Woodward DTSC-200A Instruction Manual

37941A
Operation
Release 1.0 - 0
Document ID: 37941, Revision A
DTSC-200A
ATS Controller- Operation

Manual 37941A DTSC-200A - ATS Controller - Operation
Page 2/37 © Woodward
WARNING
Read this entire manual and all other publications pertaining to the work to be performed before in-
stalling, operating, or servicing this equipment. Practice all plant and safety instructions and precau-
tions. Failure to follow instructions can cause personal injury and/or property damage.
The engine, turbine, or other type of prime mover should be equipped with an overspeed (overtempera-
ture, or overpressure, where applicable) shutdown device(s), that operates totally independently of the
prime mover control device(s) to protect against runaway or damage to the engine, turbine, or other
type of prime mover with possible personal injury or loss of life should the mechanical-hydraulic gov-
ernor(s) or electric control(s), the actuator(s), fuel control(s), the driving mechanism(s), the linkage(s),
or the controlled device(s) fail.
Any unauthorized modifications to or use of this equipment outside its specified mechanical, electrical,
or other operating limits may cause personal injury and/or property damage, including damage to the
equipment. Any such unauthorized modifications: (i) constitute "misuse" and/or "negligence" within
the meaning of the product warranty thereby excluding warranty coverage for any resulting damage,
and (ii) invalidate product certifications or listings.
CAUTION
To prevent damage to a control system that uses an alternator or battery-charging device, make sure
the charging device is turned off before disconnecting the battery from the system.
Electronic controls contain static-sensitive parts. Observe the following precautions to prevent dam-
age to these parts.
•Discharge body static before handling the control (with power to the control turned off, contact a
grounded surface and maintain contact while handling the control).
•Avoid all plastic, vinyl, and Styrofoam (except antistatic versions) around printed circuit boards.
•Do not touch the components or conductors on a printed circuit board with your hands or with
conductive devices.
OUT-OF-DATE PUBLICATION
This publication may have been revised or updated since this copy was produced. To verify that you
have the latest revision, be sure to check the Woodward website.
The revision level is shown at the bottom of the front cover after the publication number. The latest
version of most publications is available at:
http://www.woodward.com/publications
If your publication is not there, please contact your customer service representative to get the latest
copy.
Important definitions
WARNING
Indicates a potentially hazardous situation that, if not avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation that, if not avoided, could result in damage to equipment.
NOTE
Provides other helpful information that does not fall under the warning or caution categories.
Woodward reserves the right to update any portion of this publication at any time. Information provided by Woodward is believed to be
correct and reliable. However, Woodward assumes no responsibility unless otherwise expressly undertaken.
© Woodward
All Rights Reserved.

Manual 37941A DTSC-200A - ATS Controller - Operation
© Woodward Page 3/37
Revision History
Rev.
Date
Editor
Changes
A
2022-31-03
Ma
1.0-0 - Based on DTSC-200 V2.0017
Content
CHAPTER 1. GENERAL INFORMATION.....................................................................................5
Related Documents.............................................................................................................................5
QR Code.............................................................................................................................................5
CHAPTER 2. NAVIGATION /OPERATION..................................................................................6
Navigation.........................................................................................................................................12
Operation..........................................................................................................................................16
Operation Display....................................................................................................................16
Timer Display..........................................................................................................................17
LogicsManager........................................................................................................................17
CHAPTER 3. FUNCTIONAL DESCRIPTION...............................................................................19
General ATS Functionality.................................................................................................................19
Application Modes.............................................................................................................................20
Util-Util Application Mode.........................................................................................................20
Util-Gen Application Mode.......................................................................................................20
Gen-Gen Application Mode .....................................................................................................20
Blocking Transfer Operations............................................................................................................21
LogicsManager function "Inhibit ATS"......................................................................................21
Switch Failures........................................................................................................................21
Limit Switch Monitoring (Mechanical Failure, LM 21.11)...........................................................23
CHAPTER 4. CONFIGURATION .............................................................................................28
Structure of the Parameters...............................................................................................................28
Parameters.......................................................................................................................................30
Language................................................................................................................................30
Password................................................................................................................................30
Display Contrast......................................................................................................................30
Deactivate Horn ......................................................................................................................30
Code Levels............................................................................................................................31
Password................................................................................................................................31
Factory (Default) Values..........................................................................................................31
Real-Time Clock - Time...........................................................................................................32
Real-Time Clock - Date...........................................................................................................32
Version....................................................................................................................................32
APPENDIX A. MESSAGES....................................................................................................33
Timer / Operation States ...................................................................................................................33
Alarm Messages...............................................................................................................................35

