Woodward EGCP-2 User manual

Operation (End User) Manual
EGCP-2
Engine Generator Control Package
8406-115, 150–300 Vac PT Input, 9–32 Vdc
8406-116, 50–150 Vac PT Input, 9–32 Vdc
Manual 26086 (Revision E)

WARNING—DANGER OF DEATH OR PERSONAL INJURY
WARNING—FOLLOW INSTRUCTIONS
Read this entire manual and all other publications pertaining to the work to be performed
before installing, operating, or servicing this equipment. Practice all plant and safety
instructions and precautions. Failure to follow instructions can cause personal injury and/or
property damage.
WARNING—OUT-OF-DATE PUBLICATION
This publication may have been revised or updated since this copy was produced. To verify
that you have the latest revision, be sure to check the Woodward website:
www.woodward.com/pubs/current.pdf
The revision level is shown at the bottom of the front cover after the publication number. The
latest version of most publications is available at:
www.woodward.com/publications
If your publication is not there, please contact your customer service representative to get
the latest copy.
WARNING—OVERSPEED PROTECTION
The engine, turbine, or other type of prime mover should be equipped with an overspeed
shutdown device to protect against runaway or damage to the prime mover with possible
personal injury, loss of life, or property damage.
The overspeed shutdown device must be totally independent of the prime mover control
system. An overtemperature or overpressure shutdown device may also be needed for
safety, as appropriate.
WARNING—PROPER USE
Any unauthorized modifications to or use of this equipment outside its specified
mechanical, electrical, or other operating limits may cause personal injury and/or property
damage, including damage to the equipment. Any such unauthorized modifications: (i)
constitute "misuse" and/or "negligence" within the meaning of the product warranty
thereby excluding warranty coverage for any resulting damage, and (ii) invalidate product
certifications or listings.
CAUTION—POSSIBLE DAMAGE TO EQUIPMENT OR PROPERTY
CAUTION—BATTERY CHARGING
To prevent damage to a control system that uses an alternator or battery-charging device, make
sure the charging device is turned off before disconnecting the battery from the system.
CAUTION—ELECTROSTATIC DISCHARGE
Electronic controls contain static-sensitive parts. Observe the following precautions to
prevent damage to these parts.
• Discharge body static before handling the control (with power to the control turned off,
contact a grounded surface and maintain contact while handling the control).
• Avoid all plastic, vinyl, and Styrofoam (except antistatic versions) around printed circuit
boards.
• Do not touch the components or conductors on a printed circuit board with your hands
or with conductive devices.
IMPORTANT DEFINITIONS
• A WARNING indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
• A CAUTION indicates a potentially hazardous situation which, if not avoided, could result in
damage to equipment or property.
• A NOTE provides other helpful information that does not fall under the warning or caution
categories.
Revisions—Text changes are indicated by a black line alongside the text.
Woodward Governor Company reserves the right to update any portion of this publication at any time. Information
provided by Woodward Governor Company is believed to be correct and reliable. However, no responsibility is
assumed by Woodward Governor Company unless otherwise expressly undertaken.
© Woodward 2000
All Rights Reserved

