Workrite Ergonomics Essentia ES2E30-48 Programming manual

Workrite Ergonomics | 800.959.9675 www.workriteergo.com 1 of 10
Box1: 6608716-2PK-01 Box2: 4435511-01
Parts Included, Frame Set
Required & Sold Separately
F4 mm Allen Wrench Qty: 1
LPower Cord Qty: 1
ICable Spool
Qty: 2
J" White Leg Cable Loops Qty: 10
ALegs Qty: 2 BShort Bracket Qty: 4
HControl Box Qty: 1
CLe End Bracket Qty: 1
DRight End Bracket Qty: 1
E#M6 × 12 mm Flat Head Cap Screw Qty: 12
K#8 × ⅝" Pan Head Screw Qty: 10
G#12 × ¾" Pan Head Laminate Top Screw
Qty: 40
Assembly & Installation Instructions:
Essentia 2-Leg Workcenter ES2E30-48, ES3E30-48
Foot Kit
Basic or Programmable Switch
Top

2 of 10 Workrite Ergonomics | 800.959.9675 www.workriteergo.com
Verify that you have all the tools needed for the assembly
You will need the following tools:
#2 tip Phillips screwdriver or drill/driver
#3 tip Phillips screwdriver or drill/driver
M4 tip bit or 4mm Wrench (F)
If you do not have a Workrite worksurface, you will also need:
⅛" pilot drill bit
3⁄32" pilot drill bit
WARNING: Maximum loading of table assembly is 225 lb. (102 kg). Maximum load includes the weight of the
table top itself, any equipment placed upon it, and any equipment suspended or hanging under it. Loading should be evenly distributed
over table surfaces. “Payload Capacity” is the Workrite Ergonomics recommended maximum loading which includes the Workrite sourced
worksurface.
Essentia 2-Leg
V = 120 VAC, 60 Hz / 8 A maximum
IMPORTANT SAFETY INSTRUCTIONS:
When using an electrical furnishing, basic precautions should always be followed, including the following:
Read all instructions before using this Essentia Workcenter.
DANGER:To reduce the risk of electric shock, always unplug this Essentia Workcenter from the electrical outlet before
cleaning.
WARNING:To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Unplug from outlet before putting on or taking o parts.
2. Close supervision is necessary when this furnishing is used by, or near children, invalids, or disabled persons.
3. Use this furnishing only for its intended use as described in these instructions. Do not use attachments not recommended by the
manufacturer.
4. Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or
dropped into water. Return the furnishing to a service center for examination and repair.
5. Keep the cord away from heated surfaces.
6. Do not use outdoors.
7. Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
8. To disconnect, remove plug from outlet.
9. Each surface intended to support an equipment payload capacity of 225 pounds.
FOR COMMERCIAL USE ONLY
SAVE THESE INSTRUCTIONS
or
✓
IMPORTANT NOTE!
You must complete initialization (Step 12) at the end of
assembly or your workcenter WILL NOT FUNCTION PROPERLY.

Workrite Ergonomics | 800.959.9675 www.workriteergo.com 3 of 10
Layout Legs and Brackets
Check your cartons against the list on page 1 to
verify that you have all the parts needed.
Place Legs (A) and Brackets (B, C and D) on the
floor.
Attach Short & Medium Brackets
Attach Short Brackets (B) with
#M6×12mm Flat Head Cap Screws (E) to
both legs using 4 mm Allen Wrench (F).
Attach Right End Bracket (D) to sides of
the Leg (A) with Flat Head Cap Screws (E)
using 4 mm Allen Wrench (F). Attach Le
End Bracket (C) to sides of the other Leg
(A) with Flat Head Cap Screws (E) using 4
mm Allen Wrench (F).
Tighten securely.
Note: The right bracket will be on your
le and vice versa when the assembly is
seen upside down.
E#M6 × 12 mm Flat Head Cap Screw
2
1B
B
B
B
C
D
To avoid stripping the threads, always
insert and make the first few turns
of the screw BY HAND with an Allen
wrench (F), ensuring it is in straight.
B
B
D
C
E
E
E
F
E
E
E
Le Leg
Right Leg
Right Bracket
Le Bracket
front
B
B
A
A
A
A
Hardware at actual size
Caution!
Only use the #M6 × 12 mm Flat Head
Cap Screw (E) for assembly. Use of
longer screws will damage legs.

4 of 10 Workrite Ergonomics | 800.959.9675 www.workriteergo.com
Attach Base to Pre-Drilled Workrite Worksurface
If you have a non-Workrite worksurface skip to Step 4.
Note: For 2-Leg Corner and 120° Worksurface Mounting Instructions, go to: www.workriteergo.com/instructions
Position leg assemblies to align mounting holes in
brackets to pre-drilled holes in worksurface.
Attach at the four corner locations using #12 × ¾" Pan
Head Laminate Top Screws (G). If you use an electric
screwdriver, be sure it is on the lowest torque setting
to avoid stripping the holes in the top.
With frame set positioned and the four corner screws
secure, attach frame set using the remaining #12 × ¾"
Pan Head Laminate Top Screws (G).
Tighten securely.
Skip to Step 5.
3
G
G
G
G
3 screws per
Short Bracket
2 screws per End Bracket
(2 installed in Step 3b)
a
a
b
b
b
b
a
b
c
c
c
G#12 × ¾" Pan Head Laminate Top Screw
Hardware at actual size