Manual 37941A DTSC-200A - ATS Controller - Operation
Page 4/37 © Woodward
Illustrations And Tables
Illustrations
Figure 2-1: Front panel and display.....................................................................................................................................................6
Figure 2-2: Home Page explanation..................................................................................................................................................16
Figure 3-1: General ATS functionality - flowchart..........................................................................................................................19
Figure 3-2: Limit switch monitoring - failure message....................................................................................................................23
Tables
Table 1-1: Manual - Overview.............................................................................................................................................................5
Table 3-1: Limit switch monitoring - truth table for "Standard" limit switch w/o "Open" replies ...............................................24
Table 3-2: Limit switch monitoring - truth table for "Delayed" limit switch w/o "Open" replies................................................25
Table 3-3: Limit switch monitoring - truth table for "Open" limit switch with "Open" replies....................................................27
Table 4-1: Timer / operation states - display.....................................................................................................................................34

Manual 37941A DTSC-200A - ATS Controller - Operation
© Woodward Page 5/37
Chapter 1.
General Information
Related Documents
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
Type
English
German
DTSC-200A
DTSC-200A - Installation
37939
-
DTSC-200A - Configuration
37940
-
DTSC-200A - Operation
this manual 
37941
-
DTSC-200A - Application
37942
-
DTSC-200A - Interfaces
37943
-
Table 1-1: Manual - Overview
Intended Use The unit must only be operated for the uses described in this manual. The prerequisite for a proper
and safe operation of the product is correct transportation, storage, and installation as well as careful operation
and maintenance.
NOTE
This manual has been developed for a unit fitted with all available options. Inputs/outputs, functions,
configuration screens and other details described, which do not exist on your unit, may be ignored.
The present manual has been prepared to enable the installation and commissioning of the unit. On
account of the large variety of parameter settings, it is not possible to cover every possible combina-
tion. The manual is therefore only a guide. In case of incorrect entries or a total loss of functions, the
default settings can be taken from the enclosed list of parameters at the rear of this manual.
QR Code
To get access to the complete product documentation, scan this QR code or use the following link:
➔http://wwdmanuals.com/dtsc-200a

Manual 37941A DTSC-200A - ATS Controller - Operation
Page 6/37 © Woodward
Chapter 2.
Navigation / Operation
1
2
3
45
8
7
911
14
16 17 18 19
20 21 22 23 24
6
Figure 2-1: Front panel and display
Figure 2-1 illustrates the front panel/display, which includes push buttons, LEDs and the Liquid Crystal display
(LC display). A short description of the front panel is given below.
1
LED Alarm
Flashes if a new Alarm is triggered. Not acknowledged yet.
Shows that the device has minimal one unacknowledged alarm.
2
LED COMM OK
The LED flashes if any CAN message as RPDO is receipt.
3
LED ATS Inhibit
The LED indicates that the ATS transfer is inhibited.
12
LED S1 ok
The LED indicates that the source S1 is okay according to the configured operating ranges.
13
LED S1 breaker closed
The LED indicates that the load is connected to the S1 source.
14
LED S2 breaker closed
The LED indicates that the load is connected to the S2 source.