Manual 26086 EGCP-2 Engine Generator Control Package
Woodward i
Contents
REGULATORY COMPLIANCE.........................................................................V
ELECTROSTATIC DISCHARGE AWARENESS ................................................. VI
CHAPTER 1. GENERAL INFORMATION...........................................................1
Introduction.............................................................................................................1
Control Electrical Ratings .......................................................................................1
CHAPTER 2. CONTROL OVERVIEW...............................................................3
Introduction.............................................................................................................3
Operator Interface ..................................................................................................5
CHAPTER 3. SOFTWARE OVERVIEW...........................................................15
Introduction...........................................................................................................15
Status Screens .....................................................................................................15
Alarm / Event Log .................................................................................................27
Configuration Menus ............................................................................................29
Shutdowns and Alarms ........................................................................................38
Engine Control......................................................................................................43
Synchroscope.......................................................................................................45
Real Load Control.................................................................................................48
Reactive Load Control..........................................................................................50
Process Control ....................................................................................................51
Transfer Switch.....................................................................................................54
Sequencing and Comms (Communications)........................................................56
Calibration Menu ..................................................................................................58
CHAPTER 4. CONTROL FEATURES AND FUNCTIONS....................................66
Engine Control......................................................................................................66
Engine Protection .................................................................................................66
Generator Voltage and Reactive Load Control ....................................................66
Generator Protection ............................................................................................66
Mains Sensing ......................................................................................................67
Synchronizing .......................................................................................................67
Load Control .........................................................................................................67
Sequencing...........................................................................................................67
Engine Cranking ...................................................................................................68
IDLE/RATED Relay Output ..................................................................................69
Generator Voltage Control ...................................................................................69
Generator Load Control........................................................................................70
Automatic Generator Loading Functions..............................................................74
Synchronizer Description .....................................................................................77
Generator Sequencing .........................................................................................84
Inter-control Communications (RS-485 Network) ................................................93
Remote Control/Monitoring (RS-422)...................................................................94
CHAPTER 5. CALIBRATION OF CONTROL INPUTS AND OUTPUTS..................95
Introduction...........................................................................................................95
Calibration of Generator PTs and CTs.................................................................96
Calibration of the Bus PT ...................................................................................100
Speed Bias Output .............................................................................................101
Voltage Bias Output............................................................................................102
CHAPTER 6. GENERAL STARTUP INSTRUCTIONS ......................................103
Before Starting the Generator Set......................................................................103
Sequence of Startup and Checking Parameters................................................104
Loading the Generator Set .................................................................................104

EGCP-2 Engine Generator Control Package Manual 26086
ii Woodward
Contents
CHAPTER 7. TROUBLESHOOTING .............................................................107
Control Hardware and I/O.................................................................................. 107
Engine Control/Sensing Parameters ................................................................. 108
Synchronization ................................................................................................. 109
Breaker Close/Open Control ............................................................................. 110
Real Load Control.............................................................................................. 111
Reactive Load Control ....................................................................................... 112
Sequencing........................................................................................................ 113
Mains/Bus Sensing............................................................................................ 114
Communications................................................................................................ 114
CHAPTER 8. DEFINITION OF TERMS ..........................................................115
CHAPTER 9. SERVICE OPTIONS................................................................122
Product Service Options.................................................................................... 122
Returning Equipment for Repair........................................................................ 123
Replacement Parts ............................................................................................ 124
How to Contact Woodward................................................................................ 124
Engineering Services......................................................................................... 125
Technical Assistance......................................................................................... 126
APPENDIX A. EGCP-2 SETPOINT WORKSHEET ........................................127
Configuration Menu ........................................................................................... 127
Shutdown and Alarms Menu ............................................................................. 128
Engine Control Menu......................................................................................... 130
Synchronizer Menu............................................................................................ 132
Real Load Control Menu.................................................................................... 133
Reactive Load Control Menu............................................................................. 134
Process Control Menu ....................................................................................... 134
Transfer Switch Menu........................................................................................ 135
Sequencing and Comms Menu ......................................................................... 136
Calibration Menu ............................................................................................... 137
APPENDIX B. DOWNLOAD INSTRUCTIONS .................................................138
Purpose ............................................................................................................. 138
Requirements .................................................................................................... 138
Instructions ........................................................................................................ 138
EGCP-2 CONTROL SPECIFICATIONS........................................................143

