Woodley Clinispin CT25 User manual

Clinispin™CT25
User Manual

TABLE OF CONTENTS
1. Introducon 1
2. Intended Use 1
3. Features 1
4. Technical Specificaon 1
5. Standard Accessories 2
6. Installaon 2
7. Standard Parts Lisng 3
8. Tube Holder & Adaptors 4
9. Rotor Installaon 6
10. Balancing the Rotor 6
11. Operaon 7
12. Safety Precauon 9
13. Troubleshoong 9
14. Warranty Statement 10
15. Product Disposal 11

1. INTRODUCTION
This manual provides important safety informaon for this centrifuge. It should be
kept near the centrifuge for quick & easy reference. This centrifuge is equipped
with maintenance free brushless DC motor drive and a safety feature of imbalance
detecon. The centrifuge can be used for mulple applicaon diagnoscs & will
work with variety of blood collecon tubes.
2. INTENDED USE
This centrifuge is designed for blood centrifugaon & other clinical applicaons
like PRP, medical praconers, pathological laboratories and hospitals.
3.FEATURES
ŸMaximum volume of 6 / 8 x 15 ml
ŸImbalance detector with auto cut-off for safe operaon
ŸBrushless DC motor for maintenance free performance
ŸLid lock safety-the lid opens automacally on run compleon
ŸDigital display with speed and me indicator
ŸRPM seng from 500-6500 RPM with a count of 100
ŸOne press changeover from RPM to RCF funconality
ŸDigital countdown Timer
ŸReducon adaptors for tubes with volume less than 10 ml
ŸEmergency lid release during power failure
ŸAutomac internal diagnosis & error display
ŸSilent operaon.
4. TECHNICAL SPECIFICATION
Opon to choose 6 or 8 tube rotor that comes with Autoclavable andTube holders.
6 Tube Rotor 8 Tube Rotor
Autoclavable &
Non-Autoclavable
Motor Type
Maximum Speed
Run me
Brushless Motor
6500
1 min to 30 mins & infinite mode
Maximum Volume 6x15 ml 8x15 ml
Speed Seng
Speed Accuracy
500 to 6500 RPM
± 100 rpm
1

5. STANDARD ACCESSORIES
1. Power adaptor: 100-230 VAC, 50/60 Hz (Input)
24 V 6.25A (Output)
2. 6 / 8 - slots rotor (Pre-installed)
3. T-Allen Key
4. Reducon Adaptors (set of 6 / 8)
5. Tube Holder & Rubber cap (6 / 8 nos.)
6. Product user manual & warranty card
6. INSTALLATION
Gently remove the upper packaging and take out the centrifuge by holding it from
the boom. When the centrifuge is used for the first me, ensure that all the
packaging and accessories are removed from the rotor chamber. The rotor is
pre-installed. Please make sure that rotor is firmly ghtened. Accessories and user
manual are kept inside the box with the centrifuge. Please keep all the packaging
in safe storage for at least 2 years for warranty purpose.
The following points are important for proper installaon:
Deceleraon Time
Size (L x W x H)
Weight
Input Voltage
Power Consumpon
260 x 244 x 203 mm
4 Kg (with rotor)
100 W
40 ± 2 seconds
120 W
Fix Angle
Acceleraon Time
25°C
43 ± 2 seconds
Maximum RCF 3684 x g 3873 x g
Must be used on Must have
2
24 V 4A 24 V 5A

6.1 Connecng Power Adaptor
1. Connect one side of power adaptor to rear side of centrifuge and other to
supply as shown in the figure below.
2. Rotate clockwise the adaptor nut to ghten the adaptor with the centrifuge.
Ensure the power switch is OFF while connecng the power adaptor.
3. The scker on the body & jack are indicang the posion of the rib on the jack.
While fing the adaptor to the unit please match the scker posion as
shown in the figure below & gently push it in.
4. If matched correctly the plug will go in easily without much force (do not try
to force the plug in if it is not matched properly). Once the plug is inserted into
posion, turn the loose upper ring clockwise to ghten & to secure the
fitment.
7. STANDARD PARTS LISTING
21
3
Match the
rib and slot
Match the
sticker
1. View Window
2. Groove to open the lid
3.Op eratio n a nd se ttin g
Buttons
4. Display
5. Emergency Lid Release
1. Power Switch
2. Adaptor Port
Rear View
Rubber Mount/
Base Mount
1
2
Front View
2
3
4
5
1
Bottom view
3

