Worktrainer FlexiDesk FD029-WH User manual

Ax4
F
4x4
61
3 1 4 1
1 1 2 1
51BX4
82
72
91
1
8
F
4x4
10 1
7
A
1
C
D
4
B
E
4
F
4
4
8
2
St4.2*13
2
St4.2*16
11 1
11
Technical Data
Column Stage
Max. Weight Capacity
Height Range
Maximum Speed
80KG(with hook of 5kg)
650-1300mm
38mm/s
3
Accessory List:
Attention: The drawings below are only for reference which might be
slightly different from the actual object, please in kind prevail. Any tools
missing or installation problems,please contact the customer service
firstly.
No. Image Spec. Qty.
M6
St4.2
Cable tie
St4.2
Allen key 4x4 mm
M6
Component List
No. Part Qty. No. Part Qty.
No. Part Qty.
Base plate Lifting Column
Supporting beams
Control box
Power plug
No. Part Qty. No. Part Qty.
No. Part Qty. No. Part Qty.
No. Part Qty. No. Part Qty.
No. Part Qty. No. Part Qty.
STEP 1
Attach the lifting column to the
supporting beam
Battery Pack
Universal Caster
(without brake)
Universal Caster
(with brake)
Handset
(Optional)
Spanner14
Function: Hooks can suspend heavy objects
weighing less than 5 kg
Connect the lifting column(2)
and the supporting beam (4) with screws(A),
fix it with allen key(F)
STEP 2 Install the Universal Caster
Without brake
With brake
Install the universal caster(7)(8) into the base
plate(1), tighten it with spanner(11)
STEP 3 Install the lifting column
and base plate CAUTION!
Connect the lifting column (2) to the base
plate(1) with screw (B), tighten it with allen
key(F)
1
2
4
3
5
10
7
6
9
8
11
2
F
A
4
1
2
F
B
Function description
Item No.: Artikel FD029-WH & FD028-B
Installation guide
FlexiDesk

CX6
X2
9
将各连接线连接到控制盒(7)
Dx4 Ex4
DC
HS M1
6
5
10
X2
ST4.2*13
ST4.2*16
M2
STEP 4 Install the hook, control box, battery
pack and handset
Fix the control box(5), supporting beam(4) and hook(3)
with screws(C) to the tabletop, fixing the handset(10)
with screw ST42*16 and the battery pack(6) with screw
ST42*13, then tighten them with pistol drill.
STEP 5 Connect the cables to the control box (5)
Split it Trim cables Fix it
Fix the connecting lines to the table with cable
tie(D), then fix the cable tie(D) with screw(E) to
keep cable organized.
Keypad
connecting
line socket
Port for Power
Cable
Port for cable
connected to
the lifting column
Attention
Fault phenomenon Method
No response while long pressing
down arrow after connected with
a power supply
1.Check if all the cables be connected well
1.Check if all the cables be connected well
2.Contact your supplier or dealer
2.Contact your supplier or dealer
No response while pressing up
arrow/ down arrow after
connected with a power supply
Rising in a low speed
1.Check if overloaded, max loading: 80kg;
1.Check if overloaded, max loading: 80kg;
1.Check if overloaded, max loading: 80kg;
2.Contact your supplier or dealer
2.Contact your supplier or dealer
2.Contact your supplier or dealer
The motor not move as instructed 1. Contact your supplier or dealer
1.Reposition
2.Contact your supplier or dealer
Go down but not go up
Downward sliding
Frequently Reposition
Overwork
（Duty cycle:Max 2min on/18min OFF）
1.Restart after suspend for 18mins while
connecting with power;
2.Contact your supplier or dealer;
Common fault treatment
1. Power supply: AC100V-240V,50/60HZ
2. Service Environment: 0-40℃
3. Unplug the power plug before cleaning, wipe the dust on surface with slight wet dishcloth
when cleaning, be careful not to let the drops into the internal parts, not loose the connector.
4. The electric box contains electronic components, metals, plastics, wires etc., so dispose of
it in accordance with each country's environmental legislation, not the general household
waste.
5. Check carefully to ensure correct and complete assembly before using.
6. Be familiar with all functions and program settings of the product before first use.
7. Children are forbidden to play on the product because of unforeseen action when playing,
so any dangerous consequences caused by this improper action will not be on manufacturers.
8. Slight noise caused by the V-ribbed belt or brake system due to structure will not have any
effect on the use of the equipment.
9. Corrosive or abrasive materials are forbidden to clean the equipment. Must ensure that the
cleaner used will not pollute the environment.
10. This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance.
11. Cleaning and user maintenance shall not be made by children without supervision.
12. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
a similarly
qualified person in order to avoid a hazard.
13. Please make sure there is no hazard sources in your operating environment. e.g., do not
litter the tools around. Always be careful to treat the packaging materials in order to avoid any
possible danger, e.g. plastic bag may lead to choking hazard to children.
14. Keep the original package of the equipment if necessary in case of the future use in
transportation.
This marking indicates that this product should not be disposed with
other household wastes. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To
return your used device, please use the return and collection systems
or contact the retailer where the product was purchased. They can take
this product for environmental safe recycling.