Manual 26086 EGCP-2 Engine Generator Control Package
Woodward iii
Illustrations
Figure 1-1. EGCP-2 Wiring Diagram......................................................................2
Figure 2-1. Operator Interface................................................................................5
Figure 2-2. EGCP-2 Navigation............................................................................10
Figure 3-1. System Overview Engine Off Line .....................................................15
Figure 3-2. System Status Screen—Isochronous ................................................17
Figure 3-3. System Status Screen—Baseload.....................................................17
Figure 3-4. Engine Overview................................................................................18
Figure 3-5. Generator Status (Voltage Line to Line) ............................................19
Figure 3-6. I/O Status ...........................................................................................20
Figure 3-7. Synchronizer Status...........................................................................21
Figure 3-8. KW Load Status .................................................................................22
Figure 3-9. PF /KVAR Status ...............................................................................23
Figure 3-10. Sequencing Menu ............................................................................24
Figure 3-11. Sequencing Menu (Multi-Unit) .........................................................25
Figure 3-12. ATS (Automatic Transfer Switch) Status. ........................................26
Figure 3-13. Alarm / Event Screen .......................................................................27
Figure 3-14. Empty Event Log..............................................................................28
Figure 3-15. Security Code Display......................................................................29
Figure 3-16a. Configuration Menu List (Screen 1)...............................................30
Figure 3-16b. Configuration Menu List (Screen 2)...............................................30
Figure 3-16c. Configuration Menu List (Screen 3) ...............................................31
Figure 3-17. AC Power Triangle...........................................................................34
Figure 3-18. Breaker Logic and Contactor Logic .................................................37
Figure 3-19. Generator High/Low Voltage Alarms ...............................................38
Figure 3-20. Generator Over/Under Frequency...................................................39
Figure 3-21. Current goes to 160 Amps, an Alarm or Shutdown will be received
in 10 seconds...................................................................................41
Figure 3-22. Current goes to 176 Amps, an Alarm or Shutdown will be received
in 5 seconds.....................................................................................41
Figure 3-23. Current goes to 152 Amps, an Alarm or Shutdown will be received
in 20 seconds...................................................................................42
Figure 3-24. Reverse Power ................................................................................42
Figure 3-25. Typical Circuit Using Permissive Function and Run for Auto/Manual
Synchronizing ..................................................................................45
Figure 3-26. Voltage Matching (1% setpoint).......................................................46
Figure 3-27. Maximum Phase Window = 10 Degrees .........................................46
Figure 3-28. Direct (Export) Process Action.........................................................51
Figure 3-29. Indirect (Import Power) Process Action ...........................................51
Figure 3-30. Direct (Import/Export) Process Action .............................................52
Figure 3-31. EGCP-2 Control Dip Switch.............................................................52
Figure 3-32. Measured vs. Monitored ..................................................................59
Figure 3-33. Typical AVR with Aux Input (Newage SX-440)................................60
Figure 3-34. Typical AVR with External Voltage Adjust Potentiometer................60
Figure 3-35. AVR Droop.......................................................................................60
Figure 3-36. Direct proportional input to Water Temp or Oil Pressure Input. ......62
Figure 3-37. Voltage Controlled Oscillators—Effect of Offset..............................62
Figure 3-38. Voltage Controlled Oscillators—Effect of Gain................................62
Figure 3-39. Battery VCO.....................................................................................63
Figure 3-40. Oil Pressure VCO ............................................................................63
Figure 3-41. Water Temperature VCO.................................................................64
Figure 4-1. Droop Mode .......................................................................................71
Figure 4-2. Isochronous Mode .............................................................................72
Figure 4-3. Droop/Isochronous Load Sharing ......................................................73
Figure 4-4. Synchronizer Time Line—Standard Sequence .................................81

EGCP-2 Engine Generator Control Package Manual 26086
iv Woodward
Illustrations
Figure 4-5. Loss of Mains Detection Active..........................................................82
Figure 4-6. Generator Off Line .............................................................................82
Figure 4-7. Mains Parallel Unit with Voltage/Frequency Detect...........................83
Figure 4-8. Mains Parallel Unit(s) with Load Surge Detect ..................................83
Figure 4-9. Typical Automatic Sequencing Routine .............................................85
Figure 4-10. Original System Configuration .........................................................87
Figure 4-11. After a Change of Priority—Units Not Operating .............................88
Figure 4-12. Original System Configuration .........................................................88
Figure 4-13. A New Master Takes Over—Single Unit Operating on the Isolated
Bus...................................................................................................89
Figure 4-14. Changing the Priority of a Slave Unit...............................................90
Figure 4-15. Changing the Priority of a Slave Unit...............................................91
Figure 4-16. Changing the Priority of a Slave Unit...............................................91
Figure 4-17. Changing the Priority of a Slave Unit...............................................92
Figure 4-18. Changing the Priority of a Slave Unit...............................................92
Figure 4-19. Changing the Priority of a Slave Unit...............................................93
Figure 5-1. Relationship Between Voltage Bias and Generator Voltage .......... 102