8. TUBE HOLDER & ADAPTORS
This centrifuge features centrifugaon for wide range of volumes from 1ml to
15ml with the combinaon of its adaptors. The accessories included are:
“Tube Holders” are always to be used with the rotor. All of the 6 / 8 “Tube Holders”
are mandatory to be placed in the rotor whether 2,3,4 or 6 / 8 tubes are used in
balanced condion. By combining the above two adaptors and rubber caps, three
different reduced adaptor can be designed to hold different types of blood
collecon tubes.
The different adaptor combinaons along with tube holder, for different blood
collecon tubes are illustrated on pages 7 and 8.
Note: 1) Maximum RCF value changes for different length of tubes. 2) “TubeHolders” are the
part of Rotor. All 6 / 8 “Tube Holders” are mandatory to place whether 2,3,4 or 6 / 8 tubes are
used in balanced condion.
8. TUBE HOLDER & ADAPTORS
Tube Holder Adaptor “RA-1” Adaptor “RA-2” Rubber Cap
Adaptor “RA-1”
Reverse of
Adaptor “RA-2” Combination A
Reverse of
Adaptor “RA-2”
Adaptor “RA-1”
COMBINATION A:
4

ADAPTOR COMBINATION & TUBE SIZES
1) NO ADAPTOR COMBINATION
The maximum diameter and proposed length for such
combinaon are:
Maximum Tube Diameter : 18 mm
Proposed Tube Length : 90 to 120 mm
2) COMBINATION “A” :
The maximum diameter and proposed length for such
combinaon are:
Maximum Tube diameter : 13 mm
Proposed Tube Length : 75 to 100 mm
3) COMBINATION “B” OR “C” :
The maximum diameter and proposed length for such
combinaon are:
Maximum Tube Diameter : 13 mm
Proposed Tube Length : 55 to 75 mm
Check both the criteria (Max. Diameter & Proposed Length) of
the blood collecon tubes and use the appropriate
adaptor-tube holder combinaon or only tube holder to
accommodate the tubes.
Reverse of
Adaptor “RA-2”
Adaptor “RA-1” Rubber Cap
Adaptor
“RA-1”
Reverse of
Adaptor “RA-2”
Rubber Cap
COMBINATION B:
COMBINATION C:
Adaptor “RA-1”
Adaptor “RA-2” Combination C
Adaptor “RA-2”
Adaptor “RA-1”
Combination B
TUBE HOLDER
A
B C
5

9. ROTOR INSTALLATION
The rotor of the centrifuge is pre-installed. In case of any spillage, remove the
rotor as shown in the above figure to clean the rotor and its chamber thoroughly.
9.1 REMOVING ROTOR
1. To remove rotor, first remove the Tube Holders.
2. Using T-Allen key, loosen the rotor nut by rotang rotor nut counter clockwise
and take the out rotor vercally
9.2 INSTALLING THE ROTOR
1. Make sure the rotor sha and the rotor mounng hole are clean. Load the
rotor vercally into the motor sha.
2. Put the T-Allen key in the rotor nut & turn clockwise to ghten the rotor.
3. Aer properly fastening the rotor, place the Tube Holders into the rotor.
10. BALANCING THE ROTOR
1. Always balance the rotor before centrifugaon. Symmetrical loading of tubes
in the rotor is necessary. Otherwise vibraon or imbalance can occur which
can cause serious damage to the centrifuge. The following are process of
symmetrical loading of centrifuge tubes inside the rotor.
2. The samples in the tubes should be of equal volume. To achieve a balanced
To Tighten
T - Allen Key
Rotor Nut
Rotor
Motor Shaft
To Loosen
6