Manual 37941A DTSC-200A - ATS Controller - Operation
© Woodward Page 7/37
15
LED S2 ok
The LED indicates that the source S2 is okay according to the configured operating ranges.
16
LED Bypass possible
The LED indicates that the current sequence timer is possible to be bypassed. The current se-
quence timer is indicated on the Home Page View.
17
LED Settings mode entered
The LED indicates that the settings mode is entered. To leave the settings mode you must push
the Go-Back
11
Button.
18
LED LOAD TEST
The LED indicates that the LOAD TEST is currently manually initiated.
19
LED ENGINE TEST
The LED indicates that the ENGINE TEST is currently manually initiated.
20
Push Button BYPASS
If the LED Bypass possible
16
is flashing the operator can push this button to bypass a current
timer for example a stable timer.
21
Push Button SETTINGS
This button brings the operator directly into the settings mode. The settings mode is indicated
with the flashing LED Settings mode entered
17
. From there on the buttons on the right tot he
display are used to navigate through the settings menus.

Manual 37941A DTSC-200A - ATS Controller - Operation
Page 8/37 © Woodward
22
Push Button LOAD TEST
With this button the operator can manually initiate the LOAD TEST sequence. Once pushed he
must confirm over display whether he want to start the LOAD TEST with all its consequences.
NOTE
Initiating a LOAD TEST can cause a dead bus during switching the ATS control.
Confirming
No Confirming
With confirming over the return button, the manually LOAD TEST is initiated and the LED
LOAD TEST
18
will flashing.
If the LED LOAD TEST
18
is flashing the operator can abort the LOAD TEST by pushing the
LOAD TEST button again. With doing that he must confirm again to interrupt the LOAD TEST.
Confirming
No Confirming
If he confirms the abort of the load test the LED LOAD TEST
18
will be off and the DTSC-
200A goes into the normal operation.

Manual 37941A DTSC-200A - ATS Controller - Operation
© Woodward Page 9/37
23
Push Button ENGINE TEST
With this button the operator can manually initiate the ENGINE TEST sequence. Once pushed
he must confirm over display whether he want to start the ENGINE TEST [No Load Test] with
all its consequences.
Confirming
No Confirming
With confirming over the return button, the manually ENGINE TEST is initiated and the LED
ENGINE TEST
19
will flashing.
If the LED ENGINE TEST
19
is flashing the operator can abort the ENGINE TEST by pushing
the ENGINE TEST button again. With doing that he must confirm again to interrupt the
ENGINE TEST [No Load Test].
Confirming
No Confirming
If he confirms the abort of the engine test the LED ENGINE TEST
19
will be off and the
DTSC-200A goes into the normal operation.

Manual 37941A DTSC-200A - ATS Controller - Operation
Page 10/37 © Woodward
24
Push button Acknowledge
The acknowledge button has two functions:
1. If the Horn or a new alarm occurs the flashing LED Alarm
1
is disabled until a next
alarm takes place.
2. The single alarms can be acknowledged as long they are not active anymore.
Navigate to the Alarm list:
Go into Alarm List
Acknowledge an Alarm:
Go up
Go down
Acknowledge

Manual 37941A DTSC-200A - ATS Controller - Operation
© Woodward Page 11/37
25
Navigation Button Overview
The display contains on the top right corner a field which tells the operator which navigation
buttons right to the display are currently active.
Explanation:
Requestion mark –Go into alarm list
Tool –Go into configuration menu
Return –Acknowledge
Leave current screen –("Escape" / "ESC")
Cursor down –Go in the list one line down
Cursor left –Go with the cursor one step left
Cursor right –Go with the cursor one step right
Cursor up –Go in the list one line up
Display Brightness –The plus/minus buttons determine display brightness
Minus –One step less
Plus –One step more
Next Visualization Screen –Go to the next visualization screen.
One Visualization Screen back –Go one visualization screen back.
Select parameter –Go to the next parameter element in the screen
Select next parameter group –Especially for navigating in LogicsManager screens
it realizes group jumps of LogicsManager Command Variables.