Manual 26086 EGCP-2 Engine Generator Control Package
Woodward v
Regulatory Compliance
European Compliance for CE Mark:
EMC Directive Declared to 89/336/EEC COUNCIL
DIRECTIVE of 03 May 1989 on the
approximation of the laws of the member
states relating to electromagnetic
compatibility.
Low Voltage Directive Declared to the 73/23/EEC COUNCIL
DIRECTIVE of 19 February 1973 on the
harmonization of the laws of the Member
States relating to electrical equipment
designed for use within certain voltage
limits.
North American Compliance:
UL UL Listed for Ordinary Locations at 70°C
maximum Ambient. For use in the United
States and Canada.
UL File E97763
CSA CSA Certified for Ordinary Locations at
70°C maximum Ambient. For use in the
United States and Canada.
Certificate 1159277
NOTE Wiring must be in accordance with
applicable electric codes with the authority
having jurisdiction.
• The EGCP-2 is suitable for use in non-hazardous locations only.
• Wiring must be in accordance with applicable electrical codes and in
accordance with the authority having jurisdiction.
• Field wiring must be suitable for at least 90 °C (194 °F).
• Connect ground terminal to PE (Protective Earth).
• More than one live circuit (see wiring diagram)

EGCP-2 Engine Generator Control Package Manual 26086
vi Woodward
Electrostatic Discharge Awareness
All electronic equipment is static-sensitive, some components more than others.
To protect these components from static damage, you must take special
precautions to minimize or eliminate electrostatic discharges.
Follow these precautions when working with or near the control.
1. Before doing maintenance on the electronic control, discharge the static
electricity on your body to ground by touching and holding a grounded metal
object (pipes, cabinets, equipment, etc.).
2. Avoid the build-up of static electricity on your body by not wearing clothing
made of synthetic materials. Wear cotton or cotton-blend materials as much
as possible because these do not store static electric charges as much as
synthetics.
3. Keep plastic, vinyl, and Styrofoam materials (such as plastic or Styrofoam
cups, cup holders, cigarette packages, cellophane wrappers, vinyl books or
folders, plastic bottles, and plastic ash trays) away from the control, the
modules, and the work area as much as possible.
4. Do not remove the printed circuit board (PCB) from the control cabinet
unless absolutely necessary. If you must remove the PCB from the control
cabinet, follow these precautions:
•Do not touch any part of the PCB except the edges.
•Do not touch the electrical conductors, the connectors, or the
components with conductive devices or with your hands.
•When replacing a PCB, keep the new PCB in the plastic antistatic
protective bag it comes in until you are ready to install it. Immediately
after removing the old PCB from the control cabinet, place it in the
antistatic protective bag.
CAUTION—ELECTROSTATIC DISCHARGE
To prevent damage to electronic components caused by improper handling,
read and observe the precautions in Woodward manual 82715, Guide for
Handling and Protection of Electronic Controls, Printed Circuit Boards, and
Modules.

Manual 26086 EGCP-2 Engine Generator Control Package
Woodward 1
Chapter 1.
General Information
Introduction
This manual describes the Woodward EGCP-2 Engine Generator Control
Package models 8406-115 and 8406-116 (9–32 Vdc maximum input voltage
range).
Control Electrical Ratings
nominal supply voltage range 10–29 Vdc (12 or 14 volt systems)
max. power consumption
at rated voltage 20 W
max. PT input voltage range 150–300 Vac rms (8406-115)
50–150 Vac rms (8406-116)
max. CT current input range 0–6 A rms
max. generator frequency range 40–70 Hz

EGCP-2 Engine Generator Control Package Manual 26086
2 Woodward
Figure 1-1. EGCP-2 Wiring Diagram