condion of the 6"Tube Holders are mandatory to place inside the rotor
whether 2, 3, 4 or 6 / 8 tubes are being used.
3. If the tubes are not loaded symmetrically then the imbalance detector will
cut off the running centrifuge for safety reasons. This will stop the centrifuge
and Err 55 will be seen indicang the tubes are not loaded symmetrically. To
resume operaon, load the tubes symmetrically & restart the centrifuge.
4. Below are examples of incorrect method of loading tubes into the centrifuge
rotor
11. OPERATION
Aer properly installing the centrifuge, switch ON the centrifuge from the rear
side by pressing the power switch. The lid status will be seen in the display. If the lid
is open, the display will show “Lid” and if it is closed, the set RPM will be displayed.
Please ensure that the Tube Holders are inside the rotor.
11.1 SETTING THE SPEED AND TIME
1. To set the speed press the RPM/RCF buon
first, then with the use of increment&
decrement buons to set the desired speed.
2. The increase and decrease of speed will take
place in the steps of 10 RPM. The Display
window at the boom will show the values.
3. The minimum and maximum speed of the
centrifuge is 500 R P M and 6500 R P M
respecvely. Speed is to be read as value x 10 in
the display window.
Stop/Lid
RPM
RCF
Start Time
7

4. The speed can be changed during the operaon of the centrifuge, upon
changing the speed, the centrifuge will start running on the updated speed
for the remaining me le on the centrifuge cycle.
Note: Centrifuge will not run with the lid open.
5. To set me press the TIME buon first, then use INCREMENT and
DECREMENT buons, me can be set as desired me. The set me will be
displayed in the display window at the boom.
6. The me range in this centrifuge allows user to choose between 1 min & 30
minutes & infinite mode. Infinity mode displayed as ][.
7. The centrifuge incorporates a count down mer, aer each minute of
operaon the value of the mer is reduced by 1 minute.
11.2 SWITCHING TO RCF DISPLAY
Press the RPM/RCF to change the mode from RPM to RCF, while in RCF mode the
speed value is to be read as value x 10 in the display window. The maximum RCF of
the centrifuge is 3684 / 3873 xg. Press the RPM/RCF to see corresponding RCF
value.
11.3 START & STOP OPERATION
Once all the parameters like Speed & Time are set, press the “Start”buon to
START operaon.
1. Make sure that the lid is closed before starng the centrifuge.
2. The display will keep on blinking unl the set parameters are (RPM/RCF &
Time) reached. Once the set parameters are reached, the display will blink
mulple mes unl the set value is reached.
3. When centrifugaon is completed the lid of the centrifuge opens
automacally and the mer value will again start blinking.
Press the STOP/LID buon any me the centrifuge needs to be stopped.
Aer every run the lid opens by itself. In any other case, when the lid needs to be
opened push the STOP/LID buon to open the lid.
11.4 OPENING THE CENTRIFUGE LID IN CASE OF POWER FAILURE
Disconnect the centrifuge from the main
supply. Wait unl the rotor comes to a
standsll (thismay take some me).
Once the rotor has stopped, pull out the
emergency lid release as shownin the
figure. This will open the centrifuge lid.
Aer the centrifuge lid opens, push the
thread back in the hole with your hand
8

and fit the emergency release cap back in the hole.
11.5 IMBALANCE DETECTION
This centrifuge is equipped with an imbalance detecon safety feature. When the
rotor is not loaded symmetrically, imbalance detector gets acvated. This will cut
off the centrifugaon & error “Err55” will be shown on the display. To correct the
imbalance, open the centrifuge lid and correct the imbalance load using methods
described in the balancing the rotor secon (page no.10) of this manual. Aer
correctly loading the tubes into the rotor turn off the centrifuge & turn it back on.
12. SAFETY PRECAUTION
1. Never use the centrifuge in any manner not specified in the manual.
2. Never move the centrifuge while it’s operang.
3. The rotor must always be securely fastened. If the centrifuge makes an
unusual noise during the operaon, the rotor fit needs to be checked.
4. The rotor must be loaded symmetrically.
5. Do not use the centrifuge or rotor, if it is not installed correctly or it is
damaged.
6. Do not use the centrifuge or rotor if it shows any sign of external mechanical
or electrical damages.
7. The centrifuge must be used only for the specified applicaon. It must not be
operated in a hazardous or flammable environment & no hazardous or
flammable content should be centrifuged.
8. Do not fill tubes while they are in the rotor. Liquid spillage may harm the
device.
9. If liquid is spilled on the rotor or rotor chamber, the centrifuge must be
cleaned immediately.
10. “Tube Holders” are a part of the Rotor. They should be placed in the rotor
whether 2,3,4,6 or 8 tubes are being used.
13. TROUBLESHOOTING
This centrifuge has a self – diagnosc funcon. If a problem occurs, an
error/warning code will be displayed on the display screen and the operator can
determine the malfuncon with the warning code below.
ERROR PROBLEM SOLUTION
No display
No main power
connection.
Check power & properly plugin power
adaptor at both ends.
Power failure Check the main fuse of the lab.
Improper connection. Connect adaptor properly.
9