Manual 37941A DTSC-200A - ATS Controller - Operation
Page 12/37 © Woodward
Navigation
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
Individual display screens are listed in the following text. All instruments, which are available in the individual
screens, are described with their function.
Screen "Automatic operation" / "Start screen" [all application modes]
Information Text Field
Timer Countdown Field
Source Conditions
Event timer active
Navigation Button
Overview
Information Text Field
Information Text Field
The field indicates the current action.
Timer Countdown Field
Timer Countdown Field
On this place appears the countdown timer of the different states.
Some timers are allowed to be bypassed through the BYPASS
button if the BYPASS button over the LED is flashing.
Source Conditions
Source Conditions Field
The condition of the source S1 and source S2 can be observed
here.
Event timer active
Event Timer Active
It appears an *E* on this place if any exercise timer is activated.
Navigation Button
Overview
Navigation Button Overview
There is on the top right in nearly all screens the navigation but-
ton overview
25
indicated. For better navigation it tells the oper-
ator which function is laying on which button (
6
,
7
,
8
,
9
,
10
,
11
) at the moment. For more details refer to Navigation
Button Overview explanation above.

Manual 37941A DTSC-200A - ATS Controller - Operation
© Woodward Page 13/37
Screen "Source 1 values - Details" [all application modes]
1/ 2/ 3......Source 1 voltages/currents V/AL1N / V/AL2N / V/AL3N
12 / 23 / 31 Source 1 voltages VL12 / VL23 / VL31
00.0V......... Source 1 voltage
00.00Hz..... Source 1 frequency
00.0A......... Source 1 current
000kW ......Source 1 real power
000kvar..... Source 1 reactive power
1.00............ Source 1 power factor = 1
Lg0.00....... Source 1 power factor (lagging)
Ld0.00....... Source 1 power factor (leading)
............. Phase rotation clockwise 
............. Phase rotation counterclockwise 
Screen "Source 2 values - Details" [all application modes]
1/ 2/ 3......Source 2 voltages/currents V/AL1N / V/AL2N / V/AL3N
12 / 23 / 31 Source 2 voltages VL12 / VL23 / VL31
00.0V......... Source 2 voltage
00.00Hz..... Source 2 frequency
00.0A......... Source 2 current
000kW ......Source 2 real power
000kvar..... Source 2 reactive power
1.00............ Source 2 power factor = 1
Lg0.00....... Source 2 power factor (lagging)
Ld0.00....... Source 2 power factor (leading)
............. Phase rotation clockwise 
Phase rotation counterclockwise 
Screen "S1 Load Current" [all application modes]
This screen shows the current phase currents if the load is connected to
source 1. Additionally, it provides a maximum slave pointer.
With pushing the slave pointer reset button the slave pointers will be
reset.
1/ 2/ 3......Load current IL1 / IL2 / IL3
Screen "S2 Load Current" [all application modes]
This screen shows the current phase currents if the load is connected to
source 2. Additionally, it provides a maximum slave pointer.
With pushing the slave pointer reset button the slave pointers will be
reset.
1/ 2/ 3......Load current IL1 / IL2 / IL3

Manual 37941A DTSC-200A - ATS Controller - Operation
Page 14/37 © Woodward
Screen "Battery voltage value - Details" [all application modes]
This screen shows the DC supply voltage of the device. Usually it is the
battery voltage of the power panel. The measured battery voltage value is
displayed graphically and numerically.
Screen "Discrete inputs / discrete (relay) outputs –Status display" [all application modes]
This screen shows the discrete input and discrete output status on the de-
vice connected.
Status display of the discrete inputs and discrete outputs.
(Note: The configured logic for the discrete input "N.O./N.C." will deter-
mine how the DTSC-200A reacts to the state of the discrete input. If the
respective DI is configured to N.O, the unit reacts on the energized state (
); if it is configured to N.C., it reacts on the de-energized state .)
Discrete input: energized
de-energized
Discrete output: relay activated
relay de-activated
Screen "Time / Date" [all application modes]
This screen shows time and date of the internal clock.
0000-XXX-00 –Date
0000 = Year
XXX = Month
00 = Day
00:00:00 –Time00 = Hour
00 = Minute
00 = Second