Manual 26086 EGCP-2 Engine Generator Control Package
Woodward 3
Chapter 2.
Control Overview
Introduction
The EGCP-2 is a microprocessor based complete generator load control and
engine management package designed for use with an Electronic engine speed
control and a separate voltage regulator. The control's functions include:
Engine Control
• Engine Pre-glow
• Fuel Solenoid Control
• Engine Starter Control
• KVA Controlled Cool-down Timer
• Oil Pressure Monitoring
• Water Temperature Monitoring
• Battery Voltage Monitoring
• Speed Monitoring with Overspeed Protection
• Idle/Rated Relay Output
Synchronizing
• Digital signal processing to eliminate problems induced in systems with high
harmonic content causing multiple zero crossing of voltage wave forms
• Adjustable maximum phase window, voltage window, and dwell times—
windows as small as 2° phase error and 1% voltage matching respectively
• Safe dead bus closing logic internal to the control
• Multiple shot re-closing with adjustable time delays, auto-resynchronizing,
and synchronizer time-outs all available
• Manual voltage and speed adjusts for manual synchronizing (Sync-Check
still active during manual parallels)
• Synchronization across generator and mains breakers
Real (kW) Load Control
• True RMS power calculations for rapid, accurate load control even in the
presence of harmonics
• Smooth user chosen ramp rates into and out of each mode of operation
• Isochronous load-sharing of up to 8 units based on percentage loading
(allows different rated machines to proportionally balance kW loads)
• Constant base loading for optimum fuel efficiency with discrete inputs to
change load levels remotely
• Import/Export control with an external watt transducer
• Soft Utility Transfer Function
• Externally adjustable Base Load or Process Reference Levels with
independent ramp rates
• kW droop provided for manual load control

EGCP-2 Engine Generator Control Package Manual 26086
4 Woodward
Reactive (KVAR) Control
• VAR sharing on isolated busses based on percentage reactive load (allows
different rated machines to proportionally balance KVAR loads)
• Constant Power factor or VAR base loading on units which are in kW base
load control mode, or process control mode
• Externally adjustable VAR or PF control reference levels
• KVAR droop for manual VAR control
Automatic Generator Sequencing
• Automatically starts additional EGCP-2 equipped generators when load
exceeds a user specified percentage of the rated load of the operating
machines
• Provides controlled unloads for engines when the load is low enough that
the remaining engines will not exceed a user specified percentage of the
rated load
• Engine priority sequence can be changed from any unit or from a PC to
equalize run-time
Generator Protective Features
• Over/Under Voltage
• Over/Under Frequency
• Reverse Power (Inverse time delay)
• Loss of Excitation
• Overcurrent (Inverse time delay)
• Loss of mains detection
• Over/Under Voltage
• Over/Under Frequency
• Generator Load Surge
• Speed/Frequency Mismatch
• Load Surge
• KVA Load Switch
Engine Protective Features
• High/Low Coolant Temperature
• High/Low Oil Pressure
• Overspeed
• Over Crank
• Start Failure
• Six User Configurable Discrete Fault Inputs
Communication - PC Interface
• Easy upload and download of configuration setpoints
• A PC can control or monitor any unit at a site by a single connection to the
local operating network via RS-422 serial port using Modbus®* or ServLink
protocol
*—Modbus is a registered trademark of Modicon, Inc.

Manual 26086 EGCP-2 Engine Generator Control Package
Woodward 5
Operator Interface
The EGCP-2 Operator Interface is designed for simplicity and redundancy of
function in all operating modes. The backlit LCD screens are used to display
various operating and status information to the operator, as well as for reading
configuration setpoints and alarm information. The backlight on the LCD screen
will stay on whenever the engine’s speed is over 50 RPM. When the engine
shuts down, the backlight will turn off after five minutes. Pressing any key on the
front panel will first turn on the backlight and pressing the key a second time will
perform that function. The backlight will turn off after five minutes of non-use and
the engine is shut down.
NOTE
The EGCP-2 Operator Interface can only be used for unit configuration and
monitoring. Unit start/stop, sync, or mode selection commands can not be
given through the EGCP-2’s front panel.
CAUTION—TRAINED PERSONNEL
An unsafe condition could occur with improper use of these software tools.
Only trained personnel should have access to these tools.
The screens provide eight lines of Status Information, with the option of
displaying four lines of Setpoint tuning or Alarm Log information. These screens
allow the user to monitor and tune related parameters at the same time.
Figure 2-1. Operator Interface
A red Light Emitting Diode (LED) on the face of the control is used to indicate an
alarm condition by flashing repeatedly, and to indicate a shutdown condition by
staying on continuously.

