MySpot Installation Manual
8/9/2010 Page 1 of 35
Assembly instructions for all catalog numbers beginning with:
MS.M.2.39
MS.C.2.39
(Double seat with right hand and left hand tablets and with a 39” high back panel)
Tools required for assembly:
#2 Phillips screw driver
#3 Phillips screw driver
Slotted screw driver
5/32” hex wrench
3/16” hex wrench
6mm hex wrench
5/16” open end wrench
Hammer
Needle nose pliers
Power screw driver (optional)

8/9/2010 Page 2 of 35
Parts required to assemble (1) unit:
(1) – Back panel
(38-3/4”H x 68-3/4”W)
(2) – Outer back cover panels
(31-9/16”H x 31-7/8”W)
(2) – Inner back cover panels
(22-3/16”H x 31-7/8”W)

8/9/2010 Page 3 of 35
Parts required to assemble (1) unit (continued):
(2) – Internal end panels
(21-1/16”H x 22-1/2”W)
(2) – End left face cover panels
(21-3/16”H x 22-1/2”W)
(2) – End right face cover panels
(21-3/16”H x 22-1/2”W)
(1) – Seat support beam
(64-1/8”L)

8/9/2010 Page 4 of 35
Parts required to assemble (1) unit (continued):
(1) – Left front leg
(2-1/4”SQ x 24-3/16”H)
(1) – Right front leg
(2-1/4”SQ x 24-3/16”H)
LH RH
(1 each) - Left hand and right hand tablet assembly
(1) – Left arm
(6”W x 28-1/2”L)
(1) – Right arm
(6”W x 28-1/2”L)

8/9/2010 Page 5 of 35
Parts required to assemble (1) unit (continued):
(2) – Bottom panels
(23-5/8” x 27-3/8”)
(1) – Center table
(14-5/8”W x 25”D)
(2) – Back cushions
(2) – Seat cushions
(2) – Z-bars (21-3/16”L)
(4) – Pin-fast brackets

8/9/2010 Page 6 of 35
Hardware required to assemble (1) unit (shown actual size):
(8) 1/4-20 x 3/4” pan head machine screws – zinc (part# 1001501)
(4) 5/16-18 x 1” flat head socket cap screws – black (part# 26797)
(2) 1/4-20 x 85mm (3-3/8”) decorative head bolt – black (part# 26506-BLK)
(8) #12 x 3/4” flat head wood screws – zinc (part# 26791)
(14) #10 x 1-1/4” flat head wood screws – black (part# 1001591)
(2) #10 x 1-1/2” flat head wood screws – black (part# 1001592)
(8) #8 x 5/8” pan head wood screws – black (part# 1001742)
(18) #12 x 5/8” pan head wood screws – black (part# 4300-1738)

8/9/2010 Page 7 of 35
Hardware required to assemble (1) unit (shown actual size) (continued):
(4) #12 x 1” pan head wood screws – black (part# 1001739)
(32) #14 x 3/8” shoulder screws – zinc (part# 26794)
(12) Cam pins – nickel (part# 29989)
(2) Cam pins – nickel (part# 1000336)
(2) 1/4-20 barrel nut – steel (part# 20434)
(12) Cams – zinc (part# 29988)
(2) Cams – black (part# 1000335)

8/9/2010 Page 8 of 35
Hardware required to assemble (1) unit (shown actual size) (continued):
(14) Figure-8 fasteners – zinc (part# 1001663)
(4) Lock clips – black plastic (part# 1000611)

8/9/2010 Page 9 of 35
1(6) #10 x 1-1/4” (6) Figure-8
Screw (6) Figure-8’s into the predrilled holes in
the bottom edge of the back panel.
1 2

8/9/2010 Page 10 of 35
2(8) 1/4-20 x 3/4"
Attach the Z-bars onto the inside of the internal back panel.
1 2

8/9/2010 Page 11 of 35
3 (8)Shoulderscrews
Screw (4) shoulder screws into both inner back cover panels.
1 2

8/9/2010 Page 12 of 35
4
Fasten the inner back cover panels to the back panel.
1 2 3

8/9/2010 Page 13 of 35
5(8) #8 x 5/8” (4) Lock clips
Attach (2) lock clips under each inner back cover panel.
1 2 3 4

8/9/2010 Page 14 of 35
6(2) Cam pins (6) Cam pins
Screw (3) cam pins into each back panel post and screw
(2) cam pins into the brass inserts in the back panel.
1 2

8/9/2010 Page 15 of 35
7(8) #10 x 1-1/4” (8) Figure-8
Screw (4) Figure-8’s into the predrilled holes in
the bottom edge of the internal end panels.
1 2

8/9/2010 Page 16 of 35
8(6) Cams
Fasten the internal end panels to the back panel posts.
1
2
3
4

8/9/2010 Page 17 of 35
9(6) Cam pins
Screw (3) cam pins into each front leg.
1 2

8/9/2010 Page 18 of 35
10L
Attach the left hand tablet assembly to the left front leg.
1 2

8/9/2010 Page 19 of 35
10R
Attach the right hand tablet assembly to the right front leg.
1 2

8/9/2010 Page 20 of 35
11 (6)Cams
Fasten the front legs to the internal end panels.
1
2
3
4