Manual 37941A DTSC-200A - ATS Controller - Operation
© Woodward Page 15/37
Screen "LogicsManager Conditions" [all application modes]
This screen shows in list form the LogicsManager groups. From there the
operator can navigate to the according group of interest.
Navigate to the LogicsManager conditions screens
Group00: Flags condition
Group01: Alarm system
Group03: Engine control
Group04: Application
Group06: Alarms
Group08: Syst.related alarms
Group09: Discrete inputs
Group11: Clock and timer
Group12: External Dis
Group13: Discrete outputs
Group14: External DOs
Group19: ATS Status flags
Group20: ATS status flags 2
Group21: ATS alarms
Group98: LM outputs
Screen "Counters" [all application modes]
The first screen show energy counters allocated to source S1 and S2.
The second screen shows the last overlap time duration, the current phase
angle between source 1 and source 2 and the amount of load transfers since
the last reset.
Energy 0.00 kWh - Generator real energy
0.00MWh = Total generator real energy
Pos. reactive energy 0.00 Mvar - Generator reactive energy
0.00Mvarh = Total generator reactive energy
Overlap time counter 00 ms - Overlap time
00ms = Overlap time of the last transfer
Phase angle S1-S2 000.0° - Phase angle
0000.0° = Ph. angle between source 1 and source 2
Transfers to S1 - Counter transfer to source 1
00000 = Number of S1 transfers
Transfers to S2 - Counter transfer to source 2
00000 = Number of S2 transfers
Screen "Alarm list" [all application modes]
With pushing the button the operator come into the active alarm
screen All alarm messages, which have not been acknowledged and
cleared, are displayed. Each alarm is displayed in one line as alarm text,
the date and time stamp. The symbol indicates that this alarm condition
is still present.

Manual 37941A DTSC-200A - ATS Controller - Operation
Page 16/37 © Woodward
Operation
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
The display is partitioned into different areas to give an overview of the displayed data.
Information Text Field
Timer Countdown Field
Source Conditions
Event timer active
Navigation Button
Overview
Figure 2-2: Home Page explanation
Operation Display
"Operation" display
The current operation state of the unit and the condition of the
sources are displayed during normal operation.
Operation state
The current operation state of the unit is indicated in the "Messages" section of the
screen. Refer to Appendix A: Messages on page 33 for a list of the possible operation
states.
Source condition
The current source condition is indicated in the "Operation" section of the screen. The
following source conditions are possible:
S1/2 Ok
Source 1/2 is considered as "OK", i.e., the voltage and frequency of Source 1/2 are with-
in the restore limits (refer to the Configuration Manual 37939 for more information).
S1/2 Fail
Source 1/2 is considered as "not OK", i.e., the voltage or frequency of Source 1/2 are not
within the restore limits (refer to the Configuration Manual 37939 for more information).
S1/2 Restore
Source 1/2 is considered as "OK", but the stable timer for the respective source has not
yet expired (refer to the Configuration Manual 37939 for more information).

Manual 37941A DTSC-200A - ATS Controller - Operation
© Woodward Page 17/37
Timer Display
"Timer" display
If a timer is active, it is indicated in the "Messages" section of
the screen and a numerical indication in the "Timer" section
counts down the remaining time before the timer expires.
Bypass timer
If a timer is currently active, it may be bypassed with the "Bypass" button.
Note: The Bypass feature is only possible if the LED over the Bypass button is
flashing.
This means with pushing the indicated timer expires immediately and the unit
proceeds with the next operation. Refer to Appendix A: Messages on page 33
for a list of the possible timers.
LogicsManager
Some parameters of the DTSC-200A are configured via the LogicsManager (refer to Configuration Manual
37940). A typical LogicsManager screen is shown in the following. You may configure a logical operation using
various command variables, signs, and logical operators to achieve the desired logical output.
LogicsManager Screen
For configuration of the LogicsManager use the softkeys dis-
played in the navigation button overview.
Leave current screen ("Escape" / "ESC")
By pressing this softkey character you exit and go to the previous screen. If the Escape
softkey is used to leave a LogicsManager configuration screen, any unconfirmed chang-
es made will not be stored.
Change option
By pressing these softkey characters plus and minus you may change the option of the
selected LogicsManager parameter upwards or downwards.
Confirm selection
By pressing this softkey character you confirm the configured option of the selected
LogicsManager parameter.
Select parameter
By pressing this softkey character you may select the LogicsManager parameter to be
configured. Each time this softkey character is pressed, the parameter will be advanced.