EGCP-2 Engine Generator Control Package Manual 26086
6 Woodward
There are a total of 19 keys on the keypad. Each of the keys has the following
function(s):
ALARM/EVENT LOG KEYS:
ALARM / EVENT
The ALARM/EVENT key is used to access the Event
log. When pressed, the current alarm events will be displayed on the right hand
LCD screen. When multiple alarms are logged, the up and down scroll keys will
allow you to navigate within the Event log. The Event log will store up to 16
events, as more events happen the oldest alarms will be dropped off to make
room for the newer events. If power is cycled to the control, the Event log will be
cleared.
ALARM CLEAR
The ALARM CLEAR key is used to acknowledge and
clear alarm events from the Event log. To acknowledge and clear alarm and
shutdown events a Security Code of Operator Level or higher is needed. After
selecting the ALARM/EVENT key:
If the Alarm mode is Visual or Warning –
1. Pressing the ALARM CLEAR key will acknowledge the selected alarm, this
means the cursor will move from the Alarm Name line down to the Time and
Date line.
2. Pressing the Alarm Clear key a second time will remove the event from the
log.
If the Alarm/Shutdown mode is Audible, Soft Shutdown, or Hard Shutdown –
1. Pressing the ALARM CLEAR key once will de-energize Discrete Output #11,
Audible Alarm. This will happen without selecting the ALARM/EVENT key
and without a Security Code entered.
2. With the ALARM/EVENT key pressed, so the Event log is being displayed:
Pressing the ALARM CLEAR key a second time will acknowledge the
selected alarm. This means the cursor will move from the Alarm Name line
down to the Time and Date line.
3. Pressing the Alarm Clear key a third time will remove the event from the log.

Manual 26086 EGCP-2 Engine Generator Control Package
Woodward 7
NAVIGATION and ADJUSTMENT KEYS:
SCROLL
The SCROLL KEY is used to move the cursor up, down ,
left and right. It also is used to increment and decrement values while in the
configuration menus.
ESC
The ESCAPE KEY is used to move upwards (out of )the
configuration menu levels. It also is used when tuning a value to restore the
previous value, if the new value is not entered into memory (see the enter key,
below).
ENTER
The ENTER KEY is used to move downwards (into) the
configuration menu levels. It is also used to when tuning a value to enter the new
value to memory. It also serves as a means to commit alarm event items to the
alarm event list without removing them. This is known as logging the alarm event
item. Pressing the enter key while on the selected alarm/event item will “save”
that item to the event list. If the selected alarm event was an active alarm event,
the action(s) associated with the alarm event will also be cleared from the control
logic.
STATUS and CONFIGURATION KEYS:
i
STATUS
The STATUS KEY, when pressed, will put both left and right
LCDs into the status display mode. The status displays provide information about
different items of engine and generator set operation. See the STATUS MENU
buttons, below for details on the various status keys. There are no adjustment
values in the status menus.

EGCP-2 Engine Generator Control Package Manual 26086
8 Woodward
CONFIG
...
The CONFIG KEY, when pressed, will put the right hand LCD
into the configuration mode. Configuration menu items will be displayed in the
right hand screen. Status information will continue to be displayed in the left hand
screen. Since there are various menu items and adjustments in the configuration
menu, a blinking cursor is provided in the right hand display when the configure
mode is active.
STATUS MENU KEYS:
The contents of the various status menus are described in the Status Screens
section in Chapter 3 of this manual.
SYSTEM
The SYSTEM STATUS key, when pressed displays the system
status information. The system status display is also the default status display
screen (it is always the first display shown after a power up of the control). This
display shows general information about the operation of the engine generator
set.
ENGINE
The ENGINE STATUS key , when pressed displays status
information about the engine functions and operation.
GEN
The GEN STATUS key shows three phase generator
parameters when pressed.
I/O
The I/O STATUS key provides the status of all the discrete
inputs and outputs, as well as information on analog inputs and outputs.