IMPORTANT NOTE:
1. If the centrifuge is working slow or hot due to overdraw current, restart the centrifuge and
check it again.
2. Do not use liquid with density higher than 1.2g/ml for full load operaon
14. WARRANTY STATEMENT
This product is warranted to be free from defects in material and workmanship for
a period of two (2) years from date of purchase. Your product will be duly repaired
upon prompt noficaon in compliance with the following condions:
This warranty is valid only if the product is used for its intended purpose and
within the guidelines specified in this instrucon manual. This warranty does not
cover damage caused by accident, neglect, misuse, improper service, natural
forces or other causes not arising from defects in original material or
workmanship. This warranty does not cover any incidental or consequenal
damages, commercial loss or any other damages from the use of this product.
The warranty is invalidated by any non-factory modificaon, which will
immediately terminate all liabilies on us for the products or damages caused by
its use. The buyer and its customer shall be responsible for the product or use of
products as well as any supervision required for safety. If requested the products
must be returned to the distributor in well packed and insured manner and all
shipping charges must be paid. Some states do not allow limitaon on the length
of implied warranes or the exclusion or limitaon of incidental or consequenal
Err 55 Rotor not loaded
symmetrically.
Load the rotor symmetrically
& restart the centrifuge.
Centrifuge lid
cannot be
opened
Rotor is still spinning. Wait for the rotor to come to a stop.
Power failure Press emergency lid release after
rotor stops
Centrifuge
shakes during
acceleration
& makes loud
running
noises while
running
Rotor is not loaded
symmetrically.
Load rotor symmetrically & restart
operation
Either a broken tube,
damage to the rotor or
motor is the cause for
run noise.
Replace broken tube. For damaged
rotor/motor contact a service
representative.
Rotor is damaged. Remove & change rotor
Err 52 Rotor is Stuck
Turn OFF the centrifuge, Check & fit the
rotor properly & turn ON the centrifuge
10

damages. This warranty gives you specific legal rights. This warranty is given
expressly in lieu of all other warranes, expressed or implied.
The purchaser agrees that there is no warranty of merchantability or of fitness for
any intended purpose and that there are no other remedies or warranes,
expressed or implied, which extend beyond the descripon on the face of the
agreement.
This warranty is only applicable to the original purchaser.Products received
without proper authorizaon will not be entertained. All items returned for
service should be sent postage prepaid in the original packaging or other suitable
carton, padded to avoid damage. We will not be responsible for damage incurred
by improper packaging.
All items returned for service should be set postage prepaid in the original
packaging or other suitable carton, added to avoid damage. This warranty is valid
only if the warranty is registered with the supplier within 30 days from the date of
purchase.
15. PRODUCT DISPOSAL
This symbol indicates that the product was
planned for use in a country complying with the
Waste Electrical and Electronic Equipment EU
Direcve, 2012/19/EU.
This symbol indicates that the product must not be disposed of with unsorted
municipal waste. It is the product user’s responsibility to correctly dispose of the
waste equipment by handing it over to anauthorized facility to decontaminate
waste equipment from biological, chemical and/or radiological hazards prior to
disposal.
11

Woodley Equipment Company Limited
UK Office:
Locomove House
Locomove Industrial Estate
Horwich
Lancashire
BL6 5UE
United Kingdom
Tel: [phone]
Fax: [phone]
[e-mail]
Woodley Equipment Company Inc
USA Office:
37-18 Northern Boulevard, STE 512
Long Island City, NY 11101
United States
Toll Free: 1-800-471-9200
Tel: [phone]
Fax: [phone]
[e-mail]
www.woodleyequipment.com
0141-25-M-R0