Workrite Ergonomics | 800.959.9675 www.workriteergo.com 5 of 10
Attach Base to Non-Workrite
Worksurface
Note: For 2-Leg Corner and 120° Worksurface
Mounting Instructions, go to: www.workriteergo.com/instructions
Position Leg Assembly 2.875" from
the side edges and 6.125" from the
front on 23" to 30" worksurfaces,
making sure the frame runs
parallel with the back edge of the
worksurface.
Use a ⅛" drill bit to drill
pilot holes at the four
corner locations. You may
wish to mark your drill
bit so you do not drill any
more than ¾" deep and
damage your worksurface
top.
Do not drill all the way through worksurface!
Attach at the four corner locations
using #12 × ¾" Pan Head Laminate
Top Screws (G). If you use an
electric screwdriver, be sure it is on
the lowest torque setting to avoid
stripping the holes in the top.
With frame set positioned
and the four corner screws
secure, drill pilot holes first
then attach the frame set
using the remaining #12×¾"
Pan Head Laminate Top
Screws (G).
Tighten securely.
>¾"
6.125"
2.875"
2.875" 6.125" 23"– 30"
Parallel to edge
front
4
a
b
a
a
b
b
b
b
G
G
G
G
3 screws per
Short Bracket
2 screws per End Bracket
(2 installed in Step 4c)
c
d
d
d
c
c
c
c
Note: Avoid trip or tip hazards!
For uniquely shaped, non-rectangular worksurfaces, it is the
installers responsibility to position the worksurface to minimize
extended overhangs and position feet fully under the worksurface.
G#12 × ¾" Pan Head Laminate Top Screw
Hardware at actual size

6 of 10 Workrite Ergonomics | 800.959.9675 www.workriteergo.com
Attach Control Box & Cable Spools to Worksurface
Position Control Box (H).
If you have a Workrite worksurface:
Locate the two pilot holes for the Control Box and proceed to Step 6b.
If you do not have a Workrite worksurface:
Place Control Box (H) in position and use a pencil to mark pilot hole placement. Control Box should be placed
towards rear center of worksurface as shown. Remove Control Box and drill pilot holes where marked.
Do not drill all the way through worksurface!
With Control Box (H) positioned over pilot holes, attach with two #12 × ¾" Pan Head Screws (G).
Attach Cable Spool (I) with the #12 × ¾" Pan Head Screw (G) to underside of worksurface. If you do not have a
Workrite worksurface, mount Cable Spools (I) in a convenient location between Legs and Control Box.
Attach Feet (sold separately)
Refer to foot kit instructions for steps to install your feet.
a
a
b
c
c
c
b
6
G
G
G
H
G
5
I
I
G#12 × ¾" Pan Head Laminate Top Screw
Hardware at actual size
#M6 × 12 mm Flat Head Cap Screw
Hardware at actual size
Note!
Only use the #M6 × 16 mm Flat Head Cap
Screw from the Foot Kit for assembly.

Workrite Ergonomics | 800.959.9675 www.workriteergo.com 7 of 10
Attach Cable Loops and Route Cables
Attach Black Switch Cable Loops to underside of worksurface using #12 × ¾" Pan Head Screws (G), making sure
to wrap the Cable Loop around the cable prior to attaching. If you do not have a Workrite worksurface, attach
cable loops in convenient locations between legs or switch and the control box. Attach White Leg Cable Loops
(J) to underside of worksurface using 12 × ¾" Pan Head Laminate Top Screw (G) as needed for your model.
Attach Switch
Refer to switch instructions for steps to install your switch.
7
8
" White
Cable Loops (N)
on leg cables
⅛" Black Switch
Cable Loops and
screws from your
Workrite Switch
G
J
G#12 × ¾" Pan Head Laminate Top Screw
Hardware at actual size
Note: #8 × ⅝" Pan Head Screw (K) are included for fastening the P-Loops,
but the #12 × ¾" Pan Head Laminate Top Screws will work better when
mounting P-Loops in the locations shown above.

8 of 10 Workrite Ergonomics | 800.959.9675 www.workriteergo.com
Connect Leg Cables, Switch Cable and Power Cord to Control Box
Connect the Leg Cable (A) to the six position leg ports “M1” & “M2” on the Control Box (H).
Insert the Switch Cable into the switch port “HS” on the Control Box (H).
Insert the Power Cord (L) into the power port on the Control Box (H).
H
H
Leg Cable (A) into Leg Ports
“M1” & “M2”
Switch Cable into Switch
Port “HS”
Power Cord (L) in Power Port
b
a
c
b
a
c
9
L
L
A
A

Workrite Ergonomics | 800.959.9675 www.workriteergo.com 9 of 10
Put Workcenter Upright and Connect Power Cord to the Power Supply
Turn the workcenter over into an upright position.
Plug the Power Cord (L) into the power outlet.
Initialize Legs
Aer all legs and the switch are connected, and the power cord has been plugged in, hold the down arrow on
the switch until the legs make a short motion down and then back up. This initializes and synchronizes the
workcenter legs.
Adjust Feet Glides
If necessary, adjust leveling glides on the feet to level the worksurface. Unscrew to increase height, screw in to
decrease height.
You must complete this
initialization step or your
workcenter will NOT
function properly.
Cleaning instructions
To clean the Essentia legs, apply cleaner to a so cloth.
Suggested cleaners: Windex or Formula 409.
Do not use solvents and do not saturate or spray cleaners directly onto workcenter base.
Hold down the down arrow
until workcenter moves
slightly upwards!
Parts & Accessories
Visit http://workriteergo.com/documentation/other/workrite_ergonomics_pricing_specification_guide.pdf for
replacement parts.
✓
10
L
a
b
11
12
b
a
✓

10 of 10 Workrite Ergonomics | 800.959.9675 www.workriteergo.com
#1500240- Rev D