Manual 26086 EGCP-2 Engine Generator Control Package
Woodward 9
SYNC
The SYNC STATUS key shows status information regarding the
generator breaker and utility breaker synchronizer.
KW LOAD
The KW LOAD STATUS key, when pressed, shows the
status information for the KW load control of the EGCP-2.
PF / KVAR
Press the PF/KVAR STATUS key to display VAR/PF Mode
information, as well as three phase generator voltage and current.
SEQUENCE
The SEQUENCE STATUS key provides sequencing
information for multiple unit systems. Single unit systems, and units not in the
AUTO mode will not provide status information in this screen.
ATS
The ATS STATUS key, when pressed, displays the status
information for the Automatic Transfer Switch functions.

EGCP-2 Engine Generator Control Package Manual 26086
10 Woodward
Navigation Procedure
The following drawings detail a step-by-step procedure for navigating through the
EGCP-2 software. Additionally, the typical display entries seen at each step are
shown.
Figure 2-2. EGCP-2 Navigation
(next five pages)
synchronizer status
system status system status
Power Up
prime mover status prime mover status
synchronizer status synchronizer status
synchronizer status
SECURITY CODE
****
synchronizer status
SECURITY CODE
_ 0
----------------------------------------------------
ENTER SECURITY CODE
Configuration
Shutdowns and Alarms
Engine Control
Synchronizer
synchronizer status
+
+
Configuration
Shutdowns and Alarms
Engine Control
Synchronizer
LEFT HAND LCD DISPLAY RIGHT HAND LCD DISPLAY
KEYPRESS
ENGINE
SYNC
CONFIG
...
ENTER
SCROLL
ENTER
SCROLL
VIS-140A
00-6-20

Manual 26086 EGCP-2 Engine Generator Control Package
Woodward 11
synchronizer status
synchronizer status
synchronizer status
synchronizer status
synchronizer status
>AUTO SEQUENCING (*first item is list)
>MAX GEN LOAD
>NEXT GENSET DLY
>RATED LOAD DLY
synchronizer status
>AUTO SEQUENCING (*first item is list)
>MAX GEN LOAD
>NEXT GENSET DLY
>RATED LOAD DLY
synchronizer status
>AUTO SEQUENCING (*first item is list)
>MAX GEN LOAD
>NEXT GENSET DLY
>RATED LOAD DLY
Configuration (*first item in list)
Shutdowns and Alarms
Engine Control
Synchronizer
Shutdowns and Alarms
Engine Control
Synchronizer
Real Load Control
Process Control
Transfer Switch
Sequencing and Comms
Calibration (*last item in list)
Process Control
Transfer Switch
Sequencing and Comms
Calibration (*last item in list)
SCROLL
SCROLL
SCROLL
SCROLL
ENTER
SCROLL
SCROLL
From Previous Page
VIS-140B
00-6-20

EGCP-2 Engine Generator Control Package Manual 26086
12 Woodward
synchronizer status
NEXT GENSET DLY
30 Sec
-------------------WOODWARD EGCP2-------------
CONFIGURATION MENUS
From Previous Page
synchronizer status
synchronizer status
synchronizer status
synchronizer status
synchronizer status
synchronizer status
NEXT GENSET DLY
29 Sec
-------------------WOODWARD EGCP2-------------
CONFIGURATION MENUS
>AUTO SEQUENCING (*first item is list)
>MAX GEN LOAD
>NEXT GENSET DLY
>RATED LOAD DLY
>AUTO SEQUENCING (*first item is list)
>MAX GEN LOAD
>NEXT GENSET DLY
>RATED LOAD DLY
MAX GEN LOAD
60 %
---------------------SEQUENCING--------------------
%KW: 0.0
>AUTO SEQUENCING (*first item is list)
>MAX GEN LOAD
>NEXT GENSET DLY
>RATED LOAD DLY
Process Control
Transfer Switch
Sequencing and Comms
Calibration (*last item in list)
SCROLL
ENTER
ENTER
SCROLL
ENTER
ESC
ESC
VIS-140C
