician.
▪ Never use the plug without closing the fuse cover.

17
en
The appliance complies with the European directives 2006/95/EC,2004/108/EC and
2009/125/EC.
This product may not be disposed of with the normal household waste at the end of
its service life but must be delivered to a collecting point for recycling electrical and
electronic appliances. The materials are reusable in accordance with their identifica-
tion. You will make an important contribution to the protection of our environment
by recycling used appliances.
Please ask about the responsible disposal point at your community offices.
Subject to change

Kundendienst-Adresse:
wmf consumer electric GmbH
Standort Trepesch
Steinstraße 19
D-90419 Nürnberg
Germany
Tel.: [phone]
eMail: [email protected]
Hersteller:
wmf consumer electric GmbH
Messerschmittstraße 4
D-89343 Jettingen-Scheppach
Germany
www.wmf-ce.de
Änderungen vorbehalten - IB-16300011-01-1406
type: 0416300011