Manual 37941A DTSC-200A - ATS Controller - Operation
Page 18/37 © Woodward
Select group of parameters
By pressing this softkey character you may select the next group of LogicsManager pa-
rameter if you are on an LMCV parameter. Each time this softkey character is pressed,
the next parameter group will be taken. With the last group it begins with the smallest
group again.

Manual 37941A DTSC-200A - ATS Controller - Operation
© Woodward Page 19/37
Chapter 3.
Functional Description
General ATS Functionality
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
The following flowchart shows the typical ATS functionality:
Source 1 is
available
Close breaker to
Source 1
Source 1 is powering the load
Source 1 fails
„S2 start delay
timer“ expires
Send „engine
start“ signal ( de-
energize „engine
start“ relay )
Source 2
available ?
No
Source 2 stable
timer expires
Yes
Perform transfer to
Source 2
Source 2 is powering the load
Source 1
available ?
No
Source 1 stable
timer expires
Source 1 is powering the load
Engine cooldown
timer expires
Remove „engine
start“ signal
(energize Gen
start relay )
Motor load
disconnect
feature ON ?
Set Motor load
disconnect signal
No
De-energize
„Motor Load
Disconnect“ Signal
Perform transfer to
Source 1
Elevator pre-
signal feature
On ?
Set elevator pre-
signal
Motor load
disconnect
feature ON ?
Set motor load
disconnect signal
No
No
De-energize
„Elevator pre-
signal“
De-energize
„Motor Load
Disconnect“ Signal
Figure 3-1: General ATS functionality - flowchart

Manual 37941A DTSC-200A - ATS Controller - Operation
Page 20/37 © Woodward
Application Modes
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
The application mode may be configured in the unit (refer to the Configuration Manual 37940 for more infor-
mation). This is only possible in code level 2. The most important features and differences of the three applica-
tion modes are illustrated in the following section. A description of the functions that are possible during each
application mode can be found in the configuration manual (manual 37940).
Util-Util Application Mode
This application mode has the following characteristics:
•The ATS controller monitors two mains sources and transfers the load to the secondary source in
case the primary source fails
•The ATS controller operates as Master controller
Util-Gen Application Mode
This application mode has the following characteristics:
•The ATS controller monitors a mains sources and a generator source and transfers the load to the
generator source in case the mains source fails
•The ATS controller operates as Master controller
Gen-Gen Application Mode
This application mode has the following characteristics:
•The ATS controller monitors two generator sources and transfers the load to the other source in
case the regular source fails
•The ATS controller operates as Slave controller
•This application is not a stand-alone application and always combined with another ATS control-
ler in Util-Gen application mode, which operates as Master controller (refer to the Application
Manual 37942 for more information)
Engine operation special cases
In Util-Gen application mode and Gen-Gen application mode the ATS starts and stops an engine. Starting and
stopping is controlled by the state machine described above. However, in some rare situations the start/stop is af-
fected by the breaker state. These are
•If a breaker cannot be closed to a generator source (indicated by a corresponding alarm), then the engine
shall not run, it shall either not start or do a stop after cooldown
•If a breaker is connected to a generator source and cannot be opened (indicated by a corresponding alarm),
the engine shall continue to run.
•If a breaker closing to a generator source is inhibited, and the breaker is not already closed, the engine shall
not run or do a stop after cooldown.
S1
S2
G
S1
S2
G1
G2
S1
S2
